For vehicles equipped with the Electronic Vehicle Infor-
mation Center (EVIC), the power window switches,
radio, hands–free system (if equipped), and power out-
lets will remain active for up to 10 minutes after the
ignition switch is turned off. Opening either front door
will cancel this feature. The time for this feature is
programmable. For details, refer to “KEY OFF POWER
DELAY > OFF” under “Personal Settings (Customer
Programmable Features),” under “Electronic Vehicle In-
formation Center (EVIC)” in Section 3 of this manual.
SENTRY KEY — IF EQUIPPED
The Sentry Key Immobilizer System prevents unautho-
rized vehicle operation by disabling the engine. The
system does not need to be armed or activated. Operation
is automatic, regardless of whether the vehicle is locked
or unlocked.
The system uses ignition keys, which have an embedded
electronic chip (transponder), to prevent unauthorizedvehicle operation. Therefore, only keys that are pro-
grammed to the vehicle can be used to start and operate
the vehicle. The system will shut the engine off in two (2)
seconds if someone uses an invalid key to start the
engine.
NOTE:A key that has not been programmed is consid-
ered an invalid key even if it is cut to fit the ignition lock
cylinder for that vehicle.
During normal operation, after turning on the ignition
switch, the Vehicle Security Alarm Indicator Light will
turn on for three (3) seconds for a bulb check. If the light
remains on after the bulb check, it indicates that there is
a problem with the electronics. In addition, if the light
begins to flash after the bulb check, it indicates that
someone used an invalid key to start the engine. Either of
these conditions will result in the engine being shut off
after two (2) seconds.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
2

Hitches
TrailerTowing ........................ 328
HomeLink(Garage Door Opener) Transmitter . . . 160
Hood Release.......................... 129
Hoses................................ 386
Ignition............................. 12,13
Key ................................. 12
Lock................................ 13
Ignition Key Removal..................... 12
Illuminated Entry........................ 19
Infant Restraint........................ 62,63
Inflation Pressure Tires.................... 303
Information Center...................... 152
Information Center, Vehicle................. 152
Inside Rearview Mirror.................... 79
Instrument Cluster....................... 185
Instrument Panel and Controls.............. 183
Instrument Panel Lens Cleaning............. 397Integrated Power Module (Fuses)............ 405
Interior Appearance Care.................. 395
Interior Fuses.......................... 398
Interior Lighting........................ 131
Interior Lights.......................... 131
Intermittent Wipers (Delay Wipers)........... 138
Introduction............................. 4
Inverter Outlet (115V)..................... 170
Jack Location........................... 345
Jack Operation.......................345,347
Jacking Instructions...................... 348
Key, Replacement........................ 16
Key, Sentry (Immobilizer)................... 15
Keyless Entry System...................... 19
Keys................................. 12
Knee Bolster............................ 51
INDEX 465
10

Seat Belt Reminder....................... 48
Seat Belts.......................... 38,39,73
And Pregnant Women................... 50
Child Restraint....................... 62,63
Extender............................. 50
Front Seat............................ 39
Pretensioners.......................... 48
Reminder............................ 186
Seats................................. 108
Adjustment.......................... 108
Cleaning............................ 395
Fold and Tumble Rear................ 115,117
Heated.............................. 112
Lumbar Support....................... 110
Memory............................. 124
Rear Folding....................... 115,117
Reclining ............................ 109
Security Alarm (Theft Alarm)............. 17,188
Selection of Coolant (Antifreeze)..........382,418Selection of Oil......................... 369
Sentry Key (Immobilizer)................... 15
Service and Maintenance................366,422
Service Assistance....................... 448
Service Contract......................... 450
Service Manuals........................ 452
Setting the Clock................195,199,207,219
Settings, Personal........................ 155
Shifting
Automatic Transmission................. 254
Transfer Case......................... 259
Transfer Case, Shifting into Transfer
Case Neutral (N)........................ 338
Transfer Case, Shifting out of Transfer
Case Neutral (N)........................ 340
Shoulder Belt Upper Anchorage.............. 44
Shoulder Belts........................... 39
Signals, Turn.....................135,185,409
Snow Chains (Tire Chains)................. 303
INDEX 471
10
