Page 48 of 699
WARNING!
Driving with the liftgate open can allow poisonous
exhaust gases into your vehicle. You and your pas-
sengers could be injured by these fumes. Keep the
liftgate closed when you are operating the vehicle.
Power Liftgate — If Equipped
The power liftgate may be opened by pulling
up on the liftgate handle or by pressing the
LIFTGATE button on the Remote Keyless Entry
(RKE) transmitter. Press the LIFTGATE button
on the RKE transmitter twice within five seconds, to open
the power liftgate. Once the liftgate is open, pressing the
button twice within five seconds a second time will close
the liftgate. The power liftgate may also be opened and
closed with the overhead console switch. Also, the power liftgate may be closed by pressing the
liftgate switch located on the left rear trim, near the
liftgate opening. Pressing once will close the liftgate only.
This button cannot be used to open the liftgate.
To operate the power liftgate manually in the open
direction, pull the liftgate handle once to initiate power
cycle and then pull the handle a second time to put
liftgate into manual mode.
When the LIFTGATE button on the RKE transmitter is
pressed two times, the turn signals will flash twice to
signal that the liftgate is opening or closing (if Flash
Lamps with Lock is enabled in the EVIC) and the liftgate
chime will be audible. For further information, refer to
“Customer-Programmable Features (System Setup)/
Electronic Vehicle information Center (EVIC)” in “Under-
standing Your Instrument Panel”.
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 121 of 699
ELECTRICAL POWER OUTLETS ...........275
POWER INVERTER — IF EQUIPPED ........280
CUPHOLDERS ....................... .282
▫ Front Seat Cupholders ..................282
▫ Rear Cupholders .....................282
STORAGE ........................... .284
▫ Glove Compartment ...................284
▫ Door Storage ........................ .285
▫ Front Center Console ...................285
▫ Rear Full Center Console (If Equipped) ......287
▫ Rear Mini Center Console (If Equipped) .....290
CARGO AREA FEATURES ................291
▫ Rechargeable Flashlight .................291
▫ Cargo Storage ...................... .292
▫ Retractable Cargo Area
Cover — If Equipped ..................292
▫ Cargo Tie-Down Hooks .................293
REAR WINDOW FEATURES ..............294
▫ Rear Window Wiper/Washer .............294
▫ Rear Window Defroster .................295
ROOF LUGGAGE RACK — IF EQUIPPED . . . .296
▫ Deploying the Crossbars .................297
▫ Stowing the Crossbars ..................300
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119
Page 179 of 699
NOTE:Once a heat setting is selected, heat will be felt
within two to five minutes.
When the HIGH-level setting is selected, the heater will
provide a boosted heat level during the first four minutes
of operation. Then, the heat output will drop to the
normal HIGH-level. If the HIGH-level setting is selected,
the system will automatically switch to LOW-level after
approximately 60 minutes of continuous operation. At
that time, the number of illuminated LEDs changes from
two to one, indicating the change. The LOW-level setting
will turn OFF automatically after approximately 45 min-
utes.
Rear Heated Seats
On some models, the two outboard seats are equipped
with heated seats. There are two heated seat switches that
allow the rear passengers to operate the seats indepen-
dently. The heated seat switches for each heater are
located on the rear of the center console. You can choose from HIGH, LOW or OFF heat settings.
Amber indicator lights in each switch indicate the level of
heat in use. Two indicator lights will illuminate for
HIGH, one for LOW and none for OFF.
Rear Heated Seat Switches
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177
Page 210 of 699
Ambient Light
The overhead console is equipped with an ambient light
feature. This light casts illumination for improved visibil-
ity of the floor center console and PRNDL area.
Multifunction Lever
The multifunction lever is located on the left side of the
steering column.
Ambient Light
Multifunction Lever
208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 264 of 699
Sunglasses Bin Door
At the front of the console a compartment is provided for
the storage of a pair of sunglasses. The storage compart-
ment access is a “push/push” design. Push the chrome
pad on the door to open. Push the chrome pad on the
door to close.
GARAGE DOOR OPENER — IF EQUIPPED
HomeLinkreplaces up to three remote controls (hand-
held transmitters) that operate devices such as garage
door openers, motorized gates, lighting or home security
systems. The HomeLink unit operates off your vehicle’s
battery.
The HomeLink buttons, located on either the overhead
console, headliner or sunvisor, designate the three differ-
ent HomeLink channels. The HomeLink indicator is
located above the center button.
Sunglasses Bin Door
262 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 278 of 699
The front power outlet is located inside the storage area
on the center stack of the instrument panel.In addition to the front power outlet, there is also a power
outlet located in the storage area of the center console.
Front Power OutletFront Center Console Outlet
276 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 279 of 699
If your vehicle is equipped with a rear full center console,
there is also a power outlet located in the lower storage
area of the rear full center console.The rear cargo power outlet is located in the right rear
cargo area.
Rear Full Center Console Outlet
Rear Cargo Power Outlet
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 277
Page 282 of 699
POWER INVERTER — IF EQUIPPED
There is a 115 Volt, 150 Watt inverter outlet located on the
back of the center console to convert DC current to AC
current. This outlet can power cellular phones, electron-
ics and other low power devices requiring power up to
150 Watts. Certain high-end video games, such as Play-
station3 and XBox360 will exceed this power limit, as will
most power tools.
Power Inverter
280 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 284 of 699
CUPHOLDERS
Front Seat Cupholders
There are two cupholders for the front seat passengers
located in the center console.
Rear Cupholders
Rear Center Arm Rest Cupholders — If Equipped
There are two cupholders for the rear seat passengers
located in the fold-down center armrest.
Front Cupholder LocationRear Center Arm Rest Cupholders
282 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 287 of 699
To open the glove compartment, pull outward on the
latch and lower the glove box door.
Door Storage
Large storage areas are built into the door panels for easy
access.
Front Center Console
The front center console contains both an upper and a
lower storage area.
Door Panel Storage
Storage Compartment
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 285
