ever replace a wheel, make sure that the wheel’s specifications match
those of the original wheels.
It is recommended you contact an authorized tire dealer or original
equipment dealer with any questions you may have on tire specifications
or capability. Failure to use equivalent replacement tires may adversely
affect the safety, handling, and ride of your vehicle.
WARNING!
•Do not use a tire, wheel size, load rating, or speed rating other than
that specified for your vehicle. Some combinations of unapproved
tires and wheels may change suspension dimensions and perfor-
mance characteristics, resulting in changes to steering, handling,
and braking of your vehicle. This can cause unpredictable han-
dling and stress to steering and suspension components. You could
lose control and have a collision resulting in serious injury or
death. Use only the tire and wheel sizes with load ratings approved
for your vehicle.
• Never use a tire with a smaller load index or capacity, other than
what was originally equipped on your vehicle. Using a tire with a
smaller load index could result in tire overloading and failure. You
could lose control and have a collision.
• Failure to equip your vehicle with tires having adequate speed
capability can result in sudden tire failure and loss of vehicle
control.
CAUTION!
Replacing original tires with tires of a different size may result in
false speedometer and odometer readings.
TIRES
18
Tire Size:A combination of alphabetic and numeric characters that
indicate the nominal dimensions of a tire:
Load Index: a numerical code indicating the maximum load carrying
capacity of a tire at the maximum cold inflation pressure.
LOAD MAXIMUM LOAD PER TIRELOAD MAXIMUM LOAD PER
TIRE
INDEX Kg Lbs INDEX Kg Lbs
80 450 992 106 950 2094
81 462 1018 107 975 2149
82 475 1047 108 1000 2205
83 487 1074 109 1030 2271
84 500 1102 110 1060 2337
85 515 1135 111 1090 2403
86 530 1168 112 1120 2469
87 545 1201 113 1150 2535
88 560 1234 114 1180 2601
89 580 1278 115 1215 2679
90 600 1323 116 1250 2756
91 615 1356 117 1285 2833
92 630 1389 118 1320 2910
93 650 1433 119 1360 2998
94 670 1477 120 1400 3087
95 690 1521 121 1450 3197
96 710 1565 122 1500 3307
97 730 1609 123 1550 3417
98 750 1653 124 1600 3528
99 775 1708 125 1650 3638
100 808 1764 126 1700 3748
101 825 1819 127 1750 3859
102 850 1874 128 1800 3969
103 875 1919 129 1850 4079
104 900 1984 130 1900 4190
105 925 2039 131 1950 4300
PIRELLI TIRES
206
