BRIDGESTONE® - FIRESTONE®
72
The vehicle or TPMS manufacturer may advise checking the TPMS
regularly to confirm it is in working order. In addition, a new pressure
sensor, certain components, or reprogramming may be necessary
when a tire is serviced. Consult your vehicle Owner’s Manual, vehicle
manufacturer, or a Bridgestone® Firestone® Run-Flat Certified
Retailer for questions regarding TPMS operation and service.
RUN-FLAT OR LOW TIRE PRESSURE OPERATION
General Instructions
The Tire Pressure Monitoring System (TPMS) required in your vehicle
m a

y have different methods of alerting you when your tire has lost
inflation pressure. The international standard for the definition of
run-flat operation is pressure at or below 10 psi (70 kPa); however,
some vehicle manufacturers may have established a different pressure
limit. Consult your vehicle Owner’s Manual for the details of your
TPMS. Once the TPMS has indicated that a tire has reduced inflation
pressure, the run-flat mode of operation has commenced. During this
phase of operation, please follow these instructions:
• Reduce speed as much as safely and reasonably possible; do not
e
xceed 50 mph (80 km/h).The greater the speed, the less distance
t

he tire can travel.
• Avoid abrupt or aggressive acceleration, braking, or cornering
m
aneuvers as much as safely and reasonably possible. Pot holes
and other road hazards should be avoided. Careful driving limits
potential damage to the tire, wheel, and vehicle.
• Proceed to a safe and convenient location for tire service as soon
a
s possible. Take note of your mileage; your operation distance is
limited. See "Distance — How Far You Can Drive,” the next section
in this manual.
WARNING!
Serious personal injury or death may result from a tire failure or
ac
cident due to improper run-flat or low tire pressure operation.
Read and follow the instructions below, and the other
maintenance and safety recommendations elsewhere in this
manual.

MICHELIN®
176
protection throughout the normal use of the tire. Consequently, when
tires sit outdoors, unused for long periods of time (a month or more)
their surfaces become dry and more susceptible to ozone and weather
checking and the casing becomes susceptible to flat spotting. For this
reason, tires should always be stored in a cool, dry, clean, indoor
environment. If storage is for one month or more, eliminate the
weight from the tires by raising the vehicle or by removing the tires
from the vehicle. Failure to store tires in accordance with these
instructions could result in damage to your tires or premature aging
of the tires and sudden tire failure.
When tires are stored, be sure they are placed away from sources of
he
at and ozone such as hot pipes and electric generators. Be sure that
surfaces on which tires are stored are clean and free from grease,
gasoline or other substances which could deteriorate the rubber. Tires
exposed to these materials during storage or driving could be
subject to sudden failure.
FOLLOW THESE MOUNTING RECOMMENDATIONS
Tire changing can be dangerous and must be done by professionally
tr
ained persons using proper tools and procedures as specified by
the Rubber Manufacturers Association (RMA). PAX® System tires
must be mounted and dismounted only by specially trained,
authorized PAX System retailers, utilizing PAX® System
authorized equipment.
Your tires should be mounted on wheels of correct size and type and
wh
ich are in good, clean condition. Wheels that are bent, chipped,
rusted (steel wheels) or corroded (alloy wheels) may cause tire
damage. The inside of the tire must be free from foreign material.
Have your retailer check the wheels before mounting new tires.
Mismatched tires and rims can explode during mounting. Also,
mismatched tires and rims can result in dangerous tire failure on the
road. If a tire is mounted by error on the wrong-sized rim, do not
remount it on the proper rim, scrap it. It may have been damaged
internally (which is not externally visible) by having been
dangerously stretched and could fail on the highway.
Old valves may leak. When new tubeless tires are mounted, have
ne
w valves of the correct type installed. Tubeless tires must only be
mounted on wheels designed for tubeless tires i.e., wheels which
have safety humps or ledges. As with any other tire air valve, the
PAX® System valve stem-pressure sensor combination must be in

MICHELIN®
177
good condition to assure its performance. Always utilize valve caps
capable of containing the tire’s air pressure, should the valve core
leak. The valve cap is the primary seal against air loss.
It is recommended that you have your tires and wheels balanced. Tires
an
d wheels which are not balanced may cause steering difficulties, a
bumpy ride, and irregular tire wear.
SPECIAL MOUNTING INSTRUCTIONS FOR PAX® SYSTEM TIRES
PAX System wheels are different from all other wheels. Never attempt
to
mount a non-PAX System tire on a PAX System wheel, or a PAX®
System tire on a non-PAX System wheel. Attempting to do so could
cause serious injury or death. All PAX System components (tire,
wheel, support ring, pressure sensor and gel) must be utilized. Never
utilize a PAX System tire and wheel without every other properly
functioning component part, correctly installed by an Authorized
PAX System retailer. The PAX System must be used on all wheel
positions.
After a low or zero pressure driving event, the PAX System tire and
wh
eel may be hot to the touch. Always allow a PAX® System tire to
cool before attempting to handle it. Failure to do so could result in
injury.

SPECIAL MOUNTING INSTRUCTIONS FOR SELF-SUPPORTING
ZE
RO PRESSURE™ (ZP) TIRES

ZP tires can be more difficult to mount than conventional tires. They
sh
ould be mounted and demounted only by a properly trained tire
professional. ZP tires can generate a tremendous amount of heat when
run at low or zero pressure. ALWAYS ALLOW A ZP TIRE TO COOL
BEFORE ATTEMPTING TO HANDLE IT. FAILURE TO DO SO
COULD RESULT IN INJURY.
MICHELIN® ZP tires are tubeless tires designed to operate in
em
ergency conditions at low or zero air pressure.

MICHELIN® SELF SUPPORTING Zero Pressure™ (ZP) TIRES AND
SP
ECIAL SYMMETRIC HUMP-MODIFIED (SH-M) WHEELS

Some MICHELIN® ZP tires can only perform with zero pressure
ca
pability when mounted on special SH-M wheels. These tires bear
the SH-M designation immediately following the ZP designation on
the sidewall of the tire. DO NOT MOUNT ZP TIRES WITH THE SH-M
DESIGNATION ON STANDARD WHEELS. IN SUCH
