268SERVICING AND MAINTENANCE
(Continued)
Make sure that the coolant expansion bottle
overflow hoses are not kinked or obstructed.
Keep the front of the radiator clean. If your
vehicle is equipped with air conditioning, keep
the front of the condenser clean.
Do not change the thermostat for Summer or
Winter operation. If replacement is ever neces-
sary, install ONLY the correct type thermostat.
Other designs may result in unsatisfactory
engine cooling performance, poor gas mileage,
and increased emissions.
BRAKE SYSTEM
In order to ensure brake system performance, all
brake system components should be inspected
periodically. For the proper maintenance intervals
Ú page 250.
Fluid Level Check — Brake Master Cylinder
The fluid level of the master cylinder should be
checked whenever the vehicle is serviced, or
immediately if the Brake System Warning Light is
on. If necessary, add fluid to bring level within the
designated marks on the side of the reservoir of
the brake master cylinder. Be sure to clean the top
of the master cylinder area before removing cap.
With disc brakes, fluid level can be expected to fall
as the brake pads wear. Brake fluid level should be
checked when pads are replaced. If the brake fluid
is abnormally low, check the system for leaks. For
further information Ú page 307.
WARNING!
Riding the brakes can lead to brake failure and
possibly a collision. Driving with your foot resting
or riding on the brake pedal can result in
abnormally high brake temperatures, excessive
lining wear, and possible brake damage. You
would not have your full braking capacity in an
emergency.
WARNING!
Use only the manufacturer’s recommended
brake fluid Úpage 307. Using the wrong type
of brake fluid can severely damage your brake
system and/or impair its performance. The
proper type of brake fluid for your vehicle is
also identified on the original factory installed
hydraulic master cylinder reservoir.
To avoid contamination from foreign matter or
moisture, use only new brake fluid or fluid that
has been in a tightly closed container. Keep
the master cylinder reservoir cap secured at
all times. Brake fluid in an open container
absorbs moisture from the air resulting in a
lower boiling point. This may cause it to boil
unexpectedly during hard or prolonged
braking, resulting in sudden brake failure. This
could result in a collision.
Overfilling the brake fluid reservoir can result
in spilling brake fluid on hot engine parts,
causing the brake fluid to catch fire. Brake
fluid can also damage painted and vinyl
surfaces, care should be taken to avoid its
contact with these surfaces.
Do not allow petroleum based fluid to contam -
inate the brake fluid. Brake seal components
could be damaged, causing partial or
complete brake failure. This could result in a
collision.
WARNING!

23_WD_OM_EN_USC_t.book Page 268

SERVICING AND MAINTENANCE269
AUTOMATIC TRANSMISSION
Special Additives
The manufacturer strongly recommends against
using any special additives in the transmission.
Automatic Transmission Fluid (ATF) is an
engineered product and its performance may be
impaired by supplemental additives. Therefore, do
not add any fluid additives to the transmission.
Avoid using transmission sealers as they may
adversely affect seals.
Fluid Level Check
The fluid level is preset at the factory and does not
require adjustment under normal operating
conditions. Routine fluid level checks are not
required; therefore the transmission has no
dipstick. An authorized dealer can check your
transmission fluid level using special service tools.
If you notice fluid leakage or transmission
malfunction, visit an authorized dealer
immediately to have the transmission fluid level
checked. Operating the vehicle with an improper
fluid level can cause severe transmission damage.
Fluid And Filter Changes
Under normal operating conditions, the fluid
installed at the factory will provide satisfactory
lubrication for the life of the vehicle.
Routine fluid and filter changes are not required.
However, change the fluid and filter if the fluid
becomes contaminated (with water, etc.), or if the
transmission is disassembled for any reason.
Selection Of Lubricant
It is important to use the proper transmission fluid
to ensure optimum transmission performance and
life. Use only the manufacturer's specified
transmission fluid Úpage 307. It is important to
maintain the transmission fluid at the correct level
using the recommended fluid.
NOTE:No chemical flushes should be used in any trans -
mission; only the approved lubricant should be
used.
FRONT/REAR AXLE FLUID
For normal service, periodic fluid level checks are
not required. When the vehicle is serviced for other
reasons the exterior surfaces of the axle assembly
should be inspected. If gear oil leakage is
suspected inspect the fluid level.
Front Axle Fluid Level Check
The front axle oil level needs to be no lower than
1/8 inch (3 mm) below the bottom of the fill hole.
The front axle fill and drain plugs should be
tightened to 22 to 29 ft lbs (30 to 40 N·m).
CAUTION!
Do not use chemical flushes in your
transmission as the chemicals can damage your
transmission components. Such damage is not
covered by the New Vehicle Limited Warranty.
CAUTION!
If a transmission fluid leak occurs, visit an
authorized dealer immediately. Severe
transmission damage may occur. An authorized
dealer has the proper tools to adjust the fluid
level accurately.
CAUTION!
Using a transmission fluid other than the
manufacturer recommended fluid may cause
deterioration in transmission shift quality and/or
torque converter shudder Ú page 307.
CAUTION!
Do not overtighten the plugs as it could damage
them and cause them to leak.
8

23_WD_OM_EN_USC_t.book Page 269

SERVICING AND MAINTENANCE271
The fuses protect electrical systems against
excessive current.
When a device does not work, you must check the
fuse element inside the blade fuse for a break/
melt.
Also, please be aware that using power outlets for
extended periods of time with the engine off may
result in vehicle battery discharge.
Blade Fuses

Underhood Fuses
The Power Distribution Center is located in the
engine compartment near the battery jump start
posts. This center contains cartridge fuses, micro
fuses, relays, and circuit breakers. A description of
each fuse and component may be stamped on the
inside cover, otherwise the cavity number of each
fuse is stamped on the inside cover that
corresponds to the following chart.If the replaced fuse blows again, contact an
authorized dealer.
If a general protection fuse for safety systems
(air bag system, braking system), power unit
systems (engine system, transmission
system) or steering system blows, contact an
authorized dealer.
WARNING!
1 — Fuse Element
2 — Blade Fuse with a good/functional fuse
element
3 — Blade fuse with a bad/not functional fuse
element (blown fuse)
CAUTION!
When installing the power distribution center
cover, it is important to ensure the cover is
properly positioned and fully latched. Failure to
do so may allow water to get into the power
distribution center and possibly result in an
electrical system failure.
8

23_WD_OM_EN_USC_t.book Page 271

TECHNICAL SPECIFICATIONS303
Inspect the wheel mounting surface prior to
mounting the tire and remove any corrosion or
loose particles.

Wheel Mounting Surface

Tighten the lug nuts/bolts in a star pattern until
each nut/bolt has been tightened twice. Ensure
that the socket is fully engaged on the lug nut/bolt
(do not insert it half way).
NOTE:If in doubt about the correct tightness, have them
checked with a torque wrench by an authorized
dealer or service station.
After 25 miles (40 km), check the lug nut/bolt
torque to be sure that all the lug nuts/bolts are
properly tightened.
Torque Patterns

FUEL REQUIREMENTS
While operating on gasoline with the required
octane number, hearing a light knocking sound
from the engine is not a cause for concern.
However, if the engine is heard making a heavy
knocking sound, see a dealer immediately. Use of
gasoline with a lower than recommended octane
number can cause engine failure and may void the
New Vehicle Limited Warranty.Poor quality gasoline can cause problems such as
hard starting, stalling, and hesitations. If you
experience these symptoms, try another brand of
gasoline before considering service for the vehicle.
3.6L ENGINE
Do not use E-85 flex fuel or ethanol blends greater
than 15% in this engine.
This engine is designed to meet all
emissions regulations and provide
optimum fuel economy and
performance when using high quality
unleaded regular gasoline having a posted octane
number of 87 as specified by the (R+M)/2 method.
The use of higher octane premium gasoline is not
required, as it will not provide any benefit over
regular gasoline in these engines.
5.7L ENGINE
Do not use E-85 flex fuel or ethanol blends greater
than 15% in this engine.
This engine is designed to meet all
emissions regulations and provide
satisfactory fuel economy and
performance when using high-quality
unleaded gasoline having an octane range of 87 to
89 as specified by the (R+M)/2 method. The use of
89 octane plus gasoline is recommended for
optimum performance and fuel economy.
WARNING!
To avoid the risk of forcing the vehicle off the
jack, do not tighten the lug nuts/bolts fully until
the vehicle has been lowered. Failure to follow
this warning may result in personal injury.
9

23_WD_OM_EN_USC_t.book Page 303

313
INDEX
A
About Your Brakes......................................... 302Adaptive Cruise Control (ACC)
(Cruise Control).................................... 115, 117Adding Engine Coolant (Antifreeze)............... 266Adding Fuel.................................................... 135Additives, Fuel............................................... 304AdjustDown........................................................... 34Forward....................................................... 34Rearward..................................................... 34Up................................................................ 34Air BagAir Bag Operation...................................... 201Air Bag Warning Light...................... 199, 201Driver Knee Air Bag................................... 205Enhanced Accident Response......... 209, 248Event Data Recorder (EDR)....................... 248Front Air Bag............................................. 201If Deployment Occurs................................ 208Knee Impact Bolsters................................ 205Maintaining Your Air Bag System.............. 210Maintenance............................................. 210Redundant Air Bag Warning Light.............200Side Air Bags............................................. 206Transporting Pets...................................... 225
Air Bag Light.................................. 88, 199, 226
Air Cleaner, Engine (Engine Air Cleaner Filter)... 257
Air Conditioner Maintenance........................ 258Air Conditioner Refrigerant.................. 258, 259Air Conditioner System................................. 258Air ConditioningRear............................................................. 58Air Conditioning Filter.................... 60, 257, 259Air Conditioning System................................... 59Air Conditioning, Operating Tips....................... 60Air Filter........................................................ 257Air PressureTires......................................................... 289AlarmArm The System................................... 20, 21Disarm The System..................................... 20Rearm The System...................................... 21Security Alarm............................................. 91Alarm SystemSecurity Alarm............................................. 20All Wheel Drive (AWD)................................... 108Alterations/ModificationsVehicle........................................................... 9Antifreeze (Engine Coolant)................. 266, 306Disposal................................................... 267Anti-Lock Brake System (ABS)...................... 177
Anti-Lock Warning Light...................................91Assist, Hill Start............................................. 181Audio Systems (Radio).................................. 153Auto Down Power Windows..............................69Automatic Headlights.......................................47Automatic High Beams.....................................47Automatic Temperature Control (ATC)..............59Automatic Transmission......................... 98, 104Adding Fluid.............................................. 269Fluid And Filter Change............................. 269Fluid Change............................................. 269Fluid Level Check...................................... 269Fluid Type........................................ 269, 307Special Additives...................................... 269Automatic Transmission Limp Home Mode... 107Auxiliary Driving Systems.............................. 183Auxiliary Electrical Outlet (Power Outlet)..........65Auxiliary Power Outlet......................................65Axle Fluid....................................................... 307
B
Battery................................................... 89, 255Charging System Light.................................89Keyless Key Fob Replacement....................14Battery Saver Feature......................................49Belts, Seat.................................................... 226
11

23_WD_OM_EN_USC_t.book Page 313

314 Blind Spot Monitoring
.................................... 183Body Mechanism Lubrication........................ 261B-Pillar Location............................................. 286Brake Assist System...................................... 178Brake Control System, Electronic.................. 178Brake Fluid.......................................... 268, 307Brake System...................................... 268, 302Anti-Lock (ABS).......................................... 302Fluid Check............................................... 268Master Cylinder......................................... 268Parking...................................................... 102Warning Light.............................................. 88Brake/Transmission Interlock....................... 104Bulb Replacement............................... 278, 280Bulbs, Light.................................................... 227
C
Camera, Rear................................................ 134Capacities, Fluid............................................ 306Caps, Filler Oil (Engine)................................................ 253Radiator (Coolant Pressure)...................... 267Car Washes................................................... 299Carbon Monoxide Warning............................ 228Cargo Area Cover............................................. 73Cargo Compartment........................................ 73Light............................................................ 73Luggage Carrier........................................... 74Cargo Light...................................................... 73Cargo Tie-Downs.............................................. 74
Cellular Phone.............................................. 176Center High Mounted Stop Light................... 280Certification Label......................................... 136Chains, Tire................................................... 296Chart, Tire Sizing........................................... 282Check Engine Light
(Malfunction Indicator Light)............................ 96Checking Your Vehicle For Safety................. 225Checks, Safety.............................................. 225Child Restraint.............................................. 210Child RestraintsBooster Seats........................................... 213Child Seat Installation.............................. 222How To Stow An unused ALR Seat Belt.... 220Infant And Child Restraints....................... 212Locating The LATCH Anchorages.............. 217Lower Anchors And Tethers For Children.. 214Older Children And Child Restraints......... 212Seating Positions...................................... 214Child Safety Locks........................................... 25Clean Air Gasoline......................................... 304CleaningWheels..................................................... 295Climate Control................................................ 53Automatic.................................................... 53Cold Weather Operation............................... 101Compact Spare Tire...................................... 293Contract, Service.......................................... 310Cooling Pressure Cap (Radiator Cap)............ 267
Cooling System............................................. 265Adding Coolant (Antifreeze)...................... 266Cooling Capacity....................................... 306Disposal Of Used Coolant......................... 267Drain, Flush, And Refill............................. 266Inspection................................................. 266Points To Remember................................ 267Pressure Cap............................................ 267Radiator Cap............................................. 267Selection Of Coolant(Antifreeze)......................... 266, 306, 307Corrosion Protection..................................... 299Cruise Control (Speed Control)............. 115, 117Cruise Light............................................... 94, 95Customer Assistance.................................... 308Cybersecurity................................................ 153
D
Daytime Running Lights...................................46Defroster, Windshield................................... 226De-Icer, Remote Start......................................20Diagnostic System, Onboard............................96DipsticksOil (Engine)............................................... 255Disabled Vehicle Towing............................... 246DisposalAntifreeze (Engine Coolant)...................... 267Door Ajar...................................................89, 90Door Ajar Light..........................................89, 90

23_WD_OM_EN_USC_t.book Page 314

315
Door Locks
............................................... 21, 25Child-Protection Door Lock — Rear Doors.... 25Doors............................................................... 21Driver’s Seat Back Tilt..................................... 28Driving........................................................... 150
E
Economy (Fuel) Mode.................................... 104Electric Brake Control System....................... 178Anti-Lock Brake System............................. 177Electronic Roll Mitigation................. 179, 182Electric Remote Mirrors................................... 41Electrical Outlet, Auxiliary (Power Outlet)......... 65Electronic Speed Control (Cruise Control)...... 116Electronic Stability Control (ESC)...................180Electronic Throttle Control Warning Light........ 89Electronically Shifted Transfer Case.... 108, 109Emergency Gas Can Refueling...................... 242Emergency, In Case Of Freeing Vehicle When Stuck...................... 245Hazard Warning Flasher............................ 229Jacking...................................................... 232Jump Starting............................................ 239Emission Control System Maintenance........... 96
Engine........................................................... 253Air Cleaner................................................ 257Break-In Recommendations..................... 101Checking Oil Level.................................... 255Compartment.................................. 253, 254Compartment Identification............. 253, 254Cooling..................................................... 265Exhaust Gas Caution................................ 228Fails To Start............................................ 101Flooded, Starting...................................... 101Fuel Requirements.......................... 303, 306Jump Starting........................................... 239Oil.................................................... 256, 306Oil Filler Cap............................................. 253Oil Filter.................................................... 257Oil Selection........................... 256, 306, 307Oil Synthetic............................................. 257Starting........................................................ 98Engine Oil Life Reset
b
.................................. 82
Enhanced Accident Response Feature...209, 248
Ethanol......................................................... 304Exhaust Gas Cautions................................... 228Exhaust System................................... 228, 264Exterior Lights............................... 45, 227, 278
F
FiltersAir Cleaner
................................................ 257Air Conditioning........................ 60, 257, 259Engine Oil................................................. 257Engine Oil Disposal................................... 257Flashers........................................................ 229Hazard Warning........................................ 229Turn Signals.............................. 95, 227, 280Flash-To-Pass...................................................47Flooded Engine Starting................................ 101Fluid Capacities............................................ 306Fluid Leaks.................................................... 228Fluid Level ChecksBrake........................................................ 268Engine Oil................................................. 255Fluids And Lubricants.................................... 307Fog Lights..................................................... 280Fog Lights, Service........................................ 280Fold-Flat Seats.................................................28Folding Rear Seats...........................................30Forward Collision Warning............................ 186Four-Way Hazard Flasher.............................. 229Freeing A Stuck Vehicle................................. 245Front Axle (Differential)................................. 269
11

23_WD_OM_EN_USC_t.book Page 315

317
K
Key Fob
........................................................... 13Arm The System.......................................... 20Disarm The System..................................... 20Programming Additional Key Fobs.............. 15Key Fob Battery Service
(Remote Keyless Entry)................................... 14
Key Fob Programming (Remote Keyless Entry).. 15
Keyless Enter 'n Go™ Passive Entry............................................... 22Passive Entry Programming......................... 22Keys................................................................. 13Replacement............................................... 15Sentry (Immobilizer).................................... 16
L
Lane Change Assist......................................... 48LaneSense.................................................... 131Lap/Shoulder Belts....................................... 193Latches.......................................................... 227Hood........................................................... 71Lead Free Gasoline........................................ 303Leaks, Fluid................................................... 228Life Of Tires................................................... 291Liftgate............................................................ 72Liftgate Window Wiper/Washer....................... 53Light Bulbs..................................................... 227
Lights............................................................ 227Air Bag...................................... 88, 199, 226Automatic Headlights.................................. 47AWD............................................................. 94Brake Assist Warning............................... 181Brake Warning............................................. 88Bulb Replacement........................... 278, 280Cargo........................................................... 73Center Mounted Stop............................... 280Cruise............................................ 93, 94, 95Daytime Running......................................... 46Dimmer Switch, Headlight........................... 45Electric Power Steering................................ 89Electronic Stability Control........................... 91
Electronic Stability Program(ESP) Indicator... 90
Exterior...............................................45, 227Fog.....................................................94, 280Forward Collision Warning.................... 92, 94Hazard Warning Flasher........................... 229Headlights On With Wipers.......................... 47High Beam................................................... 95High Beam/Low Beam Select...................... 46Hood Open.................................................. 90Interior......................................................... 49LaneSense.................................... 92, 94, 95Lights On Reminder..................................... 48Low Fuel...................................................... 92Malfunction Indicator (Check Engine).......... 92
NEUTRAL.....................................................94Oil Temperature...........................................90Park......................................................47, 94Passing........................................................47Reading.......................................................49Rear Servicing.......................................... 280Rear Tail Lamps........................................ 280Seat Belt Reminder.....................................88Security Alarm.............................................91Service............................................. 278, 280Service AWD................................................93Side Marker.............................................. 280Sport Mode..................................................95Stop Start.............................................93, 95Traction Control........................................ 181Trailer Brake Disconnected.........................90Transmission Temperature..........................90Turn Signals....................... 45, 95, 227, 280Vanity Mirror................................................40Warning Instrument Cluster Descriptions....90Load Shed Battery Saver Mode........................87Load Shed Battery Saver On............................87Load Shed Electrical Load Reduction..............87Load Shed Intelligent Battery Sensor...............87Loading Vehicle............................................. 136Tires.......................................................... 286
11

23_WD_OM_EN_USC_t.book Page 317

318 Locks Child Protection
........................................... 25Manual........................................................ 21Power Door.................................................. 22Lubrication, Body........................................... 261Lug Nuts/Bolts.............................................. 302Luggage Carrier............................................... 74
M
Maintenance................................................... 71Maintenance Free Battery............................. 255Maintenance Schedule.................................. 249
Malfunction Indicator Light (Check Engine).. 92, 96
ManualService...................................................... 312Memory Feature (Memory Seats).................... 27Memory Seat................................................... 27Memory Seats And Radio................................ 27Methanol....................................................... 304Mirrors............................................................. 40Electric Remote........................................... 41Exterior Folding........................................... 40Heated........................................................ 41Outside........................................................ 40Rearview............................................ 40, 229Vanity.......................................................... 40Modifications/AlterationsVehicle.......................................................... 9
Monitor, Tire Pressure System...................... 188Mopar Parts.................................................. 311Multi-Function Control Lever............................ 45
N
New Vehicle Break-In Period......................... 101
O
Occupant Restraints..................................... 191Octane Rating, Gasoline (Fuel)..................... 303Oil Change Indicator........................................ 82Reset........................................................... 82Oil Filter, Change.......................................... 257Oil Filter, Selection........................................ 257Oil Pressure Light............................................. 90Oil, Engine..................................................... 256Capacity.................................................... 306Checking................................................... 255Dipstick.................................................... 255Disposal................................................... 257Filter......................................................... 257Filter Disposal........................................... 257Identification Logo.................................... 256Materials Added To.................................. 257Pressure Warning Light............................... 90Recommendation............................ 256, 306Synthetic.................................................. 257Viscosity................................................... 306
Onboard Diagnostic System.............................96Operating Precautions.....................................96Operator ManualOwner's Manual........................................ 312Outside Rearview Mirrors.................................40
P
Paint Care..................................................... 299Parking Brake............................................... 102ParkSense System, Rear............................... 125Passive Entry....................................................22Performance....................................................84Pets............................................................... 225Pinch Protection...............................................71Placard, Tire And Loading Information.......... 286PowerBrakes...................................................... 302Distribution Center (Fuses)....................... 271Door Locks...................................................22Inverter........................................................67Liftgate........................................................72Mirrors.........................................................41Outlet (Auxiliary Electrical Outlet).................65Seats...........................................................33Steering........................................... 113, 307Sunroof........................................................70Tilt/Telescoping Steering Column................26Windows......................................................68

23_WD_OM_EN_USC_t.book Page 318
