fog light bulb DODGE GRAND CARAVAN 2005 Owners Manual

▫ Steering Shaft Seal ....................391
▫ Steering Linkage ......................391
▫ Drive Shaft Universal Joints ..............391
▫ Body Lubrication .....................391
▫ Windshield Wiper Blades ................392
▫ Windshield And Rear Window Washers .....392
▫ Exhaust System ......................393
▫ Cooling System .......................394
▫ Hoses And Vacuum/Vapor Harnesses .......399
▫ Brakes .............................399
▫ Master Cylinder — ABS Brakes Brake
Fluid Level Check .....................401
▫ Fuel System Hoses ....................402 ▫ Automatic Transmission ................402
▫ Front And Rear Wheel Bearings ...........406
▫ Appearance Care And Protection
From Corrosion ......................406
▫ Cleaning The Instrument Panel And Underseat
Cup Holders ........................410

Integrated Power Module (IPM) ............412

Vehicle Storage ........................415

Replacement Light Bulbs .................415

Bulb Replacement ......................416
▫ Headlights ..........................416
▫ Front Park/Turn Signal And
Sidemarker Lights .....................418
▫ Front Fog Light ......................419372 MAINTAINING YOUR VEHICLE

NOTE: For lighted switches, see your dealer for replace-
ment instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.
LIGHT BULBS — Exterior Bulb Number
Back-up, Tail, Stop, Turn Signal, & Sidemarker . . . 3057
Center High-Mounted Stop Light ............. 921
Fog Light — If Equipped .................. 9145
Front Side marker, Park/Turn Signal ........ 3457AK
Headlight ............................. 9007
License ................................ 168 BULB REPLACEMENT
Headlights
1. Remove the three screws securing the headlight mod-
ule.416 MAINTAINING YOUR VEHICLE

Front Fog Light
1. Reach behind the front fascia from under the vehicle.
2. Twist the front fog light bulb to remove from the fog
light housing.
3. Disconnect the electrical connector and replace the
bulb.
CAUTION!Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol. Rear Tail, Stop, Turn Signal, Side Marker and
Back-up Lights
1. Raise the liftgate.
2. Remove the two tail light assembly push-in type
fasteners, by prying under the fastener head with a large
flat screwdriver. MAINTAINING YOUR VEHICLE 419
7

Liftgate ................................ 35
Lights .............................. 85,134
Airbag ........................ 57,68,84,199
Alarm .............................. 200
Anti-Lock ........................... 199
Automatic Headlights ................... 136
Back-Up ............................. 419
Battery Saver ......................... 137
Brake Warning ........................ 197
Bulb Replacement ................... 415,416
Center Mounted Stop ................... 420
Cruise .............................. 204
Dimmer Switch, Headlight ............... 135
Door Ajar ........................... 197
Engine Temperature Warning .............. 200
Fog ............................. 138,419
Hazard Warning Flasher ................. 344
Headlight Switch ...................... 135
Headlights ........................... 416 Headlights On Reminder ................. 137
High Beam Indicator .................... 202
High Beam/Low Beam Select ............. 139
Illuminated Entry ....................... 16
Interior .......................... 134,135
License ............................. 421
Liftgate Ajar .......................... 197
Lights On Reminder .................... 137
Low Fuel ............................ 197
Malfunction Indicator ................... 202
Oil Pressure .......................... 202
Park ............................. 135,418
Passing ............................. 139
Reading ............................. 150
Rear Servicing ........................ 419
Rear Tail ............................ 419
Seat Belt Reminder ..................... 200
Security Alarm ........................ 200
Service ........................... 415,416466 INDEX
