DODGE GRAND CARAVAN 2006 Owners Manual

Second Row Seat Storage bins — If Equipped
The Seat Storage Bins are located on the floor in front of
the second row seats, the area below the covers can be
used for storage when the second row seat is in the
upright position. Pull up on the storage bin latch to open the cover. Slide
the storage bin locking mechanism to the  Unlocked
position to allow greater access to the storage bin.
WARNING!In an accident, serious injury could result if the seat
storage bin covers are not properly latched. Do not
drive the vehicle with the storage bin cover open.
Keep the storage bin cover closed and latched while
the vehicle is in motion. Do not operate the storage
bin cover while the vehicle is in motion.
Storage Bin Cover UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181
3

Overhead Rail System — If Equipped
The overhead rail system contains provisions for three
movable and removable overhead storage bins. The
storage bins may be placed anywhere on the overhead
rail system.
CAUTION!Do not load objects over 1.5 lbs (0.68 kg) in the
storage bins. Failure to follow this could cause
damage to the Overhead Rail System. To Remove Storage Bins
1. Support the bin with one hand and pull the latch
handles out.182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Twist the latch handles a 1
4
turn and pull outward to
disengage the bin from the rail.
3. Remove the storage bin.
NOTE: Make sure the latch handle pops out before
removing the storage bin. To reinstall the storage bins, place the bin in the desired
location on the overhead rail, push firmly upward on the
bin with one hand, while pushing in on the latch handle,
twist a 1
4
turn to attach the bin to the rail. Push the latch
handle down to lock the storage bin in place.
WARNING!In a collision, you or others in your vehicle could be
injured if the storage bins are not properly latched to
the Overhead Rail System. Always be sure the
storage bins are fully latched. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183
3

Removable Floor Console With Fold-in-Floor
Seating — If Equipped
The removable floor console has a two power outlets,
storage tray, light, removable cell phone holder, tissue
holder, pen holder and a map holder. It can be removed
from the vehicle by pulling the release handle inside the
floor console.
To remove the console use the following procedure:
1. Open the console lid and remove the storage tray.
2. Pull up on the release handle located inside the floor
console, and slide the console rearward to disengage
from the floor. Release Handle184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Remove the floor console.
To reinstall the console, open the console lid and remove
the storage tray. Pull up on the release handle and slide
the console forward to engage the front of the console
into the floor tray. Pivot the floor console down until it is
seated on the floor tray and release the handle. Pull up on
the console to be sure it is firmly attached.
WARNING!In an accident, serious injury could result if the
removable floor console is not properly installed.
Always be sure the removable floor console is fully
latched. Cell Phone Holder Removal
1. Open the floor console lid and lift the cell phone
holder upward.
2. Squeeze the legs together to disengage the holder from
the floor console and remove the cell phone holder.
To reinstall the cell phone holder, align the pivot legs into
the guides and push forward to snap the legs into place.
Removable Floor Console Without Fold-in-Floor
Seating — If Equipped
The removable floor console has a power outlet, storage
tray, light, cell phone holder, tissue holder, and a map
holder. It can be placed between either the front seats or
middle seats. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185
3

NOTE: When the console is located between the front
seats the outlet is protected by an automatic circuit
breaker and is powered directly from the battery, items
plugged into this outlet may discharge the battery
and/or prevent engine starting. To remove the console use the following procedure:
1. Open the rear lid and remove the storage tray.
2. Pull up on the release handle located inside the floor
console to disengage the floor console, reinstall the
storage tray and close the rear lid.
Removable Floor Console
Release Handle186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

3. Using the front and rear grab handles, slide the
console rearward to disengage the front of the console
and lift up to remove the console from the floor.
4. Place the rubber mat on the floor tray.
To reinstall the console, remove the rubber mat and
relocate to the alternate floor tray, slide the console
forward to engage the front of the console into the floor
tray. Rapidly push down on the rear of the console with
enough force to engage the latch, you should hear the
latch “ snap ” into place. Pull up on the console to be sure
it is firmly attached.
WARNING!In an accident, serious injury could result if the remov-
able floor console is not properly installed. Always be
sure the removable floor console is fully latched. NOTE: When the removable floor console is located
between the middle seats, the power outlet only has
power supplied to it when the ignition switch is ON.
Cell Phone Holder
1. Open the front lid and remove the cell phone holder by
pulling rearward and up on the lower edge of the holder.
Cell Phone HolderUNDERSTANDING THE FEATURES OF YOUR VEHICLE 187
3

2. Plug in the power cord for the cellular phone into the
outlet located in the bottom of the forward console bin
and reinstall the cell phone holder.
3. Place the cell phone into the holder.
CAUTION!• Many accessories that can be plugged in draw
power from the vehicle ’ s battery, even when not
in use (i.e. cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle ’ s battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
• Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.), will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
• After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle ’ s battery.188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rear Compartment Storage Bins
Your vehicle may be equipped with open storage bins
located in each rear trim panel.
Cargo/Tub Nets
Two cargo/tub nets are available on vehicles equipped
with Fold-in-Floor Seating. The cargo nets fit in the
second row storage bin and the third row tub. The nets
are supported by hooks located in these areas. Refer to
instructions provided in the net kit.
Coat Hooks
Coat hooks are located along the headliner for the second
and third row seating positions. The coat hook load limit
is 10 lbs (4.5 kg). Exceeding the recommended load limit
can cause the coat hooks to break or disengage from the
vehicle. Cargo Area Storage
The seats in your vehicle are in-line which enables you to
stow long objects, such as lumber or skis, on the floor
without moving the seats.
NOTE: With all rear seat backs folded, a 4x8 foot sheet
of building material may be stored in the long-wheelbase
body style on top of the folded seats with the liftgate
closed. The front seats must be moved slightly forward of
the rearmost position. If the rear seats are removed no
front seat adjustment is needed and more than one 4x8
sheet of building material may be stored. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189
3

The liftgate sill plate has a raised line with the statement
“ Load To This Line ” . This line indicates how far rearward
cargo can be placed without interfering with liftgate
closing. ROOF LUGGAGE RACK — IF EQUIPPED
The crossbars and siderails are designed to carry the
weight on vehicles equipped with a luggage rack. The
load must not exceed 68 kg (150 lbs), and should be
uniformly distributed over the luggage rack crossbars.
Loading Limit
Roof Rack190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
