cruise control DODGE GRAND CARAVAN 2007 Owners Manual

1. Used for research purposes, such as to match data
with a particular crash record in an aggregate database,
provided confidentiality of personal data is thereafter
preserved
2. Used in defense of litigation involving a
DaimlerChrysler Corporation product
3. Requested by police under a legal warrant
4. Otherwise required by law
Data Parameters that May Be Recorded:
• Diagnostic trouble code(s) and warning lamp status
for electronically-controlled safety systems, including
the airbag system
• Airbag disable lamp status (if equipped)
•  Time  of airbag deployment (in terms of ignition
cycles and vehicle mileage) • Airbag deployment level (if applicable)
• Seatbelt status
• Brake status (service and parking brakes)
• Accelerator status (including vehicle speed)
• Engine control status (including engine speed)
• Cruise control status
• Traction/stability control status
DaimlerChrysler Corporation Integrated Child
Seat — If Equipped
Operating instructions for this seat are included with the
seat. If the instructions are not with the seat or in the
Owner’s Manual Package, replacement instructions can
be obtained.74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

• The pedals can be adjusted while driving.
• The pedals cannot be adjusted when the vehicle is in R
(Reverse) or when the Speed Control System is ON.
The following messages will be displayed on vehicles
equipped with the Electronic Vehicle Information Sys-
tem (EVIC) if the pedals are attempted to be adjusted
when the system is locked out (“Adjustable Pedal
Disabled — Cruise Control Engaged” or “Adjustable
Pedal Disabled — Vehicle In Reverse”).
CAUTION!Do not place any article under the adjustable pedals
or impede its ability to move as it may cause damage
to the pedal controls. Pedal travel may become
limited if movement is stopped by an obstruction in
the adjustable pedal’s path. ELECTRONIC SPEED CONTROL — IF EQUIPPED
When engaged, this device takes over the accelerator
operation at speeds greater than 30 mph (50 km/h).
Speed Control Switches164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To Activate:
Push the “ON/OFF” button once and the CRUISE indi-
cator located below the instrument cluster odometer will
illuminate showing the electronic speed control system is
on. To turn the system OFF, push the “ON/OFF” button
again and the system and indicator will turn off.
WARNING!Leaving the Electronic Speed Control system on
when not in use is dangerous. You could accidently
set the system or cause it to go faster than you want.
You could lose control and have an accident. Always
leave the system OFF when you aren’t using it. To Set At A Desired Speed:
When the vehicle has reached the desired speed, press
and release the “SET” button. Release the accelerator and
the vehicle will operate at the selected speed.
To Deactivate:
A soft tap on the brake pedal, pushing the “CANCEL”
button or normal braking while slowing the vehicle will
deactivate the speed control without erasing the set
speed memory. Pushing the “ON/OFF” button to the
OFF position or turning off the ignition erases the set
speed memory.
To Resume Speed:
To resume a previously set speed, push and release the
“RESUME/ACCEL” button. Resume can be used at any
speed above 25 mph (40 km/h). UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165
3

This is to prevent overheating of the brake system and is
a normal condition. The system will remain disabled for
about 4 minutes until the brakes have cooled. The system
will automatically reactivate and turn off the TRAC and
the OFF indicators.
If your vehicle becomes stuck in mud, ice, or snow, turn
the Traction Control System OFF before attempting to
“rock” the vehicle free.
23. Odometer/Trip Odometer
The odometer shows the total distance the vehicle has
been driven.
U.S. federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading is changed during repair or
replacement, be sure to keep a record of the reading
before and after the service so that the correct mileage can
be determined. The trip odometer shows individual trip mileage. To
switch from odometer to trip odometer, press the Trip
Odometer button.
Loose Fuel Filler Cap
If the vehicle diagnostic system determines that the fuel
filler cap is loose, improperly installed, or damaged,
GASCAP will be displayed in the instrument cluster
odometer. Tighten the fuel filler cap properly and press
the odometer reset button to turn the GASCAP message
off. If the problem continues, the message will appear the
next time the vehicle is started. See Section 7 of this
manual for more information.
24. Cruise Indicator
This display indicator shows that the Speed Control
System is ON. UNDERSTANDING YOUR INSTRUMENT PANEL 219
4

Compass Variance ....................... 170
Computer, Trip/Travel .................... 171
Console, Overhead ....................... 167
Console, Removable ................... 193,194
Contract, Service ........................ 488
Coolant Pressure Cap (Radiator Cap) .......... 436
Cooling System ......................... 434
Adding Coolant (Antifreeze) .............. 436
Coolant Capacity ...................... 461
Coolant Level ...................... 434,437
Disposal of Used Coolant ................ 437
Drain, Flush, and Refill .................. 435
Inspection ........................... 437
Points to Remember .................... 438
Pressure Cap ......................... 436
Radiator Cap ......................... 436
Selection of Coolant (Antifreeze) ...... 435,461,462
Cruise Control (Speed Control) .............. 164
Cruise Light ........................... 219 Cup Holder ......................... 187,450
Customer Assistance ..................... 486
Data Recorder, Event ...................... 73
Daytime Running Lights ................... 153
Dealer Service .......................... 419
Defroster, Rear Window ................... 304
Defroster, Windshield ................ 90,283,295
Diagnostic System, Onboard ................ 416
Digital Video Disc (DVD) Player ............. 259
Dimmer Control ........................ 152
Dipsticks
Automatic Transmission ................. 444
Oil (Engine) .......................... 420
Disabled Vehicle Towing ................... 408
Disposal
Antifreeze (Engine Coolant) ............... 437
Engine Oil ........................... 423
Domelight ............................. 152 INDEX 499
10

Door Ajar Light ......................... 213
Door Locks ............................. 27
Door Locks, Automatic .................... 29
Door Opener, Garage ..................... 177
Drive Belts ............................ 423
Drive Shaft Universal Joints ................ 431
Driving
On Slippery Surfaces .................... 326
DVD Player (Video Entertainment System) ...... 259
E-85 Fuel ............................. 360
Electric Remote Mirrors .................... 98
Electrical Power Outlets ................... 185
Electronic Speed Control (Cruise Control) ...... 164
Electronic Vehicle Information Center (EVIC) .... 172
Emergency, In Case of
Hazard Warning Flasher ................. 384
Jacking ........................ 386,387,399
Jump Starting ......................... 405 Overheating .......................... 385
Emission Control System Maintenance ...... 417,466
Engine ............................ 414,415
Air Cleaner .......................... 425
Air Cleaner Filter ...................... 424
Block Heater ......................... 315
Break-In Recommendations ................ 88
Checking Oil Level ..................... 420
Compartment ...................... 414,415
Coolant (Antifreeze) .................... 462
Cooling ............................. 434
Exhaust Gas Caution .................. 43,356
Flooded, Starting ...................... 313
Fuel Requirements .................. 353,461
Oil ........................... 420,461,462
Oil Change Interval .................... 421
Oil Disposal .......................... 423
Oil Filler Cap ......................... 422
Oil Filter Disposal ...................... 423500 INDEX

Integrated, Child ....................... 74
Lumbar Support ....................... 128
Power .............................. 124
Reclining ......................... 127,129
Removal ....................... 138,141,143
Stow  n Go (Fold in Floor) ................ 129
Tilting .............................. 137
Security Alarm (Theft Alarm) ................ 18
Selection of Coolant (Antifreeze) .......... 435,462
Sentry Key (Immobilizer) ................... 15
Sentry Key Programming ................... 17
Service Assistance ....................... 486
Service Contract ......................... 488
Service Engine Soon Light (Malfunction
Indicator) ............................. 218
Service Manuals ........................ 490
Setting the Clock ..................... 220,258
Shoulder Belts ........................... 47
Signals, Turn ................... 155,212,458,459 Sliding Door ............................ 34
Slippery Surfaces, Driving On ............... 326
Snow Chains (Tire Chains) ................. 345
Snow Tires ............................ 346
Spare Tire ..................... 340,341,389,400
Spark Plugs ............................ 424
Speed Control (Cruise Control) .............. 164
Speedometer ........................... 213
Starting ............................... 311
Automatic Transmission ................. 312
Engine Fails to Start .................... 313
Starting and Operating .................... 311
Starting Procedures ...................... 311
Steering
Column Controls ...................... 155
Linkage ............................. 431
Power ........................... 325,430
Shaft Seal ............................ 431
Tilt Column .......................... 158510 INDEX
