Airbag Light
The light should come on and remain on for 6 to 8
seconds as a bulb check when the ignition switch is first
turned ON. If the LED is not lit during starting, have it
checked. If the light stays on or comes on while driving,
have the system checked by an authorized dealer.
Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield.
Periodic Safety Checks You Should Make Outside
The Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect tread and sidewall for cuts or
cracks. Check wheel nuts for tightness, and tires (includ-
ing spare) for proper pressure.
Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil or other fluid leaks. Also, if gasoline
fumes are detected or fuel, power steering fluid, trans-
mission fluid or brake fluid leaks are suspected, the cause
should be located and corrected immediately.90 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7 of this manual. Follow
the warnings under the Cooling System Pressure
Cap paragraph.
17. Washer Fluid Light
This light turns on when the washer fluid level
falls below approximately 1/4 filled. The light will
remain on until fluid is added.
18. Transmission Range Indicator
This display indicator shows the automatic transaxle gear
selection. NOTE: You must apply the brakes before shifting from
Park.
19. Oil Pressure Warning Light
This light shows low engine oil pressure. The light
should turn on momentarily when the engine is
started. If the light turns on while driving, stop the
vehicle and shut off the engine as soon as possible. A
chime will sound for 4 minutes when this light turns on.
Do not operate the vehicle until the cause is corrected.
This light does not show how much oil is in the engine.
The engine oil level must be checked under the hood.
20. High Beam Light
This light shows that the headlights are on high
beam. Pull the turn signal lever towards the
steering wheel to switch the headlights from high or low
beam. UNDERSTANDING YOUR INSTRUMENT PANEL 217
4

 Tire Pressure Monitoring Low Pressure
Warnings ...........................349
 Base Tire Pressure Monitoring System With
Electronic Vehicle Information Center (EVIC) — If
Equipped ...........................349
 Service Tire System Soon ................351
 Using Your Compact Spare — Basic Tire Pressure
Monitoring System Only ................352
 General Information ...................353

Fuel Requirements ......................353
 Reformulated Gasoline .................354
 Gasoline/Oxygenate Blends ..............354
 MMT In Gasoline .....................355
 Materials Added To Fuel ................355  Fuel System Cautions ..................356
 Carbon Monoxide Warnings ..............356

Adding Fuel ..........................357
 Fuel Filler Cap (Gas Cap) ...............357
 Loose Fuel Filler Cap Message ............359

Flexible Fuel — Fleet Vehicles Only ..........360
 E-85 General Information ................360
 Ethanol Fuel (E-85) ....................361
 Fuel Requirements ....................361
 Selection Of Engine Oil For Flexible Fuel Vehicles
(E-85) And Gasoline Vehicles .............362
 Starting ............................362
 Cruising Range .......................363 STARTING AND OPERATING 309
5

WARNING!A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7, Maintenance, of this
manual. Follow the warnings under the Cooling
System Pressure Cap paragraph. JACKING AND TIRE CHANGING
WARNING!

Engine Oil
Checking Oil Level
To assure proper engine lubrication, the engine oil must
be maintained at the correct level. Check the oil level at
regular intervals, such as every fuel stop.
The best time to check the engine oil level is about 5
minutes after a fully warmed engine is shut off or before
starting the engine after it has sat overnight.
Checking the oil while the vehicle is on level ground will
improve the accuracy of the oil level readings. Maintain
the oil level between the MIN and MAX markings on the
dipstick. Adding one quart of oil when the reading is at
the MIN mark will result in a MAX reading on these
engines.
CAUTION!Overfilling or underfilling will cause oil aeration or
loss of oil pressure. This could damage your engine. Engine Oil Dipstick420 MAINTAINING YOUR VEHICLE

WARNING!• Use only refrigerants and compressor lubricants
approved by the manufacturer for your air condi-
tioning system. Some unapproved refrigerants are
flammable and can explode, injuring you. Other
unapproved refrigerants or lubricants can cause
the system to fail, requiring costly repairs. Refer
to Section 3 of the Warranty Information book for
further warranty information.
• The air conditioning system contains refrigerant
under high pressure. To avoid risk of personal
injury or damage to the system, adding refrigerant
or any repair requiring lines to be disconnected
should be done by an experienced repairman. Refrigerant Recovery And Recycling
R-134a Air Conditioning Refrigerant is a hydrofluorocar-
bon (HFC) that is endorsed by the Environmental Pro-
tection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by dealers or other service facilities
using recovery and recycling equipment.
NOTE: Use only manufacturer approved A/C System
Sealers, Stop Leak Products, Seal Conditioners, Compres-
sor Oil, or Refrigerants.
A/C Air Filter — If Equipped
The A/C Air Filter — if so equipped, is found behind the
filter access door located under the instrument panel on
the passenger side. To replace the filter slide the lock
toward the rear of the vehicle (unlock position). Remove
the access door and pull the filter downward. When
installing a new filter, ensure its proper orientation. Align MAINTAINING YOUR VEHICLE 429
7

WARNING!Riding the brakes can lead to brake failure and
possibly an accident. Driving with your foot resting
or riding on the brake pedal can result in abnormally
high brake temperatures, excessive lining wear, and
possible brake damage. You wouldn’t have your full
braking capacity in an emergency.
Brake And Power Steering Hoses
When the vehicle is serviced for scheduled maintenance,
inspect surface of hoses and nylon tubing for evidence of
heat and mechanical damage. Hard and brittle rubber,
cracking, tears, cuts, abrasion, and excessive swelling
indicate deterioration of the rubber. Particular attention
should be made to examining those hose surfaces nearest
to high heat sources, such as the exhaust manifold. Insure nylon tubing in these areas has not melted or
collapsed.
Inspect all hose connections such as clamps and cou-
plings to make sure they are secure and no leaks are
present.
NOTE: Often, fluid such as oil, power steering fluid,
and brake fluid are used during assembly plant opera-
tions to facilitate the assembly of hoses to couplings.
Therefore, oil wetness at the hose-coupling area is not
necessarily an indication of leakage. Actual dripping of
hot fluid when systems are under pressure (during
vehicle operation), should be noted before hose is re-
placed based on leakage.
NOTE: Inspection of brake hoses should be performed
whenever the brake system is serviced and every engine
oil change. Inspect hydraulic brake hoses for surface
cracking, scuffing, or worn spots. If there is any evidence
of cracking, scuffing, or worn spots, the hose should be440 MAINTAINING YOUR VEHICLE

Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and Mopar Total Clean. Care should be taken to avoid
soaking your leather upholstery with any liquid. Please
do not use polishes, oils, cleaning fluids, solvents, deter-
gents, or ammonia based cleaners to clean your leather
upholstery. Application of a leather conditioner is not
required to maintain the original condition.
WARNING!Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm. Cleaning High Gloss Front Door B-pillar
Appliques
When cleaning the front door B-pillar appliques, care
must be taken to avoid scratching the plastic.
1. Remove all dirt with a wet soft rag. A mild soap
solution may be used, do not use high alcohol content or
abrasive cleaners. Glass cleaners are not recommended. If
soap is used, wipe clean with a clean damp rag.
2. To maintain the high gloss shine, apply a scratch and
swirl remover onto a damp cloth and apply to door
applique. Rub the applique with a firm pressure then buff
lightly with a clean cotton cloth until a high gloss shine is
achieved.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with Mopar Glass Cleaner or any commercial household-
type glass cleaner. Never use an abrasive type cleaner.
Use caution when cleaning the inside rear window MAINTAINING YOUR VEHICLE 449
7

Once a Month
• Check tire pressure and look for unusual wear or
damage.
• Inspect the battery and clean and tighten the terminals
as required.
• Check the fluid levels of coolant reservoir, brake
master cylinder, power steering and transmission and
add as needed.
• Check all lights and all other electrical items for correct
operation. At Each Oil Change
• Change the engine oil filter.
• Inspect the exhaust system.
• Inspect the brake hoses.
• Inspect the CV joints and front suspension compo-
nents.
• Check the automatic transmission fluid level.
• Check the coolant level, hoses, and clamps.468 MAINTENANCE SCHEDULES
8 M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Oil (Engine) .......................... 422
Radiator (Coolant Pressure) ............... 436
Car Washes ............................ 447
Carbon Monoxide Warning ................. 356
Cargo Compartment
Luggage Carrier ....................... 199
Cargo (Vehicle Loading) ................... 198
Cassette Tape and Player Maintenance ......... 276
Cassette Tape Player ..................... 222
Catalytic Converter ...................... 425
Caution, Exhaust Gas .............. 43,89,356,433
CD (Compact Disc) Changer ....... 231,238,255,259
CD (Compact Disc)
Player ............ 228,232,237,243,246,251,253,259
CD (Compact Disc) Player Maintenance ........ 277
Cellular Phone ....................... 100,274
Center High Mounted Stop Light ............ 460
Center Lap Belts ......................... 53
Chains, Tire ............................ 345 Changing A Flat Tire ..................... 386
Chart, Tire Sizing ........................ 328
Check Engine Light (Malfunction Indicator
Light) ............................. 218,417
Child Restraint ...................... 75,76,77
Child Restraint Tether Anchors ............... 79
Child Safety Locks ........................ 38
Child Seat ............................ 74,82
Clean Air Gasoline ....................... 354
Cleaning
Wheels ............................. 448
Climate Control ......................... 278
Clock ............................. 220,258
Coat Hook ............................ 198
Compact Disc (CD) Maintenance ............. 277
Compact Disc (CD) Player ............... 222,228
Compact Spare Tire ...................... 340
Compass .............................. 168
Compass Calibration ..................... 169498 INDEX
