• Slide the storage bin locking mechanism to the “LOCK” position and then pull up on thestorage bin latch to open the cover.
• Pull upward on the seatback recliner lever located on the outboard side of the seat.
• The non-adjustable head restraint and seatback will fold automatically during
the seat tumble.
• The seat will automatically tumble into position for easy storage.
• Push the seat into the storage bin and close the storage bin cover.
To Unstow Second Row Seats
• Pull up on the storage bin latch to openthe cover.
• Pull up on the strap to lift the seat out of the storage bin and push the seat rear-
ward to latch the seat anchors.
• Lift the seatback to the full upright position.
• Return the head restraint to its upright position, close the storage bin cover and
slide the storage bin locking mechanism
to the “UNLOCKED” position.
Headrest In Stowed Position
Seat In Tumble Position
Seat In Stored Position
GETTING STARTED
20

Manually Folding Third Row Seats
• Lower the center head restraint down to the seatback by pushing the button on the guideand pushing the head restraint down.
• Lower the outboard head restraints by pulling on the release strap marked “1”
located on the outboard side of the head
restraint.
•
Pull release strap marked “2” located on
the rear of the seat to lower the seatback.
• Pull release strap marked “3” to release the anchors.
Center Headrest In Lowered Position
Head Restraints In Lowered Position
Seatbacks In Folded Position
