oil reset DODGE JOURNEY 2016 1.G Owners Manual

system is duty cycle based, which means the engine oil
change interval may fluctuate dependent upon your
personal driving style.
Unless reset, this message will continue to display each
time you cycle the ignition to the ON/RUN position. To
turn off the message temporarily, push and release the
UParrow button. To reset the oil change indicator system
(after performing the scheduled maintenance), perform
the following procedure:
1. Without depressing the brake pedal, push and release the ENGINE START/STOP button and cycle the igni-
tion to the ON/RUN position (do not start the engine).
2. Fully depress the accelerator pedal, slowly, three times within 10 seconds.
3. Without depressing the brake pedal, push and release the ENGINE START/STOP button once to return the
ignition to the OFF/LOCK position. NOTE:
If the indicator message illuminates when you
start the vehicle, the oil change indicator system did not
reset. If necessary, repeat this procedure.
Fuel Economy
Push and release the UPorDOWN button until “Fuel
Economy” displays highlighted in the EVIC and push the
RIGHT button. The following Fuel Economy functions
will display in the EVIC:
• Average Fuel Economy
• Distance To Empty (DTE)
• Instantaneous Fuel Economy (MPG or L/100 km)
Average Fuel Economy
Shows the average fuel economy since the last reset. When
the fuel economy is reset, the display will read “RESET” or
332 UNDERSTANDING YOUR INSTRUMENT PANEL

Trip B
•Shows the total distance traveled for Trip B since the
last reset.
• Shows the elapsed time traveled for Trip B since the
last reset.
Elapsed Time
Shows the total elapsed time of travel since the last reset.
Elapsed time will increment when the ignition is in the
ON/RUN position.
To Reset The Display
Reset will only occur while a resettable function is being
displayed. Push and release the RIGHTbutton once to
clear the resettable function.
Tire Pressure
Push and release the UPorDOWN button until “Tire
PSI:” displays highlighted in the EVIC. Push and release the
RIGHT button to view a graphic of the vehicle with
a tire pressure value at each corner of the graphic.
Vehicle Info (Customer Information Features)
Push and release the UPorDOWN button until “Vehicle
Info” displays in the EVIC and push the RIGHTbutton.
Push the UPand DOWN button to scroll through the
available information displays.
• Coolant Temp
Displays the actual coolant temperature.
• Oil Temperature
Displays the actual oil temperature.
• Oil Pressure
Displays the actual oil pressure.
• Trans Temperature
Displays the actual transmission temperature.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 335

MAINTENANCE SCHEDULE
Your vehicle is equipped with an automatic oil change
indicator system. The oil change indicator system will
remind you that it is time to take your vehicle in for
scheduled maintenance.
Based on engine operation conditions, the oil change
indicator message will illuminate. This means that ser-
vice is required for your vehicle. Operating conditions
such as frequent short-trips, trailer tow, extremely hot or
cold ambient temperatures, and E85 fuel usage will
influence when the “Change Oil” or “Oil Change Re-
quired” message is displayed. Severe Operating Condi-
tions can cause the change oil message to illuminate as
early as 3,500 miles (5,600 km) since last reset. Have your
vehicle serviced as soon as possible, within the next 500
miles (805 km).
Your authorized dealer will reset the oil change indicator
message after completing the scheduled oil change. If ascheduled oil change is performed by someone other
than your authorized dealer, the message can be reset by
referring to the steps described under “Electronic Vehicle
Information Center (EVIC)” in “Understanding Your
Instrument Panel” for further information.
NOTE:
Under no circumstances should oil change inter-
vals exceed 10,000 miles (16,000 km), twelve months or
350 hours of engine run time, whichever comes first. The
350 hours of engine run or idle time is generally only a
concern for fleet customers.
Severe Duty All Models
Change Engine Oil at 4,000 miles (6,500 km) if the vehicle
is operated in a dusty and off road environment or is
operated predominately at idle or only very low engine
RPM’s. This type of vehicle use is considered Severe Duty.
620 MAINTENANCE SCHEDULES

Luggage Rack (Roof Rack)...................290
Lug Nuts .............................. .530
Maintenance Free Battery ....................569
Maintenance Procedures ....................564
Malfunction Indicator Light (Check Engine) . . .314, 562
Manual, Service ......................... .634
Manual Transaxle Fluid Level Check ...................591, 592
Lubricant Selection ...................591, 592
Map/Reading Lights ...................... .231
Marker Lights, Side ....................... .608
Master Cylinder (Brakes) ....................586
Methanol .............................. .499
Mini-Trip Computer ...................... .334
Mirrors .............................119,254
Automatic Dimming .....................119
Electric Powered ....................... .121
Electric Remote ........................ .121Exterior Folding
....................... .123
Heated .............................. .123
Outside ............................. .121
Rearview .............................119
Vanity .............................. .123
Mode Fuel Saver ........................... .332
Modifications/Alterations, Vehicle ...............7
Monitor, Tire Pressure System ................490
MOPAR Parts ........................ .563, 633
MTBE/ETBE ........................... .499
Multi-Function Control Lever .................228
New Vehicle Break-In Period .................106
Occupant Restraints ........................46
Octane Rating, Gasoline (Fuel) .............498, 616
Oil Change Indicator ...................... .331
Oil Change Indicator, Reset ..................331
650 INDEX

Rear Window Features.....................288
Rear Wiper/Washer ....................... .288
Reclining Front Seats ...................... .204
Reclining Rear Seats ....................216, 220
Recorder, Event Data .......................77
Recreational Towing ...................... .523
Reformulated Gasoline .....................498
Refrigerant ............................. .571
Release, Hood ........................... .222
Reminder, Lights On ...................... .227
Reminder, Seat Belt .........................48
Remote Control Starting System .........................26
Remote Keyless Entry (RKE) ..................21
Panic Alarm ............................23
Programming Additional Key Fobs .........18, 24
Programming Additional Transmitters .......18, 24
Remote Sound System (Radio) Controls .........385Remote Starting
Exit Remote Start Mode .................28, 29
To Exit Remote Start Mode And Drive The
Vehicle ...............................29
Remote Starting System ......................26
Replacement Bulbs ....................... .606
Replacement Keys .........................17
Replacement Parts ........................ .563
Replacement Tires ........................ .486
Reporting Safety Defects ....................633
Resetting Oil Change Indicator ................331
Restraint, Head .......................... .207
Restraints, Child ...........................78
Retractable Cargo Area Cover ................286
Reverse Lights .......................... .610
Rocking Vehicle When Stuck .................550
Roof Rack (Luggage Rack) ...................290
Rotation, Tires .......................... .489
10
INDEX 653
