height adjustment DODGE JOURNEY 2017 1.G Owners Manual

SEATS............................... .149
▫ Driver’s Power Seat — If Equipped .........149
▫ Power Lumbar — If Equipped ..............150
▫ Front Heated Seats — If Equipped ..........151
▫ Manual Front Seat Adjustments .............152
▫ Recliner Adjustment ....................153
▫ Driver’s Seat Height Adjustment — If
Equipped ........................... .154
▫ Fold-Flat Front Passenger Seat — If Equipped . .154
▫ Head Restraints ...................... .155
▫ Third Row Passenger Seats — Seven Passenger
Models ............................. .159
▫ 60/40 Split Second-Row Passenger Seats ......159
▫ 50/50 Split Third-Row Passenger Seats With
Fold-Flat Feature — Seven Passenger Models . . .164
 TO OPEN AND CLOSE THE HOOD ..........166
 LIGHTS ............................. .168
▫ Headlight Switch ..................... .168▫
Automatic Headlights ...................168
▫ Headlights On With Wipers ...............169
▫ Headlight Time Delay ...................169
▫ Daytime Running Lights (DRL) ............170
▫ Lights-On Reminder ....................170
▫ Fog Lights — If Equipped ................170
▫ Multifunction Lever ....................171
▫ Turn Signals ......................... .171
▫ Lane Change Assist .....................171
▫ High/Low Beam Switch .................171
▫ Flash-To-Pass ........................ .172
▫ Interior

Lights ........................ .172
▫ Map/Reading Lights ....................172
 WINDSHIELD WIPERS AND WASHERS .......172
▫ Intermittent Wiper System ................172
▫ Windshield Wiper Operation ...............173
▫ Windshield Washers ....................174
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!(Continued)
be seriously or even fatally injured. Use the recliner
only when the vehicle is parked.
Driver’s Seat Height Adjustment — If Equipped
The seat height control lever is located on the outboard side
of the seat. Raise the lever to raise the seat. Lower the lever
to lower the seat. The total seat travel is approximately 2.15
inches (55 mm).
Fold-Flat Front Passenger Seat — If Equipped
This feature allows for extended cargo space. When the
seat is folded flat, it is an extension of the load floor surface
(allowing long cargo to fit from the rear hatch up to the
instrument panel). The fold-flat seatback also has a hard-
back surface that you can use as a work surface when the
seat is folded flat and the vehicle is not in motion.
Pull upward on the recline lever to fold or unfold the seat.
Seat Height Adjustment Lever
Fold-Flat Seat
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

push the adjustment button located on the base of the head
restraint, and push downward on the head restraint.
WARNING!
A loose head restraint thrown forward in a collision or
hard stop could cause serious injury or death to occu-
pants of the vehicle. Always securely stow removed
head restraints in a location outside the occupant
compartment.To remove the head restraint, push the adjustment and the
release buttons while pulling upward on the whole assem-
bly and raise it up as far as it can go. To reinstall the
headrest, put the headrest posts into the holes while
pushing the release buttons. Then adjust it to the appro-
priate height.
WARNING!
ALL the head restraints MUST be reinstalled in the
vehicle to properly protect the occupants. Follow the
re-installation instructions above prior to operating the
vehicle or occupying a seat.
NOTE: For proper routing of a Child Seat Tether, refer to
“Occupant Restraints” in “Things To Know Before Start-
ing”.
WARNING!
Driving a vehicle with the head restraints removed or
improperly adjusted could cause serious injury or
death in the event of a collision. The head restraints
should be checked prior to operating the vehicle and
never adjusted while the vehicle is in motion.
1 — Release Button
2 — Adjustment Button 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Safety Checks Inside Vehicle...................82
Safety Checks Outside Vehicle ..................84
Safety Defects, Reporting .....................487
Safety, Exhaust Gas ..........................81
Safety Information, Tire ..................... .353
Safety Tips ................................81
Seat Belt Adjustable Upper Shoulder Belt Anchorage .......41
Lap/Shoulder Belt Operation .................39
Lap/Shoulder Belts ........................37
Lap/Shoulder Belt Untwisting ................41
Pregnant Women .........................43
Seat Belt Extender .........................42
Seat Belt Pretensioner ......................43
Seat Belt Reminder ........................36
Seat Belt Maintenance ...................... .459
Seat Belt Reminder ..........................36
Seat Belts ............................. .35, 82
Adjustable Shoulder Belt ....................41
Adjustable Upper Shoulder Anchorage ..........41
Child Restraint ...........................59
Extender ...............................42
Front Seat ........................ .35, 37, 39
Inspection ..............................82
Operating Instructions ......................39 Pregnant Women
.........................43
Pretensioners ............................43
Rear Seat ...............................37
Reminder ............................. .225
Untwisting Procedure ......................41
Seats ............................... .149, 151
Adjustment ............................ .149
Easy Entry ............................ .163
Heated ............................... .151
Height Adjustment ....................149, 154
Power ............................... .149
Rear Folding ....................... .159, 164
Reclining ............................. .153
Reclining Rear ...................... .161, 164
Seatback Release ..................154, 159, 164
Tilting ............................... .149
Security Alarm ......................... .13, 228
Selection Of Coolant (Antifreeze) ...............473
SENTR
Y KEY
Key Programming .........................13
Sentry Key (Immobilizer) ......................11
Sentry Key Replacement ......................12
Service Assistance ......................... .484
Service Contract .......................... .486
Service Manuals .......................... .488
502 INDEX
