DODGE MAGNUM 2005 1.G Owners Manual

Front
AxleRear Axle
Empty Weight 2054 lbs
(932 kg)1805 lbs
(819 kg )
Load (Including driver, pass-
sengers and cargo)271 lbs
(123 kg)579 lbs
(263 kg)
Total 2325 lbs
(1055 kg)2384 lbs
(1081 kg)
GAWR 2546 lbs
(1155 kg)2708 lbs
(1228 kg)
TRAILER TOWING
In this section you will find safety tips and information
on limits to the type of towing you can reasonably do
with your vehicle. Before towing a trailer carefully re-
view this information to tow your load as efficiently and
safely as possible.
To maintain warranty coverage, follow the requirements
and recommendations in this manual concerning ve-
hicles used for trailer towing.Perform maintenance services as prescribed in the main-
tenance schedules manual. When your vehicle is used for
trailer towing, never exceed the gross axle weight rating
(GAWR) by the addition of:
•The tongue weight of the trailer.
•The weight of any other type of cargo or equipment
put in or on your vehicle.
•Remember that everything put in or on the trailer adds
to the load on your vehicle.
Warranty Requirements
The Manufacturer’s Passenger Vehicle Warranty will
apply to vehicles used to tow trailers for non-commercial
use. However the following conditions must be met:
•The maximum frontal area of the trailer cannot exceed
32 square feet (2.97 square meters).
•The trailer tongue load must be considered as part of
the combined weight of occupants and cargo, and
should never exceed the weight referenced on the Tire
and Loading Information placard. Refer to the Tire–
Safety Information Section in this manual.
STARTING AND OPERATING 251
5

•The“D”range can be selected when towing. However,
if frequent shifting occurs while in this range, the“3”
range must be selected.
NOTE:Using the“3”range while operating the vehicle
under heavy operating conditions will improve perfor-
mance and extend transmission life by reducing exces-
sive shifting and heat build up.
WARNING!
Connecting trailer brakes to your vehicle’s hydraulic
brake lines can overload your brake system and
cause it to fail. You might not have brakes when you
need them and could have an accident.
•Do not attempt to tow a trailer while using a compact
spare tire, except for emergency use only. Do not
exceed 50 mph (80km/h), and repair the damaged tire
immediately.
•When towing a trailer greater than 2000 lbs. (907 kg)
you should carry a full-size wheel and tire as a spare in
the event of a flat. If the compact spare tire is used it
may adversely affect vehicle handling.
•Whenever you pull a trailer, regardless of the trailer
size, stop lights and turn signals on the trailer are
recommended for motoring safety.
•The automatic transmission fluid and filter should be
changed if you REGULARLY tow a trailer for more
than 45 minutes of continuous operation. See Schedule
“B”in section 8 of this manual for transmission fluid
change intervals.
NOTE:
•
For vehicles equipped with Autostick. By using the
Autostick modes, and selecting a specific gear range,
frequent shifting can be avoided. The highest gear
range should be selected that allows for adequate
performance. For example, choose“4”if the desired
speed can be maintained. Choose“3”or“2”if needed
to maintain the desired speed.
252 STARTING AND OPERATING

•Extended driving at high RPM should be avoided to
prevent excess heat generation. A reduction in vehicle
speed may be required to avoid extended driving at
high RPM. Return to a higher gear range or vehicle
speed when road conditions and RPM level allows.
TRAVEL CONDI-
TIONMAXIMUM TRAILER WEIGHT(TRAILER FRONTAL AREA NOT TO EXCEED 32 SQ. FT.)
2.7L ENGINE 3.5L ENGINE 5.7L ENGINE 5.7L ENGINE WITH
TRAILER TOW
PACKAGE
UP TO 2 PERSONS
& LUGGAGE1000 lbs (454 kg) 2000 lbs (907 kg) 2000 lbs (907 kg) 3800 lbs (1724 kg)
UP TO 3 PERSONS
& LUGGAGE1000 lbs (454 kg) 2000 lbs (907 kg) 2000 lbs (907 kg) 3000 lbs (1361 kg)
UP TO 4 PERSONS
& LUGGAGE1000 lbs (454 kg) 1500 lbs (680 kg) 1500 lbs (680 kg) 1500 lbs (680 kg)
UP TO 5 PERSONS
& NO LUGGAGE1000 lbs (454 kg) 1000 lbs (454 kg) 1000 lbs (454 kg) 1000 lbs (454 kg)
A load equalizing hitch is recommended for loaded
trailer weights above 1,000 lbs (454 kg) and required for
weights above 2,000 lbs (907 kg).
STARTING AND OPERATING 253
5

CAUTION!
If the trailer weighs more than 1,000 lbs (454 kg)
loaded, it should have its own brakes and they
should be of adequate capacity. Failure to do this
could lead to accelerated brake lining wear, higher
brake pedal effort, and longer stopping distances.
WARNING!
Connecting trailer brakes to your vehicle’s hydraulic
brake lines can overload your brake system and
cause it to fail. You might not have brakes when you
need them and could have an accident.
254 STARTING AND OPERATING

WHAT TO DO IN EMERGENCIES
CONTENTS

Hazard Warning Flasher.................256

If Your Engine Overheats................256

Jacking And Tire Changing...............257
▫Preparations For Jacking................258
▫Jack Location........................259
▫Spare Tire Stowage....................261
▫Jacking And Changing a Tire.............263
▫Compact Spare Tire-For Temporary Emergency
Use Only...........................266
▫Wheel Cover Installation (If Required)......267

Jump-Starting Procedures If Battery Is Low...267

Driving On Slippery Surfaces.............269
▫Acceleration.........................269
▫Traction............................270

Freeing A Stuck Vehicle.................270

Towing A Disabled Vehicle...............271
▫With Ignition Key.....................271
▫Without The Ignition Key...............272
▫Towing This Vehicle Behind Another Vehicle
(Flat Towing With All Four Wheels On The
Ground)............................272
▫Towing This Vehicle Behind Another Vehicle
With A Tow Dolley....................272
6

HAZARD WARNING FLASHER
The hazard flasher switch is located in the center of the
instrument panel between the center air outlets.
To engage the Hazard Warning Flashers, depress the
switch on the instrument panel. When the Hazard Warn-
ing Switch is activated, all directional turn signals will
flash on and off to warn oncoming traffic of an emer-
gency. Push the switch a second time to turn off the
flashers.This is an emergency warning system and should not be
used when the vehicle is in motion. Use it when your
vehicle is disabled and is creating a safety hazard for
other motorists.
When you must leave the vehicle to seek assistance, the
Hazard Warning Flashers will continue to operate even
though the ignition switch is OFF.
NOTE:With extended use, the Hazard Warning Flash-
ers may wear down your battery.
IF YOUR ENGINE OVERHEATS
In any of the following situations, you can reduce the
potential for overheating by taking the appropriate ac-
tion.
•On the highways—Slow down.
•In city traffic—While stopped, put transmission in
neutral, but do not increase engine idle speed.
256 WHAT TO DO IN EMERGENCIES

NOTE:There are steps that you can take to slow down
an impending overheat condition. If your air conditioner
is on, turn it off. The air conditioning system adds heat to
the engine cooling system and turning off the A/C
removes this heat. You can also turn the Temperature
control to maximum heat, the Mode control to floor, and
the fan control to High. This allows the heater core to act
as a supplement to the radiator and aids in removing heat
from the engine cooling system.
CAUTION!
Driving with a hot cooling system could damage
your vehicle. If temperature gauge reads“H”, pull
over and stop the vehicle. Idle the vehicle with the
air conditioner turned off until the pointer drops
back into the normal range. If the pointer remains on
the“H”, turn the engine off immediately, and call for
service.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7, Maintenance, of this
manual. Follow the warnings under the Cooling
System Pressure Cap paragraph.
JACKING AND TIRE CHANGING
WARNING!
Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off
the road to avoid the danger of being hit when
operating the jack or changing the wheel.
WHAT TO DO IN EMERGENCIES 257
6

WARNING!
Getting under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never get any part of your body
under a vehicle that is on a jack. Never start or run
the engine while the vehicle is on a jack. If you need
to get under a raised vehicle, take it to a service
center where it can be raised on a lift.
Preparations For Jacking
•
Park the vehicle on a firm level surface, avoid ice or
slippery areas,set the parking brakeand place the
gear selector in PARK. Turn OFF the ignition.
•Turn on the Hazard Warning Flasher.
•Passengers should not remain in the vehicle when the
vehicle is being jacked.
•Block both the front and rear of the wheel diagonally
opposite the jacking position. For example, if changing
the right front tire, block the left rear wheel.
258 WHAT TO DO IN EMERGENCIES

Jack Location
The jack is stowed under an access cover under the rear
cargo floor. Follow these steps to access the jack.
NOTE:The spare tire must be removed in order to
access the jack.
•Open the liftgate.
•Fold up the tri-fold floor by lifting the handle.
Dodge Load Floor Fully Folded
WHAT TO DO IN EMERGENCIES 259
6

•Lift the access cover using the pull strap.•Remove the fastener securing the spare tire.
