WHAT TO DO IN EMERGENCIES
CONTENTS

Hazard Warning Flasher.................256

If Your Engine Overheats................256

Jacking And Tire Changing...............257
▫Preparations For Jacking................258
▫Jack Location........................259
▫Spare Tire Stowage....................261
▫Jacking And Changing a Tire.............263
▫Compact Spare Tire-For Temporary Emergency
Use Only...........................266
▫Wheel Cover Installation (If Required)......267

Jump-Starting Procedures If Battery Is Low...267

Driving On Slippery Surfaces.............269
▫Acceleration.........................269
▫Traction............................270

Freeing A Stuck Vehicle.................270

Towing A Disabled Vehicle...............271
▫With Ignition Key.....................271
▫Without The Ignition Key...............272
▫Towing This Vehicle Behind Another Vehicle
(Flat Towing With All Four Wheels On The
Ground)............................272
▫Towing This Vehicle Behind Another Vehicle
With A Tow Dolley....................272
6

HAZARD WARNING FLASHER
The hazard flasher switch is located in the center of the
instrument panel between the center air outlets.
To engage the Hazard Warning Flashers, depress the
switch on the instrument panel. When the Hazard Warn-
ing Switch is activated, all directional turn signals will
flash on and off to warn oncoming traffic of an emer-
gency. Push the switch a second time to turn off the
flashers.This is an emergency warning system and should not be
used when the vehicle is in motion. Use it when your
vehicle is disabled and is creating a safety hazard for
other motorists.
When you must leave the vehicle to seek assistance, the
Hazard Warning Flashers will continue to operate even
though the ignition switch is OFF.
NOTE:With extended use, the Hazard Warning Flash-
ers may wear down your battery.
IF YOUR ENGINE OVERHEATS
In any of the following situations, you can reduce the
potential for overheating by taking the appropriate ac-
tion.
•On the highways—Slow down.
•In city traffic—While stopped, put transmission in
neutral, but do not increase engine idle speed.
256 WHAT TO DO IN EMERGENCIES

NOTE:There are steps that you can take to slow down
an impending overheat condition. If your air conditioner
is on, turn it off. The air conditioning system adds heat to
the engine cooling system and turning off the A/C
removes this heat. You can also turn the Temperature
control to maximum heat, the Mode control to floor, and
the fan control to High. This allows the heater core to act
as a supplement to the radiator and aids in removing heat
from the engine cooling system.
CAUTION!
Driving with a hot cooling system could damage
your vehicle. If temperature gauge reads“H”, pull
over and stop the vehicle. Idle the vehicle with the
air conditioner turned off until the pointer drops
back into the normal range. If the pointer remains on
the“H”, turn the engine off immediately, and call for
service.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7, Maintenance, of this
manual. Follow the warnings under the Cooling
System Pressure Cap paragraph.
JACKING AND TIRE CHANGING
WARNING!
Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off
the road to avoid the danger of being hit when
operating the jack or changing the wheel.
WHAT TO DO IN EMERGENCIES 257
6

WARNING!
Getting under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never get any part of your body
under a vehicle that is on a jack. Never start or run
the engine while the vehicle is on a jack. If you need
to get under a raised vehicle, take it to a service
center where it can be raised on a lift.
Preparations For Jacking
•
Park the vehicle on a firm level surface, avoid ice or
slippery areas,set the parking brakeand place the
gear selector in PARK. Turn OFF the ignition.
•Turn on the Hazard Warning Flasher.
•Passengers should not remain in the vehicle when the
vehicle is being jacked.
•Block both the front and rear of the wheel diagonally
opposite the jacking position. For example, if changing
the right front tire, block the left rear wheel.
258 WHAT TO DO IN EMERGENCIES

WARNING!
•Do not attempt to push or tow your vehicle to get it
started. Vehicles equipped with an automatic trans-
mission cannot be started this way. Unburned fuel
could enter the catalytic converter and once the
engine has started, ignite and damage the converter
and vehicle. If the vehicle has a discharged battery,
booster cables may be used to obtain a start from
another vehicle. This type of start can be dangerous
if done improperly, so follow this procedure care-
fully.
•Battery fluid is a corrosive acid solution; do not
allow battery fluid to contact eyes, skin or clothing.
Don’t lean over battery when attaching clamps or
allow the clamps to touch each other. If acid splashes
in eyes or on skin, flush contaminated area immedi-
ately with large quantities of water.
•A battery generates hydrogen gas which is flam-
mable and explosive. Keep flame or spark away from
the vent holes. Do not use a booster battery or any
other booster source with an output that exceeds 12
volts.
•The battery in this vehicle has a vent hose that
should not be disconnected and should only be
replaced with a battery of the same type (vented).
NOTE:The battery is stored under an access cover
under the rear cargo floor. Remote battery terminals are
located in the engine compartment for jump starting.
1. Wear eye protection and remove any metal jewelry
such as watch bands or bracelets that might make an
inadvertent electrical contact.
2. When boost is provided by a battery in another
vehicle, park that vehicle within booster cable reach and
without letting the vehicles touch. Set the parking brake,
place the automatic transmission in PARK and turn the
ignition switch to the OFF (or LOCK) position for both
vehicles.
3. Turn off the heater, radio and all unnecessary electrical
loads.
4. Connect one end of the jumper cable to the remote
jump start positive battery post (A) in the engine com-
partment. Connect the other end of the same cable to the
positive terminal of the booster battery. Refer to the
following illustration for jump starting connections.
5. Connect the other cable, first to the negative terminal
of the booster battery andthen to the engine ground (B)
268 WHAT TO DO IN EMERGENCIES

of the vehicle with the discharged battery.Make sure
you have a good contact on the engine ground. Refer to
the following illustration for jump starting connections.
6. Start the engine in the vehicle which has the booster
battery, let the engine idle a few minutes, then start the
engine in the vehicle with the discharged battery.
7. When removing the jumper cables, reverse the above
sequence exactly. Be careful of the moving belts and fan.DRIVING ON SLIPPERY SURFACES
Acceleration
Rapid acceleration on snow covered, wet, or other slip-
pery surfaces may cause the wheels to pull erratically to
the right or left. This phenomenon occurs when there is a
difference in the surface traction under the rear (driving)
wheels.
WARNING!
Rapid acceleration on slippery surfaces is danger-
ous. Unequal traction can cause sudden pulling of
the rear wheels. You could lose control of the vehicle
and possibly have an accident. Accelerate slowly and
carefully whenever there is likely to be poor traction
(ice, snow, wet mud, loose sand, etc.).
Jump Starting
WHAT TO DO IN EMERGENCIES 269
6

WARNING!
Fast spinning tires can be dangerous. Forces gener-
ated by excessive wheel speeds may cause tire dam-
age or failure. A tire could explode and injure
someone. Do not spin your vehicle’s wheels faster
than 35 mph (55 km/h) when you are stuck. And
don’t let anyone near a spinning wheel, no matter
what the speed.
CAUTION!
Racing the engine or spinning the wheels too fast
may lead to transmission overheating and failure. It
can also damage the tires. Do not spin the wheels
above 35 mph (55 km/h).
TOWING A DISABLED VEHICLE
With Ignition Key
Your vehicle may be towed under the following condi-
tions: The gear selector must be in NEUTRAL, the
distance to be traveled must not exceed 30 miles (48 km),
and the towing speed must not exceed 30 mph (48
km/h). Exceeding these towing limits may cause a trans-
mission geartrain failure. If the transmission is not op-
erative, or if the vehicle is to be towed more than 30 miles
(48 km), the vehicle must be transported using a flat bed
or the drive shaft disconnected at the rear axle drive
flange.
WHAT TO DO IN EMERGENCIES 271
6

MAINTAINING YOUR VEHICLE
CONTENTS

2.7L Engine..........................275

3.5L Engine..........................276

5.7L Engine..........................277

Onboard Diagnostic System—OBD II......278

Emissions Inspection And Maintenance
Programs
............................279

Replacement Parts.....................280

Dealer Service........................280

Maintenance Procedures.................281
▫Engine Oil..........................281
▫Engine Oil Filter......................286▫Drive Belts—Check Condition And
Tensioner...........................286
▫Spark Plugs.........................287
▫Engine Air Cleaner Filter................287
▫Fuel Filter..........................287
▫Catalytic Converter....................287
▫Maintenance-Free Battery................289
▫Air Conditioner Maintenance.............290
▫A/C Air Filter.......................291
▫Power Steering—Fluid Check............292
▫Front & Rear Suspension Ball Joints........292
▫Steering Linkage......................292
7

▫Drive Shaft Universal Joints..............292
▫Body Lubrication.....................293
▫Windshield Wiper Blades................293
▫Windshield Washers...................293
▫Exhaust System......................294
▫Cooling System.......................295
▫Hoses And Vacuum/Vapor Harnesses.......298
▫Brakes.............................299
▫Brake Fluid Level Check................300
▫Fuel System Hoses....................301
▫Automatic Transmission................301
▫All Wheel Drive (AWD)—If Equipped.....302
▫Front And Rear Wheel Bearings...........303
▫Appearance Care And Protection From
Corrosion...........................303
▫Cleaning The Center Console Cup Holders . . . 306
Power Distribution Centers...............307
▫Front Power Distribution Center...........307
▫Rear Power Distribution Center...........309

Vehicle Storage........................313

Replacement Light Bulbs................313

Bulb Replacement......................314
▫Low Beam Headlamp, High Beam Headlamp,
And Park/Turn Lamp..................314
▫Tail/Stop, Turn Signal Lamp, And Backup
Lamp..............................315
▫License Lamp........................318

Fluids And Capacities...................319

Recommended Fluids, Lubricants And Genuine
Parts
...............................320
▫Engine.............................320
▫Chassis............................321
274 MAINTAINING YOUR VEHICLE

2.7L ENGINE
MAINTAINING YOUR VEHICLE 275
7
