Page 301 of 400
MAINTAINING YOUR VEHICLE
CONTENTS
2.7L Engine Compartment...............303
3.5L Engine Compartment...............304
5.7L Engine Compartment...............305
Onboard Diagnostic System — OBD II......306
▫Loose Fuel Filler Cap..................306
Emissions Inspection And Maintenance
Programs
............................307
Replacement Parts.....................308
Dealer Service........................308
Maintenance Procedures.................309
▫Engine Oil..........................309
▫Engine Oil Filter......................314▫Drive Belts — Check Condition And Tension . . 314
▫Spark Plugs.........................314
▫Engine Air Cleaner Filter................314
▫Fuel Filter..........................315
▫Catalytic Converter....................315
▫Maintenance-Free Battery................316
▫Air Conditioner Maintenance.............318
▫A/C Air Filter — If Equipped............319
▫Power Steering — Fluid Check............319
▫Front & Rear Suspension Ball Joints........320
▫Steering Linkage......................320
7
Page 315 of 400
WARNING!
The air induction system (air cleaner, hoses, etc) can
provide a measure of protection in the case of engine
backfire. Do not remove the air induction system (air
cleaner, hoses, etc) unless such removal is necessary
for repair or maintenance. Make sure that no one is
near the engine compartment before starting the
vehicle with the air induction system (air cleaner,
hoses, etc) removed. Failure to do so can result in
serious personal injury.
Fuel Filter
A plugged fuel filter can cause stalling, limit the speed at
which a vehicle can be driven or cause hard starting.
Should an excessive amount of dirt accumulate in the
fuel tank, filter replacement may be necessary. See your
local dealer for service.
Catalytic Converter
The catalytic converter requires the use of unleaded fuel
only. Leaded gasoline will destroy the effectiveness of the
catalyst as an emission control device.
Under normal operating conditions, the catalytic con-
verter will not require maintenance. However, it is im-
portant to keep the engine properly tuned to assure
proper catalyst operation and prevent possible catalyst
damage.
CAUTION!
Damage to the catalytic converter can result if your
vehicle is not kept in proper operating condition. In
the event of engine malfunction, particularly involv-
ing engine misfire or other apparent loss of perfor-
mance, have your vehicle serviced promptly. Contin-
ued operation of your vehicle with a severe
malfunction could cause the converter to overheat,
resulting in possible damage to the converter and the
vehicle.
MAINTAINING YOUR VEHICLE 315
7
Page 350 of 400
FLUIDS AND CAPACITIES
U.S. Metric
Fuel (approximate)
2.7 Liter Engine 18 gallons 68 liters
3.5 Liter Engine without All Wheel Drive 18 gallons 68 liters
3.5 Liter Engine with All Wheel Drive 19 gallons 72 liters
5.7 Liter Engine 19 gallons 72 liters
Engine Oil-With Filter
2.7 Liter Engine (SAE 5W-20, API Certified) 6.0 qts. 5.7 liters
3.5 Liter Engine (SAE 10W-30, API Certified) 6.0 qts. 5.7 liters
5.7 Liter Engine (SAE 5W-20, API Certified) 7.0 qts. 6.6 liters
Cooling System *
2.7 Liter Engine (MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula)
or equivalent.9.9 qts 9.4 liters
3.5 Liter Engine without All Wheel Drive (MoparAntifreeze/Coolant 5
Year/100,000 Mile Formula) or equivalent.11.1 qts 10.5 liters
3.5 Liter Engine with All Wheel Drive (MoparAntifreeze/Coolant 5 Year/
100,000 Mile Formula) or equivalent.11.4 qts 10.8 liters
5.7 Liter Engine without Severe Duty II Cooling System (Mopar
Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent.14.7 qts 13.9 liters
5.7 Liter Engine with Severe Duty II Cooling System (MoparAntifreeze/
Coolant 5 Year/100,000 Mile Formula) or equivalent.15.1 qts 14.3 liters
* Includes heater and coolant recovery bottle filled to MAX level.
350 MAINTAINING YOUR VEHICLE
Page 351 of 400
FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
Component Fluids, Lubricants, and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent
Engine Oil (2.7 Liter) Use API Certified engine oil. SAE 5W-20 is recommended. Refer to the en-
gine oil fill cap for the correct SAE grade meeting DaimlerChrysler Material
Standard MS-6395.
Engine Oil (3.5 Liter) Use API Certified engine oil. SAE 10W-30 is recommended. Refer to the en-
gine oil viscosity chart for the correct SAE grade meeting DaimlerChrysler
Material Standard MS-6395.
Engine Oil (5.7 Liter) Use API Certified engine oil. SAE 5W-20 is recommended. Refer to the en-
gine oil fill cap for the correct SAE grade meeting DaimlerChrysler Material
Standard MS-6395.
Oil Filter (2.7 Liter) Mopar05281090 or equivalent.
Oil Filter (3.5 Liter) Mopar05281090 or equivalent.
Oil Filter (5.7 Liter) Mopar05281090 or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection (2.7 Liter) 87 Octane
Fuel Selection (3.5 Liter) 87 to 89 Octane
Fuel Selection (5.7 Liter) 87 to 89 Octane
MAINTAINING YOUR VEHICLE 351
7
Page 382 of 400
ABS (Anti-Lock Brake System)............. 226
Adding Engine Coolant (Antifreeze)......... 323
Adding Fuel.......................... 265
Adding Rear Washer Fluid................ 202
Adding Washer Fluid..............103,202,321
Adjustable Pedals....................... 105
Air Cleaner, Engine (Engine Air Cleaner Filter) . 314
Air Conditioner Maintenance.............. 318
Air Conditioning....................191,193
Air Conditioning Controls................ 191
Air Conditioning Filter................199,319
Air Conditioning, Operating Tips........... 200
Air Conditioning Refrigerant...........318,319
Air Conditioning System...........191,193,318
Air Pressure, Tires...................145,245
Airbag................................ 41
Airbag Deployment.................... 46,47
Airbag Light.................... 46,49,61,142
Airbag Maintenance...................... 49
Airbag, Side........................... 47
Airbag, Window (Side Curtain)........... 42,47
Alarm (Security Alarm).................. 145
Alarm System (Security Alarm)............. 15Alignment and Balance.................. 251
All Wheel Drive (AWD)...............223,331
Alterations/Modifications, Vehicle............ 7
Antenna, Satellite Radio.................. 187
Antifreeze (Engine Coolant)............323,350
Disposal............................ 325
Anti-Lock Brake System (ABS)............. 226
Anti-Lock Warning Light..............147,228
Anti-Theft Security Alarm (Theft Alarm)...... 15
Anti-Theft System...................... 145
Appearance Care....................... 332
Auto Down Power Windows............... 28
Auto Up Power Windows................. 28
AutomaticDimmingMirror ................ 67
Automatic Door Locks.................. 24,25
Automatic Headlights.................... 96
Automatic Temperature Control (ATC)....... 193
Automatic Transaxle
Special Additives..................... 331
Automatic Transmission............214,219,330
Adding Fluid.....................330,352
Autostick ........................... 223
Fluid and Filter Changes................ 330
382 INDEX
Page 386 of 400
Flooded, Starting..................... 209
Fuel Requirements.................261,350
Oil ..........................309,350,351
Oil Change Interval................... 311
Oil Filler Cap........................ 312
OilSelection ...................... 311,350
Oil Synthetic......................... 313
Overheating......................... 284
Temperature Gauge................... 141
Enhanced Accident Response Feature......... 48
Ethanol.............................. 262
Event Data Recorder..................... 49
Exhaust Gas Caution............. 32,60,264,321
Exhaust System...................... 60,321
ExteriorFoldingMirrors .................. 68
ExteriorLighting ........................ 96
Filters
Air Cleaner.......................... 314
Air Conditioning..................199,319
Engine Fuel......................... 315
Engine Oil.......................314,351
Engine Oil Disposal................... 313Flashers
Hazard Warning...................... 284
Turn Signal........................ 99,142
Flash-To-Pass........................... 99
Flat Tire Changing...................... 286
Flooded Engine Starting.................. 209
Floor Console.......................... 122
Fluid Capacities........................ 350
Fluid Leaks............................ 62
Fluid Level Checks
Brake .............................. 329
Cooling System....................... 322
Engine Oil.......................309,310
Power Steering....................... 319
Fluids ............................... 351
Fluids, Lubricants and Genuine Parts........ 351
FogLights .......................... 98,144
Folding Rear Seat....................... 94
FreeingAStuckVehicle .................. 297
Front Suspension Ball Joints............... 320
Front Wheel Bearings.................... 332
Fuel................................. 261
Adding............................. 265
386 INDEX
Page 387 of 400
CleanAir ........................... 262
Ethanol............................. 262
Filler Cap (Gas Cap)................... 265
Filter.............................. 315
Gasoline............................ 261
Gauge............................. 140
Hoses.............................. 327
Methanol........................... 262
OctaneRating .....................261,351
Requirements.....................261,350
Tank Capacity........................ 350
Fuel System Caution.................... 266
Fueling .............................. 265
Fuses................................ 337
Garage Door Opener (HomeLink) .......... 110
Gas Cap (Fuel Filler Cap)..............265,306
Gasoline, Clean Air..................... 262
Gasoline (Fuel)........................ 261
Gasoline, Reformulated.................. 262
Gauges
Coolant Temperature.................. 141
Fuel............................... 140Speedometer......................... 140
Tachometer.......................... 140
Gear Ranges.......................... 215
General Information................. 15,22,261
Glass Cleaning......................... 335
GrossAxleWeightRating ..............268,270
GrossVehicleWeightRating ............268,270
GVWR............................... 268
Hands-Free Phone (UConnect™)............ 70
Hazard Warning Flasher.................. 284
Head Restraints......................... 92
Headlights
Cleaning............................ 335
High Beam........................... 99
High Beam/Low Beam Select Switch....... 99
Lights On Reminder.................... 98
On With Wipers.................... 97,103
Passing............................. 99
Switch .............................. 96
TimeDelay ........................... 97
Heated Seats........................... 92
Heater............................... 191
INDEX 387
