FUSES (POWER DISTRIBUTION CENTERS)
Fuses (Front Power Distribution Center)
A power distribution center is located in the engine
compartment. This center contains fuses and relays.
Cavity Car-
tridge
FuseMini
FuseDescription
1 Ð 15 Amp
BlueWasher Motor
2 Ð 25 Amp
NeutralPowertrain Control
Module (PCM)
3 Ð 25 Amp
NeutralIgnition Run/Start
4 Ð 25 Amp
NeutralAlternator/EGR Sole-
noid
5ÐÐÐ
6 Ð 25 Amp
NeutralIgnition Coils/Injectors/
Short Runner Valve
7ÐÐÐ
8 Ð 25 Amp
NeutralStarter
9ÐÐÐ
Front Power Distribution Center
MAINTAINING YOUR VEHICLE 421
7

CAUTION!
²When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribution
Center, and possibly result in an electrical system
failure.
²When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
Fuses (Rear Power Distribution Center)
There is also a power distribution center located under a
hinged access cover in the load floor in the cargo area.
This center contains fuses and relays.
Opening The Access Panel
