MIRRORS
Inside Day/Night Mirror
Adjust the mirror to center on the view through the rear
window. A two point pivot system allows for horizontal
and vertical mirror adjustment.
Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position
(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).
Inside Compass/Temperature MirrorÐIf Equipped
Adjust the mirror to center the view through the rear
window. A two point pivot system allows for horizontal
and vertical mirror adjustments.
Annoying headlight glare can be reduced by rotating the
small knob under the mirror in the clockwise direction,
so the knob points to the right (night position). The
mirror should be adjusted while set in the day position
(knob points towards rear of vehicle.)
Adjusting Rear View MirrorAdjusting Rear View Mirror
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 51
3

Lights
²
Briefly press the ªRightº button to toggle the right
reading lamp ªON/OFFº. Repeat the key press to
cycle the light
²Briefly press the ªLeftº button to toggle the left
reading lamp ªON/OFFº. Repeat the key press to
cycle the light.
NOTE:The light can be activated with the ignition off.
NOTE:The light(s) will automatically shut off after
seven minutes with ignition off.
Temperature
Press and hold the ªRightº button for 5±10 seconds (until
ÉF/ÉC toggles in the display) then release the button.
Repeat the key press to cycle the ÉF/ÉC in the display.Display ON/OFF
Press and hold the ªRightº button for 10±15 seconds
(until display toggles ON/OFF) then release the button.
Repeat the key press to cycle the display ON/OFF.
NOTE:The display will default ªONº at each new
ignition cycle.
Automatic Dimming Mirror
52 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Compass Variance
²
Find your current location and determine the correct
Zone number from the map.
²Press and hold the ªLeftº button for 5±10 seconds
(until ªZoneº appears in the display), then release the
button. The number displayed is the current Zone
value.
²If a new Zone value is desired, briefly press the ªLeftº
button to increment the displayed value, (Range 1±15)
until you find your desired Zone number.
²No button activity for 4±5 seconds ends the Zone entry
mode. The display will return to normal operation and
the new Zone number will be set.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 53
3

Compass Calibration
If ªCALº is not displayed, press and hold the ªLeftº
button for 10±15 seconds, or until ªCALº appears in the
display, then release the button. The compass is now in
calibration mode.
The mirror can be calibrated in one of two ways
²
Drive the vehicle in circles at less then 5 mph (8 km/h)
until ªCALº no longer appears in the display.
²Drive the vehicle under normal operating conditions.
Outside Mirror Ð Driver's Side
Adjust the outside mirror to center on the adjacent lane of
traffic, with a slight overlap of the view obtained on the
inside mirror.
Outside Mirror Ð Passenger's Side
Adjust the convex outside mirror so you can just see the
side of your vehicle in the part of the mirror closest to the
vehicle.
WARNING!
Vehicles and other objects seen in the passenger side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger side mirror could cause you to collide
with another vehicle or other object. Use your inside
mirror when judging the size or distance of a vehicle
seen in this convex mirror.
54 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Electric Remote-Control Mirrors Ð If Equipped
Use the mirror select switch, located on the drivers door
trim panel, to adjust the view obtained in the outside
mirrors. Press the rocker knob to the L or R for Left or
Right mirror selection. Use the center off position to
guard against accidentally moving a mirror position.
Select a mirror and press one of the four arrows for the
direction you want the mirror to move.
SEATS
Front Seat Adjustment
The adjusting bar is at the front of the seats, near the
floor. Pull the bar up to move the seat to the desired
position.
Using body pressure, move forward and rearward on the
seat to be sure the seat adjusters have latched after the
adjustment bar is released.
Power Mirror Switches
Manual Front Seat Adjuster
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 55
3

WARNING!
²Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat
could cause you to lose control. The seat belt
might not be properly adjusted and you could be
injured. Adjust the seat only while the vehicle is
parked.
²Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your
chest. In a collision you could slide under the seat
belt and be seriously or even fatally injured. Use
the recliner only when the vehicle is parked.
Reclining Bucket Seats
The recliner control is on the side of the seat. To recline,
lean forward slightly before lifting the lever, then lean
back to the desired position and release the lever. Lean
forward and lift the lever to return the seatback to its
normal position.
Manual Recline Handle
56 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Adjustable Head Restraints
Head restraints can reduce the risk of whiplash injury in
the event of impact from the rear. Pull up or push down
on the restraints so that the upper edge is as high as
practical. Push in on the release button to lower the head
restraint.
Folding Rear Seat
To provide additional storage area, the center of each rear
seatback can be folded forward. Pull on the loops shown
in the picture to fold down either or both seatbacks.
Adjustable Head Restraint
Folding Rear Seat
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 57
3

WARNING!
²It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to be
seriously injured or killed.
²Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat-
belts
²Be sure that everyone in your vehicle is in a seat
and using a seatbelt properly.
TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
the hood release lever located under the driver's side of
the instrument panel.
Hood Release Lever
58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Then lift the safety catch located under the front edge of
the hood, near the center and raise the hood.
Use the hood prop rod to secure the hood in the open
position as shown. To prevent possible damage, do not
slam the hood to close it. Use a firm downward push at
the center of the hood to ensure that both latches engage.
WARNING!
If the hood is not fully latched it could fly up when
the vehicle is moving and block your forward vision.
You could have a collision. Be sure all hood latches
are fully latched before driving.
Hood Safety Catch
Hood Prop Rod
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 59
3

LIGHTS
Front Map/Reading Lights Ð If Equipped
These lights, located under the rearview mirror, can be
turned on by means of switches located at the base of the
rearview mirror.
NOTE:The map lights will remain on when the ignition
switch is in the Run or Accessory positions.
Interior Lights
The interior lights come on when a door is opened.
The interior lights will automatically turn off in about 8
minutes if a door is left open or the dimmer control is left
in the Dome light position. Turn the ignition switch ON
to restore the interior light operation.
Dimmer Control
With the park lights or headlights
on, rotating the dimmer control
for the interior lights on the Multi-
Function Control Lever upward
will increase the brightness of the
instrument panel lights.
Front Map/Reading Lights
