keyless entry DODGE NEON 2005 2.G Owners Manual

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
mA Word About Your Keys................. 9
NIgnition Key Removal................... 9
NLocking Doors With The Key..............10
NKey-In-Ignition Reminder................11
mSentry Key............................11
NReplacement Keys......................12
NSentry Key Programming.................12
NGeneral Information....................13
mSteering Wheel Lock Ð If Equipped.........13
NTo Manually Lock The Steering Wheel.......13
NTo Release The Steering Wheel Lock.........13NAutomatic Transaxle Ignition Interlock System . .14
mDoor Locks...........................14
NManual Door Locks.....................14
NPower Door Locks Ð If Equipped..........15
NCentral Locking/Unlocking Ð If Equipped....15
NAutomatic Door Locks Ð If Equipped.......16
N
Child-Protection Door Lock System (Rear Doors).17
mInternal Emergency Trunk Lid Release.......18
mRemote Trunk Lid Release Ð If Equipped.....18
mRemote Keyless Entry Ð If Equipped........19
NTo Unlock The Doors...................19
2

REMOTE KEYLESS ENTRY Ð IF EQUIPPED
This system allows you to lock or unlock the doors and
trunk or activate the panic alarm from distances up to
about 23 feet (7 meters) using a hand held transmitter.
NOTE:A slight delay of up to two seconds can occur
before the doors or trunk will unlock.
To Unlock the Doors
Press and release the UNLOCK button once to unlock the
driver's door. Press the button twice within 5 seconds to
unlock all doors. The interior lights also come on and
remain on for about 30 seconds when you unlock the
doors.
NOTE:You may turn off this feature and unlock all
doors with one press of the button by following the
procedure shown in the Central Locking/Unlocking
paragraph.
To Lock the Doors
Press and release the LOCK button to lock all doors. The
park/lamps will flash and the horn will chirp to ac-
knowledge the signal.
Horn Chirp Feature
The horn chirp that signals that the doors have been
locked can be toggled on or off by using the following
procedure:
1. Insert the ignition key and turn the switch to the
ON/RUN position.
2. Press and hold the UNLOCK button on the transmitter
for 4 to 10 seconds.
3. Continue to hold the UNLOCK button and press the
LOCK button.
4. Release both buttons.Four Button Transmitter
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
2

3. To reassemble the transmitter case, snap two halves
together. Make sure there is an even gap between the two
halves. Test transmitter operation.
VEHICLE THEFT ALARM Ð IF EQUIPPED
The system monitors the doors, trunk key cylinder(Fleet
Vehicles Only), trunk latch(Regular Production Ve-
hicles Only), and ignition for unauthorized operation.
If something triggers the alarm, the system will signal for
about 18 minutes. For the first 3 minutes the horn will
sound and the headlights, park/turn signal lights, tail
lights and the indicator light in the cluster will flash.
Then the exterior lights will flash for another 15 minutes.
If the monitored system which triggered the alarm is
deactivated, the alarm will continue to sound until 3
minutes of alarm time is reached. If the monitored system
which triggered the alarm is deactivated after the alarm
has been on for 3 minutes, the alarm will shut off
immediately.
To set the alarm:
1. Remove the keys from the ignition switch and get out
of the vehicle.
2. Lock the door using either the door key, power door
lock switch, or the Keyless Entry Transmitter and close all
doors.
3. The indicator light in the instrument cluster will flash
rapidly for 16 seconds. This shows that the system is
arming. During this period, if a door is opened, the
ignition switch is turned on, or the power door locks are
unlocked in any manner, the system will automatically
disarm. If the light comes on but does not flash, the
system is arming but there is a problem in the trunk
circuit. After 16 seconds the indicator light will flash
slowly. This shows that the system is fully armed.
Vehicles equipped with the Sentry Key Immobilizer
System can be safely started with a valid key. A valid key
is one that is programmed to that particular vehicle. A
valid key will disarm the system, an invalid key will
trigger the alarm.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:With the system armed on vehicles built for
Fleet Service, the trunk can be opened with the key
without sounding the Theft Alarm. With the system
armed onRegular Production Vehicles, opening the
trunk with the key will cause the Theft Alarm to sound.
To disarm the system:
Unlock a front door using either the key or the Keyless
Entry Transmitter.
Starting the vehicle with a valid Sentry key will disarm
the system.
Tamper Alert
If the horn sounds 3 times when you unlock a front door
using either a key or the Keyless Entry Transmitter, the
alarm has been activated. Check the vehicle for tamper-
ing.
Security System Manual Override
The system will not arm if you lock the doors using the
manual lock control.
POWER WINDOWS Ð IF EQUIPPED
The window switches on the driver's door panel control
both front windows. The switch on the passenger's door
panel controls the passenger's window.
Power Window Switches
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
2

Interior Fuses.......................... 197
Interior Lights.......................... 60
Intermittent Wipers...................... 64
Introduction............................ 4
Jack Operation......................... 152
Jacking Instructions..................... 152
Jump Starting......................... 155
Key, Programming....................... 12
Key Release Button...................... 10
Key, Replacement....................... 12
Key, Sentry............................ 11
Key-In Reminder........................ 11
Keyless Entry System..................... 19
Keys.................................. 9
Lane Change and Turn Signals.............. 78
Lap/Shoulder Belts...................... 24
LATCH
(Lower Anchors and Tether for CHildren)..... 42
Lead Free Gasoline...................... 141
Leaks, Fluid............................ 47Light Bulbs........................198,199
Lighter, Cigar.......................... 70
Lights................................ 60
Airbag..........................39,47,79
Anti-Lock............................ 77
Brake Warning........................ 77
Center Mounted Stop.................. 201
Daytime Running...................... 62
Dimmer Switch, Headlight.............61,62
Dome............................... 61
Exterior Check........................ 47
Fog ..............................62,77
Headlights On Reminder................ 62
High Beam Indicator................... 78
Instrument Cluster..................... 61
Interior.............................. 60
Lights On Reminder.................... 62
Low Fuel............................ 79
Malfunction Indicator................... 80
Map Reading......................... 60
Oil Pressure.......................... 78
Park................................ 61
Passing............................. 62
INDEX 239
10

Rear Window Defroster.................. 110
Reclining Front Seats..................... 56
Recommended Fluids, Lubricants and Genuine
Parts............................... 203
Recreational Towing..................... 148
Reformulated Gasoline................... 142
Refrigerant............................ 177
Release, Hood.......................... 58
Remote Keyless Entry.................... 19
Remote Trunk Release.................... 18
Replacement Bulbs...................... 198
Replacement Keys....................... 12
Replacement Parts...................... 168
Replacement Tires...................... 138
Reporting Safety Defects................. 229
Rotation, Tires......................... 141
Safety Checks Inside Vehicle............... 47
Safety Checks Outside Vehicle.............. 47
Safety Defects, Reporting................. 229
Safety Information, Tire.................. 124
Safety Tips............................. 46
Satellite Radio.......................... 93Satellite Radio Antenna................... 96
Seat Belts.............................. 24
Adjustable Upper Shoulder Anchorage...... 28
And Pregnant Women.................. 30
Child Restraint........................ 39
Extender............................ 31
Front Seat............................ 24
Maintenance......................... 195
Rear Seat............................ 24
Untwisting Procedure................... 29
Seats................................. 55
Adjustment.......................... 55
Head Restraints....................... 57
Rear Folding......................... 57
Reclining............................ 56
Security Alarm (Theft Alarm).............22,79
Sentry Key.......................... 11,22
Sentry Key Programming.................. 12
Service Assistance...................... 224
Service Contract........................ 226
Service Manuals........................ 229
Setting the Clock........................ 82
Shift Speeds........................... 120
242 INDEX
