odometer DODGE NEON SRT 2004 2.G Owners Manual

Interior Lights
The interior lights come on when a door is opened.
The interior lights will automatically turn off in about 8
minutes if a door is left open or the dimmer control is left
in the Dome light position. Turn the ignition switch ON
to restore the interior light operation.
Dimmer Control
With the park lights or headlights
on, rotating the dimmer control
for the interior lights on the Multi-
Function Control Lever upward
will increase the brightness of the
instrument panel lights.
Dome Light Position
Rotate the dimmer control com-
pletely upward to the second de-
tent to turn on the interior lights.
The interior lights will remain on
when the dimmer control is in this
position.
Daytime Brightness Feature
Certain instrument panel components can be illuminated
at full brightness during the daytime. These are the
Odometer and Radio. This can be helpful when driving
with your headlights on during the daytime such as in a
parade or a funeral procession. To activate this feature,
rotate the dimmer ring on the left stalk one detent lower
than the dome light.
Multi-Function Control Lever
The Multi-Function Control Lever controls the operation
of the headlights, parking lights, turn signals, headlight
beam selection, instrument panel light dimming, interior
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 53
3

16. Malfunction Indicator Light
This light is part of an onboard diagnostic
system called OBD that monitors engine con-
trol systems. The light will illuminate briefly
when the key is in the ON/RUN position before
engine start. If the bulb does not come on when
turning the key from OFF to ON/RUN, have the
condition checked promptly.
Certain conditions such as a loose or missing gas cap,
poor fuel quality, etc., may illuminate the light after
engine start. The vehicle should be serviced if the light
stays on through several of your typical driving cycles. In
most situations, the vehicle will drive normally and will
not require towing.
If the Malfunction Indicator Light flashes when the
engine is running, serious conditions may exist that
could lead to immediate loss of power or severe catalytic
converter damage. The vehicle should be serviced as
soon as possible if this occurs.
17. Odometer/Trip Odometer Reset Knob
Press this knob to switch between the odometer and trip
odometer. While the trip odometer is being displayed,
press and hold this knob for a few seconds to reset the
trip odometer to zero miles/kilometers.
18. Odometer/Trip Odometer
Shows the total distance the vehicle has been driven.
U.S. Federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading changes during repair or
replacement, be sure to keep a record of the reading
before and after the service so the correct mileage can be
determined.
19. Door Ajar Indicator
This vacuum fluorescent indicator illuminates when a
door is not completely closed. If the door is open for more
than 8 minutes and the ignition key is in the OFF
position, the indicator will turn off.
66 UNDERSTANDING YOUR INSTRUMENT PANEL

20. Trip Indicator
This light will illuminate when the Trip Odometer is in
use.
21. Temperature Gauge
The temperature gauge shows engine coolant
temperature.
Normal operating range should be
within one notch above or one notch
below the 200 degree mark. The
gauge pointer may show a higher
than normal temperature when driv-
ing in hot weather, up mountain
grades, or in heavy stop and go
traffic.
If the pointer rises to theH(red) mark, the instrument
cluster will sound a chime. Pull off to the side of the road
at a safe area. With the vehicle in Park (automatic
transmission), or with the vehicle in neutral and the
emergrncy brake applied (manual transmission), idle the
vehicle with the air conditioner turned off until thepointer drops back into the normal range. If the pointer
remains on the H (red) mark, turn the engine off imme-
diately and call for service.
There are steps that you can take to slow down an
impending overheat condition. If your air conditioning is
on, turn it off. The air conditioning system adds heat to
the engine cooling system and turning off the A/C
removes this heat. You can also turn the Temperature
control to maximum heat, the Mode control to Floor and
the Fan control to High. This allows the heater core to act
as a supplement to the radiator and aids in removing heat
from the engine cooling system.
UNDERSTANDING YOUR INSTRUMENT PANEL 67
4

WARNING!
²Do not use a tire, wheel size or rating other than
that specified for your vehicle. Some combina-
tions of unapproved tires and wheels may change
suspension dimensions and performance charac-
teristics, resulting in changes to steering, han-
dling, and braking of your vehicle. This can cause
unpredictable handling and stress to steering and
suspension components. You could lose control
and have an accident resulting in serious injury or
death. Use only the tire and wheel sizes with load
ratings approved for your vehicle.
²Never use a tire with a smaller load index or
capacity, other than what was originally equipped
on your vehicle. Using a tire with a smaller load
index could result in tire overloading and failure.
You could lose control and have an accident.
²Failure to equip your vehicle with tires having
adequate speed capability can result in sudden
tire failure and loss of vehicle control.
CAUTION!
Replacing original tires with tires of a different size
may result in false speedometer and odometer read-
ings.
Alignment And Balance
Poor suspension alignment may result in:
²fast tire wear;
²uneven tire wear, such as feathering and one-sided
wear;
²vehicle pull to right or left.
Tires may also cause the vehicle to pull to the left or right.
Alignment will not correct this condition. See your dealer
for proper diagnosis.
Improper alignment will not cause vehicle vibration.
Vibration may be a result of tire and wheel out-of-
balance. Proper balancing will reduce vibration and
avoid tire cupping and spotty wear.
110 STARTING AND OPERATING

Maintenance Procedures.................. 136
Maintenance Schedule
Schedule9A9......................... 178
Schedule9B9......................... 171
Maintenance Schedules.................. 168
Malfunction Indicator Light.............66,134
Manual, Service........................ 188
Manual Transaxle..................87,90,155
Fluid Level Check..................... 155
Frequency of Fluid Change.............. 155
Lubricant Selection.................... 155
Master Cylinder........................ 154
Mirrors............................... 47
Electric Remote....................... 48
Outside............................. 47
Rearview............................ 47
Modifications/Alterations, Vehicle............ 6
Mopar Parts........................136,187
Multi-Function Control Lever.............53,55
Occupant Restraints...................... 19
Odometer
Trip ................................ 66Oil, Engine........................... 137
Change Interval...................... 138
Checking........................... 137
Disposal............................ 140
Filter.............................. 140
Identification Logo.................... 139
Materials Added to.................... 139
Quality............................. 139
Recommendation..................... 138
Synthetic........................... 139
Oil Pressure Light....................... 64
Onboard Diagnostic System............... 134
Operator Manuals........................ 4
Outside Air Intake....................... 82
Overheating, Engine..................... 120
Owner's Manual......................4,188
Paint Care............................ 155
Panic Alarm........................... 17
Parking Brake.......................... 92
Passing Light........................... 55
Pets.................................. 42
Placard, Tire and Loading Information....... 100
INDEX 197
10

Sizes............................... 97
Snow Tires.......................... 111
Spinning............................ 108
Tread Wear Indicators.................. 109
Towing
Disabled Vehicle...................... 130
Transaxle
Manual...........................87,90
Transmitter Battery Service................ 18
Transporting Pets........................ 42
Tread Wear Indicators................... 109
Trip Odometer Reset Button................ 66
Trunk Release Button..................... 15
Trunk Release, Emergency................. 15
Trunk Release Remote Control.............. 15
Turbo Boost Gauge....................83,113
Turbo Cool Down....................... 89
Turn Signals.........................55,64
Underhood Fuses....................... 160
Uniform Tire Quality Grades.............. 189Vacuum/Vapor Harnesses................ 152
Vehicle Identification Number............... 6
Vehicle Loading........................ 117
Vehicle Modifications/Alterations............ 6
Vehicle Storage......................... 161
Warnings and Cautions.................... 6
Warranty Information.................... 186
Washers, Windshield..................... 55
Washing Vehicle........................ 156
Wheel Alignment and Balance............. 110
Wheel and Wheel Trim Care............... 157
Window Fogging........................ 82
Windows
Power.............................. 19
Windshield Washer Aiming............... 146
Windshield Washers..................... 55
Windshield Wiper Blades................. 146
Windshield Wipers...................... 55
Wiper Blade Replacement................. 146
Wipers, Intermittent...................... 56
Wiring, Ignition........................ 142
200 INDEX
