MAINTAINING YOUR VEHICLE
CONTENTS

2.4L Turbo Charged Engine Compartment....141

Onboard Diagnostic System—OBD II......142

Emissions Inspection And Maintenance
Programs
............................143

Replacement Parts.....................144

Dealer Service........................144

Maintenance Procedures.................145
▫Engine Oil..........................145
▫Ignition Wiring System.................151
▫Crankcase Emission Control System........151
▫Fuel Filter..........................151
▫Air Cleaner Element (Filter)..............151▫Maintenance-Free Battery................152
▫Air Conditioner Maintenance.............153
▫Power Steering Fluid Check..............154
▫Front Suspension Ball Joints..............154
▫Body Lubrication.....................155
▫Windshield Wiper Blades................155
▫Windshield Wiper Blade Replacement.......156
▫Windshield Washer Aiming..............156
▫Windshield Washer Reservoir.............156
▫Exhaust System......................156
▫Cooling System.......................157
7

Engine Oil Filter
The engine oil filter should be replaced at every engine
oil change.
Engine Oil Filter Selection
All of this manufacturers engines have a full-flow type
disposable oil filter. Use a filter of this type for replace-
ment. The quality of replacement filters varies consider-
ably. Only high quality filters should be used to assure
most efficient service. Mopar Engine Oil Filters are high
quality oil filters and are recommended.
Drive Belts—Check Condition and Tension
At the mileage shown in the maintenance schedules,
check all drive belts for condition and proper tension.
Improper belt tension can cause belt slippage and failure.
Inspect the drive belts for evidence of cuts, cracks, or
glazing and replace them if there is any sign of damage
which could result in belt failure. If adjustment is re-
quired, adjust the belts according to the specifications
and procedures shown in the Service Manual.
Special tools are required to properly measure tension
and to restore belt tension to factory specifications. Also,check belt routing to make sure there is no interference
between the belts and other engine components.
Spark Plugs
Spark plugs must fire properly to assure engine perfor-
mance and emission control. New plugs should be in-
stalled at the specified mileage. The entire set should be
replaced if there is any malfunction due to a faulty spark
plug. Refer to the Vehicle Emission Control Information
(VECI) label, for proper type of spark plug for use in your
vehicle.
Catalytic Converter
The catalytic converter requires the use of unleaded fuel
only. Leaded gasoline will destroy the effectiveness of the
catalyst as an emission control device.
Under normal operating conditions, the catalytic con-
verter will not require maintenance. However, it is im-
portant to keep the engine properly tuned to assure
proper catalyst operation and prevent possible catalyst
damage.
MAINTAINING YOUR VEHICLE 149
7

Ignition Wiring System
The ignition cables should be kept clean and properly
connected. Terminals should be fully seated. Cracked,
damaged, or faulty cables should be replaced.
Crankcase Emission Control System
Proper operation of this system depends on freedom
from sticking or plugging due to deposits. As vehicle
mileage builds up, the PCV valve and passages may
accumulate deposits. If a valve is not working properly,
replace it with a new valve. DO NOT ATTEMPT TO
CLEAN THE OLD PCV VALVE!
Check ventilation hose for indication of damage or
plugging deposits. Replace if necessary.
Fuel Filter
A plugged fuel filter can cause hard starting or limit the
speed at which a vehicle can be driven. Should an
excessive amount of dirt accumulate in the fuel tank,
frequent filter replacement may be necessary.
Air Cleaner Element (Filter)
Under normal driving conditions, replace the filter at the
intervals shown on Schedule“A”. If, however, you drive
the vehicle frequently under dusty or severe conditions, the
filter element should be inspected periodically and re-
placed if necessary at the intervals shown on Schedule“B”.
NOTE:For vehicles with a Turbo engine, a small
amount of oil accumulation in the air cleaner box is
normal. The amount will depend on driving style. The air
cleaner box should be cleaned out and a new make-up-
air filter element should be installed during the normal
air filter maintenance procedure.
WARNING!
The air cleaner can provide a measure of protection
in the case of engine backfire. Do not remove the air
cleaner unless such removal is necessary for repair or
maintenance. Make sure that no one is near the
engine compartment before starting the vehicle with
the air cleaner removed. Failure to do so can result in
serious personal injury.
MAINTAINING YOUR VEHICLE 151
7

Tail/Stop, Rear Turn Signals and Back-up Lights
1. Open the trunk and move the trunk liner away from
the rear light mounting area.
2. Twist the bulb socket 1/4 turn to remove it from the
housing.
3. Pull bulb from socket and replace
Center High Mounted Stop Light
1. Twist the socket 1/4 turn and remove it from the
housing.
2. Pull the bulb out of the socket and replace.
FLUIDS AND CAPACITIES
U.S. Metric
Fuel (Approximate) 91 Octane12.5 Gallons 47.5 Liters
Engine Oil-With Filter
2.4 Liter Turbo Charged Engines (5W-30, API Certified Engine
Oils)5.0 qts 4.7 Liters
Cooling System *
2.4 Liter Turbo Charged Engines (MoparAntifreeze/Coolant 5
Year/100,000 Mile Formula)8.1 qts 7.7 Liters
* Includes heater and coolant recovery bottle filled to MAX level.
176 MAINTAINING YOUR VEHICLE

RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology)
Engine Oil Use API Certified SAE 5W-30 Engine Oil. Refer to your engine oil filler cap
for correct SAE grade meeting DaimlerChrysler Material Standard MS-6395.
Engine Oil Filter Mopar 4781452AA or equiv.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection 91 Octane.
Chassis
Component Fluids, Lubricants and Genuine Parts.
Manual Transmission Fluid MoparATF+4 Automatic Transmission Fluid. Plus 4 oz. Mopar Limited
Slip Additive Friction Modifier.
Brake Master Cylinder MoparDOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not
available, then DOT 4 or DOT 4+ is acceptable. Use only recommended
brake fluids.
Power Steering Reservoir MoparATF+4 Automatic Transmission Fluid.
MAINTAINING YOUR VEHICLE 177
7

ABS (Anti-Lock Brake) System............. 102
Adding Engine Coolant (Antifreeze)......... 159
Adding Fuel.......................... 124
Air Cleaner, Engine (Engine Air Cleaner Filter) . 151
Air Conditioner Maintenance.............. 153
Air Conditioning........................ 84
Air Conditioning Controls................. 84
Air Conditioning Refrigerant...........153,154
Air Conditioning System................. 153
Air Pressure, Tires...................... 113
Airbag................................ 30
Airbag Deployment...................... 35
Airbag Light.......................38,46,71
Airbag Maintenance...................... 37
Airbag, Side........................... 36
Alarm, Panic........................... 19
Alarm System........................21,71
Alignment and Balance.................. 118
Alterations/Modifications, Vehicle............ 6
Antenna, Satellite Radio................... 83
Antifreeze (Engine Coolant).........158,176,177
Capacities........................... 176
Anti-Lock Brake System (ABS)............. 102Anti-Lock Warning Light.................. 69
Anti-Theft Security Alarm................. 21
Appearance Care....................... 165
Arming Theft System..................... 21
Ashtrays and Lighter..................... 63
Automatic Door Locks.................... 15
Ball Joints............................ 154
Battery............................... 152
Keyless Transmitter Replacement.......... 20
Belts, Drive........................... 149
Belts, Engine.......................... 150
Body Mechanism Lubrication.............. 155
B-Pillar Location....................... 108
Brake Fluid........................... 177
Brake, Parking......................... 100
Brake System.......................102,162
Anti-Lock........................... 102
Hoses.............................. 162
Master Cylinder...................... 163
Parking............................ 100
Warning Light........................ 69
Brakes............................102,162
204 INDEX

Exhaust Pipes......................... 156
Exhaust System........................ 156
Extender, Seat Belt....................... 30
Filters
Air Cleaner.......................... 151
Engine Fuel......................... 151
Engine Oil.......................149,177
Flashers
Hazard Warning...................... 128
Flooded Engine Starting................... 96
Fluid, Brake........................... 177
Fluid Capacities........................ 176
Fluid Leaks............................ 46
Fluid Level Checks
Manual Transaxle..................... 164
Fluids............................... 177
Fog Lights...........................57,69
Folding Rear Seat....................... 52
Freeing A Stuck Vehicle.................. 137
Front Suspension Ball Joints............... 154
Fuel..............................121,177
Adding............................. 124Capacity............................ 176
Filler Cap........................... 124
Filter.............................. 151
Gauge.............................. 71
Light............................... 71
Octane Rating........................ 121
Tank Capacity........................ 176
Fuel System Caution.................... 123
Fuses................................ 170
GasCap .............................. 124
Gasoline............................. 176
Gasoline, Reformulated.................. 121
Gasoline/Oxygenate Blends............... 122
Gauges
Coolant Temperature................... 73
Fuel................................ 71
Tachometer.......................... 70
Turbo Boost.......................91,121
General Information...................... 12
Glass Cleaning......................... 168
Hazard Warning Flasher.................. 128
