DODGE NITRO 2008 1.G Owners Manual

STARTING AND OPERATING
CONTENTS
mStarting Procedures.....................245
NManual Transmission..................245
NAutomatic Transmission................245
NNormal Starting......................245
NExtreme Cold Weather (Below ±20ÉF Or
±29ÉC).............................246
NIf Engine Fails To Start.................246
NAfter Starting........................248
mEngine Block Heater Ð If Equipped.........248mManual Transmission Ð If Equipped.........249
N6-Speed Manual Transmission............249
mAutomatic Transmission..................252
NShift Lock Manual Override Ð If Equipped . . . 253
NBrake/Transmission Interlock System.......254
N4±Speed Automatic Transmission (3.7L
Engine)............................255
N5±Speed Automatic Transmission (4.0L
Engine)............................260
NGear Ranges.........................260
5

mFour-Wheel Drive Operation...............265
NMP 143 Single-Speed Part-Time Transfer Case Ð
If Equipped.........................265
NShifting Procedure - Electronically Shifted
Transfer Case........................266
NMP 140 Single-Speed Full-Time Transfer Case Ð
If Equipped.........................267
mOn-Road Driving Tips...................268
mOff-Road Driving Tips...................268
NWhen To Use 4L Or 4LO (Low) Range......268
NDriving Through Water.................268
NDriving In Snow, Mud And Sand..........270
NHill Climbing........................270
NTraction Downhill.....................271NAfter Driving Off-Road.................271
mParking Brake.........................272
mAnti-Lock Brake System..................274
mPower Steering........................277
mTire Safety Information...................279
NTire Markings........................279
NTire Identification Number (TIN)..........282
NTire Loading And Tire Pressure...........283
mTires Ð General Information...............287
NTire Pressure.........................287
NTire Inflation Pressures.................288
NTire Pressures For High Speed Operation....290
NRadial-Ply Tires......................290
242 STARTING AND OPERATING

NTire Spinning........................290
NTread Wear Indicators..................291
NLife Of Tire.........................292
NReplacement Tires.....................292
NAlignment And Balance.................293
mTire Chains...........................294
mTire Rotation Recommendations............295
mTire Pressure Monitor System (TPMS) Ð
If Equipped...........................296
NBase System Ð If Equipped..............299
NPremium System Ð If Equipped..........301
NGeneral Information...................305
mFuel Requirements......................306N3.7L Engine (If Equipped)...............306
N4.0L Engine (If Equipped)...............306
NReformulated Gasoline.................307
NGasoline/Oxygenate Blends..............307
NMMT In Gasoline.....................308
NMaterials Added To Fuel................308
NFuel System Cautions..................308
NCarbon Monoxide Warnings..............309
mAdding Fuel..........................310
NFuel Filler Cap (Gas Cap)...............310
NLoose Fuel Filler Cap Message............312
mVehicle Loading........................313
NCertification Label.....................313
STARTING AND OPERATING 243
5

mTrailer Towing.........................315
NCommon Towing Definitions.............315
NTrailer Hitch Classification...............319
NTrailer Towing Weights (Maximum Trailer
Weight Ratings)......................320
NTrailer And Tongue Weight..............323NTowing Requirements..................324
NTowing Tips.........................329
mRecreational Towing (Behind Motorhome, Etc.) . . 330
NTowing ± 2WD Models.................330
NTowing Ð 4WD Or All-Wheel Drive Models . . 331
244 STARTING AND OPERATING

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust both
inside and outside mirrors, and fasten your seat belts.
CAUTION!
Long periods of engine idling, especially at high
engine speeds can cause excessive exhaust tempera-
tures which can damage your vehicle. Do not leave
your vehicle unattended with the engine running.
WARNING!
Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
Manual Transmission
Apply the parking brake, place the gearshift control lever
in ªNº (Neutral) and depress the clutch pedal before
starting vehicle. This vehicle is equipped with a clutch
interlocking ignition system. It will not start unless the
clutch pedal is pressed to the floor.
Automatic Transmission
Start the engine with the selector lever in the ªNº
(Neutral) or ªPº (Park) position. Apply the brake before
shifting to any driving range.
Normal Starting
Normal starting of either a cold or a warm engine is
obtained without pumping or depressing the accelerator
pedal. Turn the key to the START position and release
when the engine starts. If the engine fails to start within
10 seconds, turn the key to the OFF position, wait 5
seconds, then repeat the normal starting procedure.
STARTING AND OPERATING 245
5

Tip Start Feature Ð Automatic Transmission Only
Do notpress the accelerator. Turn the ignition key briefly
to START position, and release it. The starter motor will
continue to run, but will automatically disengage itself
when the engine is running.
Extreme Cold Weather (below ±20ÉF or ±29ÉC)
To insure reliable starting at these temperatures, use of an
externally powered electric engine block heater (available
from your dealer) is recommended.
If Engine Fails to Start
If the engine fails to start after you have followed the
ªNormal Startingº or ªExtreme Cold Weatherº proce-
dures, it may be flooded. Push the accelerator pedal all
the way to the floor and hold it there while cranking the
engine. This should clear any excess fuel in case the
engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
Ignition Key Positions
246 STARTING AND OPERATING

WARNING!
Never pour fuel or other flammable liquids into the
throttle body air inlet opening in an attempt to start
the vehicle. This could result in a flash fire causing
serious personal injury.
WARNING!
Do not attempt to push or tow your vehicle to get it
started. Vehicles equipped with an automatic trans-
mission cannot be started this way. Unburned fuel
could enter the catalytic converter and once the
engine has started, ignite and damage the converter
and vehicle. If the vehicle has a discharged battery,
booster cables may be used to obtain a start from a
booster battery or the battery in another vehicle. This
type of start can be dangerous if done improperly.
Refer to Section 6 of this manual for proper jump
starting procedures and follow them carefully.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the key is
STARTING AND OPERATING 247
5

released. If this occurs, continue cranking with the accel-
erator pedal pushed all the way to the floor. Release the
accelerator pedal and the key once the engine is running
smoothly.
If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the ªNormal Startingº or ªExtreme Cold
Weatherº procedures should be repeated.
After Starting
The idle speed will automatically decrease as the engine
warms up.
CAUTION!
Long periods of engine idling, especially at high
engine speeds can cause excessive exhaust tempera-
tures which can damage your vehicle. Do not leave
your vehicle unattended with the engine running.
WARNING!
Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
ENGINE BLOCK HEATER Ð IF EQUIPPED
The engine block heater warms engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 volt AC electrical outlet with a
grounded three-wire extension cord.
²The engine block heater cord is found under the hood
clipped to the heater line on the left side of the engine.
248 STARTING AND OPERATING

WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt AC electrical cord could
cause electrocution.
Use the heater when temperatures below 0ÉF (-18ÉC) are
expected to last for several days.
MANUAL TRANSMISSION Ð IF EQUIPPED
6-Speed Manual Transmission
WARNING!
You or others could be injured if you leave the
vehicle unattended without having the parking
brake fully applied. The parking brake should al-
ways be applied when the driver is not in the vehicle,
especially on an incline.Follow the shift pattern on the gearshift knob.
NOTE:The backup lights will come on when your
vehicle is in R (Reverse) gear and the ignition is in the ON
position.
Manual Shift Controls
STARTING AND OPERATING 249
5

WARNING!
When parking your vehicle, always leave a manual
transmission in first gear and apply the parking
brake fully to guard against vehicle movement and
possible injury or damage. Never use any gear as a
substitute for the parking brake.
CAUTION!
To drive as safely as possible and to prolong the life
of your manual transmission, follow these tips:
²Before shifting from a forward gear into reverse, or
from reverse to a forward gear, stop vehicle com-
pletely. Otherwise, accelerated transmission wear may
result.
²Do not operate at sustained high engine or road
speeds in lower gears. Engine damage may result.
²Do not downshift into a low gear while traveling at too
high a speed for that gear. Engine, clutch, or transmis-
sion damage may result.
²Do not rest your foot on the clutch pedal. This causes
heat buildup and damages the clutch.
²When you slow down or go up a grade, downshift as
speed requires or the engine may overheat.
²Never hold the vehicle stopped on a hill by using the
clutch pedal. The clutch may be damaged.
²During cold weather, you may experience increased
effort in shifting until the transmission fluid warms
up. This is normal.
²Push in the clutch pedal completely when shifting.
Otherwise, transmission or clutch damage may result.
250 STARTING AND OPERATING
