DODGE POWER WAGON 2005 2.G Owners Manual

Mute/Unmute
When you mute the UConnect™system, you will still be
able to hear the conversation coming from the other
party, but the other party will not be able to hear you. In
order to mute the UConnect™system press the’Voice
Recognition’button and sayMute. In order to unmute
the UConnect™system; press the’Voice Recognition’
button and sayUnmute.
Help
If you need assistance at any prompt or if you want to
know what your options are at any prompt, sayHelp.
The UConnect™system will play all the options at any
prompt if you ask for help.
Cancel
At any prompt, you can sayCanceland you will be
returned to the previous menu.
Emergency Assistance
If you are in an emergency, sayDial EmergencyorCall
Emergencyand the UConnect™system will instruct
your cellular phone to call 911.
Towing Assistance
If you need towing assistance, sayDial Towing Assis-
tanceorCall Towing Assistance. Please refer to the
24-Hour Towing Assistance coverage details in the
DaimlerChrysler Motors Company 24-Hour Towing As-
sistance Program Guide.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101
3

SEATS
The seating options available in this truck are the result of
extensive customer research and evaluations.
WARNING!
It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.
Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
40-20-40 Front Seat
As the name implies, the seat is divided into 3 segments.
The outboard seat portions are each 40% of the total
width of the seat. The back of the center portion (20%)
easily folds down to provide an armrest/center storage
compartment (if equipped).
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Each outboard seat is independently adjustable forward
or backward and is equipped with a back recliner. The
manual seat adjustment handle is found at the front edge
of each seat cushion. Pull up on the handle and slide the
seat to get the most comfortable position.
WARNING!
Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
properly adjusted and you could be injured. Adjust
any seat only while the vehicle is parked.
Reclining Seats
The recliner handle is on the outside of the seat cushion.
Pull up on the handle to release the seat back and adjust
for comfort.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103
3

WARNING!
You can be seriously, even fatally injured riding in a
seat with the seatback reclined. Do not ride with the
seatback reclined so that the shoulder belt is no
longer resting against your chest. If you ride in this
position, the shoulder harness will no longer be
restraining you. In a collision you could slide under
the seat belt and receive serious or fatal injuries.
Recline in a seat only when the vehicle is parked.
Adjustable Head Restraints
Head restraints can reduce the risk of whiplash injury in
the event of impact from the rear. Pull up or push down
on the restraints so that the upper edge is as high as
practical, at least to the level of the ears.To lower the head restraint, push in the button and then
push down on the head restraint.
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Manual Rotary Lumbar Support Adjustment—If
Equipped
Rotating the lumbar control knob on the left side of the
driver’s seatback and on the right side of the passenger’s
seatback increases or decreases the lumbar support.
Power Seats—If Equipped
CAUTION!
Don’t put anything under a power seat. It may cause
damage to the seat controls.
Manual Lumbar Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

The power seat controls are on the outboard side of the
front seat cushions. Three switches control the seat move-
ment. The four-way switch in the center can be moved
forward or backwards to get the most comfortable posi-
tion. The same switch can be moved up and down tocontrol seat height. Change the seat angle by using the
two toggle switches, tilting it up or down.
Up, Down, Forward, and Rearward
Tilt Adjustment
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Heated Seats—If Equipped
The heated seat switches are located in the instrument
panel under the climate controls. The engine must be
running for the heated seats to operate.Each heated seat switch has two settings (HI and LOW).
Press the switch once to obtain the desired heating
position and press a second time in the same direction to
turn the heated seats OFF. If you do not purposefully
turn the switch OFF, the heating element in the seat will
remain activated until the ignition is turned off. The
indicators on the switch will illuminate when the heated
seats are in the (HI or LOW) position. Flashing telltale
lights on the switch indicate that the Heated Seat system
needs servicing.
Heated Seat Switches
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107
3

TO OPEN AND CLOSE THE HOOD
To open the hood, two latches must be released. First pull
the hood release lever located below the steering wheel at
the base of the instrument panel. Once the hood is
released you must reach into the opening beneath the
center of the grille and push up the latch to release the
safety catch before raising the hood.To prevent possible damage, do not slam the hood to
close it. Use a firm downward push at the front center of
the hood to ensure that both latches engage.
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
If the hood is not fully latched, it could fly up when
the vehicle is moving and block your forward vision.
Be sure all hood latches are latched fully before
driving.
LIGHTS
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109
3

Interior Lights
Courtesy/ dome lights are turned on when the front
doors are opened, when the dimmer control (rotating
wheel on the right side of the switch) is rotated to the
second upward detent position, or if equipped, when the
UNLOCK button is pressed on the key fob. Rotating the
dimmer control to the optional fully upward position willturn on the cargo light located on the back of the cab.
When a door is open and the interior lights are on,
rotating the dimmer control all the way down to the OFF
detent will cause all the interior lights to go out. This is
also known as thePartymode because it allows the
doors to stay open for extended periods of time without
discharging the vehicle’s battery.
The brightness of the instrument panel lighting can be
regulated by rotating the dimmer control up (brighter) or
down (dimmer). When the headlights are ON you can
supplement the brightness of the odometer, trip odom-
eter, radio and overhead console by rotating the control
up until you hear a click. This feature is termed the
“Parade”mode and is useful when headlights are re-
quired during the day.
