2. Pull the housing straight out from the body, with a
quick motion, to separate the housing from the body. If
not pulled straight, locators may be damaged.3. Push the red lock slide in on the connector and remove
the housing from the vehicle.
4. Remove the four (4) screws from the bulb strip in the
housing.
MAINTAINING YOUR VEHICLE 411
7

5. Pull the appropriate bulb straight from the bulb strip.
•Top Bulb: Park/Turn/Hazard
•Center Bulb: Stop/Park/Sidemarker
•Bottom Bulb: Backup Lights
6. Reverse procedure for installation of bulbs and hous-
ing.7. While holding the taillight firmly in place, fasten the
top screw first.
Center High-Mounted Stoplight With Cargo Light
1. Remove the two (2) screws holding the housing/lens
to the body as shown.
412 MAINTAINING YOUR VEHICLE

2. Separate the connector holding the housing and wir-
ing harness to the body.
3. Turn desired bulb socket
14turn and remove socket
and bulb from housing.
4. Pull desired bulb straight from the socket.
•Outside Bulbs: Cargo Lamps
•Inside Bulb: Center High Mount Stop Lamp
5. Reverse procedure for installation of bulbs and hous-
ing.
MAINTAINING YOUR VEHICLE 413
7

Cab Top Clearance Lights — If Equipped
1. Remove the two screws from the top of the light.2. Rotate the socket
14turn and pull it from the light
assembly.
414 MAINTAINING YOUR VEHICLE

3. Pull the bulb straight from it’s socket and replace.Fog Lights
1. Reach under the vehicle, unlock and twist connector
counterclockwise14turn and remove connector and bulb
from housing.
MAINTAINING YOUR VEHICLE 415
7

2. Pull bulb straight from the connector. 3. Reverse procedure for installation of bulbs and hous-
ing.
416 MAINTAINING YOUR VEHICLE

FLUIDS AND CAPACITIES
U.S. Metric
Fuel
5.7L, 89 Octane
2500 Shortbed Models 34 gal. 128L
2500 Longbed Models 35 gal. 132L
Engine Oil (with filter)
5.7L Engine V-8, SAE 5W-20, API Certified 7.0 qts. 6.6L
Cooling System
5.7L (MoparAntifreeze/Coolant 5 Year/100,000 Mile
Formula)18.7 qts. 17.7L
MAINTAINING YOUR VEHICLE 417
7

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) P/N 5011764AB or equivalent.
Engine Oil Use SAE 5W-20, API Certified, meeting material standard MS-6395. Refer to
oil viscosity chart for alternative grade.
Engine Oil Filter MoparEngine Oil Filter, P/N 5281090 or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection (5.7L) 89 Octane Mid-Grade, (R+M)/2 Method Preferred (87 Octane Acceptable)
418 MAINTAINING YOUR VEHICLE

Chassis
Component Fluids, Lubricants and Genuine Parts.
Automatic Transmission MoparATF+4, Automatic Transmission Fluid
Transfer Case MoparATF+4, Automatic Transmission Fluid
Manual Transmission Fluid (G-56) MoparATF+4, Automatic Transmission Fluid
Front Driveshaft Grease Fitting. Use Mopartype MS-6560 (lithium based grease), or equivalent.
Clutch Linkage Multipurpose Grease, NLGI Grade 2 E.P.
Front and Rear Axle Synthetic, GL-5 SAE, 75W-90. Limited-Slip 10.5 inch Rear AxleDOES NOT
REQUIREa limited slip additive.
Brake Master Cylinder MoparDOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not
available, then DOT 4 is acceptable. Use only recommended brake fluids.
Power Steering Reservoir MoparATF+4, Automatic Transmission Fluid
MAINTAINING YOUR VEHICLE 419
