Connector location DODGE RAM 1500 1998 2.G Repair Manual

SPLICE
NUMBERLOCATION FIG.
S312 Right Door 42
S313 Left Front Door 41
S314 Left Rear Frame Rail N/S
S315 Left Front Body 40, 44, 46
S316 At Driver Seat N/S
S318 At Passenger Seat N/S
S319 Left Front Door 41
S320 Center of Body 44
S321 Left Front Body 44
S322 Left Front Body 45, 47
S323 Left Front Body 45, 47
S324 Left Rear Chassis 51
S325 Left Rear Chassis 51
S326 Left Rear Chassis N/S
S327 Left Rear Chassis 51
S328 At Driver Seat N/S
S329 At Driver Seat N/S
S330 Center Rear of Chassis 51
S331 Center Rear of Chassis 51
S332 Left Front Door 41
S333 Left Front Body 40, 44, 46
S334 Left Front Body 40, 44, 46
S335 Left Front Body N/S
S336 Passenger Seat N/S
S337 Passenger Seat N/S
S340 Left Rear Fender 52
S341 Right Rear Fender 52
S342 Left Rear Fender 52
S343 Right Rear Fender 52
S351 Driver Seat N/S
8W - 91 - 12 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 1 RIGHT SIDE FRONT LIGHTING
Fig. 2 LEFT FRONT BUMPER AND RIGHT BATTERY TRAY
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 13
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 3 RIGHT SIDE ENGINE, 4.7L
8W - 91 - 14 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 4 RIGHT REAR ENGINE COMPARTMENT
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 15
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 5 RIGHT TOP ENGINE (3.7L/4.7L)
8W - 91 - 16 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 6 LEFT SIDE ENGINE (3.7L/4.7L)
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 17
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 7 LEFT SIDE ENGINE (5.7L)
8W - 91 - 18 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 8 RIGHT REAR ENGINE COMPARTMENT (5.7L)
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 19
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 9 RIGHT SIDE ENGINE (5.7L)
8W - 91 - 20 8W-91 CONNECTOR/GROUND/SPLICE LOCATIONDR
CONNECTOR/GROUND/SPLICE LOCATION (Continued)

Fig. 10 ENGINE (DIESEL)
DR8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 21
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
