(2) Install the coupler to the intermediate shaft
using the marks made in the removal process.
NOTE: New pinch bolts must be used for reinstalla-
tion.
(3) Install the lower pinch bolt and tighten to 57
N´m (42 ft. lbs.).
(4) Install the upper pinch bolt and tighten to 57
N´m (42 ft. lbs.).
(5) Install the left front tire and wheel assembly
(Refer to 22 - TIRES/WHEELS/WHEELS - STAN-
DARD PROCEDURE).
(6) Lower the vehicle.
(7) Reconnect the negative battery cable.
(8) Unlock the steering wheel.
INSTALLATION - 4X4 HD
(1) Install the coupler to the steering gear.
(2) Install the coupler to the intermediate shaft.
NOTE: New pinch bolts must be used for reinstalla-
tion.
(3) Install the lower pinch bolt and tighten to 28
N´m (250 in. lbs.).
(4) Install the upper pinch bolt and tighten to 57
N´m (42 ft. lbs.).
(5) Install the left front tire and wheel assembly
(Refer to 22 - TIRES/WHEELS/WHEELS - STAN-
DARD PROCEDURE).
(6) Lower the vehicle.(7) Reconnect the negative battery cable.
(8) Unlock the steering wheel.
STEERING WHEEL
REMOVAL
(1) Disable and remove the driver's side air-
bag.(Refer to 8 - ELECTRICAL/RESTRAINTS/
DRIVER AIRBAG - REMOVAL).
(2) Partially remove the steering wheel bolt and
leave the bolt in the column.
(3) Install puller CJ98-1 or equivalent using the
top of the bolt to push on. (Fig. 21)
(4) Remove and discard the steering wheel bolt.
(5) Remove the steering wheel.
INSTALLATION
NOTE: Do not reuse the old steering wheel bolt (a
new bolt must be used)
(1) Install steering wheel to the column
NOTE: Be certain that the steering wheel mounting
bolt is tightened to the proper torque specification
to ensure proper clockspring operation.
(2) Install the new steering wheel bolt. Tighten the
bolt to 61 N´m (45 ft. lbs.).
(3) Install the driver's side air bag. (Refer to 8 -
ELECTRICAL/RESTRAINTS/DRIVER AIRBAG -
INSTALLATION).
Fig. 20 INTERMEDIATE STEERING SHAFT
1 - UPPER COUPLING BOOT AND BOLT
2 - INTERMEDIATE STEERING SHAFT
3 - LOWER COUPLING BOLT
4 - STEERING GEAR
Fig. 21 STEERING WHEEL PULLER
1 - STEERING WHEEL
2 - SPECIAL TOOL CJ98-1
DRCOLUMN 19 - 15
LOWER STEERING COUPLING (Continued)

(3) Pull seat belt out of the trim panel through the
slot provided. (Fig. 5)
INSTALLATION
QUAD CAB
(1) Route the shoulder belt through the slot in the
trim.
(2) Position the trim and seat the attachment clips
fully.
(3) Install the rear door sill trim. (Refer to 23 -
BODY/INTERIOR/DOOR SILL TRIM COVER -
INSTALLATION)
STANDARD CAB
(1) Position the trim and seat the attachment clips
fully.
(2) Install the seat belt anchor and bolt and
tighten to 40 N´m (30 ft. lbs.).
BOTH BODY STYLES
(1) Install the cowl trim. (Refer to 23 - BODY/IN-
TERIOR/COWL TRIM - INSTALLATION)
(2) Install the upper b-pillar trim. (Refer to 23 -
BODY/INTERIOR/B-PILLAR UPPER TRIM -
INSTALLATION)
B-PILLAR UPPER TRIM
REMOVAL
(1) Remove the seat belt turning loop. (Refer to 8 -
ELECTRICAL/RESTRAINTS/SEAT BELT TURNING
LOOP ADJUSTER - REMOVAL)
(2) Open the trim plugs and remove the grab han-
dle bolts, if equipped. (Fig. 6)
(3) Using a trim stick C-4755 or equivalent,
remove the upper b-pillar trim. (Fig. 7) or (Fig. 8)
INSTALLATION
(1) Position the upper b-pillar trim and seat the
attachment clips fully.
(2) Install the grab handle bolts and tighten to 6
N´m (55 in. lbs.).
(3) Close the grab handle trim plugs.
(4) Install the seat belt turning loop. (Refer to 8 -
ELECTRICAL/RESTRAINTS/SEAT BELT TURNING
LOOP ADJUSTER - INSTALLATION)
Fig. 4 LOWER B-PILLAR TRIM - STANDARD CAB
1 - SEAT BELT
2 - B-PILLAR
3 - SEAT BELT ANCHOR HOLE
4 - LOWER B-PILLAR TRIM
Fig. 5 LOWER B-PILLAR TRIM - QUAD CAB
1 - SEAT BELT
2 - SEAT BELT SLOT
3 - LOWER B-PILLAR TRIM
23 - 64 INTERIORDR
B-PILLAR LOWER TRIM (Continued)

INSTALLATION
(1) Route the shoulder belt through the slot in the
trim.
(2) Position the trim and seat the attachment clips
fully.
(3) Install the seat belt anchor bolt and tighten to
40 N´m (30 ft. lbs.).
(4) Install the upper c-pillar trim. (Refer to 23 -
BODY/INTERIOR/C-PILLAR UPPER TRIM -
INSTALLATION)
C-PILLAR UPPER TRIM
REMOVAL
(1) Remove the seat belt turning loop. (Refer to 8 -
ELECTRICAL/RESTRAINTS/SEAT BELT TURNING
LOOP ADJUSTER - REMOVAL)
(2) Using a trim stick C-4755 or equivalent,
remove the upper c-pillar trim. (Fig. 11)
INSTALLATION
(1) Position the upper c-pillar trim and seat the
attachment clips fully.
(2) Install the seat belt turning loop. (Refer to 8 -
ELECTRICAL/RESTRAINTS/SEAT BELT TURNING
LOOP ADJUSTER - INSTALLATION)
FLOOR CONSOLE
REMOVAL
(1) Remove the 4WD shifter boot. (Refer to 23 -
BODY/INTERIOR/4WD FLOOR SHIFT BOOT -
REMOVAL)
(2) Using a trim stick C-4755 or equivalent, pry up
the transmission shifter boot from the console.
(3) Remove the transmission shifter extension.
(4) Remove the console inserts. (Fig. 12)
(5) Remove and discard the three bolts. (Fig. 13)
(6) Lift up on the back and remove the console.
INSTALLATION
(1) Position the front of the console up under the
instrument panel.
(2) Lower the back of the console and install three
new screws.
(3) Install the inserts.
(4) Install the transmission shifter extension.
(5) Position the transmission shifter boot in place
and seat the attachment clips fully.
(6) Install the 4WD shifter boot. (Refer to 23 -
BODY/INTERIOR/4WD FLOOR SHIFT BOOT -
INSTALLATION)
Fig. 12 FLOOR CONSOLE INSERTS
1 - BIN MAT INSERT
2 - STORAGE BIN/SHIFT BOOT
3 - CUP HOLDER MAT INSERT
4 - FLOOR CONSOLE
Fig. 13 FLOOR CONSOLE
1 - INSTRUMENT PANEL
2 - FLOOR CONSOLE
3 - BOLTS (3)
4 - SHIFTER LEVER
DRINTERIOR 23 - 67
C-PILLAR LOWER TRIM (Continued)

HEADLINER
REMOVAL
(1) Remove the a-pillar trim. (Refer to 23 - BODY/
INTERIOR/A-PILLAR TRIM - REMOVAL)
(2) Remove the upper b-pillar trim. (Refer to 23 -
BODY/INTERIOR/B-PILLAR UPPER TRIM -
REMOVAL)
(3) Remove the upper c-pillar trim, if equipped.
(Refer to 23 - BODY/INTERIOR/C-PILLAR TRIM -
REMOVAL)
(4) Remove the coat hooks. (Refer to 23 - BODY/
INTERIOR/COAT HOOK - REMOVAL)
(5) Disconnect the headliner harness electrical con-
nector at the left a-pillar.
(6) Remove the dome lamp. (Refer to 8 - ELEC-
TRICAL/LAMPS/LIGHTING - INTERIOR/DOME
LAMP - REMOVAL)
(7) Remove the overhead console. (Refer to 8 -
ELECTRICAL/OVERHEAD CONSOLE - REMOVAL)
(8) Remove the sun visors. (Refer to 23 - BODY/
INTERIOR/SUN VISOR - REMOVAL)
(9) Remove the sun visor supports. (Refer to 23 -
BODY/INTERIOR/SUN VISOR SUPPORT -
REMOVAL)
(10) Lower the headliner and disconnect the center
high mounted stop light.
(11) Lower the front of the headliner down to the
floor just in front of the instrument panel and
remove through the passenger door.
INSTALLATION
(1) Install the headliner into the vehicle through
the passenger door.
(2) Raise the headliner and insert the right side
above right side pillar trim pieces.
(3) Connect the center high mounted stop light
electrical connector.
(4) Install the sun visor supports. (Refer to 23 -
BODY/INTERIOR/SUN VISOR SUPPORT - INSTAL-
LATION)
(5) Install the coat hooks. (Refer to 23 - BODY/IN-
TERIOR/COAT HOOK - INSTALLATION)
(6) Install the sun visors. (Refer to 23 - BODY/IN-
TERIOR/SUN VISOR - INSTALLATION)
(7) Install the overhead console. (Refer to 8 -
ELECTRICAL/OVERHEAD CONSOLE - INSTALLA-
TION)
(8) Install the dome lamp. (Refer to 8 - ELECTRI-
CAL/LAMPS/LIGHTING - INTERIOR/DOME LAMP
- INSTALLATION)
(9) Connect the headliner harness electrical con-
nector at the left a-pillar.
(10) Install the upper c-pillar trim, if equipped.
(Refer to 23 - BODY/INTERIOR/C-PILLAR TRIM -
INSTALLATION)(11) Install the upper b-pillar trim. (Refer to 23 -
BODY/INTERIOR/B-PILLAR UPPER TRIM -
INSTALLATION)
(12) Install the upper a-pillar trim. (Refer to 23 -
BODY/INTERIOR/A-PILLAR TRIM - INSTALLA-
TION)
B-PILLAR GRAB HANDLE
REMOVAL
(1) Open the trim plugs and remove the bolts. (Fig.
14)
(2) Remove the grab handle.
INSTALLATION
(1) Install the grab handle and install the bolts.
(2) Tighten the bolts to 6 N´m (55 in. lbs.) and
install the trim plugs.
REAR CAB BACK PANEL TRIM
REMOVAL
(1) Remove the child seat tethers, if equipped.
(Refer to 8 - ELECTRICAL/RESTRAINTS/CHILD
TETHER - REMOVAL)
(2) Remove the screws and remove the utility
hooks/bin latch, if equipped. (Fig. 15)
Fig. 14 GRAB HANDLE
1 - GRAB HANDLE
2 - TRIM PLUGS
3 - BOLTS
23 - 68 INTERIORDR

(3) Using a trim stick C-4755 or equivalent,
remove the center seat belt trim bezel, if equipped.
(4) On quad cab models, remove the left lower
c-pillar trim panel. (Refer to 23 - BODY/INTERIOR/
C-PILLAR TRIM - REMOVAL)
(5) On standard cab models, remove the left lower
b-pillar trim panel. (Refer to 23 - BODY/INTERIOR/
B-PILLAR LOWER TRIM - REMOVAL)
(6) Remove the push pin fasteners, if equipped,
and remove the back panel trim. (Fig. 16) or (Fig. 17)
INSTALLATION
(1) Position the back panel trim behind the right
pillar trim.
(2) Route the center belt and trim bezel through
the back panel, if equipped.
(3) On standard cab models, install the left lower
b-pillar trim panel. (Refer to 23 - BODY/INTERIOR/
B-PILLAR LOWER TRIM - INSTALLATION)
(4) On quad cab models, install the left lower c-pil-
lar trim panel. (Refer to 23 - BODY/INTERIOR/C-
PILLAR TRIM - INSTALLATION)
(5) Position the center belt trim bezel, if equipped,
and seat the attachment clips fully.
(6) Install the utility hooks/bin latch and screws, if
equipped.
(7) Install the child seat tethers, if equipped.
(Refer to 8 - ELECTRICAL/RESTRAINTS/CHILD
TETHER - INSTALLATION)
REAR VIEW MIRROR
REMOVAL
(1) If equipped, disconnect mirror harness connec-
tor.
(2) Loosen the mirror base setscrew (Fig. 18).
(3) Slide the mirror base upward and off the
bracket.
Fig. 15 UTILITY HOOK/STORAGE BIN LATCH
1 - SCREW
2 - UTILITY HOOK
3 - UTILITY HOOK COVER
4 - COVER LOCK TAB
Fig. 16 CAB BACK PANEL - STANDARD CAB
1 - CAB BACK PANEL
2 - CAB BACK
3 - UTILITY HOOK
4 - STORAGE BIN LATCH
Fig. 17 CAB BACK PANEL - QUAD CAB
1 - PUSH PIN FASTENER
2 - CAB BACK
3 - CAB BACK PANEL
4 - PUSH PIN FASTENER
DRINTERIOR 23 - 69
REAR CAB BACK PANEL TRIM (Continued)

GEAR/RING GEAR/TONE RING -
INSTALLATION, PINION......3-108,3-137,3-164
GEAR/RING GEAR/TONE RING -
REMOVAL, PINION.........3-106,3-134,3-162
GEARSHIFT CABLE - DIAGNOSIS AND
TESTING....................21-210,21-368
GEARSHIFT CABLE - INSTALLATION....21-211,
21-370
GEARSHIFT CABLE - REMOVAL . . 21-210,21-369
GEARSHIFT CABLE, ADJUSTMENTS.....21-212,
21-370
GEAR/TONE RING - INSTALLATION,
PINION GEAR/RING.........3-108,3-137,3-164
GEAR/TONE RING - REMOVAL, PINION
GEAR/RING...............3-106,3-134,3-162
GEARTRAIN - ASSEMBLY, PLANETARY . . . 21-397
GEARTRAIN - CLEANING, PLANETARY . . . 21-396
GEARTRAIN - DESCRIPTION,
PLANETARY........................21-395
GEARTRAIN - DISASSEMBLY,
PLANETARY........................21-396
GEARTRAIN - INSPECTION, PLANETARY . 21-397
GEARTRAIN - OPERATION, PLANETARY . . 21-396
GEARTRAIN/OUTPUT SHAFT -
ASSEMBLY, PLANETARY..............21-244
GEARTRAIN/OUTPUT SHAFT -
DESCRIPTION, PLANETARY............21-241
GEARTRAIN/OUTPUT SHAFT -
DISASSEMBLY, PLANETARY...........21-242
GEARTRAIN/OUTPUT SHAFT -
INSPECTION, PLANETARY.............21-243
GEARTRAIN/OUTPUT SHAFT -
OPERATION, PLANETARY.............21-241
GENERAL - WARNINGS.............8W-01-7
GENERATOR / CHARGING SYSTEM -
SPECIFICATIONS, TORQUE.............8F-20
GENERATOR - DESCRIPTION...........8F-21
GENERATOR - INSTALLATION...........8F-24
GENERATOR - OPERATION.............8F-21
GENERATOR - REMOVAL...............8F-22
GENERATOR RATINGS, SPECIFICATIONS . . 8F-20
GENII - ASSEMBLY, TRANSFER CASE -
NV241............................21-428
GENII - ASSEMBLY, TRANSFER CASE -
NV244............................21-525
GENII - CLEANING, TRANSFER CASE -
NV241............................21-426
GENII - CLEANING, TRANSFER CASE -
NV244............................21-523
GENII - DESCRIPTION, TRANSFER CASE
- NV241...........................21-415
GENII - DESCRIPTION, TRANSFER CASE
- NV244...........................21-512
GENII - DIAGNOSIS AND TESTING,
TRANSFER CASE - NV241.............21-416
GENII - DISASSEMBLY, TRANSFER CASE
- NV241...........................21-417
GENII - DISASSEMBLY, TRANSFER CASE
- NV244...........................21-514
GENII - INSPECTION, TRANSFER CASE -
NV241............................21-426
GENII - INSPECTION, TRANSFER CASE -
NV244............................21-523
GENII - INSTALLATION, TRANSFER CASE
- NV241...........................21-438
GENII - INSTALLATION, TRANSFER CASE
- NV244...........................21-534
GENII - OPERATION, TRANSFER CASE -
NV241............................21-415
GENII - OPERATION, TRANSFER CASE -
NV244............................21-513
GENII - REMOVAL, TRANSFER CASE -
NV241............................21-417
GENII - REMOVAL, TRANSFER CASE -
NV244............................21-514
GENII - TRANSFER CASE, NV241.......21-438
GENII - TRANSFER CASE, NV244.......21-535
GLASS - DESCRIPTION, HEATED.........8G-1
GLASS - INSTALLATION, BACKLITE VENT . 23-87
GLASS - INSTALLATION, DOOR....23-20,23-30
GLASS - INSTALLATION, SIDE VIEW
MIRROR...........................23-43
GLASS - OPERATION, HEATED
...........8G-1
GLASS - REMOVAL, BACKLITE VENT
.....23-87
GLASS - REMOVAL, DOOR
........23-20,23-30
GLASS - REMOVAL, SIDE VIEW MIRROR
. . 23-42
GLASS RUN CHANNEL - INSTALLATION
. . 23-22,
23-31GLASS RUN CHANNEL - REMOVAL . 23-21,23-30
GLASS RUN WEATHERSTRIP -
INSTALLATION, FRONT DOOR...........23-92
GLASS RUN WEATHERSTRIP -
INSTALLATION, REAR DOOR............23-93
GLASS RUN WEATHERSTRIP -
REMOVAL, FRONT DOOR..............23-92
GLASS RUN WEATHERSTRIP -
REMOVAL, REAR DOOR...............23-93
GLOVE BOX - INSTALLATION...........23-52
GLOVE BOX - REMOVAL...............23-52
GLOVE BOX LAMP/SWITCH -
INSTALLATION.......................8L-28
GLOVE BOX LAMP/SWITCH - REMOVAL . . . 8L-27
GLOVE BOX LATCH - INSTALLATION.....23-52
GLOVE BOX LATCH - REMOVAL.........23-52
GOVERNOR - DESCRIPTION,
ELECTRONIC.......................21-197
GOVERNOR - INSTALLATION,
ELECTRONIC.......................21-200
GOVERNOR - OPERATION, ELECTRONIC . 21-198
GOVERNOR - REMOVAL, ELECTRONIC . . . 21-199
GRAB HANDLE - INSTALLATION,
B-PILLAR...........................23-68
GRAB HANDLE - REMOVAL, B-PILLAR....23-68
GRID LINE AND TERMINAL REPAIR -
STANDARD PROCEDURE...............8G-4
GRILLE - INSTALLATION...............23-40
GRILLE - INSTALLATION, COWL.........23-38
GRILLE - REMOVAL....................23-40
GRILLE - REMOVAL, COWL............23-38
GRILLE FRAME - INSTALLATION.........23-40
GRILLE FRAME - REMOVAL............23-40
GROUND - STANDARD PROCEDURE,
TESTING FOR A SHORT TO..........8W-01-9
GROUND AND SPLICE INFORMATION -
DESCRIPTION, CONNECTOR..........8W-01-7
GROUND ON FUSES POWERING
SEVERAL LOADS - STANDARD
PROCEDURE, TESTING FOR A SHORT
TO.............................8W-01-10
GROUND STRAP - DESCRIPTION, RADIO
NOISE SUPPRESSION..................8A-9
GROUND STRAP - INSTALLATION,
RADIO NOISE SUPPRESSION...........8A-10
GROUND STRAP - OPERATION, RADIO
NOISE SUPPRESSION..................8A-9
GROUND STRAP - REMOVAL, RADIO
NOISE SUPPRESSION..................8A-9
GROUNDS - DESCRIPTION, POWER......8E-10
GUIDE SEALS - DESCRIPTION, VALVE . 9-32,9-38
GUIDES - DESCRIPTION, VALVE....9-107,9-202
GUIDES AND SPRINGS - STANDARD
PROCEDURE, VALVES.................9-256
HALF SHAFT - CAUTION................3-20
HALF SHAFT - DIAGNOSIS AND TESTING . . 3-20
HALF SHAFT - INSTALLATION............3-21
HALF SHAFT - REMOVAL...............3-20
HALF SHAFT - SPECIAL TOOLS..........3-21
HALF SHAFT - SPECIFICATIONS..........3-21
HANDLE - INSTALLATION, A-PILLAR
TRIM/GRAB.........................23-63
HANDLE - INSTALLATION, B-PILLAR
GRAB..............................23-68
HANDLE - INSTALLATION, EXTERIOR
....23-21,
23-30
HANDLE - INSTALLATION, RELEASE
.......5-44
HANDLE - REMOVAL, A-PILLAR
TRIM/GRAB
.........................23-63
HANDLE - REMOVAL, B-PILLAR GRAB
....23-68
HANDLE - REMOVAL, EXTERIOR
. . . 23-20,23-30
HANDLE - REMOVAL, RELEASE
..........5-44
HANDLE ACTUATOR - INSTALLATION,
INSIDE
........................23-22,23-32
HANDLE ACTUATOR - REMOVAL, INSIDE
. 23-22,
23-31
HANDLE/BEZEL - INSTALLATION,
LUMBAR SUPPORT
...................23-82
HANDLE/BEZEL - REMOVAL, LUMBAR
SUPPORT
..........................23-82
HANDLE/LATCH REMOTE -
INSTALLATION, RELEASE
..............23-17
HANDLE/LATCH REMOTE - REMOVAL,
RELEASE
...........................23-17
HANDLING NON-DEPLOYED
SUPPLEMENTAL RESTRAINTS -
STANDARD PROCEDURE
...............8O-6HANDLING TUBING AND FITTINGS -
STANDARD PROCEDURE...............24-45
HANDS FREE MODULE - INSTALLATION....8T-2
HANDS FREE MODULE - REMOVAL.......8T-2
HARNESS - DIAGNOSIS AND TESTING,
WIRING..........................8W-01-7
HAZARD SWITCH - DESCRIPTION.......8L-14
HAZARD SWITCH - OPERATION.........8L-14
HCU (HYDRAULIC CONTROL UNIT) -
DESCRIPTION........................5-49
HCU (HYDRAULIC CONTROL UNIT) -
INSTALLATION........................5-50
HCU (HYDRAULIC CONTROL UNIT) -
OPERATION..........................5-49
HCU (HYDRAULIC CONTROL UNIT) -
REMOVAL...........................5-50
HEAD - CLEANING, CYLINDER.....9-200,9-251
HEAD - DESCRIPTION, CYLINDER . . 9-107,9-249
HEAD - INSPECTION, CYLINDER....9-200,9-252
HEAD - INSTALLATION, CYLINDER.......9-200
HEAD - INSTALLATION, LEFT CYLINDER . . 9-112
HEAD - INSTALLATION, RIGHT
CYLINDER..........................9-113
HEAD - LEFT - INSTALLATION,
CYLINDER...........................9-24
HEAD - LEFT - REMOVAL, CYLINDER......9-22
HEAD - OPERATION, CYLINDER.........9-199
HEAD - REMOVAL, CYLINDER.....9-200,9-249
HEAD - REMOVAL, LEFT CYLINDER......9-108
HEAD - REMOVAL, RIGHT CYLINDER.....9-110
HEAD - RIGHT - INSTALLATION,
CYLINDER...........................9-34
HEAD - RIGHT - REMOVAL, CYLINDER....9-33
HEAD COVER - INSTALLATION,
CYLINDER..........................9-255
HEAD COVER - REMOVAL, CYLINDER....9-255
HEAD COVER(S) - DESCRIPTION,
CYLINDER......................9-122,9-27
HEAD COVER(S) - INSTALLATION,
CYLINDER..................9-201,9-28,9-37
HEAD COVER(S) - REMOVAL, CYLINDER . 9-201,
9-28,9-37
HEAD GASKET - DIAGNOSIS AND
TESTING, CYLINDER...................9-21
HEAD GASKET FAILURE - DIAGNOSIS
AND TESTING, CYLINDER..............9-199
HEAD GASKET SELECTION - STANDARD
PROCEDURE........................9-281
HEADLAMP - INSTALLATION............8L-14
HEADLAMP - REMOVAL...............8L-14
HEADLAMP SWITCH - DESCRIPTION.....8L-14
HEADLAMP SWITCH - INSTALLATION....8L-15
HEADLAMP SWITCH - OPERATION.......8L-14
HEADLAMP SWITCH - REMOVAL........8L-14
HEADLAMP SWITCH BEZEL -
INSTALLATION, INSTRUMENT PANEL.....23-56
HEADLAMP SWITCH BEZEL - REMOVAL,
INSTRUMENT PANEL..................23-56
HEADLAMP UNIT - ADJUSTMENTS......8L-16
HEADLAMP UNIT - INSTALLATION.......8L-15
HEADLAMP UNIT - REMOVAL...........8L-15
HEADLINER - INSTALLATION...........23-68
HEADLINER - REMOVAL...............23-68
HEADREST - INSTALLATION............23-80
HEADREST - REMOVAL................23-80
HEADREST SLEEVE - INSTALLATION.....23-81
HEADREST SLEEVE - REMOVAL.........23-81
HEAT SHIELDS - DESCRIPTION..........11-8
HEAT SHIELDS - INSTALLATION..........11-8
HEAT SHIELDS - REMOVAL.............11-8
HEAT STAKING - STANDARD
PROCEDURE.........................23-3
HEATED GLASS - DESCRIPTION..........8G-1
HEATED GLASS - OPERATION...........8G-1
HEATED MIRRORS - DESCRIPTION.......8G-6
HEATED MIRRORS - OPERATION.........8G-6
HEATED SEAT ELEMENT - DESCRIPTION . . . 8G-9
HEATED SEAT ELEMENT - DIAGNOSIS
AND TESTING.......................8G-10
HEATED SEAT ELEMENT - INSTALLATION . 8G-10
HEATED SEAT ELEMENT - OPERATION....8G-10
HEATED SEAT ELEMENT - REMOVAL
.....8G-10
HEATED SEAT MODULE - DESCRIPTION
....8E-6
HEATED SEAT MODULE - DESCRIPTION
. . 8G-13
HEATED SEAT MODULE - DIAGNOSIS
AND TESTING
........................8E-6
HEATED SEAT MODULE - DIAGNOSIS
AND TESTING
.......................8G-14
DRINDEX 15
Description Group-Page Description Group-Page Description Group-Page

MODULE - INSTALLATION, FRONT
CONTROL........................8W-97-6
MODULE - INSTALLATION, FRONT
CONTROL...........................8E-5
MODULE - INSTALLATION, FUEL PUMP . . . 14-12
MODULE - INSTALLATION, FUEL TANK....14-64
MODULE - INSTALLATION, HANDS FREE . . . 8T-2
MODULE - INSTALLATION, HEATED SEAT . . . 8E-7
MODULE - INSTALLATION, HEATED SEAT . 8G-15
MODULE - INSTALLATION, INTEGRATED
POWER..........................8W-97-4
MODULE - INSTALLATION, REMOTE
KEYLESS ENTRY......................8N-8
MODULE - INSTALLATION, SENTRY KEY
IMMOBILIZER.......................8E-15
MODULE - INSTALLATION, WIPER.......8R-23
MODULE - OPERATION, AIRBAG
CONTROL..........................8O-11
MODULE - OPERATION, DRIVER DOOR....8N-5
MODULE - OPERATION, FRONT
CONTROL........................8W-97-5
MODULE - OPERATION, FRONT
CONTROL...........................8E-5
MODULE - OPERATION, FUEL PUMP.....14-11
MODULE - OPERATION, FUEL TANK......14-63
MODULE - OPERATION, HEATED SEAT.....8E-6
MODULE - OPERATION, HEATED SEAT....8G-14
MODULE - OPERATION, INTEGRATED
POWER..........................8W-97-3
MODULE - OPERATION, REMOTE
KEYLESS ENTRY......................8N-7
MODULE - OPERATION, SENTRY KEY
IMMOBILIZER.......................8E-13
MODULE - OPERATION, TRANSFER CASE
CONTROL..........................8E-16
MODULE - OPERATION, TRANSMISSION
CONTROL..........................8E-20
MODULE - OPERATION, WIPER.........8R-23
MODULE - REMOVAL, AIRBAG CONTROL . 8O-12
MODULE - REMOVAL, DRIVER DOOR.....8N-7
MODULE - REMOVAL, ENGINE CONTROL . . . 8E-4
MODULE - REMOVAL, FRONT CONTROL . 8W-97-6
MODULE - REMOVAL, FRONT CONTROL . . . 8E-5
MODULE - REMOVAL, FUEL PUMP.......14-12
MODULE - REMOVAL, FUEL TANK.......14-63
MODULE - REMOVAL, HANDS FREE.......8T-2
MODULE - REMOVAL, HEATED SEAT......8E-7
MODULE - REMOVAL, HEATED SEAT.....8G-15
MODULE - REMOVAL, INTEGRATED
POWER..........................8W-97-3
MODULE - REMOVAL, REMOTE KEYLESS
ENTRY..............................8N-7
MODULE - REMOVAL, SENTRY KEY
IMMOBILIZER.......................8E-15
MODULE - REMOVAL, WIPER...........8R-23
MODULE / SWITCH OPERATING MODES,
STANDARD PROCEDURE -
CONFIGURING A NEW.................8Q-3
MODULE LAMP REPLACEMENT -
STANDARD PROCEDURE...............8M-3
MODULE LENS REPLACEMENT -
STANDARD PROCEDURE...............8M-3
MODULE (SKIM) - DESCRIPTION,
SENTRY KEY IMMOBILIZER.............8Q-1
MODULE (SKIM) - OPERATION, SENTRY
KEY IMMOBILIZER
....................8Q-2
MOLDING - INSTALLATION, FRONT
DOOR INNER BELT
...................23-93
MOLDING - INSTALLATION, FRONT
DOOR OUTER BELT
...................23-93
MOLDING - INSTALLATION, REAR DOOR
INNER BELT
.........................23-94
MOLDING - INSTALLATION, REAR DOOR
OUTER BELT
........................23-94
MOLDING - REMOVAL, FRONT DOOR
INNER BELT
.........................23-93
MOLDING - REMOVAL, FRONT DOOR
OUTER BELT
........................23-92
MOLDING - REMOVAL, REAR DOOR
INNER BELT
.........................23-94
MOLDING - REMOVAL, REAR DOOR
OUTER BELT
........................23-93
MOLDINGS - INSTALLATION, BODY SIDE
. . 23-36
MOLDINGS - REMOVAL, BODY SIDE
.....23-36
MONITORED SYSTEMS - DESCRIPTION
....25-2
MONITORS - DESCRIPTION,
COMPONENT
.........................25-4MOTOR - DESCRIPTION, ADJUSTABLE
PEDAL...............................5-6
MOTOR - DESCRIPTION, BLOWER.......24-28
MOTOR - DESCRIPTION, DOOR LOCK.....8N-4
MOTOR - DESCRIPTION, IDLE AIR
CONTROL..........................14-28
MOTOR - DESCRIPTION, LUMBAR.......8N-18
MOTOR - DESCRIPTION, SHIFT . . 21-511,21-541,
21-575
MOTOR - DIAGNOSIS AND TESTING,
BLOWER...........................24-28
MOTOR - DIAGNOSIS AND TESTING,
DOOR LOCK.........................8N-4
MOTOR - DIAGNOSIS AND TESTING,
LUMBAR...........................8N-18
MOTOR - DIAGNOSIS AND TESTING,
STARTER ...........................8F-32
MOTOR - INSTALLATION, ADJUSTABLE
PEDAL...............................5-7
MOTOR - INSTALLATION, BLOWER......24-31
MOTOR - INSTALLATION, IDLE AIR
CONTROL..........................14-29
MOTOR - INSTALLATION, SHIFT . 21-511,21-541,
21-575
MOTOR - INSTALLATION, STARTER......8F-34
MOTOR - OPERATION, BLOWER.........24-28
MOTOR - OPERATION, DOOR LOCK.......8N-4
MOTOR - OPERATION, IDLE AIR
CONTROL..........................14-28
MOTOR - OPERATION, LUMBAR........8N-18
MOTOR - OPERATION, SHIFT.....21-511,21-541,
21-575
MOTOR - REMOVAL, ADJUSTABLE
PEDAL...............................5-7
MOTOR - REMOVAL, BLOWER..........24-31
MOTOR - REMOVAL, IDLE AIR CONTROL . . 14-29
MOTOR - REMOVAL, SHIFT.....21-511,21-541,
21-575
MOTOR - REMOVAL, STARTER..........8F-33
MOTOR - REMOVAL, WINDOW..........8N-20
MOTOR RELAY - DESCRIPTION,
STARTER ...........................8F-35
MOTOR RELAY - INSTALLATION,
STARTER ...........................8F-37
MOTOR RELAY - OPERATION, STARTER . . . 8F-36
MOTOR RELAY - REMOVAL, STARTER....8F-37
MOTOR RESISTOR BLOCK -
DESCRIPTION, BLOWER...............24-18
MOTOR RESISTOR BLOCK - DIAGNOSIS
AND TESTING, BLOWER...............24-19
MOTOR RESISTOR BLOCK -
INSTALLATION, BLOWER..............24-19
MOTOR RESISTOR BLOCK - OPERATION,
BLOWER...........................24-18
MOTOR RESISTOR BLOCK - REMOVAL,
BLOWER...........................24-19
MOTOR SWITCH - DESCRIPTION,
BLOWER...........................24-20
MOTOR SWITCH - DIAGNOSIS AND
TESTING, BLOWER...................24-20
MOTOR SWITCH - OPERATION, BLOWER . . 24-20
MOUNT - INSTALLATION, DISC BRAKE
CALIPER ADAPTER....................5-22
MOUNT - INSTALLATION, FRONT . . . 9-147,9-218,
9-287,9-59
MOUNT - INSTALLATION, REAR
....9-149,9-220,
9-288,9-61
MOUNT - REMOVAL, FRONT
. 9-146,9-217,9-286,
9-58
MOUNT - REMOVAL, REAR
. . 9-149,9-220,9-288,
9-61
MOUNTED STOP LAMP - INSTALLATION,
CENTER HIGH
.......................8L-11
MOUNTED STOP LAMP - REMOVAL,
CENTER HIGH
.......................8L-11
MOUNTED STOP LAMP UNIT -
INSTALLATION, CENTER HIGH
..........8L-11
MOUNTED STOP LAMP UNIT -
REMOVAL, CENTER HIGH
..............8L-11
MOUNTING - STANDARD PROCEDURE,
MATCH
.............................22-3
MUFFLER - 5.9L DIESEL - INSTALLATION
. 11-10
MUFFLER - 5.9L DIESEL - REMOVAL
.....11-10
MUFFLER - INSTALLATION
..............11-9
MUFFLER - REMOVAL
..................11-9
MULTI-FUNCTION SWITCH - DIAGNOSIS
AND TESTING
.......................8L-18MULTI-FUNCTION SWITCH -
INSTALLATION.......................8L-19
MULTI-FUNCTION SWITCH - REMOVAL . . . 8L-19
NAME PLATES - INSTALLATION,
EXTERIOR..........................23-38
NAME PLATES - REMOVAL, EXTERIOR....23-38
NATURAL VAC LEAK DETECTION ASSY -
DESCRIPTION.......................25-23
NATURAL VAC LEAK DETECTION ASSY -
INSTALLATION.......................25-25
NATURAL VAC LEAK DETECTION ASSY -
OPERATION.........................25-23
NATURAL VAC LEAK DETECTION ASSY -
REMOVAL..........................25-24
NAVIGATION - INSTALLATION, ANTENNA . . . 8A-6
NAVIGATION - REMOVAL, ANTENNA......8A-6
NAVIGATION/TELECOMMUNICATION -
DESCRIPTION........................8T-1
NAVIGATION/TELECOMMUNICATION -
OPERATION..........................8T-1
NECK SEAL - DIAGNOSIS AND TESTING,
RADIATOR CAP-TO-FILLER..............7-58
NEW MODULE / SWITCH OPERATING
MODES, STANDARD PROCEDURE -
CONFIGURING A......................8Q-3
NIGHT MIRROR - DESCRIPTION,
AUTOMATIC DAY.....................8N-11
NIGHT MIRROR - DIAGNOSIS AND
TESTING, AUTOMATIC DAY.............8N-11
NIGHT MIRROR - OPERATION,
AUTOMATIC DAY.....................8N-11
NIGHT MIRROR - REMOVAL,
AUTOMATIC DAY......................8N-12
NOISE - DIAGNOSIS AND TESTING,
WIND...............................23-2
NOISE OR VIBRATION - DIAGNOSIS AND
TESTING, TIRE.......................22-7
NOISE SUPPRESSION GROUND STRAP -
DESCRIPTION, RADIO..................8A-9
NOISE SUPPRESSION GROUND STRAP -
INSTALLATION, RADIO................8A-10
NOISE SUPPRESSION GROUND STRAP -
OPERATION, RADIO...................8A-9
NOISE SUPPRESSION GROUND STRAP -
REMOVAL, RADIO.....................8A-9
NON-DEPLOYED SUPPLEMENTAL
RESTRAINTS - STANDARD
PROCEDURE, HANDLING...............8O-6
NON-MONITORED CIRCUITS -
OPERATION..........................25-8
NOZZLE - DESCRIPTION, WASHER......8R-11
NOZZLE - INSTALLATION, WASHER......8R-12
NOZZLE - OPERATION, WASHER........8R-12
NOZZLE - REMOVAL, WASHER..........8R-12
NUMBER - DESCRIPTION, VEHICLE
IDENTIFICATION....................Intro.-1
NV241 GENII - ASSEMBLY, TRANSFER
CASE.............................21-428
NV241 GENII - CLEANING, TRANSFER
CASE.............................21-426
NV241 GENII - DESCRIPTION, TRANSFER
CASE.............................21-415
NV241 GENII - DIAGNOSIS AND
TESTING, TRANSFER CASE............21-416
NV241 GENII - DISASSEMBLY,
TRANSFER CASE....................21-417
NV241 GENII - INSPECTION, TRANSFER
CASE.............................21-426
NV241 GENII - INSTALLATION,
TRANSFER CASE....................21-438
NV241 GENII - OPERATION, TRANSFER
CASE.............................21-415
NV241 GENII - REMOVAL, TRANSFER
CASE.............................21-417
NV241 GENII - TRANSFER CASE........21-438
NV241/NV243 - TRANSFER CASE.......21-439
NV243 - ASSEMBLY, TRANSFER CASE . . . 21-496
NV243 - CLEANING, TRANSFER CASE . . . 21-493
NV243 - DESCRIPTION, TRANSFER CASE . 21-482
NV243 - DIAGNOSIS AND TESTING,
TRANSFER CASE....................21-483
NV243 - DISASSEMBLY, TRANSFER
CASE
.............................21-484
NV243 - INSPECTION, TRANSFER CASE
. . 21-493
NV243 - INSTALLATION, TRANSFER
CASE
.............................21-505
NV243 - OPERATION, TRANSFER CASE
. . 21-483
NV243 - REMOVAL, TRANSFER CASE
....21-484
DRINDEX 21
Description Group-Page Description Group-Page Description Group-Page

RELAY - DESCRIPTION, STARTER
MOTOR............................8F-35
RELAY - DESCRIPTION, TRANSMISSION
CONTROL.........................21-405
RELAY - DESCRIPTION, WIPER
HIGH/LOW..........................8R-20
RELAY - DESCRIPTION, WIPER ON/OFF . . . 8R-24
RELAY - DIAGNOSIS AND TESTING,
PARK LAMP.........................8L-20
RELAY - DIAGNOSIS AND TESTING,
STARTER ...........................8F-36
RELAY - DIAGNOSIS AND TESTING,
WIPER HIGH/LOW...................8R-21
RELAY - DIAGNOSIS AND TESTING,
WIPER ON/OFF......................8R-25
RELAY - INSTALLATION, A/C
COMPRESSOR CLUTCH...............24-14
RELAY - INSTALLATION, FOG LAMP......8L-13
RELAY - INSTALLATION, FUEL HEATER . . . 14-53
RELAY - INSTALLATION, FUEL PUMP.....14-28
RELAY - INSTALLATION, INTAKE AIR
HEATER ............................14-82
RELAY - INSTALLATION, PARK LAMP.....8L-21
RELAY - INSTALLATION, REAR WINDOW
DEFOGGER..........................8G-4
RELAY - INSTALLATION, STARTER
MOTOR............................8F-37
RELAY - INSTALLATION, WIPER
HIGH/LOW..........................8R-22
RELAY - INSTALLATION, WIPER ON/OFF . . 8R-26
RELAY - OPERATION, A/C COMPRESSOR
CLUTCH.............................24-13
RELAY - OPERATION, FOG LAMP........8L-13
RELAY - OPERATION, FUEL HEATER......14-52
RELAY - OPERATION, FUEL PUMP.......14-27
RELAY - OPERATION, INTAKE AIR
HEATER ............................14-82
RELAY - OPERATION, PARK LAMP.......8L-20
RELAY - OPERATION, REAR WINDOW
DEFOGGER..........................8G-3
RELAY - OPERATION, STARTER MOTOR . . . 8F-36
RELAY - OPERATION, TRANSMISSION
CONTROL.........................21-405
RELAY - OPERATION, WIPER HIGH/LOW . . 8R-20
RELAY - OPERATION, WIPER ON/OFF....8R-25
RELAY - REMOVAL, A/C COMPRESSOR
CLUTCH............................24-14
RELAY - REMOVAL, FOG LAMP.........8L-13
RELAY - REMOVAL, FUEL HEATER.......14-52
RELAY - REMOVAL, FUEL PUMP........14-28
RELAY - REMOVAL, INTAKE AIR HEATER . . 14-82
RELAY - REMOVAL, PARK LAMP........8L-21
RELAY - REMOVAL, REAR WINDOW
DEFOGGER..........................8G-3
RELAY - REMOVAL, STARTER MOTOR....8F-37
RELAY - REMOVAL, WIPER HIGH/LOW . . . 8R-21
RELAY - REMOVAL, WIPER ON/OFF......8R-26
RELAYS - DIAGNOSIS AND TESTING,
ASD AND FUEL PUMP..................8I-5
RELEASE - INSTALLATION, TILT LEVER
KNOB..............................19-16
RELEASE - REMOVAL, TILT LEVER KNOB . . 19-16
RELEASE - STANDARD PROCEDURE,
FUEL SYSTEM PRESSURE..............14-2
RELEASE BEARING - INSTALLATION,
CLUTCH
.............................6-10
RELEASE BEARING - REMOVAL, CLUTCH
...6-9
RELEASE CABLE/HANDLE ASSEMBLY -
INSTALLATION, LATCH
................23-47
RELEASE CABLE/HANDLE ASSEMBLY -
REMOVAL, LATCH
....................23-47
RELEASE HANDLE - INSTALLATION
.......5-44
RELEASE HANDLE - REMOVAL
...........5-44
RELEASE HANDLE/LATCH REMOTE -
INSTALLATION
.......................23-17
RELEASE HANDLE/LATCH REMOTE -
REMOVAL
..........................23-17
RELIEF VALVE - CLEANING, OIL
PRESSURE
.........................9-294
RELIEF VALVE - DESCRIPTION, HIGH
PRESSURE
.........................24-48
RELIEF VALVE - INSPECTION, OIL
PRESSURE
.........................9-294
RELIEF VALVE - INSTALLATION, OIL
PRESSURE
.........................9-294
RELIEF VALVE - OPERATION, HIGH
PRESSURE
.........................24-48RELIEF VALVE - REMOVAL, OIL
PRESSURE.........................9-294
REMINDER PROGRAMMING -
STANDARD PROCEDURE, ENHANCED
SEATBELT..........................8J-35
REMOTE - INSTALLATION, RELEASE
HANDLE/LATCH......................23-17
REMOTE - REMOVAL, RELEASE
HANDLE/LATCH......................23-17
REMOTE KEYLESS ENTRY MODULE -
DESCRIPTION........................8N-7
REMOTE KEYLESS ENTRY MODULE -
DIAGNOSIS AND TESTING..............8N-7
REMOTE KEYLESS ENTRY MODULE -
INSTALLATION.......................8N-8
REMOTE KEYLESS ENTRY MODULE -
OPERATION..........................8N-7
REMOTE KEYLESS ENTRY MODULE -
REMOVAL...........................8N-7
REMOTE KEYLESS ENTRY
TRANSMITTER - DIAGNOSIS AND
TESTING............................8N-8
REMOTE KEYLESS ENTRY
TRANSMITTER - SPECIFICATIONS........8N-9
REMOTE SWITCHES - DESCRIPTION.....8A-10
REMOTE SWITCHES - DIAGNOSIS AND
TESTING...........................8A-11
REMOTE SWITCHES - INSTALLATION.....8A-12
REMOTE SWITCHES - OPERATION.......8A-11
REMOTE SWITCHES - REMOVAL........8A-12
REMOVAL/INSTALLATION, REMOVAL.....25-13
REMOVAL/INSTALLATION, REMOVAL.....14-52,
14-57,14-66
REPAIR - DESCRIPTION, THREADED
HOLE.............................Intro.-8
REPAIR - STANDARD PROCEDURE,
ALUMINUM THREAD...........21-158,21-318
REPAIR - STANDARD PROCEDURE, CAM
BORE..............................9-267
REPAIR - STANDARD PROCEDURE,
CYLINDER BORE.....................9-265
REPAIR - STANDARD PROCEDURE, GRID
LINE AND TERMINAL..................8G-4
REPAIR - STANDARD PROCEDURE,
HYDROFORM FENDER RAIL............13-11
REPAIR - STANDARD PROCEDURE,
PLASTIC BODY PANEL.................23-3
REPAIR DAMAGED OR WORN THREADS
- STANDARD PROCEDURE . 9-190,9-240,9-9,9-94
REPAIRING LEAKS - STANDARD
PROCEDURE........................22-10
REQUIREMENTS - DESCRIPTION,
ENGINE COOLING SYSTEM..............24-1
REQUIREMENTS - DIESEL ENGINE -
DESCRIPTION, FUEL....................0-1
RESERVOIR - DESCRIPTION, VACUUM....8P-9
RESERVOIR - DESCRIPTION, WASHER . . . 8R-14
RESERVOIR - DIAGNOSIS AND TESTING,
VACUUM............................8P-9
RESERVOIR - INSTALLATION...........19-47
RESERVOIR - INSTALLATION, FLUID......5-24
RESERVOIR - INSTALLATION, VACUUM . . . 8P-10
RESERVOIR - OPERATION, VACUUM......8P-9
RESERVOIR - OPERATION, WASHER.....8R-15
RESERVOIR - REMOVAL...............19-47
RESERVOIR - REMOVAL, FLUID..........5-23
RESERVOIR - REMOVAL, VACUUM........8P-9
RESERVOIR TO COOLER -
INSTALLATION, RETURN HOSE.....19-44,19-45
RESERVOIR TO COOLER - REMOVAL,
RETURN HOSE.................19-44,19-45
RESISTANCE, 3.7L V-6 - IGNITION COIL....8I-5
RESISTANCE, 4.7L V-8 - IGNITION COIL....8I-5
RESISTANCE, 5.7L V-8 - IGNITION COIL....8I-5
RESISTANCE, SPECIFICATIONS - SPARK
PLUG CABLE.........................8I-4
RESISTOR BLOCK - DESCRIPTION,
BLOWER MOTOR....................24-18
RESISTOR BLOCK - DIAGNOSIS AND
TESTING, BLOWER MOTOR
............24-19
RESISTOR BLOCK - INSTALLATION,
BLOWER MOTOR
....................24-19
RESISTOR BLOCK - OPERATION,
BLOWER MOTOR
....................24-18
RESISTOR BLOCK - REMOVAL, BLOWER
MOTOR
............................24-19
RESTRAINT ANCHOR - DESCRIPTION,
CHILD
.............................8O-15RESTRAINT ANCHOR - INSTALLATION,
CHILD.............................8O-18
RESTRAINT ANCHOR - OPERATION,
CHILD.............................8O-17
RESTRAINT ANCHOR - REMOVAL, CHILD . 8O-17
RESTRAINT DEPLOYMENT - STANDARD
PROCEDURE, SERVICE AFTER A
SUPPLEMENTAL......................8O-7
RESTRAINT SYSTEM - DIAGNOSIS AND
TESTING, SUPPLEMENTAL..............8O-6
RESTRAINT SYSTEM - WARNINGS.......8O-5
RESTRAINTS - DESCRIPTION............8O-2
RESTRAINTS - OPERATION.............8O-4
RESTRAINTS - STANDARD PROCEDURE,
HANDLING NON-DEPLOYED
SUPPLEMENTAL......................8O-6
RETAINER - ASSEMBLY, OVERRUNNING
CLUTCH CAM/OVERDRIVE PISTON......21-237
RETAINER - CLEANING, OVERRUNNING
CLUTCH CAM/OVERDRIVE PISTON......21-236
RETAINER - DESCRIPTION,
OVERRUNNING CLUTCH CAM/
OVERDRIVE PISTON.................21-236
RETAINER - DISASSEMBLY,
OVERRUNNING CLUTCH CAM/
OVERDRIVE PISTON.................21-236
RETAINER - INSPECTION,
OVERRUNNING CLUTCH CAM/
OVERDRIVE PISTON.................21-237
RETAINER - INSTALLATION, A-PILLAR
WEATHERSTRIP.....................23-91
RETAINER - INSTALLATION,
CRANKSHAFT REAR OIL SEAL.....9-210,9-277
RETAINER - INSTALLATION, DRIP RAIL
WEATHERSTRIP.....................23-92
RETAINER - OPERATION, OVERRUNNING
CLUTCH CAM/OVERDRIVE PISTON......21-236
RETAINER - REMOVAL, A-PILLAR
WEATHERSTRIP.....................23-91
RETAINER - REMOVAL, CRANKSHAFT
REAR OIL SEAL.................9-209,9-277
RETAINER - REMOVAL, DRIP RAIL
WEATHERSTRIP.....................23-92
RETAINER/BULKHEAD - ASSEMBLY, 4C . . 21-363
RETAINER/BULKHEAD - DISASSEMBLY,
4C ...............................21-362
RETRACTOR - DESCRIPTION,
AUTOMATIC LOCKING.................8O-14
RETRACTOR - INSTALLATION, FRONT
CENTER SEAT BELT..................8O-29
RETRACTOR - INSTALLATION, REAR
CENTER SEAT BELT..................8O-45
RETRACTOR - INSTALLATION, REAR
OUTBOARD SEAT BELT................8O-47
RETRACTOR - OPERATION, AUTOMATIC
LOCKING...........................8O-14
RETRACTOR - REMOVAL, FRONT
CENTER SEAT BELT..................8O-29
RETRACTOR - REMOVAL, REAR CENTER
SEAT BELT .........................8O-44
RETRACTOR - REMOVAL, REAR
OUTBOARD SEAT BELT................8O-46
RETURN - DESCRIPTION, SENSOR.......8E-10
RETURN HOSE - GEAR TO COOLER -
INSTALLATION..................19-44,19-45
RETURN HOSE - GEAR TO COOLER -
REMOVAL.....................19-44,19-45
RETURN HOSE - INSTALLATION, HEATER . 24-65
RETURN HOSE - REMOVAL, HEATER.....24-64
RETURN HOSE - RESERVOIR TO
COOLER - INSTALLATION.........19-44,19-45
RETURN HOSE - RESERVOIR TO
COOLER - REMOVAL.............19-44,19-45
REVOLUTIONS PER MILE,
SPECIFICATIONS - TIRE...............22-10
RFE TRANSMISSION, SPECIAL TOOLS . . . 21-359
RING - INSTALLATION, PINION
GEAR/RING GEAR/TONE.....3-108,3-137,3-164
RING - REMOVAL, PINION GEAR/RING
GEAR/TONE...............3-106,3-134,3-162
RING FITTING - STANDARD
PROCEDURE, PISTON . . . 9-142,9-213,9-284,9-53
RINGS - ASSEMBLY, WITH INJECTED
......3-13
RINGS - ASSEMBLY, WITH SNAP
.........3-12
RINGS - DISASSEMBLY, WITH INJECTED
. . . 3-11
RINGS - DISASSEMBLY, WITH SNAP
......3-10
RKE TRANSMITTER BATTERIES -
STANDARD PROCEDURE
...............8N-8
DRINDEX 27
Description Group-Page Description Group-Page Description Group-Page

SUPPLEMENTAL RESTRAINTS -
STANDARD PROCEDURE, HANDLING
NON-DEPLOYED......................8O-6
SUPPLIES - DESCRIPTION, 5 VOLT......8E-10
SUPPLIES - OPERATION, 5 VOLT........8E-11
SUPPLY TEST - DIAGNOSIS AND
TESTING, VACUUM....................8P-2
SUPPORT - INSTALLATION, SUN VISOR . . . 23-71
SUPPORT - REMOVAL, SUN VISOR......23-70
SUPPORT BRACKET - INSTALLATION,
REAR VIEW MIRROR.................23-70
SUPPORT BRACKET - INSTALLATION,
STEERING COLUMN OPENING..........23-60
SUPPORT BRACKET - REMOVAL,
STEERING COLUMN OPENING..........23-60
SUPPORT CYLINDER - INSTALLATION....23-48
SUPPORT CYLINDER - INSTALLATION,
LOAD FLOOR........................23-72
SUPPORT CYLINDER - REMOVAL........23-48
SUPPORT CYLINDER - REMOVAL, LOAD
FLOOR.............................23-72
SUPPORT HANDLE/BEZEL -
INSTALLATION, LUMBAR..............23-82
SUPPORT HANDLE/BEZEL - REMOVAL,
LUMBAR...........................23-82
SUPPORT PLATE - INSTALLATION........5-36
SUPPORT PLATE - REMOVAL............5-35
SUPPRESSION GROUND STRAP -
DESCRIPTION, RADIO NOISE............8A-9
SUPPRESSION GROUND STRAP -
INSTALLATION, RADIO NOISE...........8A-10
SUPPRESSION GROUND STRAP -
OPERATION, RADIO NOISE..............8A-9
SUPPRESSION GROUND STRAP -
REMOVAL, RADIO NOISE...............8A-9
SURFACE PREPARATION - STANDARD
PROCEDURE, ENGINE GASKET...........9-10
SURROUND - INSTALLATION,
INSTRUMENT PANEL LOWER...........23-59
SURROUND - REMOVAL, INSTRUMENT
PANEL LOWER......................23-59
SUSPENSION - DESCRIPTION, GEAR -
INDEPENDENT FRONT.................19-17
SUSPENSION - INSTALLATION, GEAR -
INDEPENDENT FRONT.................19-18
SUSPENSION - REMOVAL, GEAR -
INDEPENDENT FRONT.................19-17
SUSPENSION - STANDARD PROCEDURE,
ALIGNMENT LINK/COIL..................2-5
SUSPENSION ARM - INSTALLATION,
LOWER.............................2-38
SUSPENSION ARM - REMOVAL, LOWER . . . 2-38
SUSPENSION, SPECIAL TOOLS - FRONT . . . 2-12
SWITCH - DESCRIPTION................8P-7
SWITCH - DESCRIPTION, BACKUP LAMP . . . 8L-8
SWITCH - DESCRIPTION, BLOWER
MOTOR............................24-20
SWITCH - DESCRIPTION, BRAKE LAMP....8L-9
SWITCH - DESCRIPTION, CLUTCH
PEDAL POSITION.....................6-13
SWITCH - DESCRIPTION, DOOR AJAR....8L-27
SWITCH - DESCRIPTION, DRIVER SEAT . . . 8N-14
SWITCH - DESCRIPTION, HAZARD.......8L-14
SWITCH - DESCRIPTION, HEADLAMP....8L-14
SWITCH - DESCRIPTION, HEATED SEAT . . 8G-11
SWITCH - DESCRIPTION, HORN
..........8H-2
SWITCH - DESCRIPTION, IGNITION
.......19-9
SWITCH - DESCRIPTION, KEY-IN
IGNITION
...........................19-11
SWITCH - DESCRIPTION, LUMBAR
CONTROL
..........................8N-17
SWITCH - DESCRIPTION, PASSENGER
AIRBAG ON/OFF
.....................8O-42
SWITCH - DESCRIPTION, PASSENGER
SEAT
..............................8N-15
SWITCH - DESCRIPTION, POWER
STEERING PRESSURE
.................19-46
SWITCH - DESCRIPTION, PTO
.....14-36,14-85
SWITCH - DESCRIPTION, REAR
WINDOW DEFOGGER
..................8G-4
SWITCH - DESCRIPTION, SEAT BELT
.....8O-51
SWITCH - DESCRIPTION, SELECTOR
....21-510,
21-539,21-574
SWITCH - DESCRIPTION, TOW/HAUL
OVERDRIVE
..................21-261,21-392
SWITCH - DESCRIPTION, WASHER
FLUID LEVEL
.........................8R-9SWITCH - DIAGNOSIS AND TESTING,
BACKUP LAMP.......................8L-8
SWITCH - DIAGNOSIS AND TESTING,
BLOWER MOTOR....................24-20
SWITCH - DIAGNOSIS AND TESTING,
BRAKE LAMP.......................8L-10
SWITCH - DIAGNOSIS AND TESTING,
CLUTCH PEDAL POSITION..............6-13
SWITCH - DIAGNOSIS AND TESTING,
DRIVER SEAT.......................8N-14
SWITCH - DIAGNOSIS AND TESTING,
HEATED SEAT .......................8G-12
SWITCH - DIAGNOSIS AND TESTING,
HORN..............................8H-2
SWITCH - DIAGNOSIS AND TESTING,
IGNITION............................19-9
SWITCH - DIAGNOSIS AND TESTING,
MULTI-FUNCTION....................8L-18
SWITCH - DIAGNOSIS AND TESTING,
PASSENGER SEAT....................8N-16
SWITCH - DIAGNOSIS AND TESTING,
POWER LOCK........................8N-4
SWITCH - DIAGNOSIS AND TESTING,
POWER MIRROR....................8N-12
SWITCH - DIAGNOSIS AND TESTING,
SEAT BELT .........................8O-51
SWITCH - DIAGNOSIS AND TESTING,
WINDOW...........................8N-20
SWITCH - INSTALLATION...............8P-8
SWITCH - INSTALLATION, ADJUSTABLE
PEDAL...............................5-6
SWITCH - INSTALLATION, BRAKE LAMP . . 8L-11
SWITCH - INSTALLATION, DRIVER SEAT . . . 8N-15
SWITCH - INSTALLATION, HEADLAMP....8L-15
SWITCH - INSTALLATION, HEATED SEAT . . 8G-13
SWITCH - INSTALLATION, IGNITION......19-11
SWITCH - INSTALLATION, MULTI-
FUNCTION..........................8L-19
SWITCH - INSTALLATION, OIL
PRESSURE.........................9-294
SWITCH - INSTALLATION, PASSENGER
AIRBAG ON/OFF.....................8O-44
SWITCH - INSTALLATION, PASSENGER
SEAT ..............................8N-16
SWITCH - INSTALLATION, POWER LOCK . . . 8N-4
SWITCH - INSTALLATION, TOW/HAUL
OVERDRIVE..................21-262,21-393
SWITCH - INSTALLATION, WASHER
FLUID LEVEL........................8R-11
SWITCH - INSTALLATION, WINDOW.....8N-21
SWITCH - OPERATION.................8P-7
SWITCH - OPERATION, BACKUP LAMP....8L-8
SWITCH - OPERATION, BLOWER MOTOR . . 24-20
SWITCH - OPERATION, BRAKE LAMP......8L-9
SWITCH - OPERATION, CLUTCH PEDAL
POSITION...........................6-13
SWITCH - OPERATION, DOOR AJAR......8L-27
SWITCH - OPERATION, DRIVER SEAT....8N-14
SWITCH - OPERATION, HAZARD.........8L-14
SWITCH - OPERATION, HEADLAMP......8L-14
SWITCH - OPERATION, HEATED SEAT....8G-12
SWITCH - OPERATION, IGNITION.........19-9
SWITCH - OPERATION, LUMBAR
CONTROL..........................8N-18
SWITCH - OPERATION, PASSENGER
AIRBAG ON/OFF.....................8O-43
SWITCH - OPERATION, PASSENGER
SEAT ..............................8N-15
SWITCH - OPERATION, POWER
STEERING PRESSURE.................19-46
SWITCH - OPERATION, PTO.......14-36,14-85
SWITCH - OPERATION, REAR WINDOW
DEFOGGER..........................8G-4
SWITCH - OPERATION, SEAT BELT.......8O-51
SWITCH - OPERATION, SELECTOR.....21-510,
21-540,21-574
SWITCH - OPERATION, TOW/HAUL
OVERDRIVE..................21-262,21-392
SWITCH - OPERATION, WASHER FLUID
LEVEL..............................8R-9
SWITCH - REMOVAL...................8P-8
SWITCH - REMOVAL, ADJUSTABLE
PEDAL...............................5-6
SWITCH - REMOVAL, BRAKE LAMP
......8L-10
SWITCH - REMOVAL, DRIVER SEAT
......8N-15
SWITCH - REMOVAL, HEADLAMP
........8L-14
SWITCH - REMOVAL, HEATED SEAT
......8G-13
SWITCH - REMOVAL, IGNITION
.........19-10SWITCH - REMOVAL, LUMBAR
CONTROL..........................8N-18
SWITCH - REMOVAL, MULTI-FUNCTION . . . 8L-19
SWITCH - REMOVAL, OIL PRESSURE.....9-294
SWITCH - REMOVAL, PASSENGER
AIRBAG ON/OFF.....................8O-43
SWITCH - REMOVAL, PASSENGER SEAT . . 8N-16
SWITCH - REMOVAL, POWER LOCK......8N-4
SWITCH - REMOVAL, POWER MIRROR . . . 8N-12
SWITCH - REMOVAL, TOW/HAUL
OVERDRIVE..................21-262,21-392
SWITCH - REMOVAL, WASHER FLUID
LEVEL.............................8R-10
SWITCH - REMOVAL, WINDOW.........8N-20
SWITCH AND KEY LOCK CYLINDER -
DIAGNOSIS AND TESTING, IGNITION.....19-11
SWITCH BEZEL - INSTALLATION,
INSTRUMENT PANEL HEADLAMP........23-56
SWITCH BEZEL - REMOVAL,
INSTRUMENT PANEL HEADLAMP........23-56
SWITCH OPERATING MODES,
STANDARD PROCEDURE -
CONFIGURING A NEW MODULE..........8Q-3
SWITCH VALVE - DESCRIPTION,
SOLENOID.........................21-398
SWITCH VALVE - OPERATION, SOLENOID . 21-398
SWITCHES - DESCRIPTION, REMOTE.....8A-10
SWITCHES - DIAGNOSIS AND TESTING,
REMOTE...........................8A-11
SWITCHES - INSTALLATION, REMOTE....8A-12
SWITCHES - OPERATION, REMOTE........8A-11
SWITCHES - REMOVAL, REMOTE........8A-12
SYMBOLS - DESCRIPTION,
INTERNATIONAL....................Intro.-5
TACHOMETER - DESCRIPTION..........8J-38
TACHOMETER - OPERATION............8J-38
TAILGATE - INSTALLATION.............23-17
TAILGATE - REMOVAL.................23-17
TAILGATE MARKER LAMP -
INSTALLATION.......................8L-18
TAILGATE MARKER LAMP - REMOVAL....8L-18
TAILPIPE - 5.9L DIESEL - INSPECTION....11-10
TAILPIPE - 5.9L DIESEL - INSTALLATION . . 11-11
TAILPIPE - 5.9L DIESEL - REMOVAL.....11-10
TAILPIPE - INSPECTION...............11-11
TAILPIPE - INSTALLATION..............11-11
TAILPIPE - REMOVAL.................11-11
TANK - DESCRIPTION, FUEL............14-17
TANK - OPERATION, FUEL..............14-17
TANK MODULE - DESCRIPTION, FUEL....14-63
TANK MODULE - INSTALLATION, FUEL....14-64
TANK MODULE - OPERATION, FUEL......14-63
TANK MODULE - REMOVAL, FUEL.......14-63
TAPPETS - DIAGNOSIS AND TESTING,
HYDRAULIC.........................9-210
TAPPETS - INSTALLATION, HYDRAULIC . . . 9-211
TAPPETS - REMOVAL, HYDRAULIC.......9-211
TASK MANAGER - DESCRIPTION.........25-1
TASK MANAGER - OPERATION...........25-5
TCM QUICK LEARN - STANDARD
PROCEDURE........................8E-23
TEMP INDICATOR - DESCRIPTION,
TRANS.............................8J-40
TEMP INDICATOR - OPERATION, TRANS
. . 8J-40
TEMP SENSOR - DESCRIPTION,
AMBIENT
..........................8M-10
TEMP SENSOR - OPERATION, AMBIENT
. . 8M-10
TEMPERATURE GAUGE - DESCRIPTION,
ENGINE
............................8J-24
TEMPERATURE GAUGE - OPERATION,
ENGINE
............................8J-24
TEMPERATURE SENSOR - DESCRIPTION,
BATTERY
...........................8F-21
TEMPERATURE SENSOR - DESCRIPTION,
ENGINE COOLANT
.....................7-38
TEMPERATURE SENSOR - DESCRIPTION,
EVAPORATOR
.......................24-22
TEMPERATURE SENSOR - DESCRIPTION,
INTAKE AIR
.........................14-30
TEMPERATURE SENSOR - DESCRIPTION,
TRANSMISSION
...............21-267,21-408
TEMPERATURE SENSOR - DIAGNOSIS
AND TESTING, AMBIENT
..............8M-10
TEMPERATURE SENSOR -
INSTALLATION, BATTERY
..............8F-21
TEMPERATURE SENSOR -
INSTALLATION, ENGINE COOLANT
........7-41
32 INDEXDR
Description Group-Page Description Group-Page Description Group-Page
