BLOWER MOTOR SWITCH
DESCRIPTION
The blower motor is controlled by a rotary-type
blower motor switch, mounted in the A/C-heater con-
trol. The switch allows the selection of one of four
different blower motor speeds and includes an Off
position.
OPERATION
The blower motor switch provides a blower motor
ground path through the A/C-heater mode control
switch. The blower motor switch directs this ground
path through or around the blower motor resistor
wires, as required to achieve the selected blower
motor speed.
The blower motor switch cannot be repaired and, if
faulty or damaged, the entire A/C-heater control
must be replaced.
DIAGNOSIS AND TESTING - BLOWER MOTOR
SWITCH
For circuit descriptions and diagrams, refer to the
appropriate wiring information. The wiring informa-
tion includes wiring diagrams, proper wire and con-
nector repair procedures, further details on wire
harness routing and retention, as well as pin-out and
location views for the various wire harness connec-
tors, splices and grounds.
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE AIRBAG SYSTEM BEFORE
ATTEMPTING ANY STEERING WHEEL, STEERING
COLUMN, OR INSTRUMENT PANEL COMPONENT
DIAGNOSIS OR SERVICE. DISCONNECT AND ISO-LATE THE BATTERY NEGATIVE (GROUND) CABLE,
THEN WAIT TWO MINUTES FOR THE AIRBAG SYS-
TEM CAPACITOR TO DISCHARGE BEFORE PER-
FORMING FURTHER DIAGNOSIS OR SERVICE. THIS
IS THE ONLY SURE WAY TO DISABLE THE AIRBAG
SYSTEM. FAILURE TO TAKE THE PROPER PRE-
CAUTIONS COULD RESULT IN AN ACCIDENTAL
AIRBAG DEPLOYMENT AND POSSIBLE PERSONAL
INJURY.
(1) Check for battery voltage at the fuse in the
Power Distribution Center (PDC). If OK, go to Step
2. If not OK, repair the shorted circuit or component
as required and replace the faulty fuse.
(2) Turn the ignition switch to the Off position.
Disconnect and isolate the battery negative cable.
Remove the A/C-heater control from the instrument
panel (Refer to 24 - HEATING & AIR CONDITION-
ING/CONTROLS/A/C HEATER CONTROL -
REMOVAL). Check for continuity between the
ground circuit cavity of the A/C-heater control wire
harness connector and a good ground. There should
be continuity. If OK, go to Step 3. If not OK, repair
the open circuit to ground as required.
(3) With the A/C-heater control wire harness con-
nector disconnected, place the A/C-heater mode con-
trol switch in any position except the Off position.
Check for continuity between the ground circuit ter-
minal and each of the blower motor driver circuit ter-
minals of the A/C-heater control as you move the
blower motor switch to each of the four speed posi-
tions. There should be continuity at each driver cir-
cuit terminal in only one blower motor switch speed
position. If OK, test and repair the blower driver cir-
cuits between the A/C-heater control connector and
the blower motor resistor as required. If not OK,
replace the faulty A/C-heater control.
DEFROST DOOR ACTUATOR
DESCRIPTION
The defrost door actuator is a reversible, 12-volt
Direct Current (DC), servo motor. The defrost door
actuator is located on the driver side end of the
HVAC housing, underneath the instrument panel
and is mechanically connected to the defroster door.
The defrost door actuator is interchangeable with
the actuators for the mode door, blend door(s) and
the recirculation door. Each actuator is contained
within an identical black molded plastic housing with
an integral wire connector receptacle. Integral
mounting tabs allow the actuator to be secured with
three screws to the HVAC housing. Each actuator
also has an identical output shaft with splines that
connects it to the linkage that drives the proper door.
The defrost door actuator does not require mechani-
Fig. 18 A/C-Heater Control - Single Zone Shown,
Dual Zone Typical
1 - MOUNTING TAB (4)
2 - A/C BUTTON
3 - SIDEVIEW MIRROR DEFROSTER BUTTON (IF EQUIPED)
4 - MODE CONTROL SWITCH
5 - TEMPERATURE CONTROL SWITCH
6 - BLOWER MOTOR SWITCH
24 - 20 CONTROLSDR

(5) Install the HVAC housing (Refer to 24 - HEAT-
ING & AIR CONDITIONING/DISTRIBUTION/HVAC
HOUSING - INSTALLATION)
BLOWER MOTOR
DESCRIPTION
The blower motor and blower wheel are located in
the passenger side end of the HVAC housing, below
the glove box. The blower motor controls the velocity
of air flowing through the HVAC housing by spinning
a squirrel cage-type blower wheel within the housing
at the selected speed. The blower motor and wheel
can be removed from the housing inside the vehicle
without removing the instrument panel or HVAC
housing.
OPERATION
The blower motor will only operate with the igni-
tion switch in the On position and the A/C-heater
mode control switch in any position, except Off. The
blower motor receives a fused battery feed circuit
through a fuse in the Power Distribution Center
(PDC) whenever the ignition switch is in the On posi-
tion. Blower motor speed is controlled by regulating
the ground path through or around the blower motor
resistor block and through the A/C-heater blower
motor switch.
The blower motor and blower motor wheel are ser-
viced only as a unit and cannot be repaired and, if
faulty or damaged, must be replaced.
DIAGNOSIS AND TESTING - BLOWER MOTOR
BLOWER MOTOR INOPERATIVE
WARNING: ON VEHICLES EQUIPPED WITH AIR-
BAGS, DISABLE THE AIRBAG SYSTEM BEFORE
ATTEMPTING ANY STEERING WHEEL, STEERING
COLUMN, OR INSTRUMENT PANEL COMPONENT
DIAGNOSIS OR SERVICE. DISCONNECT AND ISO-
LATE THE BATTERY NEGATIVE (GROUND) CABLE,
THEN WAIT TWO MINUTES FOR THE AIRBAG SYS-
TEM CAPACITOR TO DISCHARGE BEFORE PER-
FORMING FURTHER DIAGNOSIS OR SERVICE. THIS
IS THE ONLY SURE WAY TO DISABLE THE AIRBAG
SYSTEM. FAILURE TO TAKE THE PROPER PRE-
CAUTIONS COULD RESULT IN ACCIDENTAL AIR-
BAG DEPLOYMENT AND POSSIBLE PERSONAL
INJURY.
For circuit descriptions and diagrams, refer to the
appropriate wiring information. The wiring informa-
tion includes wiring, diagrams, proper wire and con-
nector repair procedures, further details on wire
harness routing and retention, as well as pin-out and
location views for the various wire harness connec-
tors, splices and grounds.
BLOWER MOTOR ELECTRICAL DIAGNOSIS
Refer to the Blower Motor Electrical Diagnosis
chart for basic checks of the blower motor circuit
(Fig. 3).
BLOWER MOTOR NOISE OR VIBRATION
Refer to the Blower Motor Noise/Vibration Diagno-
sis chart for basic checks of the blower motor when a
vibration or noise is present (Fig. 4).
24 - 28 DISTRIBUTIONDR
BLEND DOOR (Continued)

STANDARD PROCEDURE
STANDARD PROCEDURE - HANDLING TUBING
AND FITTINGS
CAUTION: The system must be completely empty
before opening any fitting or connection in the
refrigeration system. Open fittings with caution
even after the system has been emptied. If any
pressure is noticed as a fitting is loosened,
retighten fitting and evacuate the system again.
A good rule for the flexible hose lines is to keep the
radius of all bends at least 10 times the diameter of
the hose. Sharper bends will reduce the flow of
refrigerant. The flexible hose lines should be routed
so they are at least 3 inches (80 mm) from the
exhaust manifold. Inspect all flexible hose lines to
make sure they are in good condition and properly
routed.
The use of correct wrenches when making connec-
tions is very important. Improper wrenches or
improper use of wrenches can damage the fittings.
The internal parts of the A/C system will remain sta-
ble as long as moisture-free refrigerant and refrig-
erant oil is used. Abnormal amounts of dirt,
moisture or air can upset the chemical stability.
This may cause operational troubles or even seri-
ous damage if present in more than very small
quantities. Before disconnecting a component,
clean the outside of the fittings thoroughly to pre-
vent contamination from entering the refrigerant
system.
When opening a refrigeration system, have every-
thing you will need to repair the system ready. This
will minimize the amount of time the system must
be opened. Cap or plug all lines and fittings as
soon as they are opened. This will help prevent the
entrance of dirt and moisture. All new lines and
components should be capped or sealed until they
are ready to be used. Before connecting a compo-
nent, clean the outside of the fittings thoroughly to
prevent contamination from entering the refrigerant
system.
All tools, including the refrigerant dispensing mani-
fold, the manifold gauge set, and test hoses should
be kept clean and dry.
Kinks in the refrigerant tubing or sharp bends in
the refrigerant hose lines will greatly reduce the
capacity of the entire system. High pressures are pro-
duced in the system when it is operating. Extreme
care must be exercised to make sure that all connec-
tions are pressure tight. Dirt and moisture can enter
the system when it is opened for repair or replace-
ment of lines or components. The refrigerant oil willabsorb moisture readily out of the air. This moisture
will convert into acids within a closed system.
STANDARD PROCEDURE - DIODE
REPLACEMENT
(1) Disconnect and isolate the battery negative
cable. If the vehicle has dual batteries, remove the
negative cable from both batteries.
(2) Locate the diode in the harness, and remove
the protective covering.
(3) Remove the diode from the harness. Note the
direction of current flow (Fig. 1).
(4) Remove the insulation from the wires in the
harness. Only remove enough insulation to solder in
the new diode.
(5) Install the new diode in the harness, making
sure current flow is correct. If necessary refer to the
appropriate wiring diagram for current flow.
(6) Solder the connections together using rosin
core type solder only.Do not use acid core solder.
(7) Tape the diode to the harness using electrical
tape. Make sure the diode is completely sealed from
the elements.
(8) Reconnect the battery negative cable(s) and
test the affected systems.
Fig. 1 Diode Identification
1 - CURRENT FLOW
2 - BAND INDICATES CURRENT FLOW
3 - DIODE AS SHOWN IN WIRING DIAGRAMS
DRPLUMBING 24 - 45
PLUMBING (Continued)

After the system has been tested for leaks and
evacuated, a refrigerant (R-134a) charge can be
injected into the system.
NOTE: When connecting the service equipment
coupling to the line fitting, verify that the valve of
the coupling is fully closed. This will reduce the
amount of effort required to make the connection.
(1) If using a separate vacuum pump close all
valves before disconnecting pump. Connect manifold
gauge set to the A/C service ports.
NOTE: Always refer to the underhood HVAC Speci-
fication label for the refrigerant fill level of the vehi-
cle being serviced.
(2) Measure refrigerant (refer to capacities). Refer
to the instructions provided with the equipment
being used.
(3) Verify engine is shut off. Open the suction and
discharge valves. Open the charge valve to allow the
refrigerant to flow into the system. When the trans-
fer of refrigerant has stopped, close the suction and
discharge valve.
(4) If all of the charge did not transfer from the
dispensing device, put vehicle controls into the fol-
lowing mode:
²Automatic transmission in park or manual
transmission in neutral
²Engine at idle
²A/C mode control set to outside air
²A/C mode control set to panel mode
²A/C temperature control set to full cool
²Blower motor control set on highest speed
²Vehicle windows closed
If the A/C compressor does not engage, test the
compressor clutch control circuit and correct any fail-
ure (Refer to 8 - ELECTRICAL/WIRING DIAGRAM
INFORMATION - DIAGNOSIS AND TESTING).
(5) Open the suction valve to allow the remaining
refrigerant to transfer to the system.
WARNING: TAKE CARE NOT TO OPEN THE DIS-
CHARGE (HIGH-PRESSURE) VALVE AT THIS TIME.
(6) Close all valves and test the A/C system perfor-
mance.
(7) Disconnect the charging station or manifold
gauge set. Install the service port caps.
REFRIGERANT CHARGE CAPACITY
The R-134a refrigerant system charge capacity for
this vehicle can be found on the underhood HVAC
specfication tag.
A/C COMPRESSOR
DESCRIPTION
DESCRIPTION - A/C COMPRESSOR
The A/C system on models equipped with the 5.9L
engine use a Sanden SD-7 reciprocating swash plate-
type compressor. This compressor has a fixed dis-
placement of 165 cubic centimeter (10.068 cubic
inches) and has both the suction and discharge ports
located on the cylinder head.
The A/C system on models equipped with the 3.7L,
4.7L and 5.7L engines use a Denso 10S17 reciprocat-
ing swash plate-type compressor. This compressor
has a fixed displacement of 170 cubic centimeter and
has both the suction and discharge ports located on
the cylinder head.
A label identifying the use of R-134a refrigerant is
located on both A/C compressors.
DESCRIPTION - HIGH PRESSURE RELIEF
VALVE
A high pressure relief valve is located on the com-
pressor cylinder head, which is on the rear of the
compressor. This mechanical valve is designed to
vent refrigerant from the system to protect against
damage to the compressor and other system compo-
nents, caused by condenser air flow restriction or an
overcharge of refrigerant.
OPERATION
OPERATION - A/C COMPRESSOR
The A/C compressor is driven by the engine
through an electric clutch, drive pulley and belt
arrangement. The compressor is lubricated by refrig-
erant oil that is circulated throughout the refrigerant
system with the refrigerant.
The compressor draws in low-pressure refrigerant
vapor from the evaporator through its suction port. It
then compresses the refrigerant into a high-pressure,
high-temperature refrigerant vapor, which is then
pumped to the condenser through the compressor dis-
charge port.
The compressor cannot be repaired. If faulty or
damaged, the entire compressor assembly must be
replaced. The compressor clutch, pulley and clutch
coil are available for service.
OPERATION - HIGH PRESSURE RELIEF VALVE
The high pressure relief valve vents the system
when a discharge pressure of 3445 to 4135 kPa (500
to 600 psi) or above is reached. The valve closes
24 - 48 PLUMBINGDR
PLUMBING (Continued)

DEPLOYMENT - STANDARD
PROCEDURE, SERVICE AFTER A
SUPPLEMENTAL RESTRAINT............8O-7
DETECTION ASSY - DESCRIPTION,
NATURAL VAC LEAK..................25-23
DETECTION ASSY - INSTALLATION,
NATURAL VAC LEAK..................25-25
DETECTION ASSY - OPERATION,
NATURAL VAC LEAK..................25-23
DETECTION ASSY - REMOVAL, NATURAL
VAC LEAK..........................25-24
DETECTION PUMP - DESCRIPTION, LEAK . 25-13
DETECTION PUMP - INSTALLATION,
LEAK..............................25-16
DETECTION PUMP - OPERATION, LEAK . . . 25-14
DETECTION PUMP - REMOVAL, LEAK....25-16
DEVICES - STANDARD PROCEDURE,
ELECTROSTATIC DISCHARGE (ESD)
SENSITIVE........................8W-01-8
DIAGNOSTIC TROUBLE CODES -
DESCRIPTION........................25-1
DIAGNOSTICS (OBD) - DIAGNOSIS AND
TESTING, ON-BOARD...................7-5
DIAGRAMS - DESCRIPTION, HOW TO
USE WIRING......................8W-01-1
DIAGRAMS - HYDRAULIC SCHEMATICS,
SCHEMATICS.................21-176,21-337
DIESEL - CLEANING, RADIATOR - 5.9L....7-56
DIESEL - CLEANING, RADIATOR FAN -
5.9L................................7-35
DIESEL - CLEANING, WATER PUMP -
5.9L................................7-62
DIESEL - DESCRIPTION.................14-62
DIESEL - DESCRIPTION, 5.9L............11-3
DIESEL - DESCRIPTION, BELT
TENSIONER - 5.9L.....................7-23
DIESEL - DESCRIPTION, COOLING
SYSTEM FLOW - 5.9L...................7-3
DIESEL - DESCRIPTION, ENGINE 5.9L....9-232
DIESEL - DESCRIPTION, ENGINE BLOCK
HEATER - 5.9L........................7-37
DIESEL - DESCRIPTION, ENGINE
COOLANT THERMOSTAT - 5.9L...........7-46
DIESEL - DESCRIPTION, FAN DRIVE
VISCOUS CLUTCH - 5.9L...............7-52
DIESEL - DESCRIPTION, RADIATOR -
5.9L................................7-56
DIESEL - DESCRIPTION, TRANS COOLER
- 5.9L..............................7-68
DIESEL - DESCRIPTION, WATER PUMP -
5.9L................................7-62
DIESEL - FUEL INJECTOR FIRING ORDER . 14-48
DIESEL - INSPECTION, RADIATOR - 5.9L . . . 7-56
DIESEL - INSPECTION, RADIATOR FAN -
5.9L................................7-35
DIESEL - INSPECTION, TAILPIPE - 5.9L . . . 11-10
DIESEL - INSPECTION, WATER PUMP -
5.9L................................7-62
DIESEL - INSTALLATION................11-8
DIESEL - INSTALLATION...............14-62
DIESEL - INSTALLATION.....19-26,19-31,19-42
DIESEL - INSTALLATION, BELT
TENSIONER - 5.9L.....................7-24
DIESEL - INSTALLATION, DRIVE BELT -
5.9L
................................7-29
DIESEL - INSTALLATION, ENGINE BLOCK
HEATER - 5.9L
........................7-38
DIESEL - INSTALLATION, ENGINE
COOLANT THERMOSTAT - 5.9L
...........7-47
DIESEL - INSTALLATION, EXCEPT
........14-19
DIESEL - INSTALLATION, MUFFLER -
5.9L
...............................11-10
DIESEL - INSTALLATION, RADIATOR -
5.9L
................................7-57
DIESEL - INSTALLATION, RADIATOR FAN
- 5.9L
..............................7-36
DIESEL - INSTALLATION, TAILPIPE - 5.9L
. 11-11
DIESEL - INSTALLATION, WATER PUMP -
5.9L
................................7-62
DIESEL - MAINTENANCE SCHEDULES,
24-VALVE CUMMINS TURBO
.............0-12
DIESEL - OPERATION, BELT TENSIONER
- 5.9L
..............................7-23
DIESEL - OPERATION, ENGINE BLOCK
HEATER - 5.9L
........................7-38
DIESEL - OPERATION, ENGINE COOLANT
THERMOSTAT - 5.9L
...................7-46DIESEL - OPERATION, FAN DRIVE
VISCOUS CLUTCH - 5.9L...............7-52
DIESEL - OPERATION, RADIATOR - 5.9L . . . 7-56
DIESEL - OPERATION, TRANS COOLER -
5.9L................................7-69
DIESEL - OPERATION, WATER PUMP -
5.9L................................7-62
DIESEL - REMOVAL....................11-7
DIESEL - REMOVAL...................14-62
DIESEL - REMOVAL.........19-25,19-30,19-41
DIESEL - REMOVAL, BELT TENSIONER -
5.9L................................7-23
DIESEL - REMOVAL, DRIVE BELT - 5.9L....7-29
DIESEL - REMOVAL, ENGINE BLOCK
HEATER - 5.9L........................7-38
DIESEL - REMOVAL, ENGINE COOLANT
THERMOSTAT - 5.9L...................7-47
DIESEL - REMOVAL, EXCEPT...........14-17
DIESEL - REMOVAL, MUFFLER - 5.9L.....11-10
DIESEL - REMOVAL, RADIATOR - 5.9L.....7-56
DIESEL - REMOVAL, RADIATOR FAN -
5.9L................................7-35
DIESEL - REMOVAL, TAILPIPE - 5.9L.....11-10
DIESEL - REMOVAL, WATER PUMP -
5.9L................................7-62
DIESEL - SPECIFICATIONS, 5.9L.........9-244
DIESEL - TORQUE, FUEL SYSTEM -
EXCEPT.............................14-3
DIESEL ENGINE - DESCRIPTION, FUEL
REQUIREMENTS.......................0-1
DIESEL ENGINE - DIAGNOSIS AND
TESTING............................11-5
DIESEL ENGINE - DIAGNOSIS AND
TESTING, COOLING SYSTEM.............7-7
DIESEL ENGINE - INSTALLATION........8R-17
DIESEL ENGINE - INSTALLATION, 5.9L . . . 24-54,
24-58,24-72
DIESEL ENGINE - INSTALLATION,
EXCEPT............................8R-17
DIESEL ENGINE - REMOVAL............8R-16
DIESEL ENGINE - REMOVAL, 5.9L . . 24-53,24-56,
24-70
DIESEL ENGINE - REMOVAL, EXCEPT....8R-15
DIESEL ENGINE - STANDARD
PROCEDURE, DRAINING COOLING
SYSTEM 5.9L........................7-18
DIESEL ENGINE - STANDARD
PROCEDURE, REFILLING COOLING
SYSTEM 5.9L........................7-19
DIESEL ENGINE - TORQUE, FUEL
SYSTEM............................14-48
DIESEL ENGINE, SPECIAL TOOLS - 5.9L . . 9-246
DIESEL ENGINES - DESCRIPTION,
ENGINE OIL...........................0-2
DIESEL FUEL SYSTEM - DESCRIPTION . . . 14-45
DIESEL FUEL SYSTEM, SPECIAL TOOLS . . 14-49
DIESEL ONLY - ASSEMBLY, 5.9L..........7-70
DIESEL ONLY - DISASSEMBLY, 5.9L.......7-70
DIFFERENTIAL - ASSEMBLY . . . 3-129,3-156,3-47,
3-73,3-99
DIFFERENTIAL - DISASSEMBLY....3-128,3-155,
3-47,3-72,3-98
DIFFERENTIAL - INSTALLATION....3-130,3-157,
3-48,3-74,3-99
DIFFERENTIAL - REMOVAL
. . . 3-127,3-155,3-46,
3-72,3-97
DIFFERENTIAL CASE BEARINGS -
INSTALLATION
....3-106,3-134,3-161,3-48,3-75
DIFFERENTIAL CASE BEARINGS -
REMOVAL
........3-105,3-134,3-161,3-48,3-75
DIFFERENTIAL COVER - INSTALLATION
....3-97
DIFFERENTIAL COVER - REMOVAL
........3-97
DIFFERENTIAL TRAC-RITE - ASSEMBLY
. . 3-133,
3-161
DIFFERENTIAL TRAC-RITE - CLEANING
. . . 3-132,
3-160
DIFFERENTIAL TRAC-RITE -
DESCRIPTION
..................3-131,3-158
DIFFERENTIAL TRAC-RITE -
DISASSEMBLY
..................3-131,3-158
DIFFERENTIAL TRAC-RITE - INSPECTION
. 3-132,
3-160
DIFFERENTIAL TRAC-RITE - OPERATION
. . 3-131,
3-158
DIFFERENTIAL-TRAC-LOK - ASSEMBLY
. . . 3-103
DIFFERENTIAL-TRAC-LOK -
DESCRIPTION
.......................3-100DIFFERENTIAL-TRAC-LOK - DIAGNOSIS
AND TESTING.......................3-100
DIFFERENTIAL-TRAC-LOK -
DISASSEMBLY.......................3-101
DIFFERENTIAL-TRAC-LOK - OPERATION . . . 3-100
DIMENSIONS - SPECIFICATIONS, BODY
OPENING...........................23-99
DIMENSIONS - SPECIFICATIONS, FRAME . . 13-16
DIODE - INSTALLATION............8W-01-14
DIODE - REMOVAL................8W-01-14
DIODE REPLACEMENT - STANDARD
PROCEDURE........................24-45
DISC - INSTALLATION, CLUTCH...........6-5
DISC - REMOVAL, CLUTCH...............6-5
DISC BRAKE CALIPER ADAPTER MOUNT
- INSTALLATION......................5-22
DISC BRAKE CALIPERS - DESCRIPTION....5-16
DISC BRAKE CALIPERS - OPERATION.....5-16
DISC BRAKE ROTOR, DIAGNOSIS AND
TESTING............................5-32
DISCHARGE (ESD) SENSITIVE DEVICES -
STANDARD PROCEDURE,
ELECTROSTATIC...................8W-01-8
DISCHARGE LINE - DESCRIPTION, A/C....24-56
DISPLAY TEST MODE - DESCRIPTION,
STATE ..............................25-1
DISTRIBUTION - DESCRIPTION, POWER . 8W-97-1
DISTRIBUTION - OPERATION, POWER . . 8W-97-1
DISTRIBUTION DUCT - INSTALLATION,
FLOOR.............................24-34
DISTRIBUTION DUCT - REMOVAL,
FLOOR.............................24-33
DISTRIBUTION SYSTEMS, SPECIAL
TOOLS - POWER...................8W-97-2
DOME LAMP - DESCRIPTION...........8L-26
DOME LAMP - INSTALLATION..........8L-26
DOME LAMP - OPERATION.............8L-26
DOME LAMP - REMOVAL..............8L-26
DOOR - INSTALLATION...........23-18,23-28
DOOR - INSTALLATION, BLEND.........24-27
DOOR - INSTALLATION, DEFROST.......24-31
DOOR - INSTALLATION, FUEL FILL.......23-39
DOOR - INSTALLATION, MODE..........24-38
DOOR - INSTALLATION, RECIRCULATION . . 24-40
DOOR - REMOVAL...............23-18,23-28
DOOR - REMOVAL, BLEND.............24-27
DOOR - REMOVAL, DEFROST...........24-31
DOOR - REMOVAL, FUEL FILL..........23-39
DOOR - REMOVAL, MODE..............24-38
DOOR - REMOVAL, RECIRCULATION.....24-39
DOOR ACTUATOR - DESCRIPTION,
BLEND.............................24-17
DOOR ACTUATOR - DESCRIPTION,
DEFROST...........................24-20
DOOR ACTUATOR - DESCRIPTION,
MODE.............................24-23
DOOR ACTUATOR - DESCRIPTION,
RECIRCULATION.....................24-24
DOOR ACTUATOR - INSTALLATION,
BLEND.............................24-18
DOOR ACTUATOR - INSTALLATION,
DEFROST...........................24-21
DOOR ACTUATOR - INSTALLATION,
MODE.............................24-23
DOOR ACTUATOR - INSTALLATION,
RECIRCULATION.....................24-25
DOOR ACTUATOR - OPERATION, BLEND . . 24-17
DOOR ACTUATOR - OPERATION,
DEFROST...........................24-21
DOOR ACTUATOR - OPERATION, MODE . . . 24-23
DOOR ACTUATOR - OPERATION,
RECIRCULATION
.....................24-24
DOOR ACTUATOR - REMOVAL, BLEND
....24-17
DOOR ACTUATOR - REMOVAL, DEFROST
. . 24-21
DOOR ACTUATOR - REMOVAL, MODE
....24-23
DOOR ACTUATOR - REMOVAL,
RECIRCULATION
.....................24-24
DOOR AJAR INDICATOR - DESCRIPTION
. . 8J-23
DOOR AJAR INDICATOR - OPERATION
....8J-23
DOOR AJAR SWITCH - DESCRIPTION
....8L-27
DOOR AJAR SWITCH - OPERATION
......8L-27
DOOR GLASS - INSTALLATION
.....23-20,23-30
DOOR GLASS - REMOVAL
........23-20,23-30
DOOR GLASS RUN WEATHERSTRIP -
INSTALLATION, FRONT
................23-92
DOOR GLASS RUN WEATHERSTRIP -
INSTALLATION, REAR
.................23-93
10 INDEXDR
Description Group-Page Description Group-Page Description Group-Page

HEATED SEAT MODULE - INSTALLATION . . . 8E-7
HEATED SEAT MODULE - INSTALLATION . . 8G-15
HEATED SEAT MODULE - OPERATION.....8E-6
HEATED SEAT MODULE - OPERATION....8G-14
HEATED SEAT MODULE - REMOVAL.......8E-7
HEATED SEAT MODULE - REMOVAL.....8G-15
HEATED SEAT SENSOR - DESCRIPTION . . . 8G-11
HEATED SEAT SENSOR - DIAGNOSIS
AND TESTING.......................8G-11
HEATED SEAT SENSOR - OPERATION....8G-11
HEATED SEAT SENSOR - REMOVAL......8G-11
HEATED SEAT SWITCH - DESCRIPTION . . . 8G-11
HEATED SEAT SWITCH - DIAGNOSIS
AND TESTING.......................8G-12
HEATED SEAT SWITCH - INSTALLATION . . 8G-13
HEATED SEAT SWITCH - OPERATION.....8G-12
HEATED SEAT SWITCH - REMOVAL......8G-13
HEATED SEAT SYSTEM - DESCRIPTION....8G-7
HEATED SEAT SYSTEM - DIAGNOSIS
AND TESTING........................8G-8
HEATED SEAT SYSTEM - OPERATION.....8G-8
HEATER - 5.9L DIESEL - DESCRIPTION,
ENGINE BLOCK.......................7-37
HEATER - 5.9L DIESEL - INSTALLATION,
ENGINE BLOCK.......................7-38
HEATER - 5.9L DIESEL - OPERATION,
ENGINE BLOCK.......................7-38
HEATER - 5.9L DIESEL - REMOVAL,
ENGINE BLOCK.........................7-38
HEATER - DESCRIPTION, ENGINE BLOCK . . . 7-36
HEATER - DESCRIPTION, FUEL..........14-51
HEATER - DESCRIPTION, INTAKE AIR.....14-80
HEATER - DIAGNOSIS AND TESTING,
ENGINE BLOCK.......................7-36
HEATER - DIAGNOSIS AND TESTING,
FUEL..............................14-52
HEATER - INSTALLATION, ENGINE
BLOCK..............................7-37
HEATER - INSTALLATION, INTAKE AIR....14-80
HEATER - OPERATION, ENGINE BLOCK....7-36
HEATER - OPERATION, FUEL............14-51
HEATER - OPERATION, INTAKE AIR......14-80
HEATER - REMOVAL, ENGINE BLOCK......7-37
HEATER - REMOVAL, INTAKE AIR........14-80
HEATER AND AIR CONDITIONER -
DESCRIPTION........................24-1
HEATER AND AIR CONDITIONER -
OPERATION..........................24-1
HEATER CONTROL - DESCRIPTION, A/C . . . 24-14
HEATER CONTROL - INSTALLATION, A/C . . 24-15
HEATER CONTROL - REMOVAL, A/C......24-15
HEATER CORE - DESCRIPTION..........24-63
HEATER CORE - INSTALLATION.........24-63
HEATER CORE - OPERATION............24-63
HEATER CORE - REMOVAL.............24-63
HEATER INLET HOSE - INSTALLATION....24-64
HEATER INLET HOSE - REMOVAL........24-64
HEATER PERFORMANCE TEST -
DIAGNOSIS AND TESTING..............24-6
HEATER RELAY - DESCRIPTION, FUEL....14-52
HEATER RELAY - DESCRIPTION, INTAKE
AIR ...............................14-82
HEATER RELAY - INSTALLATION, FUEL . . . 14-53
HEATER RELAY - INSTALLATION, INTAKE
AIR ...............................14-82
HEATER RELAY - OPERATION, FUEL......14-52
HEATER RELAY - OPERATION, INTAKE
AIR ...............................14-82
HEATER RELAY - REMOVAL, FUEL.......14-52
HEATER RELAY - REMOVAL, INTAKE AIR . . 14-82
HEATER RETURN HOSE - INSTALLATION . . 24-65
HEATER RETURN HOSE - REMOVAL......24-64
HEIGHT ADJUSTMENT - 4WD (LD) -
STANDARD PROCEDURE.................2-3
HEIGHT MEASUREMENT - 4WD (LD) -
STANDARD PROCEDURE.................2-3
HEMI ENGINE - INSTALLATION, 3.7L/4.7L
AND 5.7L......................24-59,24-73
HEMI ENGINE - REMOVAL, 3.7L/4.7L
AND 5.7L......................24-57,24-71
HIGH BEAM INDICATOR - DESCRIPTION
. . 8J-28
HIGH BEAM INDICATOR - OPERATION
....8J-28
HIGH MOUNTED STOP LAMP -
INSTALLATION, CENTER
...............8L-11
HIGH MOUNTED STOP LAMP -
REMOVAL, CENTER
...................8L-11
HIGH MOUNTED STOP LAMP UNIT -
INSTALLATION, CENTER
...............8L-11HIGH MOUNTED STOP LAMP UNIT -
REMOVAL, CENTER...................8L-11
HIGH PRESSURE RELIEF VALVE -
DESCRIPTION.......................24-48
HIGH PRESSURE RELIEF VALVE -
OPERATION.........................24-48
HIGH SPEEDS - DESCRIPTION, TIRE
PRESSURE..........................22-7
HIGH/LOW RELAY - DESCRIPTION,
WIPER.............................8R-20
HIGH/LOW RELAY - DIAGNOSIS AND
TESTING, WIPER.....................8R-21
HIGH/LOW RELAY - INSTALLATION,
WIPER.............................8R-22
HIGH/LOW RELAY - OPERATION, WIPER . . 8R-20
HIGH/LOW RELAY - REMOVAL, WIPER . . . 8R-21
HIGH-PRESSURE FUEL LINE LEAKS -
DIAGNOSIS AND TESTING.............14-58
HINGE - INSTALLATION.....23-16,23-22,23-31,
23-46
HINGE - INSTALLATION, CENTER SEAT
BACK..............................23-79
HINGE - REMOVAL....23-16,23-22,23-31,23-46
HINGE - REMOVAL, CENTER SEAT BACK . . 23-78
HINGE COVER - INSTALLATION, CENTER
SEAT BACK INERTIA..................23-77
HINGE COVER - REMOVAL, CENTER
SEAT BACK INERTIA..................23-77
HITCH - INSTALLATION, TRAILER........13-25
HITCH - REMOVAL, TRAILER...........13-25
HOAT COOLANT - DESCRIPTION..........7-32
HOISTING - STANDARD PROCEDURE......0-20
HOLDDOWN - DESCRIPTION, BATTERY . . . 8F-14
HOLDDOWN - INSTALLATION, BATTERY . . . 8F-14
HOLDDOWN - OPERATION, BATTERY.....8F-14
HOLDDOWN - REMOVAL, BATTERY......8F-14
HOLDER - INSTALLATION, CUP.........23-51
HOLDER - REMOVAL, CUP.............23-51
HOLDING CLUTCHES - DESCRIPTION....21-371
HOLDING CLUTCHES - OPERATION.....21-372
HOLE PLUG - INSTALLATION, CAMSHAFT
CORE..............................9-206
HOLE PLUG - REMOVAL, CAMSHAFT
CORE..............................9-205
HOLE REPAIR - DESCRIPTION,
THREADED........................Intro.-8
HONING - STANDARD PROCEDURE,
CYLINDER BORE.................9-128,9-38
HOOD - INSTALLATION................23-47
HOOD - REMOVAL....................23-46
HOOK - INSTALLATION, COAT...........23-66
HOOK - REMOVAL, COAT..............23-66
HOOK ASSEMBLY - INSTALLATION,
FRONT TOW........................13-23
HOOK ASSEMBLY - REMOVAL, FRONT
TOW ..............................13-23
HORN - DIAGNOSIS AND TESTING.......8H-1
HORN - INSTALLATION.................8H-2
HORN - REMOVAL....................8H-2
HORN SWITCH - DESCRIPTION..........8H-2
HORN SWITCH - DIAGNOSIS AND
TESTING............................8H-2
HORN SYSTEM - DESCRIPTION..........8H-1
HORN SYSTEM - DIAGNOSIS AND
TESTING............................8H-1
HORN SYSTEM - OPERATION............8H-1
HOSE - GEAR TO COOLER -
INSTALLATION, RETURN..........19-44,19-45
HOSE - GEAR TO COOLER - REMOVAL,
RETURN......................19-44,19-45
HOSE - INSTALLATION, FRONT BRAKE.....5-13
HOSE - INSTALLATION, HEATER INLET....24-64
HOSE - INSTALLATION, HEATER RETURN . 24-65
HOSE - INSTALLATION, PRESSURE . 19-44,19-45
HOSE - INSTALLATION, REAR BRAKE......5-12
HOSE - REMOVAL, FRONT..............5-12
HOSE - REMOVAL, HEATER INLET.......24-64
HOSE - REMOVAL, HEATER RETURN.....24-64
HOSE - REMOVAL, PRESSURE.....19-44,19-45
HOSE - REMOVAL, REAR BRAKE
.........5-11
HOSE - RESERVOIR TO COOLER -
INSTALLATION, RETURN
..........19-44,19-45
HOSE - RESERVOIR TO COOLER -
REMOVAL, RETURN
.............19-44,19-45
HOSE ASSEMBLY - INSTALLATION, REAR
TUBE
...............................5-13
HOSE ASSEMBLY - REMOVAL, REAR
TUBE
...............................5-12HOSE CLAMPS - DESCRIPTION...........7-3
HOSE CLAMPS - OPERATION.............7-5
HOSES/TUBES - DESCRIPTION, WASHER . 8R-11
HOSES/TUBES - OPERATION, WASHER . . . 8R-11
HOUSING - ASSEMBLY, HVAC...........24-35
HOUSING - DIAGNOSIS AND TESTING,
CLUTCH..............................6-7
HOUSING - DISASSEMBLY, HVAC........24-35
HOUSING - INSTALLATION, CLUTCH.......6-9
HOUSING - INSTALLATION, GEAR........9-300
HOUSING - INSTALLATION, HVAC........24-36
HOUSING - INSTALLATION, ROCKER.....9-255
HOUSING - REMOVAL, CLUTCH...........6-9
HOUSING - REMOVAL, GEAR...........9-299
HOUSING - REMOVAL, HVAC...........24-34
HOUSING - REMOVAL, ROCKER.........9-255
HOUSING BUSHING AND SEAL -
INSTALLATION, EXTENSION...........21-440
HOUSING BUSHING AND SEAL -
REMOVAL, EXTENSION...............21-440
HOUSING COVER - INSTALLATION, GEAR . 9-301
HOUSING COVER - REMOVAL, GEAR.....9-301
HOUSING FLUID LEAK - DIAGNOSIS AND
TESTING, CONVERTER.........21-144,21-318
HOUSING SEAL - INSTALLATION,
ADAPTER...............21-128,21-364,21-85
HOUSING SEAL - INSTALLATION,
EXTENSION . 21-128,21-201,21-507,21-536,21-85
HOUSING SEAL - REMOVAL, ADAPTER . . 21-128,
21-364,21-85
HOUSING SEAL - REMOVAL,
EXTENSION . 21-128,21-201,21-507,21-536,21-85
HOUSING SEAL AND DUST BOOT -
INSTALLATION, EXTENSION.....21-476,21-571
HOUSING SEAL AND DUST BOOT -
REMOVAL, EXTENSION.........21-476,21-571
HOW TO USE WIRING DIAGRAMS -
DESCRIPTION.....................8W-01-1
H-SECTION REPLACEMENT - STANDARD
PROCEDURE, REAR FRAME............13-13
HUB / BEARING - INSTALLATION.........2-32
HUB / BEARING - REMOVAL.............2-31
HVAC HOUSING - ASSEMBLY...........24-35
HVAC HOUSING - DISASSEMBLY........24-35
HVAC HOUSING - INSTALLATION........24-36
HVAC HOUSING - REMOVAL............24-34
HYDRAULIC BOOSTER - DIAGNOSIS
AND TESTING........................5-30
HYDRAULIC LASH ADJUSTER -
DIAGNOSIS AND TESTING.........9-125,9-32
HYDRAULIC PRESSURE TEST -
DIAGNOSIS AND TESTING......21-141,21-316
HYDRAULIC SCHEMATICS, SCHEMATICS
AND DIAGRAMS..............21-176,21-337
HYDRAULIC TAPPETS - DIAGNOSIS AND
TESTING...........................9-210
HYDRAULIC TAPPETS - INSTALLATION . . . 9-211
HYDRAULIC TAPPETS - REMOVAL.......9-211
HYDROBOOST - INSTALLATION..........5-27
HYDROBOOST - INSTALLATION, ALL
EXCEPT.............................5-27
HYDROBOOST - REMOVAL..............5-26
HYDROBOOST - REMOVAL, ALL EXCEPT . . . 5-26
HYDRO-BOOST BRAKE BOOSTER -
INSTALLATION........................5-32
HYDRO-BOOST BRAKE BOOSTER -
REMOVAL
...........................5-31
HYDROFORM FENDER RAIL REPAIR -
STANDARD PROCEDURE
...............13-11
HYDROSTATIC LOCK - STANDARD
PROCEDURE
...................9-190,9-240
IDENTIFICATION - DESCRIPTION,
FASTENER
.........................Intro.-5
IDENTIFICATION AND INFORMATION -
DESCRIPTION, SECTION
.............8W-01-6
IDENTIFICATION NUMBER -
DESCRIPTION, VEHICLE
..............Intro.-1
IDLE AIR CONTROL MOTOR -
DESCRIPTION
.......................14-28
IDLE AIR CONTROL MOTOR -
INSTALLATION
.......................14-29
IDLE AIR CONTROL MOTOR -
OPERATION
.........................14-28
IDLE AIR CONTROL MOTOR - REMOVAL
. . 14-29
IDLER SHAFT - INSTALLATION
......9-179,9-81
IDLER SHAFT - REMOVAL
..........9-179,9-81
IGNITION - SPECIFICATIONS, TORQUE
.....8I-3
16 INDEXDR
Description Group-Page Description Group-Page Description Group-Page

RKE TRANSMITTER CUSTOMER
PREFERENCES - STANDARD
PROCEDURE.........................8N-8
RKE TRANSMITTER PROGRAMING -
STANDARD PROCEDURE...............8N-9
ROCKER ARM / ADJUSTER ASSEMBLY -
DESCRIPTION.......................9-125
ROCKER ARM / ADJUSTER ASSEMBLY -
INSTALLATION.......................9-126
ROCKER ARM / ADJUSTER ASSEMBLY -
REMOVAL..........................9-126
ROCKER ARM / ADJUSTER ASSY -
CLEANING..........................9-262
ROCKER ARM / ADJUSTER ASSY -
DESCRIPTION.......................9-261
ROCKER ARM / ADJUSTER ASSY -
INSPECTION........................9-262
ROCKER ARM / ADJUSTER ASSY -
INSTALLATION..................9-203,9-263
ROCKER ARM / ADJUSTER ASSY -
REMOVAL.....................9-203,9-261
ROCKER ARM - DESCRIPTION.......9-31,9-37
ROCKER ARM - INSTALLATION..........9-31
ROCKER ARM - REMOVAL..........9-31,9-37
ROCKER HOUSING - INSTALLATION......9-255
ROCKER HOUSING - REMOVAL.........9-255
ROD - INSPECTION, CONNECTING.......9-283
ROD - INSPECTION, PISTON &
CONNECTING...................9-140,9-213
ROD - INSTALLATION, PISTON &
CONNECTING...................9-140,9-213
ROD - REMOVAL, PISTON &
CONNECTING..............9-139,9-212,9-281
ROD BEARING AND CRANKSHAFT
JOURNAL CLEARANCE - STANDARD
PROCEDURE, CONNECTING............9-272
ROD BEARING FITTING - STANDARD
PROCEDURE, CONNECTING............9-129
ROD BEARING FITTING, STANDARD
PROCEDURE - CONNECTING.............9-49
ROD END - DIAGNOSIS AND TESTING,
OUTER TIE..........................19-32
ROD END - INSTALLATION, OUTER TIE . . . 19-33
ROD END - INSTALLATION, TIE.........19-37
ROD END - REMOVAL, OUTER TIE.......19-32
ROD END - REMOVAL, TIE.............19-37
ROTATION - STANDARD PROCEDURE,
TIRE................................22-3
ROTOR, DIAGNOSIS AND TESTING -
DISC BRAKE.........................5-32
ROUTING, 5.7L V-8 ENGINE - FIRING
ORDER / CABLE.......................8I-4
RUN CHANNEL - INSTALLATION, GLASS . . 23-22,
23-31
RUN CHANNEL - REMOVAL, GLASS . 23-21,23-30
RUN WEATHERSTRIP - INSTALLATION,
FRONT DOOR GLASS.................23-92
RUN WEATHERSTRIP - INSTALLATION,
REAR DOOR GLASS..................23-93
RUN WEATHERSTRIP - REMOVAL,
FRONT DOOR GLASS.................23-92
RUN WEATHERSTRIP - REMOVAL, REAR
DOOR GLASS.......................23-93
RUNOUT - DIAGNOSIS AND TESTING,
TIRE AND WHEEL.....................22-1
RWAL VALVE - DESCRIPTION
............5-50
RWAL VALVE - INSTALLATION
...........5-51
RWAL VALVE - OPERATION
.............5-50
RWAL VALVE - REMOVAL
...............5-51
SAFETY PRECAUTIONS AND WARNINGS,
WARNING
...........................23-1
SAFETY PRECAUTIONS AND WARNINGS,
WARNING
...........................13-4
SAFETY PRECAUTIONS, STANDARD
PROCEDURE
.........................8L-7
SAFETY PRECAUTIONS, WARNING -
WINDSHIELD
........................23-88
SANDING/BUFFING & POLISHING -
DESCRIPTION, FINESSE
...............23-74
SCHEDULES, 24-VALVE CUMMINS
TURBO DIESEL - MAINTENANCE
.........0-12
SCHEMATICS AND DIAGRAMS -
HYDRAULIC SCHEMATICS
.......21-176,21-337
SCHEMATICS, SCHEMATICS AND
DIAGRAMS - HYDRAULIC
.......21-176,21-337
SEAL - DIAGNOSIS AND TESTING,
RADIATOR CAP-TO-FILLER NECK
.........7-58SEAL - FRONT - INSTALLATION,
CRANKSHAFT OIL......9-136,9-208,9-275,9-46
SEAL - FRONT - REMOVAL,
CRANKSHAFT OIL......9-135,9-208,9-275,9-46
SEAL - INSTALLATION, ADAPTER
HOUSING...............21-128,21-364,21-85
SEAL - INSTALLATION, DOOR OPENING . . . 23-92
SEAL - INSTALLATION, EXTENSION
HOUSING . . . 21-128,21-201,21-507,21-536,21-85
SEAL - INSTALLATION, EXTENSION
HOUSING BUSHING..................21-440
SEAL - INSTALLATION, FRONT OUTPUT
SHAFT....21-442,21-477,21-508,21-538,21-572
SEAL - INSTALLATION, OIL PUMP
FRONT............................21-391
SEAL - INSTALLATION, PINION....3-126,3-154,
3-45,3-71,3-96
SEAL - INSTALLATION, STEERING GEAR
INPUT SHAFT.......................19-29
SEAL - REAR - INSTALLATION,
CRANKSHAFT OIL......9-138,9-209,9-276,9-47
SEAL - REAR - REMOVAL, CRANKSHAFT
OIL .................9-137,9-209,9-276,9-47
SEAL - REMOVAL, ADAPTER HOUSING . . 21-128,
21-364,21-85
SEAL - REMOVAL, DOOR OPENING......23-92
SEAL - REMOVAL, EXTENSION
HOUSING . . . 21-128,21-201,21-507,21-536,21-85
SEAL - REMOVAL, EXTENSION HOUSING
BUSHING..........................21-440
SEAL - REMOVAL, FRONT OUTPUT
SHAFT....21-441,21-477,21-507,21-537,21-572
SEAL - REMOVAL, OIL PUMP FRONT.....21-391
SEAL - REMOVAL, PINION....3-126,3-153,3-44,
3-70,3-95
SEAL - REMOVAL, STEERING GEAR
INPUT SHAFT.......................19-27
SEAL AND DUST BOOT - INSTALLATION,
EXTENSION HOUSING..........21-476,21-571
SEAL AND DUST BOOT - REMOVAL,
EXTENSION HOUSING..........21-476,21-571
SEAL AREA LEAKS - DIAGNOSIS AND
TESTING, REAR.............9-137,9-209,9-65
SEAL RETAINER - INSTALLATION,
CRANKSHAFT REAR OIL..........9-210,9-277
SEAL RETAINER - REMOVAL,
CRANKSHAFT REAR OIL..........9-209,9-277
SEALER LOCATIONS - SPECIFICATIONS . . 23-102
SEALERS - STANDARD PROCEDURE,
FORM-IN-PLACE GASKETS......9-239,9-9,9-94
SEALS - DESCRIPTION, VALVE GUIDE . 9-32,9-38
SEALS - DESCRIPTION, VALVE STEM....9-127,
9-203
SEALS - INSTALLATION, AXLE SHAFT . 3-43,3-70,
3-94
SEALS - REMOVAL, AXLE SHAFT . 3-43,3-69,3-94
SEALS - REMOVAL, VALVE SPRINGS.....9-260
SEAT - FRONT - INSTALLATION.........23-81
SEAT - FRONT - REMOVAL.............23-81
SEAT - INSTALLATION, CENTER.........23-76
SEAT - REAR - INSTALLATION..........23-83
SEAT - REAR - REMOVAL..............23-83
SEAT - REMOVAL, CENTER.............23-75
SEAT BACK - INSTALLATION, CENTER
ARMREST..........................23-77
SEAT BACK - REAR - INSTALLATION
.....23-83
SEAT BACK - REAR - REMOVAL
.........23-83
SEAT BACK - REMOVAL, CENTER
ARMREST
..........................23-76
SEAT BACK CUSHION / COVER - FRONT
- INSTALLATION
.....................23-82
SEAT BACK CUSHION / COVER - FRONT
- REMOVAL
.........................23-82
SEAT BACK CUSHION / COVER - REAR -
INSTALLATION
.......................23-84
SEAT BACK CUSHION / COVER - REAR -
REMOVAL
..........................23-84
SEAT BACK HINGE - INSTALLATION,
CENTER
............................23-79
SEAT BACK HINGE - REMOVAL, CENTER
. . 23-78
SEAT BACK INERTIA HINGE COVER -
INSTALLATION, CENTER
...............23-77
SEAT BACK INERTIA HINGE COVER -
REMOVAL, CENTER
...................23-77
SEAT BACK LID - INSTALLATION,
CENTER
............................23-79
SEAT BACK LID - REMOVAL, CENTER
....23-79SEAT BACK REAR - FOOTMANS LOOP
BRACKETS - INSTALLATION............23-85
SEAT BACK REAR - FOOTMANS LOOP
BRACKETS - REMOVAL................23-85
SEAT BELT - INSTALLATION, FRONT
CENTER............................8O-31
SEAT BELT - REMOVAL, FRONT CENTER . . 8O-30
SEAT BELT & RETRACTOR -
INSTALLATION, FRONT CENTER.........8O-29
SEAT BELT & RETRACTOR -
INSTALLATION, REAR CENTER..........8O-45
SEAT BELT & RETRACTOR -
INSTALLATION, REAR OUTBOARD.......8O-47
SEAT BELT & RETRACTOR - REMOVAL,
FRONT CENTER......................8O-29
SEAT BELT & RETRACTOR - REMOVAL,
REAR CENTER.......................8O-44
SEAT BELT & RETRACTOR - REMOVAL,
REAR OUTBOARD....................8O-46
SEAT BELT BUCKLE - INSTALLATION,
FRONT OUTBOARD...................8O-38
SEAT BELT BUCKLE - REMOVAL, FRONT
OUTBOARD.........................8O-37
SEAT BELT SWITCH - DESCRIPTION.....8O-51
SEAT BELT SWITCH - DIAGNOSIS AND
TESTING...........................8O-51
SEAT BELT SWITCH - OPERATION.......8O-51
SEAT BELT TENSION REDUCER -
DESCRIPTION.......................8O-53
SEAT BELT TENSION REDUCER -
DIAGNOSIS AND TESTING.............8O-54
SEAT BELT TENSION REDUCER -
OPERATION..........................8O-54
SEAT BELT TENSIONER - DESCRIPTION . . . 8O-52
SEAT BELT TENSIONER - OPERATION....8O-53
SEAT BELT TURNING LOOP ADJUSTER -
INSTALLATION......................8O-55
SEAT BELT TURNING LOOP ADJUSTER -
REMOVAL..........................8O-55
SEAT CUSHION / COVER - FRONT -
INSTALLATION.......................23-83
SEAT CUSHION / COVER - FRONT -
REMOVAL..........................23-83
SEAT CUSHION / COVER - REAR -
INSTALLATION.......................23-84
SEAT CUSHION / COVER - REAR -
REMOVAL..........................23-84
SEAT CUSHION - INSTALLATION,
CENTER............................23-79
SEAT CUSHION - REMOVAL, CENTER.....23-79
SEAT CUSHION COVER - INSTALLATION,
CENTER............................23-79
SEAT CUSHION COVER - REMOVAL,
CENTER............................23-79
SEAT CUSHION FRAME - REAR -
INSTALLATION.......................23-85
SEAT CUSHION FRAME - REAR -
REMOVAL..........................23-85
SEAT ELEMENT - DESCRIPTION, HEATED . . 8G-9
SEAT ELEMENT - DIAGNOSIS AND
TESTING, HEATED....................8G-10
SEAT ELEMENT - INSTALLATION,
HEATED............................8G-10
SEAT ELEMENT - OPERATION, HEATED . . . 8G-10
SEAT ELEMENT - REMOVAL, HEATED....8G-10
SEAT MODULE - DESCRIPTION, HEATED . . . 8E-6
SEAT MODULE - DESCRIPTION, HEATED . . 8G-13
SEAT MODULE - DIAGNOSIS AND
TESTING, HEATED.....................8E-6
SEAT MODULE - DIAGNOSIS AND
TESTING, HEATED....................8G-14
SEAT MODULE - INSTALLATION, HEATED
. . . 8E-7
SEAT MODULE - INSTALLATION, HEATED
. 8G-15
SEAT MODULE - OPERATION, HEATED
.....8E-6
SEAT MODULE - OPERATION, HEATED
....8G-14
SEAT MODULE - REMOVAL, HEATED
......8E-7
SEAT MODULE - REMOVAL, HEATED
.....8G-15
SEAT SENSOR - DESCRIPTION, HEATED
. . 8G-11
SEAT SENSOR - DIAGNOSIS AND
TESTING, HEATED
....................8G-11
SEAT SENSOR - OPERATION, HEATED
....8G-11
SEAT SENSOR - REMOVAL, HEATED
.....8G-11
SEAT STORAGE BIN - INSTALLATION,
UNDER
............................23-80
SEAT STORAGE BIN - REMOVAL, UNDER
. . 23-80
SEAT STORAGE BIN COVERING -
INSTALLATION, UNDER
................23-80
28 INDEXDR
Description Group-Page Description Group-Page Description Group-Page

WATER PUMP BYPASS - DESCRIPTION....7-59
WATER PUMP BYPASS - OPERATION......7-60
WATER SEPARATOR - DESCRIPTION,
FUEL FILTER........................14-50
WATER SEPARATOR - INSTALLATION,
FUEL FILTER........................14-50
WATER SEPARATOR - OPERATION, FUEL
FILTER.............................14-50
WATER SEPARATOR - REMOVAL, FUEL
FILTER.............................14-50
WATER TO OIL COOLER - REMOVAL......7-69
WATERDAM - INSTALLATION......23-25,23-34
WATERDAM - REMOVAL..........23-25,23-34
WATER-IN-FUEL INDICATOR -
DESCRIPTION.......................8J-45
WATER-IN-FUEL INDICATOR -
OPERATION.........................8J-45
WATER-TO-AIR COOLER - INSTALLATION . . 7-70
WEAR - STANDARD PROCEDURE,
MEASURING TIMING CHAIN............9-167
WEAR INDICATORS - DIAGNOSIS AND
TESTING, TREAD......................22-8
WEAR PATTERNS - DIAGNOSIS AND
TESTING, TIRE.......................22-8
WEAR, STANDARD PROCEDURE -
MEASURING TIMING CHAIN.............9-77
WEATHERSTRIP - INSTALLATION, DRIP
RAIL..............................23-91
WEATHERSTRIP - INSTALLATION, FRONT
DOOR GLASS RUN...................23-92
WEATHERSTRIP - INSTALLATION, REAR
DOOR GLASS RUN.....................23-93
WEATHERSTRIP - REMOVAL, DRIP RAIL . . 23-91
WEATHERSTRIP - REMOVAL, FRONT
DOOR GLASS RUN...................23-92
WEATHERSTRIP - REMOVAL, REAR
DOOR GLASS RUN...................23-93
WEATHERSTRIP RETAINER -
INSTALLATION, A-PILLAR..............23-91
WEATHERSTRIP RETAINER -
INSTALLATION, DRIP RAIL.............23-92
WEATHERSTRIP RETAINER - REMOVAL,
A-PILLAR...........................23-91
WEATHERSTRIP RETAINER - REMOVAL,
DRIP RAIL..........................23-92
WELD LOCATIONS - SPECIFICATIONS . . . 23-120
WELD PROCESS - SPECIFICATIONS......13-15
WHEEL - INSTALLATION, STEERING
......19-15
WHEEL - REMOVAL, STEERING
.........19-15
WHEEL ALIGNMENT - DESCRIPTION
.......2-1
WHEEL ALIGNMENT - OPERATION
.........2-2
WHEEL ALIGNMENT, SPECIAL TOOLS
......2-7
WHEEL ANTILOCK - DIAGNOSIS AND
TESTING, REAR
.......................5-48
WHEEL BALANCE - STANDARD
PROCEDURE, TIRE
....................22-4
WHEEL COVER - REMOVAL
............22-14WHEEL INSPECTION, DIAGNOSIS AND
TESTING...........................22-11
WHEEL INSTALLATION - STANDARD
PROCEDURE, DUAL REAR.............22-12
WHEEL REPLACEMENT - STANDARD
PROCEDURE........................22-12
WHEEL RUNOUT - DIAGNOSIS AND
TESTING, TIRE.......................22-1
WHEEL SPEED SENSOR - DESCRIPTION,
FRONT..............................5-47
WHEEL SPEED SENSOR - DIAGNOSIS
AND TESTING, REAR...................5-49
WHEEL SPEED SENSOR -
INSTALLATION, FRONT.................5-48
WHEEL SPEED SENSOR -
INSTALLATION, REAR..................5-48
WHEEL SPEED SENSOR - OPERATION,
FRONT..............................5-47
WHEEL SPEED SENSOR - REMOVAL,
FRONT..............................5-48
WHEEL SPEED SENSOR - REMOVAL,
REAR...............................5-48
WHEEL WITH MATCHING TIRE -
DESCRIPTION, FULL SIZE, SPARE.......22-15
WHEELHOUSE SPLASH SHIELD -
INSTALLATION, FRONT................23-41
WHEELHOUSE SPLASH SHIELD -
INSTALLATION, REAR.................23-41
WHEELHOUSE SPLASH SHIELD -
REMOVAL, FRONT....................23-41
WHEELHOUSE SPLASH SHIELD -
REMOVAL, REAR.....................23-41
WHEELS - DESCRIPTION..............22-11
WHEELS - INSTALLATION, REAR DUAL....5-35
WHEELS - OPERATION................22-11
WHEELS - REMOVAL, REAR DUAL........5-34
WIND NOISE - DIAGNOSIS AND TESTING . . 23-2
WINDOW DEFOGGER RELAY -
DESCRIPTION, REAR..................8G-2
WINDOW DEFOGGER RELAY -
INSTALLATION, REAR..................8G-4
WINDOW DEFOGGER RELAY -
OPERATION, REAR....................8G-3
WINDOW DEFOGGER RELAY -
REMOVAL, REAR.....................8G-3
WINDOW DEFOGGER SWITCH -
DESCRIPTION, REAR..................8G-4
WINDOW DEFOGGER SWITCH -
OPERATION, REAR....................8G-4
WINDOW DEFOGGER SYSTEM -
DIAGNOSIS AND TESTING, REAR.........8G-2
WINDOW MOTOR - REMOVAL..........8N-20
WINDOW REGULATOR - MANUAL -
INSTALLATION..................23-27,23-35
WINDOW REGULATOR - MANUAL -
REMOVAL.....................23-26,23-35
WINDOW REGULATOR - POWER -
INSTALLATION..................23-26,23-34WINDOW REGULATOR - POWER -
REMOVAL.....................23-25,23-34
WINDOW SWITCH - DIAGNOSIS AND
TESTING...........................8N-20
WINDOW SWITCH - INSTALLATION......8N-21
WINDOW SWITCH - REMOVAL..........8N-20
WINDOWS - DESCRIPTION, POWER.....8N-19
WINDOWS - DIAGNOSIS AND TESTING,
POWER............................8N-19
WINDOWS - OPERATION, POWER.......8N-19
WINDSHIELD SAFETY PRECAUTIONS,
WARNING..........................23-88
WIPER & WASHER SYSTEM - CLEANING . . 8R-6
WIPER & WASHER SYSTEM -
DIAGNOSIS AND TESTING..............8R-6
WIPER & WASHER SYSTEM -
INSPECTION.........................8R-7
WIPER ARM - DESCRIPTION...........8R-17
WIPER ARM - INSTALLATION...........8R-18
WIPER ARM - OPERATION.............8R-18
WIPER ARM - REMOVAL..............8R-18
WIPER BLADE - DESCRIPTION..........8R-18
WIPER BLADE - INSTALLATION.........8R-20
WIPER BLADE - OPERATION...........8R-19
WIPER BLADE - REMOVAL.............8R-19
WIPER HIGH/LOW RELAY -
DESCRIPTION.......................8R-20
WIPER HIGH/LOW RELAY - DIAGNOSIS
AND TESTING.......................8R-21
WIPER HIGH/LOW RELAY -
INSTALLATION......................8R-22
WIPER HIGH/LOW RELAY - OPERATION . . 8R-20
WIPER HIGH/LOW RELAY - REMOVAL....8R-21
WIPER MODULE - DESCRIPTION........8R-22
WIPER MODULE - INSTALLATION.......8R-23
WIPER MODULE - OPERATION..........8R-23
WIPER MODULE - REMOVAL...........8R-23
WIPER ON/OFF RELAY - DESCRIPTION . . . 8R-24
WIPER ON/OFF RELAY - DIAGNOSIS AND
TESTING...........................8R-25
WIPER ON/OFF RELAY - INSTALLATION . . . 8R-26
WIPER ON/OFF RELAY - OPERATION.....8R-25
WIPER ON/OFF RELAY - REMOVAL......8R-26
WIPERS/WASHERS - DESCRIPTION
.......8R-1
WIPERS/WASHERS - OPERATION
........8R-4
WIRE SPLICING - STANDARD
PROCEDURE
.....................8W-01-15
WIRING - DESCRIPTION, TRAILER TOW
. . 8L-24
WIRING DIAGRAMS - DESCRIPTION,
HOW TO USE
.....................8W-01-1
WIRING HARNESS - DIAGNOSIS AND
TESTING
.........................8W-01-7
WIRING/TERMINAL, SPECIAL TOOLS
. . 8W-01-10
WORN THREADS - STANDARD
PROCEDURE, REPAIR
DAMAGED OR
...........9-190,9-240,9-9,9-94
DRINDEX 37
Description Group-Page Description Group-Page Description Group-Page
