SEATS
TABLE OF CONTENTS
page page
CENTER SEAT
REMOVAL.............................75
INSTALLATION.........................76
CENTER ARMREST / SEAT BACK
REMOVAL.............................76
INSTALLATION.........................77
CENTER SEAT BACK INERTIA HINGE COVER
REMOVAL.............................77
INSTALLATION.........................77
CENTER SEAT BACK HINGE
REMOVAL.............................78
INSTALLATION.........................79
CENTER SEAT BACK LID
REMOVAL.............................79
INSTALLATION.........................79
CENTER SEAT CUSHION
REMOVAL.............................79
INSTALLATION.........................79
CENTER SEAT CUSHION COVER
REMOVAL.............................79
INSTALLATION.........................79
UNDER SEAT STORAGE BIN LID
REMOVAL.............................80
INSTALLATION.........................80
UNDER SEAT STORAGE BIN
REMOVAL.............................80
INSTALLATION.........................80
UNDER SEAT STORAGE BIN COVERING
REMOVAL.............................80
INSTALLATION.........................80
UNDER SEAT STORAGE BIN LATCH
REMOVAL.............................80
INSTALLATION.........................80
HEADREST
REMOVAL.............................80
INSTALLATION.........................80
HEADREST SLEEVE
REMOVAL.............................81INSTALLATION.........................81
SEAT - FRONT
REMOVAL.............................81
INSTALLATION.........................81
LUMBAR SUPPORT HANDLE/BEZEL
REMOVAL.............................82
INSTALLATION.........................82
SEAT BACK CUSHION / COVER - FRONT
REMOVAL.............................82
INSTALLATION.........................82
SEAT CUSHION / COVER - FRONT
REMOVAL.............................83
INSTALLATION.........................83
SEAT TRACK
REMOVAL.............................83
INSTALLATION.........................83
SEAT - REAR
REMOVAL.............................83
INSTALLATION.........................83
SEAT BACK - REAR
REMOVAL.............................83
INSTALLATION.........................83
SEAT BACK CUSHION / COVER - REAR
REMOVAL.............................84
INSTALLATION.........................84
SEAT CUSHION / COVER - REAR
REMOVAL.............................84
INSTALLATION.........................84
SEAT CUSHION FRAME - REAR
REMOVAL.............................85
INSTALLATION.........................85
SEAT BACK REAR - FOOTMANS LOOP
BRACKETS
REMOVAL.............................85
INSTALLATION.........................85
CENTER SEAT
REMOVAL
NOTE: Do not reuse the seat fasteners, always
replace with new ones.
(1) Remove and discard the front bolts. (Fig. 1)(2) Position the seats forward, remove the rear
bolts and discard.
(3) Disconnect the 12v power supply electrical con-
nector, if equipped. (Fig. 2)
(4) Fold the seat backs forward and roll the seat
assembly back in the vehicle.
(5) Remove the nuts attaching the center seat to
the drivers seat and the passenger seat and discard.
(Fig. 3)
DRSEATS 23 - 75

UNDER SEAT STORAGE BIN
LID
REMOVAL
NOTE: Do not reuse the seat fasteners, always
replace with new ones.
(1) Open the center seat cushion/storage bin.
(2) Position the seat cushion cover aside, remove
the hinge bolts and discard. (Fig. 11)
(3) Remove the seat cushion.
INSTALLATION
NOTE: Do not reuse the seat fasteners, always
replace with new ones.
(1) Position the center seat cushion the hinges and
install new bolts.
(2) Tighten the bolts to 20 N´m (15 ft. lbs.).
(3) Position the cushion cover back over the
hinges.
UNDER SEAT STORAGE BIN
REMOVAL
(1)Remove the center seat cushion. (Refer to 23 -
BODY/SEATS/CENTER SEAT CUSHION - REMOVAL)
(2) Remove the six screws and remove the bin.
INSTALLATION
(1) Install the bin over the seat cushion hinges and
install the six screws.
(2) Install the center seat cushion. (Refer to 23 -
BODY/SEATS/CENTER SEAT CUSHION - INSTAL-
LATION)
UNDER SEAT STORAGE BIN
COVERING
REMOVAL
(1) Remove the under seat storage bin. (Refer to
23 - BODY/SEATS/UNDER SEAT STORAGE BIN -
REMOVAL)
(2) Disconnect the j-straps and remove the cover.
INSTALLATION
(1) Install the storage bin cover and connect the
j-straps.
(2) Install the under seat storage bin. (Refer to 23
- BODY/SEATS/UNDER SEAT STORAGE BIN -
INSTALLATION)
UNDER SEAT STORAGE BIN
LATCH
REMOVAL
(1) Open the under seat storage bin.
(2) Remove the two screws and remove the latch
assembly.
INSTALLATION
(1)Install the latch assembly and install the screws.
HEADREST
REMOVAL
(1) Raise the headrest.
(2) Press the headrest release button and remove
the headrest.
INSTALLATION
(1) Position the headrest.
(2) Press the release button and install the head-
rest.
Fig. 11 CENTER SEAT CUSHION HINGE
1 - CENTER SEAT CUSHION
2 - HINGE BOLTS
3 - SEAT CUSHION HINGE
4 - STORAGE BIN/CUSHION
23 - 80 SEATSDR

HEADREST SLEEVE
REMOVAL
(1) Remove the headrest. (Refer to 23 - BODY/
SEATS/HEADREST - REMOVAL)
(2) Grasp the sleeves and pull up and out of the
seat back to remove.
INSTALLATION
(1) Position each headrest sleeve into correct seat
back hole and press into place fully.
(2) Install the headrest. (Refer to 23 - BODY/
SEATS/HEADREST - INSTALLATION)
SEAT - FRONT
REMOVAL
NOTE: Do not reuse the seat fasteners, always
replace with new ones.
(1) Remove and discard the front bolts. (Fig. 12)
(2) Position the seats forward, remove the rear
bolts and discard.
(3) Disconnect the 12v power supply electrical con-
nector, if equipped. (Fig. 13)
(4) Fold the seat backs forward and roll the seat
assembly back in the vehicle.
(5) Separate the seat assembly by removing and
discarding the three nuts on either the drivers or
passengers seat. (Fig. 14)
(6) Remove each section of the seat assembly from
the vehicle.
INSTALLATION
NOTE: Do not reuse the seat fasteners, always
replace with new ones.
(1) Position each seat section into the vehicle and
tip back.Fig. 12 FRONT SEAT ASSEMBLY
1 - FRONT SEAT ASSEMBLY
2 - REAR BOLTS (4)
3 - ELECTRICAL CONNECTOR
4 - FRONT BOLTS (4)
Fig. 13 CENTER SEAT ATTACHMENTS
1 - CENTER SEAT ASSEMBLY
2 - FRONT NUTS (2)
3 - POWER SUPPLY ELECTRICAL CONNECTOR
4 - REAR NUTS (4)
5 - 12V POWER SUPPLY HARNESS
Fig. 14 REAR ATTACHMENTS
1 - 12V POWER SUPPLY HARNESS
2 - CENTER SEAT STORAGE BIN
3 - FRONT SEAT TRACKS
4 - REAR NUTS (4)
DRSEATS 23 - 81

(2) Install the three nuts attaching the center seat
section to the other seat, and tighten to 25 N´m (18
ft. lbs.).
(3) Roll the seat assembly forward and install new
rear bolts.
(4) Connect the 12v power supply electrical con-
nector.
(5) Tighten the rear bolts to 40 N´m (30 ft. lbs.).
(6) Fold the seat backs up and slide the seats to
the rear.
(7) Install new front bolts and tighten to 28 N´m
(21 ft. lbs.).
LUMBAR SUPPORT HANDLE/
BEZEL
REMOVAL
CAUTION: Care must be taken not to damage the
handle or bezel surface when removing.
(1) Using a trim stick C-4755 or equivalent, pry
the manual lumbar knob out of the bezel surround.
(Fig. 15)
(2) Remove the bezel retaining screws and remove
the bezel. (Fig. 16)
INSTALLATION
(1) Align the bezel to the seat back and install the
screws.
(2) Snap the manual lumbar knob onto the shaft of
the drive mechanism into the bezel surround.
SEAT BACK CUSHION / COVER
- FRONT
REMOVAL
(1) Remove the front seat. (Refer to 23 - BODY/
SEATS/SEAT - FRONT - REMOVAL)
(2) Remove the lumbar handle and bezel, if
equipped. (Refer to 23 - BODY/SEATS/LUMBAR
SUPPORT HANDLE/BEZEL - REMOVAL)
(3) Remove the headrest sleeves. (Refer to 23 -
BODY/SEATS/HEADREST SLEEVE - REMOVAL)
(4) Unzip the zip strip at the lower end of the seat
back and remove the seat back cover and cushion.
INSTALLATION
(1) Install the seat back cushion and cover onto
the seat frame assembly.
(2) Connect the zip strip at the bottom of the seat
back.
(3) Install the headrest sleeves. (Refer to 23 -
BODY/SEATS/HEADREST SLEEVE - INSTALLA-
TION)
(4) Install the lumbar bezel and handle, if
equipped. (Refer to 23 - BODY/SEATS/LUMBAR
SUPPORT HANDLE/BEZEL - INSTALLATION)
(5) Install the seat. (Refer to 23 - BODY/SEATS/
SEAT - FRONT - INSTALLATION)
Fig. 15 MANUAL LUMBAR KNOB
Fig. 16 MANUAL LUMBAR BEZEL
1 - LUMBAR SHAFT
2 - SCREWS
3 - BEZEL
23 - 82 SEATSDR
SEAT - FRONT (Continued)

(3) Install the rear seat. (Refer to 23 - BODY/
SEATS/SEAT - REAR - INSTALLATION)
SEAT BACK CUSHION / COVER
- REAR
REMOVAL
(1) Remove the rear seat back. (Refer to 23 -
BODY/SEATS/SEAT BACK - REAR - REMOVAL)
(2) Remove the headrest sleeves. (Refer to 23 -
BODY/SEATS/HEADREST SLEEVE - REMOVAL)
(3) Unzip the zip strip at the bottom of the seat
back and remove the cover.
INSTALLATION
(1) Install the seat back cover and connect the zip
strip.
(2) Install the headrest sleeves. (Refer to 23 -
BODY/SEATS/HEADREST SLEEVE - INSTALLA-
TION)
(3) Install the seat back. (Refer to 23 - BODY/
SEATS/SEAT BACK - REAR - INSTALLATION)
SEAT CUSHION / COVER -
REAR
REMOVAL
(1) Remove the rear seat. (Refer to 23 - BODY/
SEATS/SEAT - REAR - REMOVAL)
(2) Separate the zip strip at the rear of the seat
cushion and remove the cushion and cover.
INSTALLATION
(1) Install the seat cushion and cover over the
cushion frame assembly and connect the zip strip.
(2) Install the seat. (Refer to 23 - BODY/SEATS/
SEAT - REAR - INSTALLATION)
Fig. 18 SEAT BACK ATTACHMENT
1 - OUTER SEAT BACK FRAME HOOKS (2)
2 - OUTER FOOTMANS LOOP (2)
3 - INNER SEAT BACK FRAME HOOKS (2)
4 - INNER FOOTMANS LOOP (2)
5 - SEAT BACK
Fig. 19 REAR SEAT HINGE
1 - SEAT BACK BOLT (2)
2 - SEAT CUSHION
3 - SEAT BACK/CUSHION HINGE
4 - SEAT BACK
23 - 84 SEATSDR
SEAT BACK - REAR (Continued)

GEAR/RING GEAR/TONE RING -
INSTALLATION, PINION......3-108,3-137,3-164
GEAR/RING GEAR/TONE RING -
REMOVAL, PINION.........3-106,3-134,3-162
GEARSHIFT CABLE - DIAGNOSIS AND
TESTING....................21-210,21-368
GEARSHIFT CABLE - INSTALLATION....21-211,
21-370
GEARSHIFT CABLE - REMOVAL . . 21-210,21-369
GEARSHIFT CABLE, ADJUSTMENTS.....21-212,
21-370
GEAR/TONE RING - INSTALLATION,
PINION GEAR/RING.........3-108,3-137,3-164
GEAR/TONE RING - REMOVAL, PINION
GEAR/RING...............3-106,3-134,3-162
GEARTRAIN - ASSEMBLY, PLANETARY . . . 21-397
GEARTRAIN - CLEANING, PLANETARY . . . 21-396
GEARTRAIN - DESCRIPTION,
PLANETARY........................21-395
GEARTRAIN - DISASSEMBLY,
PLANETARY........................21-396
GEARTRAIN - INSPECTION, PLANETARY . 21-397
GEARTRAIN - OPERATION, PLANETARY . . 21-396
GEARTRAIN/OUTPUT SHAFT -
ASSEMBLY, PLANETARY..............21-244
GEARTRAIN/OUTPUT SHAFT -
DESCRIPTION, PLANETARY............21-241
GEARTRAIN/OUTPUT SHAFT -
DISASSEMBLY, PLANETARY...........21-242
GEARTRAIN/OUTPUT SHAFT -
INSPECTION, PLANETARY.............21-243
GEARTRAIN/OUTPUT SHAFT -
OPERATION, PLANETARY.............21-241
GENERAL - WARNINGS.............8W-01-7
GENERATOR / CHARGING SYSTEM -
SPECIFICATIONS, TORQUE.............8F-20
GENERATOR - DESCRIPTION...........8F-21
GENERATOR - INSTALLATION...........8F-24
GENERATOR - OPERATION.............8F-21
GENERATOR - REMOVAL...............8F-22
GENERATOR RATINGS, SPECIFICATIONS . . 8F-20
GENII - ASSEMBLY, TRANSFER CASE -
NV241............................21-428
GENII - ASSEMBLY, TRANSFER CASE -
NV244............................21-525
GENII - CLEANING, TRANSFER CASE -
NV241............................21-426
GENII - CLEANING, TRANSFER CASE -
NV244............................21-523
GENII - DESCRIPTION, TRANSFER CASE
- NV241...........................21-415
GENII - DESCRIPTION, TRANSFER CASE
- NV244...........................21-512
GENII - DIAGNOSIS AND TESTING,
TRANSFER CASE - NV241.............21-416
GENII - DISASSEMBLY, TRANSFER CASE
- NV241...........................21-417
GENII - DISASSEMBLY, TRANSFER CASE
- NV244...........................21-514
GENII - INSPECTION, TRANSFER CASE -
NV241............................21-426
GENII - INSPECTION, TRANSFER CASE -
NV244............................21-523
GENII - INSTALLATION, TRANSFER CASE
- NV241...........................21-438
GENII - INSTALLATION, TRANSFER CASE
- NV244...........................21-534
GENII - OPERATION, TRANSFER CASE -
NV241............................21-415
GENII - OPERATION, TRANSFER CASE -
NV244............................21-513
GENII - REMOVAL, TRANSFER CASE -
NV241............................21-417
GENII - REMOVAL, TRANSFER CASE -
NV244............................21-514
GENII - TRANSFER CASE, NV241.......21-438
GENII - TRANSFER CASE, NV244.......21-535
GLASS - DESCRIPTION, HEATED.........8G-1
GLASS - INSTALLATION, BACKLITE VENT . 23-87
GLASS - INSTALLATION, DOOR....23-20,23-30
GLASS - INSTALLATION, SIDE VIEW
MIRROR...........................23-43
GLASS - OPERATION, HEATED
...........8G-1
GLASS - REMOVAL, BACKLITE VENT
.....23-87
GLASS - REMOVAL, DOOR
........23-20,23-30
GLASS - REMOVAL, SIDE VIEW MIRROR
. . 23-42
GLASS RUN CHANNEL - INSTALLATION
. . 23-22,
23-31GLASS RUN CHANNEL - REMOVAL . 23-21,23-30
GLASS RUN WEATHERSTRIP -
INSTALLATION, FRONT DOOR...........23-92
GLASS RUN WEATHERSTRIP -
INSTALLATION, REAR DOOR............23-93
GLASS RUN WEATHERSTRIP -
REMOVAL, FRONT DOOR..............23-92
GLASS RUN WEATHERSTRIP -
REMOVAL, REAR DOOR...............23-93
GLOVE BOX - INSTALLATION...........23-52
GLOVE BOX - REMOVAL...............23-52
GLOVE BOX LAMP/SWITCH -
INSTALLATION.......................8L-28
GLOVE BOX LAMP/SWITCH - REMOVAL . . . 8L-27
GLOVE BOX LATCH - INSTALLATION.....23-52
GLOVE BOX LATCH - REMOVAL.........23-52
GOVERNOR - DESCRIPTION,
ELECTRONIC.......................21-197
GOVERNOR - INSTALLATION,
ELECTRONIC.......................21-200
GOVERNOR - OPERATION, ELECTRONIC . 21-198
GOVERNOR - REMOVAL, ELECTRONIC . . . 21-199
GRAB HANDLE - INSTALLATION,
B-PILLAR...........................23-68
GRAB HANDLE - REMOVAL, B-PILLAR....23-68
GRID LINE AND TERMINAL REPAIR -
STANDARD PROCEDURE...............8G-4
GRILLE - INSTALLATION...............23-40
GRILLE - INSTALLATION, COWL.........23-38
GRILLE - REMOVAL....................23-40
GRILLE - REMOVAL, COWL............23-38
GRILLE FRAME - INSTALLATION.........23-40
GRILLE FRAME - REMOVAL............23-40
GROUND - STANDARD PROCEDURE,
TESTING FOR A SHORT TO..........8W-01-9
GROUND AND SPLICE INFORMATION -
DESCRIPTION, CONNECTOR..........8W-01-7
GROUND ON FUSES POWERING
SEVERAL LOADS - STANDARD
PROCEDURE, TESTING FOR A SHORT
TO.............................8W-01-10
GROUND STRAP - DESCRIPTION, RADIO
NOISE SUPPRESSION..................8A-9
GROUND STRAP - INSTALLATION,
RADIO NOISE SUPPRESSION...........8A-10
GROUND STRAP - OPERATION, RADIO
NOISE SUPPRESSION..................8A-9
GROUND STRAP - REMOVAL, RADIO
NOISE SUPPRESSION..................8A-9
GROUNDS - DESCRIPTION, POWER......8E-10
GUIDE SEALS - DESCRIPTION, VALVE . 9-32,9-38
GUIDES - DESCRIPTION, VALVE....9-107,9-202
GUIDES AND SPRINGS - STANDARD
PROCEDURE, VALVES.................9-256
HALF SHAFT - CAUTION................3-20
HALF SHAFT - DIAGNOSIS AND TESTING . . 3-20
HALF SHAFT - INSTALLATION............3-21
HALF SHAFT - REMOVAL...............3-20
HALF SHAFT - SPECIAL TOOLS..........3-21
HALF SHAFT - SPECIFICATIONS..........3-21
HANDLE - INSTALLATION, A-PILLAR
TRIM/GRAB.........................23-63
HANDLE - INSTALLATION, B-PILLAR
GRAB..............................23-68
HANDLE - INSTALLATION, EXTERIOR
....23-21,
23-30
HANDLE - INSTALLATION, RELEASE
.......5-44
HANDLE - REMOVAL, A-PILLAR
TRIM/GRAB
.........................23-63
HANDLE - REMOVAL, B-PILLAR GRAB
....23-68
HANDLE - REMOVAL, EXTERIOR
. . . 23-20,23-30
HANDLE - REMOVAL, RELEASE
..........5-44
HANDLE ACTUATOR - INSTALLATION,
INSIDE
........................23-22,23-32
HANDLE ACTUATOR - REMOVAL, INSIDE
. 23-22,
23-31
HANDLE/BEZEL - INSTALLATION,
LUMBAR SUPPORT
...................23-82
HANDLE/BEZEL - REMOVAL, LUMBAR
SUPPORT
..........................23-82
HANDLE/LATCH REMOTE -
INSTALLATION, RELEASE
..............23-17
HANDLE/LATCH REMOTE - REMOVAL,
RELEASE
...........................23-17
HANDLING NON-DEPLOYED
SUPPLEMENTAL RESTRAINTS -
STANDARD PROCEDURE
...............8O-6HANDLING TUBING AND FITTINGS -
STANDARD PROCEDURE...............24-45
HANDS FREE MODULE - INSTALLATION....8T-2
HANDS FREE MODULE - REMOVAL.......8T-2
HARNESS - DIAGNOSIS AND TESTING,
WIRING..........................8W-01-7
HAZARD SWITCH - DESCRIPTION.......8L-14
HAZARD SWITCH - OPERATION.........8L-14
HCU (HYDRAULIC CONTROL UNIT) -
DESCRIPTION........................5-49
HCU (HYDRAULIC CONTROL UNIT) -
INSTALLATION........................5-50
HCU (HYDRAULIC CONTROL UNIT) -
OPERATION..........................5-49
HCU (HYDRAULIC CONTROL UNIT) -
REMOVAL...........................5-50
HEAD - CLEANING, CYLINDER.....9-200,9-251
HEAD - DESCRIPTION, CYLINDER . . 9-107,9-249
HEAD - INSPECTION, CYLINDER....9-200,9-252
HEAD - INSTALLATION, CYLINDER.......9-200
HEAD - INSTALLATION, LEFT CYLINDER . . 9-112
HEAD - INSTALLATION, RIGHT
CYLINDER..........................9-113
HEAD - LEFT - INSTALLATION,
CYLINDER...........................9-24
HEAD - LEFT - REMOVAL, CYLINDER......9-22
HEAD - OPERATION, CYLINDER.........9-199
HEAD - REMOVAL, CYLINDER.....9-200,9-249
HEAD - REMOVAL, LEFT CYLINDER......9-108
HEAD - REMOVAL, RIGHT CYLINDER.....9-110
HEAD - RIGHT - INSTALLATION,
CYLINDER...........................9-34
HEAD - RIGHT - REMOVAL, CYLINDER....9-33
HEAD COVER - INSTALLATION,
CYLINDER..........................9-255
HEAD COVER - REMOVAL, CYLINDER....9-255
HEAD COVER(S) - DESCRIPTION,
CYLINDER......................9-122,9-27
HEAD COVER(S) - INSTALLATION,
CYLINDER..................9-201,9-28,9-37
HEAD COVER(S) - REMOVAL, CYLINDER . 9-201,
9-28,9-37
HEAD GASKET - DIAGNOSIS AND
TESTING, CYLINDER...................9-21
HEAD GASKET FAILURE - DIAGNOSIS
AND TESTING, CYLINDER..............9-199
HEAD GASKET SELECTION - STANDARD
PROCEDURE........................9-281
HEADLAMP - INSTALLATION............8L-14
HEADLAMP - REMOVAL...............8L-14
HEADLAMP SWITCH - DESCRIPTION.....8L-14
HEADLAMP SWITCH - INSTALLATION....8L-15
HEADLAMP SWITCH - OPERATION.......8L-14
HEADLAMP SWITCH - REMOVAL........8L-14
HEADLAMP SWITCH BEZEL -
INSTALLATION, INSTRUMENT PANEL.....23-56
HEADLAMP SWITCH BEZEL - REMOVAL,
INSTRUMENT PANEL..................23-56
HEADLAMP UNIT - ADJUSTMENTS......8L-16
HEADLAMP UNIT - INSTALLATION.......8L-15
HEADLAMP UNIT - REMOVAL...........8L-15
HEADLINER - INSTALLATION...........23-68
HEADLINER - REMOVAL...............23-68
HEADREST - INSTALLATION............23-80
HEADREST - REMOVAL................23-80
HEADREST SLEEVE - INSTALLATION.....23-81
HEADREST SLEEVE - REMOVAL.........23-81
HEAT SHIELDS - DESCRIPTION..........11-8
HEAT SHIELDS - INSTALLATION..........11-8
HEAT SHIELDS - REMOVAL.............11-8
HEAT STAKING - STANDARD
PROCEDURE.........................23-3
HEATED GLASS - DESCRIPTION..........8G-1
HEATED GLASS - OPERATION...........8G-1
HEATED MIRRORS - DESCRIPTION.......8G-6
HEATED MIRRORS - OPERATION.........8G-6
HEATED SEAT ELEMENT - DESCRIPTION . . . 8G-9
HEATED SEAT ELEMENT - DIAGNOSIS
AND TESTING.......................8G-10
HEATED SEAT ELEMENT - INSTALLATION . 8G-10
HEATED SEAT ELEMENT - OPERATION....8G-10
HEATED SEAT ELEMENT - REMOVAL
.....8G-10
HEATED SEAT MODULE - DESCRIPTION
....8E-6
HEATED SEAT MODULE - DESCRIPTION
. . 8G-13
HEATED SEAT MODULE - DIAGNOSIS
AND TESTING
........................8E-6
HEATED SEAT MODULE - DIAGNOSIS
AND TESTING
.......................8G-14
DRINDEX 15
Description Group-Page Description Group-Page Description Group-Page

SENSOR - REMOVAL, LINE PRESSURE
(LP)..............................21-383
SENSOR - REMOVAL, MAP.............14-33
SENSOR - REMOVAL, OUTPUT SPEED . . . 21-391
SENSOR - REMOVAL, OXYGEN..........14-35
SENSOR - REMOVAL, POSITION . . 21-443,21-478
SENSOR - REMOVAL, REAR WHEEL
SPEED..............................5-48
SENSOR - REMOVAL, THROTTLE
POSITION..........................14-41
SENSOR - REMOVAL, TRANSMISSION
RANGE............................21-265
SENSOR - REMOVAL, WATER IN FUEL....14-66
SENSOR CIRCUIT - DIAGNOSIS AND
TESTING, AMBIENT TEMPERATURE......8M-10
SENSOR RETURN - DESCRIPTION.......8E-10
SENSOR (TRS) - DIAGNOSIS AND
TESTING, TRANSMISSION RANGE......21-264
SENSOR/MAP SENSOR - DESCRIPTION,
INTAKE AIR TEMPERATURE............14-82
SENSOR/MAP SENSOR - INSTALLATION,
INTAKE AIR TEMPERATURE............14-82
SENSOR/MAP SENSOR - OPERATION,
INTAKE AIR TEMPERATURE............14-82
SENSOR/MAP SENSOR - REMOVAL,
INTAKE AIR TEMPERATURE............14-82
SENSOR/PRESSURE SENSOR -
DESCRIPTION, INLET AIR
TEMPERATURE......................14-79
SENSOR/PRESSURE SENSOR -
INSTALLATION, INLET AIR
TEMPERATURE......................14-79
SENSOR/PRESSURE SENSOR -
OPERATION, INLET AIR TEMPERATURE . . . 14-79
SENSOR/PRESSURE SENSOR -
REMOVAL, INLET AIR TEMPERATURE....14-79
SENSOR/SWITCH - DESCRIPTION, OIL
PRESSURE..........................9-67
SENSOR/SWITCH - INSTALLATION, OIL
PRESSURE..........................9-67
SENSOR/SWITCH - OPERATION, OIL
PRESSURE..........................9-67
SENSOR/SWITCH - REMOVAL, OIL
PRESSURE..........................9-67
SENTRY KEY IMMOBILIZER MODULE -
DESCRIPTION.......................8E-13
SENTRY KEY IMMOBILIZER MODULE -
INSTALLATION.......................8E-15
SENTRY KEY IMMOBILIZER MODULE -
OPERATION.........................8E-13
SENTRY KEY IMMOBILIZER MODULE -
REMOVAL..........................8E-15
SENTRY KEY IMMOBILIZER MODULE
(SKIM) - DESCRIPTION................8Q-1
SENTRY KEY IMMOBILIZER MODULE
(SKIM) - OPERATION..................8Q-2
SENTRY KEY IMMOBILIZER SYSTEM
INDICATOR LAMP - DESCRIPTION........8Q-5
SENTRY KEY IMMOBILIZER SYSTEM
INDICATOR LAMP - OPERATION..........8Q-5
SENTRY KEY IMMOBILIZER SYSTEM
INITIALIZATION, STANDARD
PROCEDURE.........................8Q-3
SENTRY KEY IMMOBILIZER SYSTEM
(SKIS) - DESCRIPTION.................8Q-1
SENTRY KEY IMMOBILIZER SYSTEM
(SKIS) - OPERATION...................8Q-2
SENTRY KEY IMMOBILIZER SYSTEM
TRANSPONDER PROGRAMMING,
STANDARD PROCEDURE...............8Q-4
SEPARATOR - DESCRIPTION, FUEL
FILTER / WATER .....................14-50
SEPARATOR - INSTALLATION, FUEL
FILTER / WATER .....................14-50
SEPARATOR - OPERATION, FUEL FILTER
/ WATER ...........................14-50
SEPARATOR - REMOVAL, FUEL FILTER /
WATER.............................14-50
SERVO - ASSEMBLY, FRONT...........21-209
SERVO - ASSEMBLY, REAR............21-251
SERVO - CLEANING, FRONT...........21-209
SERVO - CLEANING, REAR............21-251
SERVO - DESCRIPTION.................8P-6
SERVO - DESCRIPTION, FRONT
........21-208
SERVO - DESCRIPTION, REAR
.........21-251
SERVO - DISASSEMBLY, FRONT
........21-209
SERVO - DISASSEMBLY, REAR
.........21-251
SERVO - INSPECTION, FRONT
.........21-209SERVO - INSTALLATION................8P-6
SERVO - OPERATION..................8P-6
SERVO - OPERATION, FRONT..........21-208
SERVO - OPERATION, REAR...........21-251
SERVO - REMOVAL....................8P-6
SETTING TRANSMITTER CODES -
STANDARD PROCEDURE..............8M-12
SHAFT - ASSEMBLY, PLANETARY
GEARTRAIN/OUTPUT.................21-244
SHAFT - CAUTION, HALF................3-20
SHAFT - DESCRIPTION, PLANETARY
GEARTRAIN/OUTPUT.................21-241
SHAFT - DIAGNOSIS AND TESTING,
HALF...............................3-20
SHAFT - DIAGNOSIS AND TESTING,
PROPELLER...........................3-1
SHAFT - DISASSEMBLY, PLANETARY
GEARTRAIN/OUTPUT.................21-242
SHAFT - HD FRONT - INSTALLATION,
PROPELLER...........................3-7
SHAFT - HD FRONT - REMOVAL,
PROPELLER...........................3-7
SHAFT - INSPECTION, PLANETARY
GEARTRAIN/OUTPUT.................21-243
SHAFT - INSTALLATION, BALANCE........9-80
SHAFT - INSTALLATION, HALF...........3-21
SHAFT - INSTALLATION, IDLER.....9-179,9-81
SHAFT - INSTALLATION, REAR
PROPELLER...........................3-8
SHAFT - OPERATION, PLANETARY
GEARTRAIN/OUTPUT..................21-241
SHAFT - REMOVAL, BALANCE...........9-80
SHAFT - REMOVAL, HALF...............3-20
SHAFT - REMOVAL, IDLER.........9-179,9-81
SHAFT - REMOVAL, REAR PROPELLER.....3-8
SHAFT - SPECIAL TOOLS, HALF..........3-21
SHAFT - SPECIAL TOOLS, PROPELLER.....3-6
SHAFT - SPECIFICATIONS, HALF..........3-21
SHAFT - SPECIFICATIONS, PROPELLER.....3-6
SHAFT - STANDARD PROCEDURE,
PROPELLER...........................3-3
SHAFT FRONT BEARING -
INSTALLATION, OUTPUT..............21-216
SHAFT FRONT BEARING - REMOVAL,
OUTPUT...........................21-216
SHAFT- LD FRONT - INSTALLATION,
PROPELLER...........................3-7
SHAFT- LD FRONT - REMOVAL,
PROPELLER...........................3-6
SHAFT REAR BEARING - INSTALLATION,
OUTPUT...........................21-217
SHAFT REAR BEARING - REMOVAL,
OUTPUT...........................21-216
SHAFT SEAL - INSTALLATION, FRONT
OUTPUT . . . 21-442,21-477,21-508,21-538,21-572
SHAFT SEAL - INSTALLATION, STEERING
GEAR INPUT........................19-29
SHAFT SEAL - REMOVAL, FRONT
OUTPUT . . . 21-441,21-477,21-507,21-537,21-572
SHAFT SEAL - REMOVAL, STEERING
GEAR INPUT........................19-27
SHAFT SEALS - INSTALLATION, AXLE . 3-43,3-70,
3-94
SHAFT SEALS - REMOVAL, AXLE . 3-43,3-69,3-94
SHAFTS - ASSEMBLY, AXLE.............3-69
SHAFTS - DISASSEMBLY, AXLE..........3-68
SHAFTS - INSTALLATION, AXLE....3-124,3-152,
3-43,3-69,3-94
SHAFTS - REMOVAL, AXLE . . . 3-124,3-152,3-43,
3-67,3-93
SHIELD - INSTALLATION, FRONT
WHEELHOUSE SPLASH................23-41
SHIELD - INSTALLATION, REAR
WHEELHOUSE SPLASH................23-41
SHIELD - REMOVAL, FRONT
WHEELHOUSE SPLASH................23-41
SHIELD - REMOVAL, REAR
WHEELHOUSE SPLASH................23-41
SHIELDS - DESCRIPTION, HEAT..........11-8
SHIELDS - INSTALLATION, HEAT.........11-8
SHIELDS - REMOVAL, HEAT.............11-8
SHIFT BOOT - INSTALLATION, 4WD
FLOOR
.............................23-62
SHIFT BOOT - REMOVAL, 4WD FLOOR
....23-62
SHIFT COVER - INSTALLATION
....21-129,21-87
SHIFT COVER - REMOVAL
.......21-129,21-87
SHIFT INTERLOCK - ADJUSTMENTS,
BRAKE TRANSMISSION
........21-196,21-365SHIFT INTERLOCK - DIAGNOSIS AND
TESTING, BRAKE TRANSMISSION......21-196,
21-364
SHIFT INTERLOCK SYSTEM -
DESCRIPTION, BRAKE TRANSMISSION . . 21-196,
21-364
SHIFT INTERLOCK SYSTEM -
OPERATION, BRAKE TRANSMISSION....21-196,
21-364
SHIFT LEVER - ADJUSTMENT....21-446,21-481
SHIFT LEVER - INSTALLATION . . . 21-445,21-480
SHIFT LEVER - INSTALLATION, GEAR.....19-12
SHIFT LEVER - REMOVAL.......21-444,21-479
SHIFT LEVER - REMOVAL, GEAR........19-12
SHIFT MECHANISM - DESCRIPTION....21-252,
21-398
SHIFT MECHANISM - INSTALLATION.....21-87
SHIFT MECHANISM - OPERATION......21-252,
21-398
SHIFT MECHANISM - REMOVAL.........21-86
SHIFT MOTOR - DESCRIPTION . . 21-511,21-541,
21-575
SHIFT MOTOR - INSTALLATION . . 21-511,21-541,
21-575
SHIFT MOTOR - OPERATION....21-511,21-541,
21-575
SHIFT MOTOR - REMOVAL.....21-511,21-541,
21-575
SHOCK - DIAGNOSIS AND TESTING . . . 2-24,2-38
SHOCK - DIAGNOSIS AND TESTING,
SPRING.............................2-41
SHOCK - INSTALLATION.............2-38,2-43
SHOCK - REMOVAL................2-38,2-43
SHOES - ADJUSTMENT, PARKING BRAKE . . 5-41
SHOES - INSTALLATION................5-40
SHOES - REMOVAL....................5-39
SIDE - INSTALLATION, LEFT............9-123
SIDE - INSTALLATION, RIGHT...........9-123
SIDE - REMOVAL, LEFT................9-122
SIDE - REMOVAL, RIGHT..............9-122
SIDE BEZEL - INSTALLATION,
INSTRUMENT PANEL DRIVER...........23-58
SIDE BEZEL - REMOVAL, INSTRUMENT
PANEL DRIVER......................23-58
SIDE CURTAIN AIRBAG - DESCRIPTION . . . 8O-56
SIDE CURTAIN AIRBAG - INSTALLATION . . 8O-58
SIDE CURTAIN AIRBAG - OPERATION....8O-56
SIDE CURTAIN AIRBAG - REMOVAL......8O-57
SIDE IMPACT SENSOR - DESCRIPTION . . . 8O-59
SIDE IMPACT SENSOR - OPERATION.....8O-59
SIDE MOLDINGS - INSTALLATION, BODY . . 23-36
SIDE MOLDINGS - REMOVAL, BODY.....23-36
SIDE VIEW MIRROR - INSTALLATION.....23-42
SIDE VIEW MIRROR - REMOVAL........23-41
SIDE VIEW MIRROR FLAG -
INSTALLATION.......................23-27
SIDE VIEW MIRROR FLAG - REMOVAL . . . 23-27
SIDE VIEW MIRROR GLASS -
INSTALLATION.......................23-43
SIDE VIEW MIRROR GLASS - REMOVAL . . 23-42
SIDEVIEW MIRROR - REMOVAL.........8N-12
SIGNAL INDICATOR - DESCRIPTION,
TURN..............................8J-40
SIGNAL INDICATOR - OPERATION, TURN . . 8J-41
SIGNAL LAMP - INSTALLATION,
PARK/TURN.........................8L-21
SIGNAL LAMP - REMOVAL, PARK/TURN . . 8L-21
SIGNAL SYSTEM - DESCRIPTION, TURN . . 8L-18
SIGNAL SYSTEM - OPERATION, TURN....8L-18
SILL TRIM COVER - INSTALLATION,
REAR DOOR........................23-71
SILL TRIM COVER - REMOVAL, REAR
DOOR.............................23-71
SIZE, SPARE WHEEL WITH MATCHING
TIRE - DESCRIPTION, FULL............22-15
SKID PLATE - INSTALLATION, FRONT.....13-23
SKID PLATE - INSTALLATION, TRANSFER
CASE..............................13-26
SKID PLATE - REMOVAL, FRONT........13-23
SKID PLATE - REMOVAL, TRANSFER
CASE..............................13-26
SLEEVE - INSTALLATION, HEADREST.....23-81
SLEEVE - REMOVAL, HEADREST
........23-81
SMOKE DIAGNOSIS CHARTS -
DIAGNOSIS AND TESTING
.............9-236
SNAP RINGS - ASSEMBLY, WITH
.........3-12
SNAP RINGS - DISASSEMBLY, WITH
......3-10
SOLENOID - DESCRIPTION
............21-252
30 INDEXDR
Description Group-Page Description Group-Page Description Group-Page
