snow chains DODGE RAM 1500 GAS 2004 3.G Owners Manual

NTire Spinning........................248
NTread Wear Indicators..................249
NReplacement Tires.....................249
NAlignment And Balance.................250
mSupplemental Tire Pressure Information.......251
mTire Chains...........................251
mSnow Tires...........................253
mTire Rotation Recommendations............253
NDual Rear Wheels.....................255
mFuel Requirements......................256
NReformulated Gasoline.................257
NGasoline/Oxygenate Blends..............257
NMMT In Gasoline.....................258NSulfur In Gasoline.....................258
NMaterials Added To Fuel................259
NAdding Fuel.........................259
NFuel System Cautions..................261
NCarbon Monoxide Warnings..............262
mFlexible FuelÐ(Fleet Vehicles Only)..........262
NE-85 General Information................262
NEthanol Fuel (E-85)....................263
NFuel Requirements....................263
NSelection Of Engine Oil.................264
NStarting............................265
NCruising Range.......................265
NReplacement Parts.....................265
STARTING AND OPERATING 201
5

These cautions apply to all chain traction devices, includ-
ing link and cable (radial) chains.
Tire chain use is permitted only on the rear tires of Ram
4X2 trucks.
NOTE:The use of class ªSº chains is permitted on 1500
Ram Trucks with P245/70R17 tires only.
NOTE:The use of class ªUº chains is permitted on the
front and rear of 4X4, 2500 Ram Trucks with LT245/
70R17E tires.
NOTE:The use of class ªUº chains is permitted on the
front and rear of 4X4, 3500 Ram Trucks with Dual Rear
Wheels and LT235/80R17E tires.
NOTE:On 4X2 2500/3500 Ram Trucks, class ªUº snow
chains are permitted on the rear wheels only of vehicles
equipped with LT245/70R17, LT265/70R17, and LT235/
80R17 size tires.NOTE:On 4x4 2500/3500 SRW (Single Rear Wheel)
Ram Trucks, class ªUº snow chains are permitted on the
rear wheels only of vehicles equipped with LT265/
70R17E.
CAUTION!
Do not use tire chains on 4x4 Ram trucks equipped
with P265/70R17, LT275/70R17, P275/60R20, or P275/
55R20 tires. There may not be adequate clearance for
the chains and you are risking structural or body
damage to your vehicle. Do not use tire chains on the
4X2 front wheels of 2500/3500 SRW (Single Rear
Wheels) equipped with LT245/70R17, LT265/70R17
LT235/80R17 tires or 4X4 front wheels of Ram Trucks
equipped with LT265/70R17E. There may not be
adequate clearance for the chains and you are risking
structural or body damage to your vehicle.
252 STARTING AND OPERATING

FREEING A STUCK VEHICLE
If vehicle becomes stuck in snow, sand, or mud, it can
often be moved by a rocking motion. Move the gear
selector rhythmically between DRIVE and REVERSE,
while applying slight pressure to the accelerator.
In general, the least amount of accelerator pedal pressure
to maintain the rocking motion without spinning the
wheels or racing the engine is most effective. Racing the
engine or spinning the wheels, due to the frustration of
not freeing the vehicle, may lead to transmission over-
heating and failure. Allow the engine to idle with the
transmission selector in NEUTRAL for at least one
minute after every five rocking-motion cycles. This will
minimize overheating and reduce the risk of transmis-
sion failure during prolonged efforts to free a stuck
vehicle.
EMERGENCY TOW HOOKS Ð IF EQUIPPED
Your vehicle may be equipped with emergency tow
hooks.
WARNING!
Chains are not recommended for freeing a stuck
vehicle. Chains may break, causing serious injury or
death.
WARNING!
Stand clear of vehicles when pulling with tow
hooks. Tow straps and chains may break, causing
serious injury.
316 WHAT TO DO IN EMERGENCIES

Seat Belts..........................33,34,70
Adjustable Upper Shoulder Anchorage........ 41
And Pregnant Women................... 44
Child Restraint.......................55,67
Extender............................. 44
Front Seat............................ 34
Pretensioners.......................... 42
Reminder............................ 145
Seats...............................91,92
Adjustment........................... 91
Child............................... 67
Folding Floor......................... 130
Heated.............................. 96
Lumbar Support........................ 94
Power............................... 95
Reclining............................. 93
Security Alarm.......................29,147
Selection of Coolant...................... 381
Sentry Key............................. 11Service Assistance....................... 404
Service Contract......................... 406
Service Manuals........................ 410
Setting the Clock........................ 151
Shifting............................... 208
Automatic Transmission................. 208
Manual Transmission................... 213
Transfer Case......................... 219
Transfer Case, Shifting into Transfer
Case Neutral (N)..................285,287
Transfer Case, Shifting out of Transfer
Case Neutral (N)..................286,289
Shoulder Belt Upper Anchorage.............. 41
Shoulder Belts........................... 34
Side Airbag............................. 53
Signals, Turn........................... 103
Snow Chains........................... 251
Snow Plow............................ 280
Snow Tires............................ 253
INDEX 425
10
