wipers DODGE RAM 1500 GAS 2004 3.G Owners Manual

NAdjustable Head Restraints...............93
NManual Rotary Lumbar Support
Adjustment Ð If Equipped...............94
NPower Seats Ð If Equipped...............95
NHeated Seats Ð If Equipped..............96
mTo Open And Close The Hood..............97
mLights................................99
NInterior Lights........................99
NBattery Saver........................100
NHeadlamp Delay Ð If Equipped..........101
NHeadlights, Parking Lights, Panel Lights.....101
NDaytime Running Lights (Canada And Fleet
Vehicles Only).......................102
NLights-On Reminder...................102NFog Lights Ð If Equipped...............102
NCargo Light.........................103
mMultifunction Control Lever...............103
NTurn Signals.........................103
NPassing Light........................104
NHigh Beam / Low Beam Select Switch......104
NWindshield Wipers....................105
NWindshield Washers...................106
mTilt Steering Column....................107
mDriver Adjustable Pedals Ð If Equipped......108
NAdjustment.........................108
mElectronic Speed Control Ð If Equipped......109
NTo Activate..........................109
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Windshield Wipers
The wipers and washers are operated by a switch in the
multifunction control lever. Turn the end of the handle to
select the desired wiper speed.
Intermittent Wiper System
The intermittent feature of this system was designed for
use when weather conditions make a single wiping cycle,
with a variable pause between cycles, desirable. For
maximum delay between cycles, rotate the control knob
into the upper end of the delay range.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner. This will remove accu-
mulations of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc.
Windshield Washers
The fluid reservoir is located under the hood and should
be checked for fluid level at regular intervals. Fill the
reservoir with windshield washer solvent only (not ra-
diator antifreeze).To prevent freeze-up of your windshield washer system
in cold weather, select a solution or mixture that meets or
exceeds the temperature range of your climate. This
rating information can be found on most washer fluid
containers.
WARNING!
Commercially available windshield washer solvents
are flammable. They could ignite and burn you. Care
must be exercised when filling or working around
the washer solution.
After the engine has warmed, operate the defroster for a
few minutes to reduce the possibility of smearing or
freezing the fluid on the cold windshield. Mopar All
Weather Windshield Washer Solution, used with water as
342 MAINTAINING YOUR VEHICLE

Climate Control......................... 185
Clock................................ 151
Clutch............................... 349
Clutch Linkage Maintenance................ 350
Compact Disc Maintenance................. 184
Compact Disc Player..................158,164
Compact Spare Tire...................... 247
Compass.............................. 117
Compass Calibration..................... 117
Compass Variance....................... 118
Computer, Trip/Travel.................... 114
Console, Overhead....................... 113
Contract, Service........................ 406
Converter, Catalytic...................... 266
Cooling System......................... 344
Coolant Capacity...................... 379
Coolant Level......................... 344
Disposal of Used Coolant................ 347
Drain, Flush, and Refill.................. 345Inspection........................... 344
Radiator Cap......................344,347
Selection of Coolant...............346,379,381
Temperature Gauge..................... 146
Cruise Control.......................... 109
Cup Holder............................ 128
Customer Assistance..................... 404
Daytime Running Lights................... 102
Dealer Service.......................... 326
Defroster, Rear Window..............78,191,195
Defroster, Windshield..................186,189
Delay Wipers........................... 105
Differential, Limited-Slip.................. 228
Dipsticks
Automatic Transmission................. 352
Power Steering........................ 339
Disc Brakes............................ 348
416 INDEX

Hub Caps............................. 308
Ignition.............................14,204
Key ............................... 11,14
Lock................................ 14
Infant Restraint........................55,56
Inflation Pressure Tires.................... 251
Inside Rearview Mirror.................... 75
Instrument Cluster....................142,143
Instrument Panel and Controls.............. 141
Instrument Panel Lens Cleaning............. 364
Interior Appearance Care.................. 363
Intermittent Wipers...................... 105
Introduction............................. 4
Jack Location........................... 296
Jack Operation.......................... 302
Jump Starting.......................... 312Key, Replacement........................ 12
Key, Sentry............................. 11
Key-In Reminder......................... 11
Keyless Entry System...................... 22
Keys................................ 11,16
Lane Change and Turn Signals.............. 103
Lap Belts.............................. 42
Lap/Shoulder Belts....................... 34
LATCH (Lower Anchors and Tether for CHildren) . 59
Lights...............................70,99
Airbag............................55,144
Anti-Lock Warning..................148,232
Battery Saver......................... 100
Brake Warning........................ 147
Bulb Replacement...................... 366
Cap Top Clearance..................... 374
Center Mounted Stop................... 372
Check Engine......................... 143
420 INDEX

Shifting............................. 208
Transmitter, Garage Door Opener............ 120
Tread Wear Indicators.................... 249
Trip Computer.......................... 114
Trip Odometer.......................148,150
Turn Signals...................103,144,366,370
Underhood Fuses........................ 365
Universal Transmitter..................... 120
Variance, Compass....................... 118
Vehicle Identification Number................ 6
Vehicle Loading......................240,267
Vehicle Modifications/Alterations.............. 7
Vehicle Storage......................... 365
Voltmeter............................. 144
Warning Lights (Instrument Cluster Description) . 143
Warnings and Cautions..................... 5Warranty Information..................... 407
Washers, Windshield..................106,342
Washing Vehicle......................... 361
Wheel Alignment and Balance............... 250
Wheel and Wheel Trim.................... 362
Wheel Changing........................ 301
Wheel Mounting........................ 302
Wheel Nut Torque....................307,311
Wind Buffeting.......................... 33
Window Airbag.......................... 53
Window Fogging........................ 196
Windows.............................. 31
Power............................... 31
Rear Sliding........................... 32
Windshield Defroster..................186,189
Windshield Washers................105,106,342
Fluid............................105,342
Windshield Wiper Blades.................. 342
Windshield Wipers....................... 105
428 INDEX

Wiper Blade Replacement.................. 342 Wipers, Intermittent...................... 105
INDEX 429
