3. Pull the bulb straight out from the socket.
4. Reverse procedure for installation of bulbs and hous-
ing.
Side Marker Lights (Dual Rear Wheels)
1. Push rearward on the side marker light assembly.
2. Pull the entire assembly from the fender. 3. Turn socket
14turn counterclockwise and remove from
assembly to access the bulb.
4. Pull bulb straight out from socket.
5. Reverse procedure for installation of bulbs and hous-
ing.
MAINTAINING YOUR VEHICLE 481
7

Fog Lights
1. Reach under the vehicle, unlock and twist connector
counterclockwise14turn and remove connector and bulb
from housing.
2. Pull bulb straight from the connector. 3. Reverse procedure for installation of bulbs and hous-
ing.
482 MAINTAINING YOUR VEHICLE

FLUIDS AND CAPACITIES
U.S. Metric
Fuel 3.7L/4.7L, 87 Octane5.7L, 89 Octane
1500 Shortbed Models 26 gal. 98L 1500 Longbed Models 35 gal. 132L
1500 Shortbed Models 34 gal. 128L
2500 Shortbed Models 34 gal. 128L 2500 Longbed Models 35 gal. 132L
3500 Shortbed Models 34 gal. 128L 3500 Longbed Models 35 gal. 132L
MAINTAINING YOUR VEHICLE 483
7

U.S. Metric
Engine Oil (with filter) 3.7L Engine V-6, SAE 5W-30, API Certified 5.0 qts. 4.7L
4.7L Engine V-8, SAE 5W-30, API Certified 6.0 qts. 5.7L
5.7L Engine V-8, SAE 5W-20, API Certified 7.0 qts. 6.6L
Cooling System 3.7L (Mopar  Antifreeze/Coolant 5 Year/100,000 Mile
Formula) 17 qts. 16L
4.7L (Mopar  Antifreeze/Coolant 5 Year/100,000 Mile
Formula) 17 qts. 16L
5.7L (Mopar  Antifreeze/Coolant 5 Year/100,000 Mile
Formula) 18.7 qts. 17.7L
484 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent.
3.7/4.7L Engine Oil Use SAE 5W-30, API Certified, meeting material standard MS-6395.
5.7L Engine Oil Use SAE 5W-20, API Certified, meeting material standard MS-6395.
Engine Oil Filter Mopar Engine Oil Filter, P/N 5281090 or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com- partment.
Fuel Selection (all except 5.7L) 87 Octane, (R+M)/2 Method
Fuel Selection (5.7L) 89 Octane, (R+M)/2 Method, Mid-Grade Preferred (87 Octane acceptable)
MAINTAINING YOUR VEHICLE 485
7

Chassis
Component Fluids, Lubricants and Genuine Parts.
Automatic Transmission Mopar ATF+4, Automatic Transmission Fluid.
Transfer Case Mopar ATF+4, Automatic Transmission Fluid.
NVG 246 Automatic Transfer Case Only Mopar PN 05179014AA, NVG 246 Automatic Transmission Fluid or
equivalent.
Manaul Transmission Fluid (G238) Mopar ATF+4, Automatic Transmission Fluid.
Manual Transmission Fluid (G-56) Mopar ATF+4, Automatic Transmission Fluid.
Clutch Linkage Multipurpose Grease, NLGI Grade 2 E.P. or equivalent.
1500 Model Front Axle (4X4) GL-5 SAE 75W-90 (MS-9763) or equivalent.
1500 Model Rear Axle Mopar Synthetic Gear Lubricant SAE 75W-140 (MS-8985). Limited-Slip
Rear Axles on 1500 Models Require the addition of 118 ml (4 oz.) Mo-
par  limited slip additive or equivalent.
2500/3500 Model Front and Rear Axle Synthetic, GL-5 SAE, 75W-90 or equivalent. Limited-Slip 10.5/11.5 inch Rear Axles DO NOT REQUIRE a limited slip additive.
Brake Master Cylinder Mopar DOT 3 and SAE J1703 should be used or equivalent. If DOT 3
brake fluid is not available, then DOT 4 is acceptable. Use only recom-
mended brake fluids.
Power Steering Reservoir Mopar ATF+4, Automatic Transmission Fluid.
486 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULES
CONTENTS

Emission Control System Maintenance ........488

Maintenance Schedules ...................488 ▫
Schedule “B” ........................491
▫ Schedule “A” ........................503
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

EMISSION CONTROL SYSTEM MAINTENANCE
The “Scheduled” maintenance services, listed inbold
type in this section (Section 8) must be done at the times
or mileages specified to assure the continued proper
functioning of the emission control system. These, and all
other maintenance services included in this manual,
should be done to provide best vehicle performance and
reliability. More frequent maintenance may be needed for
vehicles in severe operating conditions such as dusty
areas and very short trip driving.
Inspection and service also should be done any time a
malfunction is suspected.
NOTE: Maintenance, replacement, or repair of the emis-
sion control devices and systems on your vehicle may be
performed by any automotive repair establishment or
individual using any automotive part which has been
certified pursuant to U.S. EPA or, in the State of Califor-
nia, California Air Resources Board regulations.
MAINTENANCE SCHEDULES
There are two maintenance schedules that show the
required service for your vehicle.
First is Schedule “B”. It is for vehicles that are operated
under one or more of the following conditions that are
listed below and at the beginning of the schedule.
•Day or night temperatures are below 32° F (0° C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90° F (32°C).
•Trailer towing.
•Snowplowing.
488 MAINTENANCE SCHEDULES
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

•Heavy Loading.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert operation.
•If equipped for and operating with E-85 (ethanol)
fuel.
NOTE: IfANY of these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow schedule “B” of the
 Maintenance Schedules section of this manual.
NOTE: IfANY of these apply to you then flush and
replace your engine coolant every 102,000 miles (170 000
km) or 60 months, whichever comes first and follow
schedule “B” of the Maintenance Schedules section of
this manual.
NOTE: Most vehicles are operated under the conditions
listed for Schedule B. Second is Schedule
“A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
ule B.
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.
NOTE: Under no circumstances should oil change in-
tervals exceed 6000 miles (10 000 km) or 6 months
whichever comes first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
MAINTENANCE SCHEDULES 489
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

At Each Stop for Fuel
•Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required. When refilling the washer fluid reservoir,
take some washer fluid and apply it to a cloth or towel
and wipe clean the wiper blades, this will help blade
performance.
Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant bottle, brake master
cylinder, and transmission and add as needed.
•Check all lights and all other electrical items for correct
operation.
At Each Oil Change
•Change the engine oil filter.
•Lubricate Drivetrain/Steering/Suspension Grease Fit-
tings (if equipped)
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints/U— joints (if equipped) and
front suspension components.
•Check the automatic transmission fluid level.
•Check the manual transmission fluid level.
•Check the coolant level, hoses, and clamps.
•Lubricate Front Drive Shaft Fitting (2500/3500, 4X4).
