WARNINGS AND CAUTIONS
This manual containsWARNINGSagainst operating
procedures which could result in an accident or bodily
injury. It also contains CAUTIONSagainst procedures
which could result in damage to your vehicle. If you do
not read this entire manual you may miss important
information. Observe all Warnings and Cautions.
VAN CONVERSIONS/CAMPERS
The Manufacturer’s Warranty does not apply to body
modifications or special equipment installed by van
conversion/camper manufacturers/ body builders. See
the Warranty information book, Section 2.1.C. Such
equipment includes video monitors, VCRs, heaters,
stoves, refrigerators, etc. For warranty coverage and
service on these items, contact the applicable manufac-
turer. Operating instructions for the special equipment in-
stalled by the conversion/camper manufacturer should
also be supplied with your vehicle. If these instructions
are missing, please contact your selling dealer for assis-
tance in obtaining replacement documents from the
applicable manufacturer.
INTRODUCTION 5
1

Each heated seat switch has two settings (HI and LOW).
Press the switch once to obtain High heat level, then
press the switch again to obtain Low heat level. Pressing
the switch a third time will turn the heated seats OFF. If
you do not purposefully turn the switch OFF, the seat
heating level will automatically change to the next lower
level, or OFF. The High heat level operates for 30 minutes
(approximate), the Low heat level operates for 30 min-
utes (approximate). The seat heat will also turn OFF
when the ignition is turned OFF. Both of the indicators
ON identifies High heat level. The lower indicator On
only, identifies Low heat level. Flashing indicator lights
on the switch indicate that the Heated Seat System needs
servicing.WARNING!
Persons who are unable to feel pain to the skin
because of advanced age, chronic illness, diabetes,
spinal cord injury, medication, alcohol use, exhaus-
tion or other physical condition must exercise care
when using the seat heater. It may cause burns even
at low temperatures, especially if used for long
periods of time.
Do not place anything on the seat that insulates
against heat, such as a blanket or cushion. This may
cause the seat heater to overheat.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159
3

Compact Disc Maintenance ................273

Radio Operation And Cellular Phones ........273

Climate Controls .......................274
▫ Heater Only — Fleet Vehicles .............274
▫ Air Conditioning And Heating —
If Equipped .........................277 ▫
Electric Rear Window Defroster And Heated
Sideview Mirrors — If Equipped ..........280
▫ Air Conditioning With Dual Zone Temperature
Control — If Equipped .................280
▫ Operating Tips .......................285
▫ Operating Tips Chart ...................287
216 UNDERSTANDING YOUR INSTRUMENT PANEL

CLIMATE CONTROLS
The controls for the heating and ventilation system in this
vehicle consist of a series of rotary knobs. These comfort
controls can be set to obtain desired interior conditions.
Heater Only — Fleet Vehicles
Climate Control Location
Manual Heating Controls
274 UNDERSTANDING YOUR INSTRUMENT PANEL

STARTING AND OPERATING
CONTENTS

Ignition/Starter Switch ...................294
▫ Lock ..............................294
▫ Off ...............................294
▫ On................................294
▫ Start ..............................295
▫ ACC ..............................295
▫ Manual Transmission Key Release Button ....295
▫ Key Reminder .......................296

Starting Procedures .....................296 ▫
Manual Transmission ..................296
▫ Automatic Transmission ................296
▫ If Engine Fails To Start .................297
▫ Engine Block Heater — If Equipped ........297
▫ After Starting ........................298

Transmission Shifting ....................299
▫ Automatic Transmission With Overdrive .....299
▫ Manual Transmission ..................304

Four-Wheel- Drive Operation — If Equipped . . . 308
5

If Engine Fails To Start
If the engine fails to start after you have followed the
normal starting procedure, it may be flooded. Push the
accelerator pedal all the way to the floor and hold it there
while cranking the engine. This should clear any excess
fuel in case the engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the key is
released. If this occurs, continue cranking with the accel-
erator pedal pushed all the way to the floor. Release the
accelerator pedal and the key once the engine is running
smoothly. If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the normal starting procedure should be
repeated.
WARNING!
Never pour fuel or other flammable liquids into the
throttle body air inlet opening in an attempt to start
the vehicle. This could result in a flash fire causing
serious personal injury.
Engine Block Heater — If Equipped
The engine block heater warms the engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 volt AC electrical outlet with
grounded, three-wire extension cord.
STARTING AND OPERATING 297
5

The engine block heater cord is routed under the hood to
the right side of the vehicle and held to the body with
removable clips.
WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt electrical cord could
cause electrocution.
After Starting
The idle speed is automatically controlled and will de-
crease as the engine warms up.
CAUTION!
Long periods of engine idling, especially at high
engine speeds can cause excessive exhaust tempera-
tures which can damage your vehicle. Do not leave
your vehicle unattended with the engine running.
WARNING!
Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
298 STARTING AND OPERATING

WARNING!
Battery fluid is a corrosive acid solution; do not
allow battery fluid to contact eyes, skin or clothing.
Don’t lean over battery when attaching clamps or
allow the clamps to touch each other. If acid splashes
in eyes or on skin, flush contaminated area immedi-
ately with large quantities of water.
A battery generates hydrogen gas which is flam-
mable and explosive. Keep flame or spark away
from the vent holes.
Do not use a booster battery or any other booster
source that has a greater than 12 volt system, i.e. Do
not use a 24 volt power source.
1. Remove all metal jewelry such as watch bands or
bracelets which might make an unintended electrical
contact. 2. Park the booster vehicle within cable reach but with-
out letting the vehicles touch. Set the parking brake on
both vehicles, place the automatic transmission in Park or
the manual transmission in Neutral, and turn the ignition
OFF.
3. Turn off the heater, radio, and all unnecessary electri-
cal loads.
4. Connect one end of a jumper cable to the positive
terminal of the booster battery. Connect the other end of
the same cable to the positive terminal of the discharged
battery.
WARNING!
Do not permit vehicles to touch each other as this
could establish a ground connection and personal
injury could result.
WHAT TO DO IN EMERGENCIES 417
6

Heated Mirrors.................... 1 19,280,283
Heated Seats ........................... 158
Heater ............................... 277
High Beam/Low Beam Select (Dimmer) Switch . . 167
Hitches Trailer Towing ........................ 372
Hoisting .............................. 416
HomeLink (Garage Door Opener) Transmitter . . . 183
Hood Release .......................... 160
Hoses ................................ 449
Hub Caps ............................. 411
Ignition ............................. 14,294
Key ............................... 12,14
Lock ................................ 14
Infant Restraint ...................... 56,93,94
Inflation Pressure Tires .................... 352
Inside Rearview Mirror .................... 116
Instrument Cluster .................... 218,219 Instrument Panel and Controls
.............. 217
Instrument Panel Lens Cleaning ............. 465
Integrated Power Module .................. 466
Interior Appearance Care .................. 464
Interior Lights .......................... 162
Intermittent Wipers (Delay Wipers) ........... 168
Introduction ............................. 4
Jack Location ........................... 399
Jack Operation .......................... 405
Jump Starting .......................... 416
Key, Replacement ........................ 13
Key, Sentry (Immobilizer) ................... 12
Key-In Reminder ......................... 12
Keyless Entry System ...................... 22
Keys ................................ 12,16
Knee Bolster ............................ 43
524 INDEX

Lumbar Support....................... 148
Power ........................... 149,151
Rear Folding ....................... 153,155
Reclining ......................... 146,147
Reclining Rear ........................ 153
Security Alarm (Theft Alarm) .............26,222
Selection of Coolant (Antifreeze) ............. 485
Sentry Key (Immobilizer) ................... 12
Service Assistance ....................... 510
Service Contract ......................... 512
Service Manuals ........................ 514
Setting the Clock .............227,230,238,252,265
Shift Speeds ........................... 307
Shifting ............................... 299
Automatic Transmission ................. 299
Manual Transmission ................. 304,306
Transfer Case ......................... 311
Transfer Case, Shifting into Transfer Case Neutral (N) .................. 387,390 Transfer Case, Shifting out of Transfer
Case Neutral (N) .................. 389,392
Shoulder Belt Upper Anchorage ............38,76
Shoulder Belts ......................... 31,68
Side Airbag ............................. 89
Signals, Turn ........................... 166
Sliding Rear Window Power ............................... 29
Snow Chains (Tire Chains) ................. 352
Snow Plow ............................ 382
Snow Tires ............................ 354
Spare Tire .......................... 347,348
Spark Plugs ............................ 436
Speed Control (Cruise Control) .............. 172
Speedometer ........................... 220
Starting ............................... 296
Automatic Transmission ................. 296
Engine Block Heater .................... 297
Engine Fails to Start .................... 297
530 INDEX
