DODGE RAM 1500 GAS 2007 3.G Owners Manual

Reclining Seats (2500/3500/Mega Cab Models)
The recliner handle is on the outside of the seat cushion.
Pull up on the handle, as shown, to release the seat back
and adjust for comfort.WARNING!
You can be seriously, even fatally, injured riding in a
seat with the seatback reclined. Do not ride with the
seatback reclined so that the shoulder belt is no
longer resting against your chest. If you ride in this
position, the shoulder harness will no longer be
restraining you. In a collision you could slide under
the seat belt and receive serious or fatal injuries.
Recline in a seat only when the vehicle is parked.
Adjustable Head Restraints
Head restraints can reduce the risk of neck injury in the
event of impact from the rear. Pull up or push down on
the restraints so that the upper edge is as high as
practical, at least to the level of the ears.
Manual Recline Lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151
3

To lower the head restraint, push in the button and then
push down on the head restraint.Manual Rotary Lumbar Support Adjustment — If
Equipped
Rotating the lumbar control knob on the left side of the
driver’s seatback and on the right side of the passenger’s
seatback increases or decreases the lumbar (lower back)
support.
Head Restraints
Manual Lumbar Adjustment
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Power Seats (1500 Standard and Quad Cab
Models) — If Equipped
CAUTION!
Don’t put anything under a power seat. It may cause
damage to the seat controls.
Power Seat Switch
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153
3

The power seat controls are on the outboard side of the
front seat cushions. One switch controls the seat move-
ment. The six-way switch can be moved forward or back-
wards to get the most comfortable position. The same
switch can be moved up and down to control seat height or
to change the seat angle by tilting it up or down.Power Seats (2500/3500/Mega Cab Models) — If
Equipped
CAUTION!
Don’t put anything under a power seat. It may cause
damage to the seat controls or the Occupant Classi-
fication System.
Power Seat Switch Position
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Power Seat SwitchUp, Down, Forward, and Rearward
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155
3

The power seat controls are on the outboard side of the
front seat cushions. Three switches control the seat move-
ment. The four-way switch in the center can be moved
forward or backwards to get the most comfortable posi-
tion. The same switch can be moved up and down to
control seat height. Change the seat angle by using the
two toggle switches, tilting it up or down.Rear Seat Features — Mega Cab Models
Reclining Rear Seats — Mega Cab Models
The recliner handle is on the outside of the seat cushion.
Pull up on the handle, as shown, to release the seat back
and adjust for comfort.
Tilt Adjustment
Rear Seat Recliner Handle
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Folding Rear Seat (Table Mode) — Mega Cab
Models
Both the left and right rear seat backs can be folded down
and used as a table.
To fold either rear seat back down (Table Mode), lift the
handle and fold the seat back forward. Simply lift the seat
back to return the seat to the upright position. Verify that
it is locked in place.
Table Mode Handle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157
3

Folding Rear Seat (Kneel Mode) — Mega Cab
Models
Both the left and right rear seats can be folded flat (Kneel
Mode) and used for carrying cargo. Each of the rear seatbacks provide 2 D-rings and each of the rear storage bin
lids provide 2 slotted cutouts. Use a cargo tie down to
secure cargo in the cargo carrying area.
Table Mode
Securing Cargo
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
•It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision,
people riding in these areas are more likely to be
seriously injured or killed.
•Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat
belts.
•Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
WARNING!
Cargo must be securely tied down before driving
your vehicle. Improperly secured cargo can fly
around in a sudden stop and strike someone in the
vehicle, causing serious injury or possible death.
Secure cargo with a cargo tie down using the
D-Rings provided on the back of the seats and the
slotted cutouts in the rear storage bin lid.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159
3

NOTE:The rear seat will drop and move forward in
Kneel Mode.
To fold either rear seat flat (Kneel Mode), lift the handle
and fold the seat forward. Simply lift the seat back to
return the seat to the upright position. Verify that it is
locked in place.
Kneel Mode Handle
Kneel Mode
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
