DODGE RAM 2003 Service Repair Manual

8W-53 WIPERS
Component Page
Data Link Connector................. 8W-53-2
Front Control Module............. 8W-53-2, 3, 4
Fuse 8............................ 8W-53-3
G104.............................. 8W-53-4
G105.............................. 8W-53-4
G106............................ 8W-53-3, 4
Instrument Cluster................... 8W-53-2
Integrated Power Module.......... 8W-53-2, 3, 4Component Page
Multi-Function Switch................ 8W-53-2
Washer Fluid Level Switch............. 8W-53-4
Washer Pump Motor-Front............. 8W-53-4
Wiper High/Low Relay.............. 8W-53-3, 4
Wiper Motor-Front................. 8W-53-3, 4
Wiper On/Off Relay.................. 8W-53-3
DR8W-53 WIPERS 8W - 53 - 1

8W-54 TRAILER TOW
Component Page
Brake Lamp Switch.................. 8W-54-5
Electric Brake Provision............... 8W-54-5
Front Control Module............. 8W-54-2, 3, 5
Fuse 1............................ 8W-54-5
Fuse 15.......................... 8W-54-2, 3
Fuse 24............................ 8W-54-5
Fuse 33.......................... 8W-54-2, 3
Fuse 46.......................... 8W-54-2, 3
Fuse 47.......................... 8W-54-2, 3
G103............................ 8W-54-3, 4Component Page
G104.......................... 8W-54-3, 4, 5
G106.............................. 8W-54-5
Integrated Power Module.......... 8W-54-2, 3, 5
Park Lamp Relay.................. 8W-54-2, 3
PTCNo.5........................ 8W-54-2, 3
Trailer Tow Connector............ 8W-54-2, 3, 4
Trailer Tow Connector-Add On...... 8W-54-2, 4, 5
Trailer Tow Left Turn Relay.......... 8W-54-2, 3
Trailer Tow Right Turn Relay......... 8W-54-2, 3
DR8W-54 TRAILER TOW 8W - 54 - 1
