(27) Install the engine collar (Fig. 59) onto the
transmission and the engine. Tighten the bolts to 54
N´m (40 ft.lbs.).(28) Align and connect propeller shaft(s).
(29) Adjust gearshift cable if necessary.
(30) Install any skid plates removed previously.
(Refer to 13 - FRAMES & BUMPERS/FRAME/
TRANSFER CASE SKID PLATE - INSTALLATION)
(31) Lower vehicle.
(32) Fill transmission with MopartATF +4, Auto-
matic Transmission Fluid.
Fig. 59 Transmission Collar
1 - ENGINE
2 - ENGINE TO TRANSMISSION COLLAR
3 - TRANSMISSION
21 - 512 AUTOMATIC TRANSMISSION - 45RFE/545RFEDR
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

SCHEMATICS AND DIAGRAMS
HYDRAULIC SCHEMATICS
HYDRAULIC FLOW IN PARK/NEUTRAL
DRAUTOMATIC TRANSMISSION - 45RFE/545RFE 21 - 513
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

HYDRAULIC FLOW IN NEUTRAL OVER 8MPH
21 - 514 AUTOMATIC TRANSMISSION - 45RFE/545RFEDR
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

HYDRAULIC FLOW IN REVERSE
DRAUTOMATIC TRANSMISSION - 45RFE/545RFE 21 - 515
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

HYDRAULIC FLOW IN REVERSE BLOCK
21 - 516 AUTOMATIC TRANSMISSION - 45RFE/545RFEDR
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

HYDRAULIC FLOW IN FIRST GEAR (FROM N OR OD)
DRAUTOMATIC TRANSMISSION - 45RFE/545RFE 21 - 517
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

HYDRAULIC FLOW IN FIRST GEAR (AFTER LAUNCH FROM REST)
21 - 518 AUTOMATIC TRANSMISSION - 45RFE/545RFEDR
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

HYDRAULIC FLOW IN FIRST GEAR (FROM K/D)
DRAUTOMATIC TRANSMISSION - 45RFE/545RFE 21 - 519
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

HYDRAULIC FLOW IN SECOND GEAR
21 - 520 AUTOMATIC TRANSMISSION - 45RFE/545RFEDR
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)

HYDRAULIC FLOW IN SECOND GEAR EMCC
DRAUTOMATIC TRANSMISSION - 45RFE/545RFE 21 - 521
AUTOMATIC TRANSMISSION - 45RFE/545RFE (Continued)
