DODGE RAM 2500 DIESEL 2004 3.G Owners Manual

5. Twist connector on turn signal/park light bulb1¤4turn
and remove connector and bulb from housing.
6. Remove housing from vehicle with headlight halogen
bulb in housing.
7. Twist collar on headlight halogen bulb
1¤4turn and
remove headlight bulb from the housing.
8. Replace headlight or turn signal bulb. Do not touch
the headlight halogen bulb.
9. Reverse procedure for installation of bulbs and hous-
ing.
10. Tighten the outboard fastener first.
Tail, Stop, Turn and Backup Lights
1. Remove the two (2) screws that pass through the bed
sheetmetal.
MAINTAINING YOUR VEHICLE 371
7

2. Pull the housing straight out from the body, with a
quick motion, to separate the housing from the body. If
not pulled straight, locators may be damaged.3. Push the red lock slide in on the connector and remove
the housing from the vehicle.
4. Remove the four (4) screws from the bulb strip in the
housing.
372 MAINTAINING YOUR VEHICLE

5. Pull the appropriate bulb straight from the bulb strip.
²Top Bulb: Park/Turn/Hazard
²Center Bulb: Stop/Park/Sidemarker
²Bottom Bulb: Backup Lights
6. Reverse procedure for installation of bulbs and hous-
ing.7. While holding the taillight firmly in place, fasten the
top screw first.
Center High-Mounted Stoplight With Cargo Light
1. Remove the two (2) screws holding the housing/lens
to the body as shown.
MAINTAINING YOUR VEHICLE 373
7

2. Separate the connector holding the housing and wir-
ing harness to the body.
3. Turn desired bulb socket
1¤4turn and remove socket
and bulb from housing.
4. Pull desired bulb straight from the socket.
²Outside Bulbs: Cargo Lamps
²Inside Bulb: Center High Mount Stop Lamp
5. Reverse procedure for installation of bulbs and hous-
ing.
374 MAINTAINING YOUR VEHICLE

Cab Top Clearance Lights Ð If Equipped
1. Remove the two screws from the top of the light.2. Rotate the socket
1¤4turn and pull it from the light
assembly.
MAINTAINING YOUR VEHICLE 375
7

3. Pull the bulb straight from it's socket and replace.Tailgate ID Lights (Dual Rear Wheels)
1. Remove the two screws and housing and access the
bulb sockets from the rear.
376 MAINTAINING YOUR VEHICLE

2. Turn socket1¤4turn counterclockwise to access the
bulb.3. Pull bulb straight out from socket.
4. Reverse procedure for installation of bulbs and hous-
ing.
MAINTAINING YOUR VEHICLE 377
7

Side Marker Lights (Dual Rear Wheels)
1. Push rearward on the side marker light assembly.
2. Pull the entire assembly from the fender.
3. Turn socket
1¤4turn counterclockwise and remove from
assembly to access the bulb.
4. Pull bulb straight out from socket.5. Reverse procedure for installation of bulbs and hous-
ing.
Fog Lights
1. Reach under the vehicle, unlock and twist connector
counterclockwise1¤4turn and remove connector and bulb
from housing.
378 MAINTAINING YOUR VEHICLE

2. Pull bulb straight from the connector.
3. Reverse procedure for installation of bulbs and hous-
ing.FLUID CAPACITIES
FLUID CAPACITIES U.S. Metric
Fuel
2500 Shortbed Models 34 gal. 128L
2500 Longbed Models 35 gal. 132L
3500 Shortbed Models 34 gal. 128L
3500 Longbed Models 35 gal. 132L
Engine Oil
5.9L Diesel Engine I-6 12.0 qts. 11.4L
Cooling System
5.9L Diesel Engine I-6 7 gal. 26.5L
MAINTAINING YOUR VEHICLE 379
7

RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MopartAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) P/N 5011764AB or equivalent.
Engine Oil For the proper quality and SAE Grade oil for your engine, refer to the sec-
tion9Maintenance Procedures.9
Engine Oil Filter MopartEngine Oil Filter, P/N 05083285AA or equivalent.
Engine Fuel Filter MopartFuel Filter, P/N 05015581AB or equivalent.
Fuel Selection Refer to the section9Fuel Requirements9for detailed information on fuel se-
lection.
380 MAINTAINING YOUR VEHICLE
