DODGE RAM 2500 DIESEL 2007 3.G Owners Manual

â–«Radial-Ply Tires ......................307
▫ Compact Spare Tire — If Equipped .........308
▫ Limited Use Spare — If Equipped .........309
â–« Tire Spinning ........................309
â–« Tread Wear Indicators ..................310
â–« Life Of Tire .........................311
â–« Replacement Tires .....................311
â–« Alignment And Balance .................312

Supplemental Tire Pressure Information – If
Equipped ............................313

Tire Chains ...........................313

Snow Tires ...........................315

Tire Rotation Recommendations ............315
â–« Dual Rear Wheels .....................316

Engine Runaway .......................317

Fuel Requirements (Diesel Engines) ..........318
â–« Fuel Specifications ....................318

Adding Fuel (Diesel Engines) ..............320
â–« Fuel Filler Cap (Gas Cap) ...............321
â–« Bulk Fuel Storage .....................322

Vehicle Loading ........................323
â–« Certification Label .....................323
STARTING AND OPERATING 251
5

Trailer Towing .........................327
â–« Common Towing Definitions .............327
â–« Trailer Hitch Classification ...............331
â–« Trailer Towing Weights (Maximum Trailer
Weight Ratings) ......................332
â–« Trailer And Tongue Weight ..............332
â–« Towing Requirements ..................333
â–« Towing Tips .........................338
▫ Trailer Towing Mirrors — If Equipped ......339

Snowplow ............................341
â–« Before Plowing .......................342 â–«
Snowplow Prep Package Model Availability . . 342
â–« Over The Road Operation With Snowplow
Attached ...........................343
â–« Methods For Removing Snow ............343
â–« Operating Tips .......................343
â–« General Maintenance ...................344

Recreational Towing (Behind Motorhome, Etc.) . . 345
▫ Recreational Towin g – 2 Wheel
Drive Models ........................345
▫ Recreational Towin g – 4 Wheel
Drive Models ........................345
252 STARTING AND OPERATING

STARTING PROCEDURES – DIESEL ENGINES
The starter should not be operated for more than 15-
second intervals. Waiting a few seconds between such
intervals will protect the starter from overheating.
WARNING!
Be sure to turn off the engine if you want to rest or
sleep in your car. Accidents can be caused by inad-
vertently moving the gear selection lever or by
pressing the accelerator pedal. This may cause exces-
sive heat in the exhaust system, resulting in over-
heating and vehicle fire which may cause serious or
fatal injuries.
WARNING!
Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
Manual Transmission – If Equipped
Apply the parking brake, place the gearshift control lever
in NEUTRAL and depress the clutch pedal to the floor
before starting the vehicle. This vehicle is equipped with
a clutch interlocking ignition system. It will not start
unless the clutch is fully depressed.
Automatic Transmission – If Equipped
Start the engine with the selector lever in NEUTRAL or
PARK position. Apply the brake before shifting to any
driving range.
STARTING AND OPERATING 253
5

The Cummins Diesel engine is equipped with several
features designed to assist cold weather starting and
operation:
•The engine block heater is a resistance heater installed
in the water jacket of the engine just above and behind
the oil filter. It requires a 110–115 volt AC electrical
outlet with a grounded, three-wire extension cord.
NOTE: The engine block heater cord is a factory in-
stalled option. If your vehicle is not equipped, heater
cords are available from your authorized Mopar dealer.
•A 12–volt heater built into the fuel filter housing aids
in preventing fuel gelling. It is controlled by a built-in
thermostat.
•A heated intake air system both improves engine
starting and reduces the amount of white smoke
generated by a warming engine.
Normal Starting Procedure — Engine Manifold
AirTemperature Above 66°F (19°C)
Observe the Instrument Panel Cluster lights when start-
ing the engine.
1. Always apply the parking brake.
2. Shift into PARK for an automatic transmission. Fully
depress and hold the clutch and shift into NEUTRAL for
a manual transmission. Models with manual transmis-
sion are equipped with a clutch interlocking cranking
system. The clutch must be fully depressed to start the
vehicle.
3. Turn the ignition key to the ON position and look at
the instrument panel cluster lamps.
254 STARTING AND OPERATING

CAUTION!
If WATER IN FUEL indicator light remains on DO
NOT START engine before you drain water from the
fuel filter to avoid engine damage. See Section 7 —
Maintaining Your Vehicle, for water drain proce-
dures.
4. Turn the ignition key to START and crank the engine.
Do not press the accelerator during starting.
CAUTION!
Do not crank engine for more than 15 seconds at a
time as starter motor damage may result. Turn key to
OFF and wait at least two minutes before trying
again.
5. When the engine starts, release the key.
6. Check to see that there is oil pressure.
7. Release the parking brake.
Starting Procedure — Engine Manifold Air
Temperature Below 66°F (19°C)
NOTE: The temperature displayed on the overhead
console (if equipped) does not necessarily reflect the
engine manifold air temperature. When certain engine
temperatures fall below 66°F (19°C) the lamp will remain
on indicating the intake manifold heater system is active.
Follow the steps in the Normal Starting Procedure ex-
cept:
STARTING AND OPERATING 255
5

CAUTION!
Do not crank engine for more than 15 seconds at a
time or starter motor damage may result. Turn key to
OFF and wait at least 2 minutes for starter to cool
before repeating start procedure.
•The WAIT TO START light will remain on for a period
of time (length of time depends on engine tempera-
ture).
•After the WAIT TO START light goes off, turn the
ignition key to START. Do not press the accelerator
during starting.
•After engine start-up, check to see that there is oil
pressure.
•Allow the engine to idle about three minutes until
the manifold heaters have completed the post-heat
cycle.
•Release the parking brake and drive.
NOTE: Engine idle speed will automatically increase to
1000 rpm at low coolant temperatures to improve engine
warm-up.
NOTE: If the engine stalls or if the ignition switch is left
On for more than 2 minutes after the WAIT TO START
light goes out, reset the grid heaters by turning the
ignition switch to Off for at least 5 seconds and then back
On. Repeat steps 3 through 7 of the normal starting
procedure.
For Extremely Cold Weather Starting — Engine
Manifold Air Temperature Below 0°F (- 18°C)
In extremely cold weather below 0°F (- 18°C) it may be
beneficial to cycle the manifold heaters twice before
256 STARTING AND OPERATING

attempting to start the engine. This can be accomplished
by turning the ignition OFF for at least 5 seconds and
then back ON after the WAIT TO START light has gone
off, but before the engine is started. However, repeated
cycling of the manifold heaters will result in damage to
the heater elements or reduced battery voltage.
NOTE: If multiple pre-heat cycles are used before
starting, additional engine run time may be required to
maintain battery state of charge at a satisfactory level.
•If the engine stalls after the initial start, the ignition
must be turned to the OFF position for at least 5
seconds and then to the ON position to recycle the
manifold heaters.
NOTE: Excessive white smoke and poor engine perfor-
mance will result if manifold heaters are not recycled.
•Heat generated by the manifold heaters dissipates
rapidly in a cold engine. If more than two minutes pass between the time the WAIT TO START light goes
OFF and the engine is started, recycle the manifold
heaters by turning the ignition OFF for at least 5
seconds and then back ON.
•If the vehicle is driven and vehicle speed exceeds 19
mph (31 km) before the manifold heater post-heat
(after start) cycle is complete, the manifold heaters will
shut off.
•If the engine is started before the WAIT TO START
light turns off, the preheat cycle will turn off.
•If the engine is cranked for more than 10 seconds, the
post-heat cycle will turn off.
NOTE: Engine idle speed will automatically increase to
1000 rpm at low coolant temperatures to improve engine
warm-up.
STARTING AND OPERATING 257
5

NOTE:When a diesel engine is allowed to run out of
fuel or the fuel gels at low temperatures, air is pulled into
the fuel system.
You may try priming as described below.
1. Add a substantial quantity of fuel to the tank (5 to 10
gallons) or eliminate the gelled fuel condition.
2. Crank the engine for 1 to 2 seconds. If the engine does
not start, then release the key or starter button back to the
RUN position (do not turn the key back to the OFF
position). The electric fuel transfer pump will continue to
run and purge air from the system for about 20 seconds.
After 20 seconds, attempt to start the engine again.
3. Start the engine using the Normal Starting Procedure.
4. Repeat the procedure if the engine does not start.WARNING!
Do not open the high pressure fuel system when
cranking the engine or with the engine running.
Engine operation causes high fuel pressure. High
pressure fuel spray can cause serious injury or death.
NOTE: The engine may run rough until the air is forced
from all the fuel lines.
258 STARTING AND OPERATING

Starting Fluids
WARNING!
STARTING FLUIDS or flammable liquids are
NEVER TO BE USED in the Cummins Diesel (see
Warning label). Never pour diesel fuel, flammable
liquid, starting fluids (ether) into the air cleaner
canister, air intake piping, or turbocharger inlet in an
attempt to start the vehicle. This could result in a
flash fire and explosion causing serious personal
injury and engine damage.
The engine is equipped with an automatic electric air
preheating system. If the instructions in this manual are
followed, the engine should start in all conditions.
WARNING!
Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
NORMAL OPERATION (DIESEL ENGINE)
Observe the following when the engine is operating.
•All message center lights are off.
•Check Engine Lamp is off.
•Engine Oil Pressure is above 10 psi (69 kPa) at idle.
•Low Oil Pressure light is off.
STARTING AND OPERATING 259
5

•Voltmeter Operation:
•The voltmeter may show a gauge fluctuation if
certain engine temperatures are below 66°F (19°C).
This cycling operation is caused by the post-heat
cycle of the intake manifold heater system. The
number of cycles and the length of the cycling
operation is controlled by the engine control mod-
ule, this time will not exceed 150 seconds. The
needle should then stabilize at the approximate
operation point.
•The cycling action will cause temporary dimming of
the headlamps, interior lamps, and also a noticeable
reduction in blower motor speed.
Cold Weather Precautions
Operation in ambient temperature below 32°F (0°C) may
require special considerations. The following charts sug-
gest these options:
Fuel Operating Range
* No. 1 diesel fuel should only be used where extended
arctic conditions (-10°F/-23°C) exist.
260 STARTING AND OPERATING
