not freeing the vehicle, may lead to transmission over-
heating and failure. Allow the engine to idle with the
transmission selector in NEUTRAL for at least one
minute after every five rocking-motion cycles. This will
minimize overheating and reduce the risk of transmis-
sion failure during prolonged efforts to free a stuck
vehicle.
EMERGENCY TOW HOOKS — IF EQUIPPED
Your vehicle may be equipped with emergency tow
hooks.
NOTE: For off-road recovery, it is recommended to use
both of the front tow hooks to minimize the risk of
damage to the vehicle.
WARNING!
Chains are not recommended for freeing a stuck
vehicle. Chains may break, causing serious injury or
death.
WARNING!
Stand clear of vehicles when pulling with tow
hooks. Tow straps and chains may break, causing
serious injury.
WHAT TO DO IN EMERGENCIES 371
6

CAUTION!
Tow hooks are for emergency use only, to rescue a
vehicle stranded off road. Do not use tow hooks for
tow truck hookup or highway towing. You could
damage your vehicle.
TOWING A DISABLED VEHICLE
Proper towing or lifting equipment is required to prevent
damage to your vehicle. Use only tow bars and other
equipment designed for the purpose, following equip-
ment manufacturer’s instructions. Use of safety chains is
mandatory. Attach a tow bar or other towing device to
the main structural members of the vehicle—not to
bumpers or associated brackets. State and local laws
applying to vehicles under tow must be observed.
4-Wheel- Drive Vehicles
CAUTION!
To avoid damage to the transfer case while towing,
always use one of the following methods.
NOTE: The Transfer Case must be in the neutral posi-
tion, and the transmission must be in Park (Automatic
Transmission), or in gear (Manual Transmission) to tow a
4WD vehicle with one end of the vehicle raised.
The manufacturer recommends towing with all wheels
OFF the ground. Acceptable methods are to tow vehicle
on a flatbed or with one end of vehicle raised and the
opposite end on a towing dolly.
372 WHAT TO DO IN EMERGENCIES

2–Wheel- Drive Vehicles
Provided that the transmission is operable, tow with the
transmission in Neutral and the ignition key in the OFF
position along with the front wheels raised and the rear
wheels on the ground. Speed must not exceed 30 mph (50
km/h) and distance must not exceed 15 miles (25 km).
CAUTION!
Towing faster than 30 mph (50 km/h) or for more
than 15 miles (25 km) can cause severe damage to the
transmission.
If the vehicle is to be towed faster than 30 mph (50 km/h)
or more than 15 miles (25 km) the vehicle must be towed
with the rear wheels raised and the front wheels on the
ground. It may also be towed on a flatbed or with the
front wheels raised and the rear wheels on a dolly.
WHAT TO DO IN EMERGENCIES 373
6

MAINTAINING YOUR VEHICLE
CONTENTS

Engine Compartment ....................378
▫ 5.9L HO Cummins Turbo Diesel ...........378

Onboard Diagnostic System (OBD II) .........379

Replacement Parts ......................379

Engine Data Plate ......................380

Dealer Service .........................380

Service Information .....................380

Maintenance Procedures ..................383
▫ Engine Oil ..........................383 ▫
Drive Belt ...........................389
▫ Engine Air Cleaner Filter ................389
▫ Draining Fuel/Water Separator Filter .......391
▫ Maintenance Free Batteries ...............394
▫ Air Conditioner Maintenance .............396
▫ Power Steering — Fluid Check ............397
▫ Front Suspension Ball Joints ..............397
▫ Steering Linkage — Inspection ............398
▫ Front Prop Shaft Lubrication .............398
7

▫Front Axle Universal Drive Joints And Pivot
Bearings ............................398
▫ Body Lubrication .....................399
▫ Windshield Wiper Blades ................399
▫ Windshield Washers ...................399
▫ Exhaust System ......................400
▫ Cooling System .......................401
▫ Fan ...............................407
▫ Charge Air Cooler (Inter-Cooler) ..........408
▫ Hoses And Vacuum/Vapor Harnesses .......408
▫ Brake System ........................409
▫ Clutch Linkage .......................411
▫ Clutch Hydraulic System ................411 ▫
Rear Axle And 4X4 Front Driving
Axle Fluid Level ......................411
▫ Transfer Case — If Equipped .............412
▫ Manual Transmission — If Equipped .......412
▫ Automatic Transmission ................413
▫ Front Wheel Bearings ..................415
▫ Selection Of Lubricating Grease ...........416
▫ Noise Control System Required Maintenance &
Warranty ...........................417
▫ Appearance Care And Protection
From Corrosion ......................422

Fuses (Integrated Power Module) ...........426

Vehicle Storage ........................431

Replacement Light Bulbs .................432
376 MAINTAINING YOUR VEHICLE

Bulb Replacement ......................433
▫ Headlight (Halogen)/Front Park
And Turn Lights ......................433
▫ Fog Lights ..........................436
▫ Tail, Stop, Turn And Backup Lights .........437
▫ Center High-Mounted Stoplight (CHMSL) With
Cargo Light .........................440
▫ Cab Top Clearance Lights — If Equipped ....441
▫ Tailgate ID Lights (Dual Rear Wheels) — If
Equipped ...........................443 ▫
Rear Light Bar ID Marker (Dual Rear Wheel) –
If Equipped .........................444
▫ Side Marker Lights (Dual Rear Wheels) ......445

Fluid Capacities ........................445

Fluids, Lubricants And Genuine Parts ........446
▫ Engine .............................446
▫ Chassis ............................447
MAINTAINING YOUR VEHICLE 377
7

ENGINE COMPARTMENT
5.9L HO CUMMINS TURBO DIESEL
378 MAINTAINING YOUR VEHICLE

ONBOARD DIAGNOSTIC SYSTEM (OBD II)
Vehicles equipped with California emissions controls
have a sophisticated onboard diagnostic system called
OBDII. This system monitors the performance of the
emissions, engine, and automatic transmission control
systems. When these systems are operating properly,
your vehicle will provide excellent performance and fuel
economy, as well as engine emissions well within current
government regulations.
If any of these systems require service, the OBD II system
will turn on the “Malfunction Indicator Light.” It will
also store diagnostic codes and other information to
assist your service technician in making repairs. Al-
though your vehicle will usually be driveable and not
need towing, see your dealer for service as soon as
possible.CAUTION!
Prolonged driving with the “Malfunction Indicator
Light” on could cause further damage to the emis-
sion control system. It could also affect fuel economy
and driveability. The vehicle must be serviced before
any emissions tests can be performed.
If the “Malfunction Indicator Light” is flashing,
severe catalytic converter damage and power loss
will soon occur. Immediate service is required.
REPLACEMENT PARTS
Use of genuine Mopar parts for normal/scheduled
maintenance and repairs is highly recommended to in-
sure the designed performance. Damage or failures
caused by the use of non-Mopar parts for maintenance
and repairs will not be covered by the manufacturer’s
warranty.
MAINTAINING YOUR VEHICLE 379
7

ENGINE DATA PLATE
Use the information from the engine data plate when
discussing service or sourcing parts for your engine. The
engine data plate is located on the intake side of the
breather cover.
DEALER SERVICE
Your dealer has the qualified service personnel, special
tools and equipment to perform all service operations in
an expert manner. Service manuals are available which
include detailed service information for your vehicle.
Refer to these manuals before attempting any procedure
yourself.
NOTE: Intentional tampering with emissions control
systems can result in civil penalties being assessed
against you.
WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the proper equipment.
If you have any doubt about your ability to perform
a service job, take your vehicle to a competent
mechanic.
SERVICE INFORMATION
Mopar Fluids, Lubricants and Parts are available from
your dealer and will help you keep your vehicle operat-
ing at its best. Your dealer also has the qualified service
personnel, special tools and equipment to perform all
service operations in an expert manner. Service manuals
are available which include detailed service information
for your vehicle. Refer to these manuals before attempt-
ing any procedure yourself. See Service Publications
information at the back of this manual.
