DODGE RAM 2500 POWER WAGON 2008 3.G Owners Manual

There are stampings in the sheet metal on the inner side
bulkheads of the box in front of and behind both wheel
housings. Place wooden boards across the box from side
to side to create separate load compartments in the
pickup box.
There are four tie-down cleats bolted to the lower sides of
the pickup box that can sustain loads up to 1000 lbs (450
kg) total.
SLIDE-IN CAMPERS
DO NOTuse slide-in campers on your vehicle.
EASY-OFF TAILGATE
The tailgate can be removed quickly. Tailgate removal is
sometimes required for pickup box loading. To remove
the tailgate unlatch the tailgate and remove the support
cables by releasing the lock tang from the pivot, then
rotate and pull away from the box. Once the cables are
free, move to the right side of the tailgate hinge bracket.
Raise the right side of the tailgate until the right side
pivot clears the hanger bracket. Slide the entire tailgate to
the right to free the left side pivot. Remove the tailgate
from the vehicle entirely. Do not carry the tailgate loose in
the truck pickup box.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171
3

NOTE:Dual rear wheel pickup models require properly
spaced rear clearance lights. If such a vehicle is operated
without a tailgate, suitable lights must be installed.
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
mInstruments And Controls.................177
mInstrument Cluster......................178
mInstrument Cluster Description.............179
mElectronic Digital Clock..................190
NClock Setting Procedure.................190
mRadio General Information................191
NRadio Broadcast Signals.................191
NTwo Types Of Signals..................191
NElectrical Disturbances..................191NAM Reception.......................191
NFM Reception........................191
mSales Code REF Ð AM/FM/CD (Single Disc)
Radio With Optional Satellite Radio And Hands
Free Phone Capability...................192
NOperating Instructions - Radio Mode.......192
NOperation Instructions - CD Mode.........196
NOperation Instructions - Auxiliary Mode.....198
NOperating Instructions - Hands Free Phone Ð
If Equipped.........................1994

NOperating Instructions - Satellite Radio Ð
If Equipped.........................199
mSales Code RAQ ± AM/FM/CD (6-Disc) Radio
With Optional Satellite Radio, Hands Free Phone,
And Vehicle Entertainment Systems (VES)
Capabilities...........................200
NOperating Instructions - Radio Mode.......200
NOperation Instructions - (CD Mode For CD
Audio Play).........................205
NLoad/Eject Button (CD Mode For CD Audio
Play)..............................207
NNotes On Playing MP3 Files.............208
NOperation Instructions - (CD Mode For MP3
Audio Play).........................211
NLoad/Eject Button (CD Mode For MP3 Play) . . 211mSales Code RAK ± AM/FM/Cassette/CD (6-Disc)
Radio With Optional Satellite Radio, Hands Free
Phone, Video, MP3, And WMA Capabilities....213
NOperating Instructions - Radio Mode.......213
NOperating Instructions Ð Tape Player.......218
NSeek Button.........................218
NFast Forward (FF).....................218
NRewind (RW)........................218
NTape Eject...........................218
NScan Button.........................219
NChanging Tape Direction................219
NMetal Tape Selection...................219
NPinch Roller Release...................219
NNoise Reduction......................219
174 UNDERSTANDING YOUR INSTRUMENT PANEL

NOperation Instructions - (CD Mode For CD
Audio Play).........................219
NLoad/Eject Button (CD Mode For CD Audio
Play)..............................220
NNotes On Playing MP3 Files.............222
NOperation Instructions - (CD Mode For MP3
And WMA Audio Play).................225
NLoad/Eject Button (CD Mode For MP3 And
WMA Play).........................225
mSales Code REC Ð AM/FM/CD (6±Disc) Radio
With Navigation System..................227
NOperating Instructions Ð Satellite Radio
(If Equipped)........................228
NREC Setting The Clock.................228
NAudio Clock Display...................230mSatellite Radio Ð If Equipped..............231
NSystem Activation.....................231
NElectronic Serial Number/Sirius Identification
Number (ESN/SID)....................232
NSelecting Satellite Mode In REF, RAQ, And
RAK Radios.........................233
NSelecting a Channel....................233
NStoring And Selecting Pre-Set Channels......234
NUsing The PTY (Program Type) Button Ð
If Equipped.........................234
NPTY Button9Scan9.....................234
NPTY Button9Seek9.....................234
NSatellite Antenna......................234
NReception Quality.....................235
UNDERSTANDING YOUR INSTRUMENT PANEL 175
4

mRemote Sound System Controls Ð If Equipped . . 235
NRadio Operation......................236
NTape Player.........................236
NCD Player..........................236
mCassette Tape And Player Maintenance.......237
mCompact Disc Maintenance................238
mRadio Operation And Cellular Phones........238mClimate Controls.......................239
NHeater Only Ð Fleet Vehicles.............239
NAir Conditioning And Heating Ð
If Equipped.........................242
NAir Conditioning With Dual Zone Temperature
Control Ð If Equipped.................245
NOperating Tips.......................249
NOperating Tips Chart...................251
176 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENTS AND CONTROLS
1 Ð Headlight Switch 6 Ð Passenger Airbag* 11 Ð Cup Holders
2 Ð Air Outlets 7 Ð Glove Box 12 Ð Cigar Lighter
3 Ð Instrument Cluster 8 Ð Power Outlet 13 Ð Electronic Axle Locker and Disconnecting Sway Bar Switch
4 Ð Climate Controls 9 Ð Heated Seat Switch 14 Ð Parking Brake Release Lever
5 Ð Radio 10 Ð TPMS ªLight Loadº Reset Switch* 15 Ð Adjustable Pedal Control Switch*
* If EquippedUNDERSTANDING YOUR INSTRUMENT PANEL 177
4

INSTRUMENT CLUSTER
178 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER DESCRIPTION
1. Check Gages
This light illuminates when the Voltmeter, Engine
Oil Pressure or Engine Coolant Temperature
gages indicate a reading either too high or too low.
Examine the gages carefully, and follow the instructions
above for each indicated problem.
NOTE:When the ignition switch is turned to OFF, the
Fuel Gage, Voltmeter, Oil Pressure and Engine Coolant
Temperature gages may not show accurate readings.
When the engine is not running, turn the ignition switch
to ON to obtain accurate readings.
2. Voltage Gauge
When the engine is running, the gauge indicates
the electrical system voltage. The pointer should
stay within the normal range if the battery ischarged. If the pointer moves to either extreme left or
right and remains there during normal driving, the
electrical system should be serviced.
NOTE:If the gauge pointer moves to either extreme of
the gauge, the ªCheck Gagesº indicator will illuminate
and a single chime will sound. The ªCheck Gagesº
indicator may also illuminate prior to the voltage gauge
moving out of normal range. In either case, see you local
authorized Dealer for system service.
3. Turn Signal Indicators
Lights in instrument cluster flash when outside turn
signals are operating.
4. Tachometer
The tachometer indicates engine speed in revolutions per
minute.
UNDERSTANDING YOUR INSTRUMENT PANEL 179
4

CAUTION!
Do not operate the engine with the tachometer
pointer at high rpm for extended periods. Engine
damage may occur.
5. Airbag Indicator Light
The indicator lights and remains lit for 6 to 8 seconds
when the ignition is first turned on. If the light stays on,
flickers or comes on while driving, have the airbag
system checked by an authorized dealer.
6. High Beam Indicator
This indicator shows that headlights are on high
beam.
7. Seat Belt Reminder Light
When the ignition switch is first turned ON, this
light will turn on for 5 to 8 seconds as a bulb check.During the bulb check, if the driver's seat belt is unbuck-
led, a chime will sound. After the bulb check or when
driving, if the driver seat belt remains unbuckled, the
Seat Belt Warning Light will flash or remain on continu-
ously. Refer to9Enhanced Driver Seat Belt Reminder
System (BeltAlertŸ)9in the Occupant Restraints section
for more information.
8. Speedometer
The speedometer shows the vehicle speed in miles per
hour and/or kilometers per hour.
9. Oil Pressure Gauge
The pointer should always indicate some oil pres-
sure when the engine is running. A continuous
high or low reading, under normal driving conditions,
may indicate a lubrication system malfunction. Immedi-
ate service should be obtained.(See page 413 for more
information.)
180 UNDERSTANDING YOUR INSTRUMENT PANEL
