DODGE RAM 3500 DIESEL 2006 3.G Owners Manual

Miles 45,000 52,500 60,000 67,500 75,000
(Kilometers) (72 000) (84 000) (96 000) (108 000) (120 000)
[Months] [36] [42] [48] [54] [60]
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/3500,
4X4).X X XXX
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Lubricate outer tie rod ends 2500/3500 (4X4) mod-
els only.X X XXX
Check transfer case fluid level. X
Flush and replace engine coolant at 60 months, if
not replaced at 102,000 miles (163 000 km).X
Inspect drive belts, replace as necessary. X X
Inspect water pump weep hole for blockage X X X
Replace fuel filter element. Clean the water in fuel
sensor.XXX
SCHEDULE “A” 461
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 45,000 52,500 60,000 67,500 75,000
(Kilometers) (72 000) (84 000) (96 000) (108 000) (120 000)
[Months] [36] [42] [48] [54] [60]
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Inspect fan hub. X
Inspect damper. X
Inspect front wheel bearings. X
Replace fuel filter element. Clean the water in fuel
sensorX
462 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 82,500 90,000 97,500 100,000 105,000
(Kilometers) (132 000) (144 000) (156 000) (160 000) (168 000)
[Months] [66] [72] [78] [84]
Change engine oil and engine oil filter. X X
Lubricate Front Drive Shaft Fitting (2500/3500,
4X4).X X XXX
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Lubricate outer tie rod ends 2500/3500 (4X4) mod-
els only.X X XXX
Flush and replace engine coolant, if not replaced at
60 mos.X
Check transfer case fluid level (4X4). X
Inspect drive belt, replace as required. X
Inspect fan hub. X
Inspect damper. X
Inspect water pump weep hole for blockage. X X
SCHEDULE “A” 463
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 82,500 90,000 97,500 100,000 105,000
(Kilometers) (132 000) (144 000) (156 000) (160 000) (168 000)
[Months] [66] [72] [78] [84]
Replace fuel filter element. Clean the water in fuel
sensor.XX
Inspect front wheel bearings. X
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
Drain and refill automatic transmission fluid. Re-
place filter and adjust bands (48 RE only).X
464 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 112,500 120,000 127,500 135,000 142,500 150,000
(Kilometers) (181 000) (193 000) (205 000) (217 000) (229 000) (241 000)
[Months] [90] [96] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/
3500, 4X4).X X XXXX
Rotate tires. X X X X X X
Check spare tire for proper pressure and cor-
rect stowage.X X XXXX
Lubricate outer tie rod ends 2500/3500 (4X4)
models only.X X XXXX
Flush and replace engine coolant at 120
months, if not replaced at 100,000 miles (160
000 km).X
Inspect drive belt, replace as required. X X
Drain and refill transfer case fluid (4X4). X
Check tranfer case fluid level (4X4).X
Inspect fan hub. X X
SCHEDULE “A” 465
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 112,500 120,000 127,500 135,000 142,500 150,000
(Kilometers) (181 000) (193 000) (205 000) (217 000) (229 000) (241 000)
[Months] [90] [96] [102] [108] [114] [120]
Inspect damper. X X
Inspect water pump weep hole for blockage. X X X
Replace fuel filter element. Clean the water in
fuel sensor.XXX
Inspect front wheel bearings. X X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Adjust valve lash clearance.X
Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
466 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
SCHEDULE “A” 467
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For Your
Vehicle..............................470
▫Prepare For The Appointment............470
▫Prepare A List........................470
▫Be Reasonable With Requests.............470

If You Need Assistance...................470

Warranty Information (U.S. Vehicles Only).....473

MoparParts.........................473
Reporting Safety Defects..................473
▫In Canada..........................473

Publication Order Forms..................474

Department Of Transportation Uniform Tire
Quality Grades........................475
▫Treadwear..........................475
▫Traction Grades......................475
▫Temperature Grades...................476
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisable
to make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized
Chrysler, Dodge, or Jeep dealer. We strongly recommend
that you take your vehicle to your selling dealer. They
know you and your vehicle best, and are most concerned
that you get prompt and high quality service. The
manufacturer’s dealers have the facilities, factory-trained
470 IF YOU NEED CONSUMER ASSISTANCE
