DODGE RAM 4500 CHASSIS CAB 2008 3.G Owners Manual

²Check the windshield washer solvent and add if
required. When refilling the washer fluid reservoir,
take some washer fluid and apply it to a cloth or towel
and wipe clean the wiper blades, this will help blade
performance.
Once a Month
²Check tire pressure and look for unusual wear or
damage.
²Inspect the batteries and clean and tighten the termi-
nals as required.
²Check the fluid levels of coolant reservoir, transmis-
sion and transfer case (if equipped), add as needed.
²Check master cylinder reservoir fluid level for indica-
tions of brake maintenance.
²Check Filter MinderŸ. Replace air cleaner filter
element if necessary.
²Check all lights and all other electrical items for correct
operation.
At Each Oil Change
²Change the engine oil filter.
²Inspect the exhaust system.
²Inspect the brake hoses.
²Inspect the U-Joints ( if equipped) and front suspen-
sion components.
²Check the automatic transmission fluid level.
²Check the manual transmission fluid level.
²Check the coolant level, hoses, and clamps.
²Lubricate outer tie rod ends (4X4) models only.
²Lubricate Front Drive Shaft Fitting (4X4).
MAINTENANCE SCHEDULES 481
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
Oil Change Indicator System
Your vehicle is equipped with an engine oil change
indicator system. This system will alert you when it is
time to change your engine oil by displaying the words
ªOil Change Requiredº on your Electronic Vehicle Infor-
mation Center (EVIC). The engine oil change indicator
system is duty cycle based, which means the engine oil
change interval may fluctuate depending on your per-
sonal driving style. Driving styles such as frequent stopand go type driving can increase the frequency of the
engine oil change. This is the result of more frequent
regeneration of the exhaust aftertreatment system, which
can decrease the life of the engine oil. Failure to change
the engine oil per the maintenance schedule can result in
internal engine damage.
For information on resetting the Oil Change Indicator
message, refer to ªOil Change Required ± If Equipped,º
under ªSystem Status (EVIC Displays)º in the ªElectronic
Vehicle Information Center (EVIC)º Section of this
manual.
482 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Maintenance Schedule
Miles 7,500 15,000 22,500 30,000 37,500
(Kilometers) (12 000) (24 000) (36 000) (48 000) (60 000)
[Months] [6] [12] [18] [24] [30]
Change engine oil and engine oil filter. X X X X X
Lubricate Front Drive Shaft Fitting (4X4). X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Lubricate outer tie rod ends. X X X X X
Check transfer case fluid level (4X4). X
Change front axle fluid (3500/4500/5500 4X4) (Die-
sel Engine only).XX
Change rear axle fluid (3500 4X4 and 4X2) (Diesel
Engine Only)XX
Change automatic transmission fluid. X
Replace fuel filter element. X X
MAINTENANCE SCHEDULES 483
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 7,500 15,000 22,500 30,000 37,500
(Kilometers) (12 000) (24 000) (36 000) (48 000) (60 000)
[Months] [6] [12] [18] [24] [30]
Inspect brake linings. X
Inspect and adjust parking brake if necessary. X
Inspect fan hub.X
Inspect damper.X
Inspect front wheel bearings. X
Inspect drive belt, replace as necessary. X
484 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 45,000 52,500 60,000 67,500 75,000
(Kilometers) (72 000) (84 000) (97 000) (109 000) (121 000)
[Months] [36] [42] [48] [54] [60]
Change engine oil and engine oil filter. X X X X X
Lubricate Front Drive Shaft Fitting (4X4). X X X X X
Rotate tires. X X X X X
Check spare tire for proper pressure and correct
stowage.X X XXX
Lubricate outer tie rod ends. X X X X X
Drain and refill transfer case fluid (4X4). X
Change front axle fluid (3500/4500/5500 4X4) (Die-
sel Engine only).XXX
Change rear axle fluid (3500 4X4 and 4X2) (Diesel
Engine only)XXX
Change rear axle fluid (4500/5500 4X4 and 4X2). X
Change automatic transmission fluid. X
Change manual transmission fluid. X
MAINTENANCE SCHEDULES 485
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 45,000 52,500 60,000 67,500 75,000
(Kilometers) (72 000) (84 000) (97 000) (109 000) (121 000)
[Months] [36] [42] [48] [54] [60]
Flush and replace engine coolant at 60 months, if
not replaced at 100,000 miles (160 000 km).X
Inspect drive belt, replace as necessary. X X
Replace fuel filter element. X X X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Inspect fan hub. X
Inspect damper. X
Inspect front wheel bearings. X
Replace Crankcase Ventilation Filter (CCV). X
486 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 82,500 90,000 97,500 100,000 105,000
(Kilometers) (133 000) (145 000) (157 000) (160 000) (169 000)
[Months] [66] [72] [78] [84]
Change engine oil and engine oil filter. X X X X
Lubricate Front Drive Shaft Fitting (4X4). X X X X
Rotate tires. X X X X
Check spare tire for proper pressure and correct
stowage.XXX X
Lubricate outer tie rod ends. X X X X
Flush and replace engine coolant, if not replaced at
60 mos.X
Check transfer case fluid level (4X4). X
Change front axle fluid (3500/4500/5500 4X4) (Die-
sel Engine only).XX
Change rear axle fluid (3500 4X4 and 4X2) (Diesel
Engine only).XX
Change automatic transmission fluid. X
Inspect drive belt, replace as required.* X X
MAINTENANCE SCHEDULES 487
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 82,500 90,000 97,500 100,000 105,000
(Kilometers) (133 000) (145 000) (157 000) (160 000) (169 000)
[Months] [66] [72] [78] [84]
Inspect fan hub. X
Inspect damper. X
Replace fuel filter element. X X
Inspect front wheel bearings. X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
488 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 112,500 120,000 127,500 135,000 142,500 150,000
(Kilometers) (181 000) (193 000) (205 000) (217 000) (229 000) (241 000)
[Months] [90] [96] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X X X X
Lubricate Front Drive Shaft Fitting (4X4). X X X X X X
Rotate tires. X X X X X X
Check spare tire for proper pressure and cor-
rect stowage.X X XXXX
Lubricate outer tie rod ends. X X X X X X
Flush and replace engine coolant at 120
months, if not replaced at 100,000 miles (161
000 km).X
Inspect drive belt, replace as required.* X X X
Drain and refill transfer case fluid (4X4). X
Check transfer case fluid level (4X4).X
Change front axle fluid (3500/4500/5500 4X4)
( Diesel Engine only).XXX
MAINTENANCE SCHEDULES 489
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 112,500 120,000 127,500 135,000 142,500 150,000
(Kilometers) (181 000) (193 000) (205 000) (217 000) (229 000) (241 000)
[Months] [90] [96] [102] [108] [114] [120]
Change rear axle fluid (3500 4X4 and 4X2)
(Diesel Engine only).XXX
Change rear axle fluid (4500/5500 4X4 and
4X2).X
Change automatic transmission fluid. X X
Change manual transmission fluid. X
Inspect fan hub. X X
Inspect damper. X X
Replace fuel filter element. X X X
Inspect front wheel bearings. X X
Inspect brake linings. X X
Inspect and adjust parking brake if necessary. X X
Adjust valve lash clearance.X
Replace Crankcase Ventilation Filter (CCV). X
