spark plugs replace DODGE RAM 5500 CHASSIS CAB 2008 3.G Owners Manual

MAINTAINING YOUR VEHICLE
CONTENTS
mEngine Compartment Ð 6.7L Diesel Engine....400
mEngine CompartmentÐ 5.7L Gas Engine......401
mOnboard Diagnostic System (OBD II).........402
NLoose Fuel Filler Cap Message............402
mReplacement Parts......................403
mEngine Data Plate......................403
mDealer Service.........................403
mService Information.....................404
mMaintenance Procedures..................406NEngine Oil..........................406
NDrive Belts (Gas Engines)...............413
NDrive Belt (Diesel Engines)..............413
NEngine Air Cleaner Filter (Gas Engines).....413
NEngine Air Cleaner Filter (Diesel Engines)....414
NDraining Fuel/Water Separator Filter (Diesel
Engines)............................417
NEngine Fuel Filter (Gas Engines)...........420
NSpark Plugs (Gas Engines)...............420
7

mixture in excess of 5% can negatively impact the on-
engine fuel filter's ability to separate water from the fuel,
resulting in high pressure fuel system corrosion or dam-
age.
NOTE:As sufficient testing has not been completed,
ethanol blends are not recommended or approved for use
with your Cummins Diesel equipped vehicle.
NOTE:In addition, commercially available fuel addi-
tives are not necessary for the proper operation of your
Cummins Diesel equipped vehicle.
Engine Fuel Filter (Gas Engines)
A plugged fuel filter can cause stalling, limit the speed at
which a vehicle can be driven or cause hard starting.
Should an excessive amount of dirt accumulate in the
fuel tank, frequent filter replacement may be necessary.
Spark Plugs (Gas Engines)
Spark plugs must fire properly to assure engine perfor-
mance and emission control. New plugs should be in-
stalled at the specified mileage. The entire set should be
replaced if there is any malfunction due to a faulty spark
plug, malfunctioning spark plugs can damage the cata-
lytic converter. For proper type of replacement spark
plugs, refer to the Fluids, Lubricants and Genuine Parts
section in this manual.
Catalytic Converter (Gas Engines)
The catalytic converter requires the use of unleaded fuel
only. Leaded gasoline will destroy the effectiveness of the
catalyst as an emission control device.
Under normal operating conditions, the catalytic con-
verter will not require maintenance. However, it is im-
portant to keep the engine properly tuned to assure
proper catalyst operation and prevent possible catalyst
damage.
420 MAINTAINING YOUR VEHICLE

Perform Maintenance Every(Where time and mileage
are listed, follow the interval that occurs first.)
Maintenance Items Miles Kilometers or Months
Inspect Exhaust System. Perform the first inspection at
12,000 miles (20 000 km) or 12 months.24,000 40 000 24
Inspect the front suspension, tie rod ends and boot
seals, replace if necessary.24,000 40 000 24
Replace the engine air cleaner filter. 30,000 50 000 30
Inspect the transfer case fluid. 30,000 50 000 30
Replace the spark plugs on 5.7L engines.30,000 50 000 30
Change the automatic transmission fluid & filter and
change main sump filter and spin-on cooler return
filter (if equipped), if using your vehicle for any of the
following: police, taxi, fleet or frequent trailer towing.60,000 100 000 60
Change the transfer case fluid if using your vehicle for
any of the following: police, taxi, fleet, off-road or fre-
quent trailer towing.60,000 100 000 60
MAINTENANCE SCHEDULES 495
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Folding Floor......................... 163
Heated.............................. 119
Lumbar Support....................... 117
Power.............................. 117
Reclining............................ 115
Security Alarm (Theft Alarm).............19,177
Selection of Coolant (Antifreeze)..........435,476
Sentry Key (Immobilizer)................... 15
Sentry Key Programming................... 17
Sentry Key Replacement................... 16
Service Assistance....................... 500
Service Contract......................... 502
Service Information...................... 404
Service Manuals........................ 504
Setting the Clock.............184,188,196,209,222
Settings, Personal........................ 146
Shifting............................... 273
Manual Transmission................... 285
Transfer Case......................... 292Transfer Case, Shifting into Transfer Case
Neutral (N).......................370,372
Transfer Case, Shifting out of Transfer Case
Neutral (N).......................371,374
Shoulder Belt Upper Anchorage.............. 43
Shoulder Belts........................... 35
Signals, Turn........................... 126
Sliding Rear Window
Power............................34,162
Slippery Surfaces, Driving On............... 304
Snow Chains (Tire Chains)................. 333
Snow Plow............................ 365
Snow Tires............................ 334
Soot Filter............................. 422
Spare Tire............................. 329
Spark Plugs.........................420,476
Speed Control (Cruise Control).............. 132
Speedometer........................... 175
Starting............................252,255
INDEX 523
