airbag DODGE STRATUS COUPE 2004 2.G Owners Manual

The air bags will operate only when the ignition switch is
in the ``ON'' or ``START'' position.
When an impact sensor detects a front or side impact of
sufficient force, it automatically ignities materials in the
module inflator which generate gas and inflates the
appropriate air bags.
NOTE:A collision that is not severe enough to need
airbag protection will not activate the system. This does
not mean something is wrong with the air bag system.
Deployment of the air bags produces a sudden, loud
noise and releases some smoke and powder. This is not
dangerous and does not indicate a fire in the vehicle.
People with breathing problems may feel some tempo-
rary irritation from chemicals used to inflate the bags. If
irritation continues see your doctor. You may open the
windows after air bags inflates, if it is safe to do so.
After deployment, the air bags deflate very rapidly, so
there is little danger of not being able to see. The time
between the sensors first detecting an impact and the air
bags deflating after deployment is shorter than a blink of
an eye.
WARNING!
²Air bags inflate very quickly and with great force.
In certain situations, contact with an inflating air
bag may cause small cuts, abrasions, and bruises.
Driver 's and passenger 's front air bag system
Driver
Front passenger
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 95
3

²If you decide to junk or scrap your vehicle, we urge
you to first take it to an authorized dealer so that the
SRS can be made safe for disposal.
Caution label
Passenger restraint warning/caution labels for the SRS
are located in the vehicle as shown in the illustration.
Transporting Pets
Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision.
Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.
102 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

!120,000 Miles (192 000 km) or at 120 months
NFlush and replace engine coolant.
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NInspect disc brake pads, rotors and calipers for
wear and leaks.
NInspect suspension system for looseness and dam-
age.
NInspect ball joint and steering linkage seals for
grease leaks and damage.
NCheck and service exhaust system as required
(connection portion of muffler, muffler pipes and
converter heat shields).
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!120,000 Miles (192 000 km) or at 120 months
NCheck fuel system for leak
(tank, pipe line and connection, and fuel tank
filler tube cap).
NCheck evaporative emission control system for
leaks and clogging (except evaporative emission
canister).
NReplace ignition cables.
NCheck distributor cap and rotor.
NChange engine oil and engine oil filter.
NRotate tires.
NInspect SRS*2airbag system.
*2: Supplemental Restraint System
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
348 MAINTENANCE

!117,000 Miles (187 000 km) or at 117 months
NChange engine oil and engine oil filter.
NRotate tires.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!120,000 Miles (192 000 km) or at 120 months
NReplace air cleaner filter.
NReplace spark plugs, standard type.
NCheck drive belts condition (for the generator,
water pump, power steering pump).
NReplace timing belt.*1
*1: For California, Massachusetts and Vermont
this maintenance is recommended but not re-
quired.
NInspect SRS*1airbag system.
*1: Supplemental Restraint System.
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
!120,000 Miles (192 000 km) or at 120 months
NChange manual transaxle fluid.
NChange automatic transaxle fluid.
NCheck fuel hoses condition.
NFlush and replace engine coolant.
NCheck coolant hoses (radiator hose, heater hose).
NInspect rear drum brake linings and rear wheel
cylinders (except vehicles with disc brakes) for
wear and leaks of all wheels.
NCheck brake hoses for deterioration or leaks.
NInspect ball joint and steering linkage seals for
grease leaks and damage.
NInspect drive shaft boots for grease leaks and damage.
NCheck and service exhaust system as required
(connection portion of muffler, muffler pipes and
converter heat shields).
NCheck fuel system for leaks
(tank, pipe line and connection, and fuel tank
filler tube cap).
MILEAGE/
MONTHSDEALERSHIP
NAME/CODE DATEREPAIR
ORDER #
MAINTENANCE 361
9

UNIBELT restraint system............... 69
Seatback.............................. 60
Seats
Front seats........................... 57
Rear seats............................ 66
SECURITY indicator................49,107,112
Service Assistance...................... 372
Service Manuals........................ 377
Setting the clock........................ 216
Severe maintenance schedule.............. 349
Snow tires............................ 339
Spare tire.......................266,267,367
Spark plugs........................317,369
Speedometer.......................106,108
Starting
At extremely cold ambient temperature..... 153
Flooded engine....................... 153
Normal conditions.................... 152
Steering system
Steering lock......................... 151
Tilt lock lever........................ 175
Sun visors............................ 209
Sunroof............................... 46Supplemental Restraint System - Airbag
Maintenance......................... 329
Warning light.....................107,116
Supplemental Restraint System (SRS) - Air bag . . 89
Supplemental Restraint System warning light . . 116
Tachometer........................106,108
Tape Player........................... 219
Temperature Gage, Engine Coolant.......... 279
Theft protection........................ 151
Theft-alarm
SECURITY indicator..............49,107,112
System.............................. 48
Timing belt........................... 334
Tips for driving in various conditions........ 201
Tire chains............................ 339
Ti re s
Compact spare tire.................... 267
Inflation pressure...............334,366,367
Maintenance......................334,337
Quality Grading...................... 379
Rotation............................ 338
Size (tire and wheels).................. 367
INDEX 387
