sensor DODGE STRATUS COUPE 2005 2.G Owners Manual

1. Air bag module (Driver)
2. Air bag module (Passenger)
3. Air bag control unit (including the front impact sen-
sors)
4. SRS warning light5. Side air bag modules (if so equipped)
6. Side impact sensors (if so equipped)
The air bag control unit monitors the readiness of the
electronic parts of the system whenever the ignition
switch is in the ``ON'' or ``START'' position. These
include all of the items listed above and all related
wiring.
94 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

The air bags will operate only when the ignition switch is
in the ``ON'' or ``START'' position.
When an impact sensor detects a front or side impact of
sufficient force, it automatically ignities materials in the
module inflator which generate gas and inflates the
appropriate air bags.
NOTE:A collision that is not severe enough to need
airbag protection will not activate the system. This does
not mean something is wrong with the air bag system.
Deployment of the air bags produces a sudden, loud
noise and releases some smoke and powder. This is not
dangerous and does not indicate a fire in the vehicle.
People with breathing problems may feel some tempo-
rary irritation from chemicals used to inflate the bags. If
irritation continues see your doctor. You may open the
windows after air bags inflates, if it is safe to do so.
After deployment, the air bags deflate very rapidly, so
there is little danger of not being able to see. The time
between the sensors first detecting an impact and the air
bags deflating after deployment is shorter than a blink of
an eye.
WARNING!
²Air bags inflate very quickly and with great force.
In certain situations, contact with an inflating air
bag may cause small cuts, abrasions, and bruises.
Event Data Recording
Your vehicle is equipped with an9EDR9- Event Data
Recorder which is capable of collecting and storing data
in the event of an air bag deployment.
The EDR may record the following information;
± Condition of Specific vehicle systems;
± Whether the driver and front passenger seat belts were
buckled;
± Condition of SRS warning light;
± Diagnostic code(s);
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 95
3

CAUTION!
Using leaded gasoline in your vehicle will damage
the engine, catalytic converter, and the oxygen sen-
sors. Further, using leaded gasoline is illegal, and
will void warranty coverage of the engine, catalytic
converter, and oxygen sensors.
Gasoline additives
Many fuel suppliers add detergents to their gasoline to
minimize fuel injector fouling and to control intake valve
deposits. These detergent gasolines are highly recom-
mended for use in your vehicle. They help keep your
engine in tune and your emission control system working
properly.
Octane requirement
2.4 liter engine model
Your vehicle is designed to operate on unleaded gasoline
having a minimum octane rating of 87 [(MON+RON)/2],
or 91 RON.
3.0 liter engine model
Your vehicle is designed to operate on regular grade
unleaded gasoline having a minimum octane rating of 87
[(MON+RON)/2], or 91 RON. If optimum performance
is wanted, it is recommended to use premium grade
unleaded gasoline having an octane rating of 91
[(MON+RON)/2], or 95 RON.
MON: Motor Octane Number
RON: Research Octane Number
Reformulated Gasoline
Many areas of the country require the use of cleaner
burning fuel referred to as ªReformulated Gasolineº.
Reformulated gasolines contain oxygenates, and are spe-
cially blended to reduce vehicle emissions and improve
air quality.
The manufacturer supports the use of reformulated gaso-
lines. Properly blended reformulated gasolines will pro-
vide excellent performance and durability of engine and
fuel system components.
STARTING AND DRIVING 147
5

6 mph (10 km/h). It stops operating when the vehicle
decelerates to a speed below approximately 3 mph (5
km/h).
3. After driving on snow or icy roads, remove any snow
and ice that may have adhered to the wheel areas. When
doing this be careful not to damage the wheel speed
sensors and cables located at each wheel on vehicles
equipped with an anti-lock braking system.STEERING WHEEL TILT LOCK LEVER
To adjust the steering wheel height, release the tilt lock
lever while raising or lowering the steering wheel to the
desired height.
After adjustment, securely lock the lever by pulling it
downward.
I24A0060
Wheel speed
sensorG09A0270
Unlock
Lock
STARTING AND DRIVING 177
5

To turn off the function, press the display switch (C) more
than 6 seconds, less than 9 seconds. When the green
indicator (A) goes off, the automatic anti-glare will not
function.
To turn the function back on, press the display switch (C)
more than 6 seconds, less than 9 seconds.
NOTE:
²
Do not spray glass cleaner on the sensor (B), as
reduced sensitivity could result.
Electrochromic mirror operation (if so equipped)
A-Garage door opener button
Press the button to operate devices such as garage
door openers, motorized gates, or home lighting.!P.
134
NOTE:Garage door button must be programmed.B-Display switch
Press the switch to change the mode of compass,
outside temperature and anti-glare operation.!P.
182.
C-Dome light switch.
D-Display.
The compass and outside temperature are displayed.
To turn on/off the display, press the display switch
(C) less than 3 seconds.!P. 183.I08A0560
STARTING AND DRIVING 181
5

To listen to a tape
To operate the APS (Automatic Program Sensor)
system
The start of each song on a prerecorded music tape can be
found by using the Fast forward APS button (1) or
Rewind APS button (5). As many as 7 programs can be
skipped over in this manner.
Fast forward APS operation:
Press the APS button (1) to the number of songs you
desire to skip over. The frequency-display window will
display the number songs selected. The tape will be
fast-forwarded to the start of the song, and playback will
begin.
Rewind APS operation:
Press the APS button (5) to the number of the selection
you desire to skip over including the one now being
played. The frequency-display window will display the
number of songs selected. The tape will be rewind to the
start of the song, and playback will begin.
To listen to a CD
To select CD mode
Mode change button - 4
Select the desired mode (CD player mode or CD au-
tochanger mode) by pressing this button.
To select a desired track
Track up button - 1
Press this button until the desired track is reached.
Track down button - 5
Press this button until the desired track is reached.
The frequency display window will display the number
of tracks selected.
To select a desired disc (CD autochanger only)
Disc up button - 3
Press this button until the desired disc is reached.
FOR PLEASANT DRIVING 233
6

Air cleaner filter
The air cleaner filter will become dirty and loaded with
dust during use, and the filtering effect will be substan-
tially reduced. Replace it with a new filter in accordance
with the schedule in this manual.
1. Unclamp the air cleaner cover.
2. Take out the air cleaner filter.After replacing the air cleaner filter, reinstall the cover in
its original position.
CAUTION!
Take care not to damage the engine air flow sensor
when removing the air cleaner cover.
Evaporative emission control system (except
evaporative emission canister)
If the fuel-vapor vent line is clogged or damaged, the
fuel-vapor mixture will escape, polluting the atmosphere.
Have the system checked at an authorized dealer at the
mileage specified on the scheduled maintenance chart.
M23A0130
316 MAINTENANCE
