wiper blades DODGE STRATUS COUPE 2005 2.G Owners Manual

WINDSHIELD WASHER
The windshield washer can be operated by pulling the
lever toward you to spray fluid when the ignition key is
in either the ªONº or ªACCº position.
When washer fluid is sprayed, the wipers will automati-
cally operate several times.
The spraying fluid stops when the lever is released.
PRECAUTIONS TO OBSERVE WHEN USING
WIPERS AND WASHERS
CAUTION!
If the washer is used in cold weather, the washer
fluid sprayed onto the glass might freeze, resulting
in poor visibility. Heat the glass with the defroster
before using the washer.
NOTE
1. Do not use the wipers when the glass is dry; this could
scratch the glass and wear the wiper blades prematurely.
2. Before operating the wipers in cold weather, check to
be sure that the wiper blades are not frozen to the
windshield. Attempting to operate the wipers while the
blades are frozen could damage the wiper motor.
3. If the wipers become blocked by ice or other deposits
on the glass, the motor may be damaged even if the
wiper switch is OFF. If obstruction occurs, park your
E13A1300
130 INSTRUMENTS AND CONTROLS

vehicle in a safe place, turn off the ignition, and clean the
deposits from the glass so that the wipers operate
smoothly.
4. Avoid using the washer for more than 20 seconds at a
time. To avoid pump damage, do not operate the washer
when the fluid reservoir is empty.
5. During cold weather, be sure to add a washer solution
that will not freeze in the washer reservoir. Failure to do
so could result in the loss of windshield washer function
and damage to the system components.
6. Replace wiper blades when they are worn to avoid
loss of visibility when in use. Use the appropriate size
replacement blades; if you have questions, ask your
authorized dealer.DOME LIGHT
The dome/reading light can be operated by moving the
switch as follows:
1. (ON) - The dome light ``ON''.
2. (DOOR) - The dome light goes on when any door is
opened.
3. (OFF) - The dome light stays ``OFF''.
E19A0970
Type 1
INSTRUMENTS AND CONTROLS 131
4

VEHICLE CARE
CONTENTS
mCleaning the inside of your vehicle.........253
NPlastic, vinyl leather, fabric, and flocked parts . . 253
NUpholstery..........................253
NGenuine leather (if so equipped)...........254
mCleaning the outside of your vehicle........254
NForeign material.......................254
NWashing............................255
NDuring cold weather...................256
NWaxing your vehicle....................257NPolishing your vehicle..................258
NDamaged paint.......................258
NCleaning plastic parts...................258
NChrome parts........................259
NAluminum wheels (if so equipped).........259
NWindow glass........................259
NWiper blades.........................259
NCleaning the sunroof (if so equipped).......259
NEngine compartment...................259
7

Chrome parts
To prevent spots and corrosion of chrome parts, wash
with water, dry thoroughly, and apply a nonabrasive
automotive wax. If the chrome is severely damaged or
pitted use a commercially available chrome polish.
Aluminum wheels (if so equipped)
A protective coating is provided over aluminum wheels.
Clean aluminum wheels with a cleaner designed for use
on aluminum and apply an appropriate protection agent.
CAUTION!
²Do not use abrasive cleaners.
²Brushes may damage the aluminum wheel sur-
face. Be sure to use a sponge, chamois, etc.
²Do not apply hot water directly from a steam
cleaner to the wheel surface.
²Wheels exposed to sea water or road chemicals
should be cleaned as soon as possible.
Window glass
The window glass can be cleaned using only a sponge
and water. Glass cleaner can be used to remove wax, oil,
grease, dead insects, etc. After washing the glass, wipe
dry with a clean, dry, soft cloth.
Wiper blades
Use a soft cloth and glass cleaner to remove grease, dead
insects, etc., from the wiper blades.
Replace the wiper blades when they no longer clean the
windshield properly.
Cleaning the sunroof (if so equipped)
Clean the inside of the sunroof with a soft cloth. Hard
deposits should be wiped away with a cloth dipped in
warm, neutral detergent solution. Wipe away the solu-
tion with a sponge dipped in fresh water.
NOTE: The surface treatment on the inside of the glass
may be removed if a hard cloth or organic solvent is used.
Engine compartment
Never spray or splash water on the electrical components
in the engine compartment, as this may adversely affect
the electrical circuits.
VEHICLE CARE 259
7

NDisconnection and connection.............327
mAutomatic transaxle.....................329
NTo check the fluid level..................330
NProcedure for checking the fluid level.......330
mManual transaxle.......................331
mDisc brake pads, rear drum brake linings
and rear wheel cylinders.................331
mBrake hoses...........................331
mBall joint, steering linkage seal and drive
shaft boots...........................331
mSupplemental Restraint System (SRS)........331
mHood lock release mechanism and
safety catch
...........................332
mExhaust system........................332
mWindshield wiper blades.................333
NWindshield washers....................333
mParking brake.........................334
mDrive belt (for generator, water pump, power
steering pump)
........................335
mTiming belt...........................336
mTi re s................................336
NTire inflation pressures..................340
NRadial ply tires.......................341
N
Tire pressure for sustained high-speed driving...342
NReplacing tire and wheels................342
NTire maintenance......................342
NCargo loads..........................346
NTread wear indicators...................346
NTire rotation.........................347
NTire chains...........................348
NSnow tires...........................348
mRegular Maintenance Schedule.............349
mSevere Maintenance Schedule..............357
310 MAINTENANCE

WINDSHIELD WIPER BLADES
Check the wiper blades occasionally. Periodic cleaning of
the wiper blades is suggested to remove the accumula-
tion of salt and road film. The wiper blade arms and glass
areas should be cleaned with a sponge or cloth and a
mild detergent or non-abrasive cleaner.
If the blades continue to streak or smear, they should be
replaced.
NOTE: Do not operate wipers for long periods on dry
glass; this accelerates deterioration of the rubber and
could scratch the glass.
Windshield washers
The windshield washer reservoir is in the engine com-
partment. Check the fluid level at regular intervals and
replenish the fluid if necessary.
NOTE: When freezing weather is anticipated flush out
the water in the reservoir by operating the pump. Fill the
reservoir with windshield antifreeze (not radiator anti-
freeze) and operate the system for a few seconds to flush
out any residual water.
M31A0730
MAINTENANCE 333
9

Tire chains.......................... 348
Tread wear indicators.................. 346
Tools................................ 266
Towing.............................. 284
Trailering........................... 205
Trailer Towing......................... 205
Transaxle
Automatic transaxle................... 155
Autostick........................... 165
Manual transaxle..................... 168
Transmission
Automatic transmission................ 160
Transmitter, Garage Door Opener........... 134
Transporting Pets....................... 103
Trip odometer......................... 108
Trip odometer reset button................ 108
Trunklid .............................. 35
Turbocharger boost gauge................ 108
Turn signal indicators.................109,114
Lever.............................. 124
Uniform Tire Quality Grades.............. 387
Universal Transmitter.................... 134Vanity mirror.......................... 211
Vehicle Identification Number............... 5
Vehicle labeling........................ 372
Vehicle Weights........................ 375
Ventilators............................ 237
Warnings and Cautions.................... 5
Warranty Information.................... 382
Washer fluid level indicator............... 109
Washer
Windshield.......................130,333
Washing.............................. 255
Waxing.............................. 257
Wheel covers.......................... 268
Whip antenna......................... 221
Windshield washers..................130,333
Windshield wiper blades................. 333
Windshield wipers...................... 128
396 INDEX
