8W-31 TRANSMISSION CONTROL SYSTEM
Component Page
Autostick Switch..................... 8W-31-5
Battery............................ 8W-31-2
Brake Transmission Shift Interlock
Solenoid......................... 8W-31-4
Crankshaft Position Sensor............ 8W-31-3
Data Link Connector................. 8W-31-8
Front Control Module........... 8W-31-4, 5, 8, 9
Fuse 15........................ 8W-31-2, 6, 7
G100.............................. 8W-31-2
G101.............................. 8W-31-2
G103............................ 8W-31-5, 9
G200.............................. 8W-31-5
Ignition Switch...................... 8W-31-9Component Page
Input Speed Sensor................... 8W-31-5
Integrated Power Module . . 8W-31-2, 4, 5, 6, 7, 8, 9
Output Speed Sensor................. 8W-31-5
Park/Neutral Position Switch........... 8W-31-9
Powertrain Control Module....... 8W-31-3, 4, 8, 9
Solenoid/Pressure Switch Assy........ 8W-31-6, 7
Throttle Position Sensor............... 8W-31-3
Torque Converter Clutch Solenoid....... 8W-31-9
Transmission Control
Module.............. 8W-31-2, 3, 4, 5, 6, 7, 8
Transmission Control Relay........ 8W-31-2, 6, 7
Transmission Range Sensor.......... 8W-31-4, 5
RS8W-31 TRANSMISSION CONTROL SYSTEM8W-31-1
