8W-80 CONNECTOR PIN-OUTS
Component Page
A/C Compressor Clutch............... 8W-80-6
A/C Pressure Sensor.................. 8W-80-6
A/C-Heater Control C1 (MTC).......... 8W-80-6
A/C-Heater Control C2 (MTC).......... 8W-80-7
Accelerator Pedal Position Sensor
(Diesel).......................... 8W-80-7
Adjustable Pedals Module
(Except Export)................... 8W-80-7
Adjustable Pedals Relay
(Except Export)................... 8W-80-8
Adjustable Pedals Switch
(Except Export)................... 8W-80-8
Airbag Control Module (ORC).......... 8W-80-8
Ambient Temperature Sensor (Except
Base)........................... 8W-80-9
ATC Remote Sensor (ATC)............. 8W-80-9
Auto Temp Control C1................ 8W-80-9
Auto Temp Control C2................ 8W-80-9
Auto Temp Control C3............... 8W-80-10
Automatic Day/Night Mirror (Premium/
Luxury)........................ 8W-80-10
Autostick Switch (Except Export)....... 8W-80-10
Back-Up Lamp Switch (MTX).......... 8W-80-10
Battery Temperature Sensor (2.4L/
Diesel)......................... 8W-80-11
Blower Motor Resistor C1 (MTC)....... 8W-80-11
Blower Motor Resistor C2 (MTC)....... 8W-80-11
Body Control Module C1.............. 8W-80-11
Body Control Module C2.............. 8W-80-12
Body Control Module C3.............. 8W-80-13
Body Control Module C4.............. 8W-80-14
Body Control Module C5.............. 8W-80-15
Boost Pressure Sensor (Diesel)......... 8W-80-15
Brake Fluid Level Switch............. 8W-80-16
Brake Lamp Switch................. 8W-80-16
Brake Transmission Shift Interlock Solenoid
(EATX) ......................... 8W-80-16
C100............................. 8W-80-16
C100............................. 8W-80-17
C101............................. 8W-80-17
C101............................. 8W-80-18
C102 (2.4L)........................ 8W-80-18
C102 (2.4L)........................ 8W-80-18
C102 (3.3L/3.8L).................... 8W-80-19
C102 (3.3L/3.8L).................... 8W-80-19
C103 (Diesel)...................... 8W-80-19
C103 (Diesel)...................... 8W-80-20
C106 (Export)...................... 8W-80-20
C106 (Export)...................... 8W-80-20
C107 (Export)...................... 8W-80-20
C107 (Export)...................... 8W-80-21
C110 (2.4L)........................ 8W-80-21Component Page
C110 (2.4L)........................ 8W-80-21
C111 (2.4L)........................ 8W-80-21
C111 (2.4L)........................ 8W-80-22
C200............................. 8W-80-22
C200............................. 8W-80-24
C201............................. 8W-80-26
C201............................. 8W-80-26
C202............................. 8W-80-26
C202............................. 8W-80-26
C203 (United Kingdom).............. 8W-80-27
C203 (United Kingdom).............. 8W-80-27
C204 (Premium).................... 8W-80-27
C204 (Premium).................... 8W-80-27
C300 (LHD)....................... 8W-80-28
C300 (LHD)....................... 8W-80-28
C300 (RHD Except Lowline)........... 8W-80-29
C300 (RHD Lowline)................ 8W-80-29
C300 (RHD)....................... 8W-80-29
C301 (Base/Power Locks)............. 8W-80-30
C301 (Base/Power Locks)............. 8W-80-30
C301 (LHD Premium/Memory)......... 8W-80-30
C301 (LHD Premium/Memory)......... 8W-80-30
C301 (RHD/LHD Premium Except
Memory)........................ 8W-80-31
C301 (RHD/LHD Premium Except
Memory)........................ 8W-80-31
C302 (Except RHD Memory).......... 8W-80-31
C302 (Except RHD Memory).......... 8W-80-31
C302 (RHD Memory)................ 8W-80-32
C302 (RHD Memory)................ 8W-80-32
C303 (LHD)....................... 8W-80-32
C303 (LHD)....................... 8W-80-33
C303 (RHD)....................... 8W-80-33
C303 (RHD)....................... 8W-80-33
C304............................. 8W-80-34
C304............................. 8W-80-34
C305............................. 8W-80-34
C305............................. 8W-80-34
C306............................. 8W-80-35
C306............................. 8W-80-35
C307 (Heated Seats)................. 8W-80-35
C307 (Heated Seats)................. 8W-80-35
C308............................. 8W-80-36
C308............................. 8W-80-36
C309............................. 8W-80-36
C309............................. 8W-80-37
C310 (Front Console)................ 8W-80-37
C310 (Front Console)................ 8W-80-37
C311 ............................. 8W-80-37
C311 ............................. 8W-80-38
C312............................. 8W-80-38
C312............................. 8W-80-39
RS8W-80 CONNECTOR PIN-OUTS8W-80-1
ProCarManuals.com
Page 983 of 2177
Component Page
C313 (Rear Console)................. 8W-80-39
C313 (Rear Console)................. 8W-80-39
C314 (Highline).................... 8W-80-40
C314 (Highline).................... 8W-80-40
C315 (Highline).................... 8W-80-41
C315 (Highline).................... 8W-80-41
C316 (Power Sliding Door)............ 8W-80-41
C316 (Power Sliding Door)............ 8W-80-42
C317 (Power Sliding Door)............ 8W-80-42
C317 (Power Sliding Door)............ 8W-80-42
C318 (Trailer Tow).................. 8W-80-43
C318 (Trailer Tow).................. 8W-80-43
C319 (Lowline)..................... 8W-80-43
C319 (Lowline)..................... 8W-80-44
C320............................. 8W-80-44
C320............................. 8W-80-44
C321............................. 8W-80-44
C321............................. 8W-80-45
C322 (Memory)..................... 8W-80-45
C322 (Memory)..................... 8W-80-45
C324 (Manual Sliding Door)........... 8W-80-46
C324 (Manual Sliding Door)........... 8W-80-46
C325 (Manual Sliding Door)........... 8W-80-46
C325 (Manual Sliding Door)........... 8W-80-46
C326............................. 8W-80-46
C326............................. 8W-80-47
C327............................. 8W-80-47
C327............................. 8W-80-47
C328 (Sunroof)..................... 8W-80-47
C328 (Sunroof)..................... 8W-80-47
C329 (Diesel)...................... 8W-80-48
C329 (Diesel)...................... 8W-80-48
C330 (Diesel)...................... 8W-80-48
C330 (Diesel)...................... 8W-80-48
C331 (Diesel)...................... 8W-80-48
C331 (Diesel)...................... 8W-80-49
C332 (3 Zone ATC).................. 8W-80-49
C332 (3 Zone ATC).................. 8W-80-49
Cabin Heater Assist C1 (Diesel)........ 8W-80-50
Cabin Heater Assist C2 (Diesel)........ 8W-80-50
Camshaft Position Sensor (Diesel)...... 8W-80-50
Camshaft Position Sensor (Gas)........ 8W-80-50
CD Changer....................... 8W-80-51
Center Dome Lamp (Base/Highline)..... 8W-80-51
Center High Mounted Stop Lamp....... 8W-80-51
Clockspring C1..................... 8W-80-51
Clockspring C2..................... 8W-80-52
Clockspring C3..................... 8W-80-52
Clockspring C4..................... 8W-80-52
Clutch Pedal Interlock Switch (MTX).... 8W-80-52
Clutch Pedal Upstop Switch (Diesel).... 8W-80-52
Controller Antilock Brake............. 8W-80-53
Crank Case Ventilation Heater (Diesel) . . 8W-80-53
Crankshaft Position Sensor (Diesel)..... 8W-80-53Component Page
Crankshaft Position Sensor (Gas)....... 8W-80-54
Data Link Connector................ 8W-80-54
Dosing Pump (Diesel)................ 8W-80-54
Driver Airbag Squib 1................ 8W-80-55
Driver Airbag Squib 2................ 8W-80-55
Driver Blend Door Actuator (ATC)...... 8W-80-55
Driver Blend Door Actuator (MTC)...... 8W-80-55
Driver Door Courtesy Lamp........... 8W-80-56
Driver Door Lock Switch............. 8W-80-56
Driver Heated Seat Back............. 8W-80-56
Driver Heated Seat Cushion........... 8W-80-56
Driver Heated Seat Module C1......... 8W-80-56
Driver Heated Seat Module C2......... 8W-80-57
Driver Heated Seat Module C3......... 8W-80-57
Driver Power Seat Front Riser Motor.... 8W-80-57
Driver Power Seat Front Riser Position
Sensor......................... 8W-80-57
Driver Power Seat Horizontal Motor.... 8W-80-58
Driver Power Seat Horizontal Position
Sensor......................... 8W-80-58
Driver Power Seat Rear Riser Motor.... 8W-80-58
Driver Power Seat Rear Riser Position
Sensor......................... 8W-80-58
Driver Power Seat Recliner Motor...... 8W-80-58
Driver Power Seat Recliner Position
Sensor......................... 8W-80-59
Driver Power Seat Switch............ 8W-80-59
Driver Power Window Motor.......... 8W-80-59
Driver Power Window Switch
(LHD Except Lowline)............. 8W-80-60
Driver Power Window Switch (LHD
Lowline)........................ 8W-80-60
Driver Power Window Switch (RHD).... 8W-80-60
Driver Seat Belt Switch.............. 8W-80-61
Driver Seat Belt Tensioner............ 8W-80-61
DVD Screen....................... 8W-80-61
DVD/CD Changer C1................ 8W-80-61
DVD/CD Changer C2................ 8W-80-62
DVD/CD Changer C3................ 8W-80-62
EGR Solenoid (3.3L/3.8L Export)....... 8W-80-62
EGR Solenoid (Diesel)............... 8W-80-62
Engine Control Module C1 (Diesel)..... 8W-80-63
Engine Control Module C2 (Diesel)..... 8W-80-64
Engine Coolant Temp Sensor (Diesel).... 8W-80-65
Engine Coolant Temp Sensor (Gas)..... 8W-80-65
Engine Oil Pressure Sensor (Diesel)..... 8W-80-66
Engine Oil Pressure Switch (Gas)...... 8W-80-66
EVAP/Purge Solenoid (Gas)........... 8W-80-66
Evaporator Temperature Sensor........ 8W-80-66
Floor Console Lamp................. 8W-80-67
Floor Console Power Outlet........... 8W-80-67
Front Blower Module C1 (ATC)........ 8W-80-67
Front Blower Module C2 (ATC)........ 8W-80-67
Front Cigar Lighter................. 8W-80-68
8W - 80 - 2 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com
Page 984 of 2177
Component Page
Front Intrusion Sensor (United
Kingdom)....................... 8W-80-68
Front Reading Lamps/Switch.......... 8W-80-68
Front Washer Pump Motor............ 8W-80-68
Fuel Heater (Diesel)................. 8W-80-68
Fuel Injector No. 1 (2.4L/3.3L/3.8L)..... 8W-80-69
Fuel Injector No. 1 (Diesel)............ 8W-80-69
Fuel Injector No. 2 (2.4L/3.3L/3.8L)..... 8W-80-69
Fuel Injector No. 2 (Diesel)............ 8W-80-69
Fuel Injector No. 3 (2.4L/3.3L/3.8L)..... 8W-80-70
Fuel Injector No. 3 (Diesel)............ 8W-80-70
Fuel Injector No. 4 (2.4L/3.3L/3.8L)..... 8W-80-70
Fuel Injector No. 4 (Diesel)............ 8W-80-70
Fuel Injector No. 5 (3.3L/3.8L)......... 8W-80-71
Fuel Injector No. 6 (3.3L/3.8L)......... 8W-80-71
Fuel Pressure Sensor (Diesel).......... 8W-80-71
Fuel Pressure Solenoid (Diesel)........ 8W-80-71
Fuel Pump Module.................. 8W-80-72
Generator......................... 8W-80-72
Glow Plug Relay (Diesel)............. 8W-80-72
Headlamp Switch................... 8W-80-72
Headlamp Washer Pump Motor
(Export)........................ 8W-80-73
High Note Horn.................... 8W-80-73
Hood Ajar Switch (Export)............ 8W-80-73
Idle Air Control Motor (Gas)........... 8W-80-73
Ignition Coil (2.4L).................. 8W-80-73
Ignition Coil (3.3L/3.8L).............. 8W-80-74
Ignition Switch..................... 8W-80-74
Inlet Air Temperature Sensor.......... 8W-80-74
Input Speed Sensor (EATX)........... 8W-80-74
Instrument Cluster.................. 8W-80-74
Instrument Panel Switch Bank........ 8W-80-75
Integrated Power Module C1.......... 8W-80-75
Integrated Power Module C2.......... 8W-80-76
Integrated Power Module C3.......... 8W-80-76
Integrated Power Module C4.......... 8W-80-77
Integrated Power Module C5.......... 8W-80-77
Integrated Power Module C6.......... 8W-80-77
Integrated Power Module C7.......... 8W-80-78
Integrated Power Module C8.......... 8W-80-78
Integrated Power Module C9.......... 8W-80-79
Knock Sensor (2.4L)................. 8W-80-79
Knock Sensor (3.3L/3.8L ABS Except
Export)......................... 8W-80-79
Leak Detection Pump (3.3L/3.8L Except
Export)......................... 8W-80-79
Left B-Pillar Switch (Power Sliding
Door).......................... 8W-80-80
Left Cinch/Release Motor (Power Sliding
Door).......................... 8W-80-80
Left Combination Relay (Trailer Tow).... 8W-80-80
Left Cylinder Lock Switch............ 8W-80-80
Left Door Speaker (Lowline)........... 8W-80-81
Left Door Speaker (Midline/Highline).... 8W-80-81Component Page
Left Fog Lamp (Except Export)........ 8W-80-81
Left Fog Lamp (Export).............. 8W-80-81
Left Front Door Ajar Switch (Base)..... 8W-80-81
Left Front Door Lock Motor/Ajar Switch
(Except Base).................... 8W-80-82
Left Front Park/Turn Signal Lamp
(Except Export)................... 8W-80-82
Left Front Wheel Speed Sensor........ 8W-80-82
Left Full Open Switch (Power Sliding
Door).......................... 8W-80-82
Left Headlamp (Except Export)........ 8W-80-83
Left Headlamp Leveling Motor (Export) . . 8W-80-83
Left High Beam Lamp (Export)........ 8W-80-83
Left Instrument Panel Speaker........ 8W-80-83
Left Liftgate Flood Lamp............. 8W-80-84
Left Low Beam Lamp (Export)......... 8W-80-84
Left Mid Reading Lamp (Premium/
Luxury)........................ 8W-80-84
Left Park Lamp (Export)............. 8W-80-84
Left Power Mirror................... 8W-80-84
Left Rear Lamp Assembly............ 8W-80-85
Left Rear Pillar Speaker.............. 8W-80-85
Left Rear Reading Lamp (Luxury)...... 8W-80-85
Left Rear Speaker (Lowline)........... 8W-80-85
Left Rear Speaker (Midline/Highline).... 8W-80-86
Left Rear Vent Motor................ 8W-80-86
Left Rear Wheel Speed Sensor......... 8W-80-86
Left Remote Radio Switch............ 8W-80-86
Left Repeater Lamp (Export).......... 8W-80-87
Left Seat Airbag.................... 8W-80-87
Left Side Impact Airbag Control
Module......................... 8W-80-87
Left Sliding Door Control Module C1
(Power Sliding Door).............. 8W-80-87
Left Sliding Door Control Module C2
(Power Sliding Door).............. 8W-80-88
Left Sliding Door Latch Sensing Switch
(Power Sliding Door).............. 8W-80-88
Left Sliding Door Lock Motor
(Power Sliding Door).............. 8W-80-88
Left Sliding Door Lock Motor/Ajar Switch
(Manual Sliding Door)............. 8W-80-89
Left Sliding Door Motor (Power Sliding
Door).......................... 8W-80-89
Left Speed Control Switch............ 8W-80-89
Left Stop/Turn Signal Relay
(Trailer Tow)..................... 8W-80-89
Left Turn Signal Lamp (Export)........ 8W-80-90
Left Visor/Vanity Lamp (Except Base) . . . 8W-80-90
License Lamp (Manual Release)........ 8W-80-90
License Lamp (Power Liftgate)......... 8W-80-90
License Lamp (Power Release)......... 8W-80-91
Lift Pump Motor (Diesel)............. 8W-80-91
Liftgate Ajar Switch (Manual Release) . . . 8W-80-91
Liftgate Ajar Switch (Power Release).... 8W-80-91
RS8W-80 CONNECTOR PIN-OUTS8W-80-3
ProCarManuals.com
Page 985 of 2177
Component Page
Liftgate Cinch/Release Motor (Power
Liftgate)........................ 8W-80-92
Liftgate Cylinder Lock Switch (Export) . . 8W-80-92
Liftgate Left Pinch Sensor (Power
Liftgate)........................ 8W-80-92
Liftgate Right Pinch Sensor (Power
Liftgate)........................ 8W-80-92
Low Note Horn..................... 8W-80-92
Manifold Absolute Pressure Sensor (Gas) . 8W-80-93
Mass Air Flow Sensor (Diesel)......... 8W-80-93
Memory Seat/Mirror Module C1........ 8W-80-93
Memory Seat/Mirror Module C2........ 8W-80-94
Memory Seat/Mirror Module C3........ 8W-80-94
Memory Seat/Mirror Module C4........ 8W-80-94
Memory Set Switch................. 8W-80-95
Message Center (Highline)............ 8W-80-95
Mode Door Actuator (ATC)............ 8W-80-95
Mode Door Actuator (MTC)........... 8W-80-95
Multi-Function Switch............... 8W-80-96
Natural Vacuum Leak Detection Assembly
(2.4L Except Export)............... 8W-80-96
Output Speed Sensor (EATX).......... 8W-80-96
Overhead Console (Except Base)....... 8W-80-96
Oxygen Sensor 1/1 Upstream (Gas)..... 8W-80-97
Oxygen Sensor 1/2 Downstream (Gas) . . . 8W-80-97
Passenger Airbag................... 8W-80-97
Passenger Blend Door Actuator (ATC) . . . 8W-80-97
Passenger Blend Door Actuator (MTC) . . . 8W-80-98
Passenger Door Courtesy Lamp........ 8W-80-98
Passenger Door Lock Switch........... 8W-80-98
Passenger Folding Mirror Relay (Export) . 8W-80-98
Passenger Heated Seat Back.......... 8W-80-99
Passenger Heated Seat Cushion........ 8W-80-99
Passenger Heated Seat Module C1...... 8W-80-99
Passenger Heated Seat Module C2...... 8W-80-99
Passenger Heated Seat Module C3..... 8W-80-100
Passenger Power Seat Front Riser
Motor......................... 8W-80-100
Passenger Power Seat Horizontal
Motor......................... 8W-80-100
Passenger Power Seat Rear Riser
Motor......................... 8W-80-100
Passenger Power Seat Recliner Motor . . 8W-80-100
Passenger Power Seat Switch......... 8W-80-101
Passenger Power Window Motor....... 8W-80-101
Passenger Power Window Switch...... 8W-80-101
Passenger Seat Belt Switch.......... 8W-80-101
Passenger Seat Belt Tensioner........ 8W-80-102
Power Folding Mirror Switch (Export) . . 8W-80-102
Power Liftgate Module C1........... 8W-80-102
Power Liftgate Module C2........... 8W-80-103
Power Liftgate Motor............... 8W-80-103
Power Mirror Switch............... 8W-80-104
Power Outlet (Except Lowline)........ 8W-80-104
Power Seat Circuit Breaker (30A)..... 8W-80-104Component Page
Power Window Circuit Breaker (25A) . . . 8W-80-104
Power Window Switch (LHD Lowline) . . 8W-80-105
Powertrain Control Module C1 (NGC) . . 8W-80-105
Powertrain Control Module C1
(SBEC)........................ 8W-80-106
Powertrain Control Module C2 (NGC) . . 8W-80-107
Powertrain Control Module C2 (SBEC) . 8W-80-108
Powertrain Control Module C3 (NGC) . . 8W-80-109
Powertrain Control Module C4 (NGC)
(EATX) ........................ 8W-80-110
Radiator Fan No. 1 (Diesel).......... 8W-80-111
Radiator Fan No. 1 (Gas)............ 8W-80-111
Radiator Fan No. 2 (Diesel).......... 8W-80-111
Radiator Fan No. 2 (Gas)............ 8W-80-111
Radiator Fan Relay (Gas)............ 8W-80-112
Radiator Fan Relay No. 1 (Diesel)..... 8W-80-112
Radiator Fan Relay No. 2 (Diesel)..... 8W-80-112
Radiator Fan Relay No. 3 (Diesel)..... 8W-80-113
Radio C1......................... 8W-80-113
Radio C2 (CD Changer)............. 8W-80-114
Radio C2 (DVD/CD Changer)......... 8W-80-114
Rear A/C-Heater Unit (3 Zone MTC).... 8W-80-114
Rear Auto Temp Control Switch
(3 Zone ATC).................... 8W-80-115
Rear Blower Front Control Switch
(3 Zone MTC)................... 8W-80-115
Rear Blower Motor Power Module C1
(3 Zone ATC).................... 8W-80-115
Rear Blower Motor Power Module C2
(3 Zone ATC).................... 8W-80-116
Rear Blower Rear Control Switch C1
(3 Zone MTC)................... 8W-80-116
Rear Blower Rear Control Switch C2
(3 Zone MTC)................... 8W-80-116
Rear Dome Lamp (Except Luxury)..... 8W-80-116
Rear Intrusion Sensor (United
Kingdom)...................... 8W-80-117
Rear Mode Motor (3 Zone ATC)........ 8W-80-117
Rear Power Outlet................. 8W-80-117
Rear Temperature Motor (3 Zone ATC) . . 8W-80-117
Rear Washer Pump Motor............ 8W-80-118
Rear Wiper Motor.................. 8W-80-118
Recirculation Door Actuator (ATC)..... 8W-80-118
Recirculation Door Actuator (MTC)..... 8W-80-118
Remote Keyless Entry Antenna
(Japan)........................ 8W-80-119
Remote Keyless Entry Module........ 8W-80-119
Right B-Pillar Switch (Power Sliding
Door).......................... 8W-80-119
Right Cinch/Release Motor
(Power Sliding Door).............. 8W-80-119
Right Combination Relay
(Trailer Tow).................... 8W-80-120
Right Cylinder Lock Switch (Export) . . . 8W-80-120
Right Door Speaker (Lowline)......... 8W-80-120
8W - 80 - 4 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com
Page 986 of 2177
Component Page
Right Door Speaker (Midline/Highline) . . 8W-80-120
Right Fog Lamp (Except Export)...... 8W-80-121
Right Fog Lamp (Export)............ 8W-80-121
Right Front Door Ajar Switch (Base) . . . 8W-80-121
Right Front Door Lock Motor/Ajar Switch
(Except Base)................... 8W-80-121
Right Front Park/Turn Signal Lamp
(Except Export).................. 8W-80-121
Right Front Wheel Speed Sensor...... 8W-80-122
Right Full Open Switch (Power Sliding
Door).......................... 8W-80-122
Right Headlamp (Except Export)...... 8W-80-122
Right Headlamp Leveling Motor
(Export)....................... 8W-80-122
Right High Beam Lamp (Export)...... 8W-80-123
Right Instrument Panel Speaker...... 8W-80-123
Right Liftgate Flood Lamp........... 8W-80-123
Right Low Beam Lamp (Export)....... 8W-80-123
Right Mid Reading Lamp (Premium/
Luxury)........................ 8W-80-123
Right Park Lamp (Export)........... 8W-80-124
Right Power Mirror................ 8W-80-124
Right Rear Lamp Assembly.......... 8W-80-124
Right Rear Pillar Speaker........... 8W-80-125
Right Rear Reading Lamp (Luxury).... 8W-80-125
Right Rear Speaker (Lowline)......... 8W-80-125
Right Rear Speaker (Midline/Highline) . . 8W-80-125
Right Rear Vent Motor.............. 8W-80-125
Right Rear Wheel Speed Sensor....... 8W-80-126
Right Remote Radio Switch.......... 8W-80-126
Right Repeater Lamp (Export)........ 8W-80-126
Right Seat Airbag.................. 8W-80-126
Right Side Impact Airbag Control
Module........................ 8W-80-127Component Page
Right Sliding Door Control Module C1
(Power Sliding Door).............. 8W-80-127
Right Sliding Door Control Module C2
(Power Sliding Door).............. 8W-80-127
Right Sliding Door Latch Sensing Switch (Power
Sliding Door)................... 8W-80-128
Right Sliding Door Lock Motor
(Power Sliding Door).............. 8W-80-128
Right Sliding Door Lock Motor/Ajar
Switch (Manual Sliding Door)....... 8W-80-128
Right Sliding Door Motor (Power Sliding
Door).......................... 8W-80-128
Right Speed Control Switch.......... 8W-80-129
Right Stop/Turn Signal Relay (Trailer
Tow) .......................... 8W-80-129
Right Turn Signal Lamp (Export)...... 8W-80-129
Right Visor/Vanity Lamp (Except Base) . 8W-80-129
Sentry Key Immobilizer Module....... 8W-80-130
Siren (United Kingdom)............. 8W-80-130
Solenoid/Pressure Switch Assy (EATX) . . 8W-80-130
Speed Control Servo (Gas)........... 8W-80-130
Sunroof Module (Except Export)....... 8W-80-131
Sunroof Switch (Except Export)....... 8W-80-131
Thatcham Alarm Module (United
Kingdom)...................... 8W-80-131
Throttle Position Sensor (Gas)........ 8W-80-132
Traction Control Switch............. 8W-80-132
Trailer Tow Connector (Except Export) . . 8W-80-132
Transmission Control Module (3.3L/
3.8L).......................... 8W-80-133
Transmission Range Sensor (EATX).... 8W-80-134
Vehicle Speed Sensor (MTX).......... 8W-80-134
Washer Fluid Level Switch........... 8W-80-134
Water In Fuel Sensor (Diesel)......... 8W-80-134
Wiper Module..................... 8W-80-134
RS8W-80 CONNECTOR PIN-OUTS8W-80-5
ProCarManuals.com
Page 987 of 2177
A/C COMPRESSOR CLUTCH - LT. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 C3 20DB/YL (2.4L) A/C COMPRESSOR CLUTCH RELAY OUTPUT
1 C3 18DB/YL (3.3L/3.8L/DIESEL) A/C COMPRESSOR CLUTCH RELAY OUTPUT
2 Z153 18BK/GY GROUND
A/C PRESSURE SENSOR - GRAY 4 WAY
CAV CIRCUIT FUNCTION
1 K900 18DB/DG (GAS) SENSOR GROUND
1 C918 20BK/LB (DIESEL) A/C PRESSURE SENSOR GROUND
2 F855 20PK/YL (2.4L) 5 VOLT SUPPLY
2 F851 20LB/PK (DIESEL) SENSOR REFERENCE VOLTAGE B
2 F855 18PK/YL (3.3L/3.8L) 5 VOLT SUPPLY
3 C18 18LB/BR (3.3L/3.8L) A/C PRESSURE SENSOR SIGNAL
3 C18 20LB/BR (DIESEL) A/C PRESSURE SENSOR SIGNAL
3 C18 18LB/BR (2.4L) A/C PRESSURE SIGNAL
4- -
A/C-HEATER CONTROL C1 (MTC) - BLACK/RED 20 WAY
CAV CIRCUIT FUNCTION
1 Z24 18BK/OR GROUND
2 C121 20DB/DG (LHD) SENSOR GROUND
2 C121 22DB/DG (RHD) SENSOR GROUND
3 C22 20LB/WT (3 ZONE) REAR TEMPERATURE FEEDBACK SIGNAL
4- -
5 F850 20LB/PK (3 ZONE) 5 VOLT SUPPLY
6- -
7 C32 22DB/TN RECIRCULATION DOOR DRIVER (A)
8 C54 22LB/YL (3 ZONE) REAR BLEND DOOR DRIVER
9 C34 22DB/LB COMMON DOOR DRIVER (B)
10 D25 20WT/VT PCI BUS
11 - -
12 C121 20DB/DG (3 ZONE) REAR TEMPERATURE RETURN
13 F504 20GY/PK IGNITION SWITCH OUTPUT (RUN)
14 E12 20OR/GY PANEL LAMPS DRIVER
15 C21 22LB EVAPORATOR TEMPERATURE SENSOR SIGNAL
16 C33 22LB/BR PASSENGER BLEND DOOR DRIVER (A)
17 C61 22DB/LG (EXCEPT BASE) DRIVER BLEND DOOR DRIVER (A)
18 C35 22LB/LG MODE DOOR DRIVER (A)
19 C53 22LB (3 ZONE) REAR MODE DOOR DRIVER
20 C154 20LB/OR (3 ZONE) REAR COMMON DOOR DRIVER
8W - 80 - 6 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com
Page 988 of 2177
A/C-HEATER CONTROL C2 (MTC) - BLACK/BLUE 10 WAY
CAV CIRCUIT FUNCTION
1- -
2 C75 12DB/GY BLOWER MOTOR HIGH DRIVER
3 C74 12DB/WT BLOWER MOTOR M3 DRIVER
4 Z134 12BK/OR (LHD EXPORT) GROUND
4 Z134 12BK/LG (EXCEPT LHD EXPORT) GROUND
5 C71 16DB/BR BLOWER MOTOR LOW DRIVER
6- -
7- -
8- -
9 C73 14DB/VT BLOWER MOTOR M2 DRIVER
10 C72 16DB/OR BLOWER MOTOR M1 DRIVER
ACCELERATOR PEDAL POSITION SENSOR (DIESEL) - 10 WAY
CAV CIRCUIT FUNCTION
A- -
B- -
C- -
D K4 20BK/LB LOW IDLE POSITION SWITCH GROUND
E K151 20WT LOW IDLE POSITION SWITCH SENSE
F- -
G- -
H K22 20OR/DB ACCELERATOR PEDAL POSITION SENSOR SIGNAL
J K167 20BR/YL ACCELERATOR PEDAL POSITION SENSOR GROUND
K F852 20VT/PK ACCELERATOR PEDAL POSITION SENSOR 5 VOLT
SUPPLY
ADJUSTABLE PEDALS MODULE (EXCEPT EXPORT)-4WAY
CAV CIRCUIT FUNCTION
1 A128 18RD/OR ADJUSTABLE PEDALS RELAY OUTPUT
2 Z146 18BK/YL GROUND
3 Q102 18OR/LB ADJUSTABLE PEDALS SWITCH SENSE
4 Q103 18OR/LG ADJUSTABLE PEDALS SWITCH GROUND
RS8W-80 CONNECTOR PIN-OUTS8W-80-7
ProCarManuals.com
Page 989 of 2177
ADJUSTABLE PEDALS RELAY (EXCEPT EXPORT)-9WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4 A108 18LG/RD FUSED B(+) (I.O.D.)
5 A128 18RD/OR ADJUSTABLE PEDALS RELAY OUTPUT
6 P201 20LG/DB ADJUSTABLE PEDALS RELAY CONTROL
7- -
8 A108 20LG/RD FUSED B(+) (I.O.D.)
9- -
ADJUSTABLE PEDALS SWITCH (EXCEPT EXPORT) - (DK GRAY) 8 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3- -
4- -
5- -
6- -
7 Q102 18OR/LB ADJUSTABLE PEDALS SWITCH SENSE
8 Q103 18OR/LG ADJUSTABLE PEDALS SWITCH GROUND
AIRBAG CONTROL MODULE (ORC) - YELLOW/RED 23 WAY
CAV CIRCUIT FUNCTION
1 R54 18LB/YL PASSENGER SEAT BELT TENSIONER LINE 2
2 R56 18LB/DG PASSENGER SEAT BELT TENSIONER LINE 1
3 R62 18LB/VT (EXCEPT LHD EXPORT) PASSENGER SQUIB 2 LINE 2
3 R62 18LG/DB (LHD EXPORT) PASSENGER SQUIB 2 LINE 2
4 R64 18LB/WT PASSENGER SQUIB 2 LINE 1
5 R42 18LB/BR PASSENGER SQUIB 1 LINE 2
6 R44 18LB/OR PASSENGER SQUIB 1 LINE 1
7 R53 18LG/YL DRIVER SEAT BELT TENSIONER LINE 2
8 R55 18LG/DG DRIVER SEAT BELT TENSIONER LINE 1
9 R61 18LG/DB DRIVER SQUIB 2 LINE 1
10 R63 18LG/WT DRIVER SQUIB 2 LINE 2
11 R43 18LG/BR DRIVER SQUIB 1 LINE 1
12 R45 18LG/OR DRIVER SQUIB 1 LINE 2
13 - -
14 F201 18PK/OR ORC RUN-START DRIVER
15 F100 18PK/VT ORC RUN ONLY DRIVER
16 Z12 18BK/OR GROUND
17 R59 18LG/TN DRIVER SEAT BELT SWITCH LINE 1
18 R57 18LG/GY DRIVER SEAT BELT SWITCH LINE 2
19 - -
20 - -
21 D25 20WT/VT PCI BUS
22 - -
23 - -
8W - 80 - 8 8W-80 CONNECTOR PIN-OUTSRS
ProCarManuals.com
Page 990 of 2177
AMBIENT TEMPERATURE SENSOR (EXCEPT BASE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 G31 18VT/LG (EXCEPT 2.4L) AMBIENT TEMPERATURE SENSOR SIGNAL
1 G31 18VT/LG (2.4L) AAT SIGNAL
2 K900 18DB/DG (2.4L) SENSOR GROUND
2 G931 18VT/BR (EXCEPT 2.4L) AMBIENT TEMPERATURE SENSOR RETURN
ATC REMOTE SENSOR (ATC)-4WAY
CAV CIRCUIT FUNCTION
1 F600 20LB/PK PROTECTED IGNITION
2 D40 20WT/LB KDB NO. 2 CLOCK
3 C905 20BR/LB SENSOR RETURN
4 D18 20WT/YL KDB NO. 2 DATA
AUTO TEMP CONTROL C1 - NATURAL 13 WAY
CAV CIRCUIT FUNCTION
1 C161 22LB/WT DRIVER BLEND DOOR DRIVER (B)
2 C61 22DB/LG DRIVER BLEND DOOR DRIVER (A)
3 C133 22DB/WT PASSENGER BLEND DOOR DRIVER (B)
4 C33 22LB/BR PASSENGER BLEND DOOR DRIVER (A)
5 C132 22DB/YL RECIRCULATION DOOR DRIVER (B)
6 C32 22DB/TN RECIRCULATION DOOR DRIVER (A)
7 C135 22DB/WT MODE DOOR DRIVER (B)
8 C35 22LB/LG MODE DOOR DRIVER (A)
9 C53 22LB REAR MODE DOOR DRIVER (A)
10 C154 22LB/OR REAR MODE DOOR DRIVER (B)
11 C54 22LB/YL REAR BLEND DOOR DRIVER (A)
12 C169 22DB/OR REAR BLEND DOOR DRIVER (B)
13 - -
AUTO TEMP CONTROL C2 - BLACK 13 WAY
CAV CIRCUIT FUNCTION
1 C21 22LB (LHD) EVAPORATOR TEMPERATURE SENSOR SIGNAL
1 C21 22LB (RHD) EVAPORATOR TEMPERATURE SENSOR SIGNAL
2 C121 22DB/DG (RHD) SENSOR GROUND
2 C121 20DB/DG (LHD) SENSOR GROUND
3 E12 20OR/GY PANEL LAMPS DRIVER
4 A114 18GY/RD FUSED B(+) (I.O.D.)
5 F504 20GY/PK FUSED IGNITION SWITCH OUTPUT (RUN)
6 D25 20WT/VT PCI BUS
7 C56 22DB/VT (LHD) BLOWER MOTOR CONTROL
7 C56 22DB/LB (RHD) BLOWER MOTOR CONTROL
8 C59 22DB/LB REAR BLOWER MOTOR CONTROL
9 D22 20WT/TN (3 ZONE) KDB CLOCK
10 D17 22WT/DG KDB DATA
11 Z24 18BK/OR GROUND
12 - -
13 - -
RS8W-80 CONNECTOR PIN-OUTS8W-80-9
