Page 17 of 236
To Lock the Doors:
NOTE:To enable/disable the Lamp Flash, see proce-
dure described above.
Press and release the LOCK button on the transmitter.
The horn will chirp once and the park and tail lights will
blink to acknowledge that the door is locked and that the
alarm system is armed. The horn chirp can be disabled at
the dealership if so desired.
NOTE:The horn chirp feature can be enabled or dis-
abled by performing the following procedure:
1. Press and hold the Lock button on the transmitter.
2. Continue to hold the Lock button, wait at least 4 but
no longer than 10 seconds, then press the Unlock button.
3. Release both buttons.
To Unlock the Trunk:
Press and hold the trunk button on the transmitter to
unlatch the trunk. The front and rear park/turn signal
lights will blink 3 times.
Panic Alarm
The panic alarm unlocks the driver's door, turns on the
interior lights, flashes the park and fog lights and sounds
the horn for 3 minutes or until the alarm is turned off.
Panic mode does not work when the vehicle is driven.
To Use the Panic Alarm:
Press and hold the Panic button to activate the alarm.
Press and hold the Panic button or turn the key in the
ignition to the RUN position to deactivate the alarm. The
alarm will also shut itself off after 3 minutes.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
2
Page 49 of 236
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
mConvertible Top Operation.................51
NTo Raise The Top......................51
NTo Lower The Top......................53
mConsole Features........................54
mMirrors...............................55
NInside Day/Night Mirror.................55
NElectric Remote Control Mirrors............55
NMirror Adjustment.....................56
mSeats.................................57NManual Front Seat Adjustments............57
NReclining Seat.........................57
mTo Open And Close The Hood..............58
mLights................................60
NCourtesy/Reading Lights.................60
NInterior Lights........................61
NMulti-Function Control Lever..............61
NHeadlights, Parking Lights, Instrument Panel
Lights, And Front Fog Lights..............62
3
Page 61 of 236
Interior Lights
The interior lights come on when a door is opened and
the dome switch is not in the defeat position.
Battery Saver Feature Ð Interior Lights
The interior courtesy lights come on when a door is open
or left ajar. To prevent battery drain, if you leave a door
open or ajar, these lights will turn off after 15 minutes.
After you close the door, the interior courtesy lights will
again function in the normal manner.
Multi-Function Control Lever
The Multi-Function Control Lever controls the operation
of the headlights, parking lights, turn signals, headlight
beam selection, instrument panel light dimming, interior
lights, the passing lights, and fog lights. The lever is
located on the left side of the steering column.
Dimmer Control
With the parking lights or headlights
on, rotating the dimmer control for the
interior lights on the Multi-Function
Control Lever upward will increase
the brightness of the instrument panel
lights.
Dome Light Position
Rotate the dimmer control completely
upward to the second detent to turn
on the interior lights. The interior
lights will remain on when the dim-
mer control is in this position.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 61
3
Page 62 of 236
Interior Light Defeat (OFF)
Rotate the dimmer control to the ex-
treme bottom ªOFFº position. The in-
terior lights will remain off when the
doors are open.
Parade Mode (Daytime Brightness Feature)
Rotate the dimmer control to the first
detent (white semi-circle). This feature
brightens the odometer and radio dis-
play when the parking lights or head-
lights are on during daylight condi-
tions.
Headlights, Parking Lights, Instrument Panel
Lights, and Front Fog Lights
Turn the end of the Multi-Function Control Lever to the
first detent for parking light operation. Turn to the
second detent for headlight operation. Pull out the end of
the Multi-Function Control Lever to turn on the front fog
lights.
62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 186 of 236
REPLACEMENT BULBS
Interior Light Bulbs
Message Center Indicators.................. 103
Cluster................................ 103
Gauge Pack............................ 103
Heater Control........................... 37
Interior Light..........................212±2
Courtesy Footwell Lights................... 194
Exterior Light Bulbs
Headlight-Low/High Beam.... Serviced at dealer only
Aux. Headlight-High Beam.........(HB3A) 9005XS
Front Park/Turn......................3157AK
Fog Light.......................(H10 U) 9145
Front Sidemarker.......................2886X
Center Stop Light.......... 16LED(not serviceable)
Rear Tail/Stop..........................3157
Rear Tail Light.......................... 194
Rear Marker Light........................ 194
Back up Light..........................3157
Rear Turn Light.......................3457AK
License................................ 168
NOTE:You will note that upon turning the (HID) High
Intensity Discharge Headlamp Bulbs on, there is a blue
hue to the lamps. This diminishes and becomes more
white after approximately 10 seconds as the system
charges.
186 MAINTAINING YOUR VEHICLE
Page 230 of 236
Hazard Warning Flasher.................75,132
Headlights............................ 188
Aiming............................. 193
High Beam........................... 65
High Beam/Low Beam Select Switch......... 65
Switch............................... 62
Time Delay........................... 63
Heater................................ 90
High Beam Indicator...................... 77
Hood Latch Maintenance.................. 163
Hood Release........................... 58
Hoses.............................170,171
Hydraulic Clutch Fluid.................... 175
Ignition
Key ................................. 11
Timing.............................. 154
Wiring System........................ 154
Infant Restraint.......................... 33Instrument Cluster........................ 74
Instrument Panel and Controls............... 73
Instrument Panel Lens Cleaning............. 178
Interior and Instrument Lights..........See Lights
Interior Lights........................... 61
Intermittent Wipers....................... 69
Introduction............................. 4
Jump Starting.......................... 134
Key-In Reminder......................... 12
Keyless Entry System...................... 15
Keys.................................. 11
Knee Bolster............................ 38
Lap/Shoulder Belts....................... 27
LATCH (Lower Anchors and Tether for CHildren) . 35
Latches
Hood............................... 163
230 INDEX
Page 231 of 236
Light Bulbs............................ 186
Lights................................. 60
Airbag.............................41,79
Anti-Lock Warning...................... 75
Back-Up............................. 61
Brake Warning......................... 79
Daytime Running....................... 63
Dimmer Switch, Headlight................ 61
Exterior Check......................... 48
Fog .............................62,64,78
Hazard Warning Flasher...............75,132
Headlight Switch....................... 62
Headlights.........................62,188
High Beam Indicator.................... 77
Instrument Cluster...................... 62
Interior...........................61,186
Lights On Reminder..................... 63
Malfunction Indicator.................... 76
Map Reading.......................... 60Oil Pressure........................... 78
Passing.............................. 65
Reading.............................. 60
Seat Belt Reminder...................... 77
Turn Signal.......................61,64,75
Loading Vehicle
Capacities........................... 130
Tires ............................... 112
Locks
Door................................ 13
Low Tire Indicator....................... 124
Low Tire Pressure System.................. 124
Lower Anchors and Tether for CHildren (LATCH) . 35
Lubricants..........................162,163
Lubrication, Body....................... 162
Maintenance Schedule.................... 200
Light Duty Schedule9B9................. 203
Schedule9A9......................... 210
INDEX 231
