Page 90 of 264
Trunk Ajar Light
This light indicates that the trunk is not latched.
Engine Coolant Temperature Light
A red LED light on the Coolant Temperature
gauge will illuminate to warn of an overheated
engine coolant condition.
Low Oil Pressure Light
A red LED light on the Oil Pressure gauge will
illuminate to indicate low engine oil pressure. The
light should come on briefly as a bulb check when the
engine is first started. If the light stays on or comes on
while driving, stop the vehicle and shut off the engine.
DO NOT operate the vehicle until the cause is corrected.
NOTE:This light does not indicate how much oil is in
the engine. The engine oil level must be checked under
the hood.
Charge System Light
A red LED light on the Voltage gauge will illumi-
nate when there is a charging system malfunction
or a possible accessory drive belt failure.
CAUTION!
The accessory belt also drives the water pump.
Operating the vehicle with a failed belt can cause
engine overheating and possible severe engine dam-
age.
Fog Light ON Indicator
This light indicates that the fog lights are on.
90 UNDERSTANDING YOUR INSTRUMENT PANEL
Page 158 of 264
▫Body Lubrication.....................179
▫Front And Rear Suspension Ball Joints......179
▫Steering Linkage......................180
▫Body Mechanism Lubrication.............180
▫Windshield Washers...................182
▫Exhaust System......................182
▫Cooling System.......................183
▫Hoses And Vacuum/Vapor Harnesses.......188
▫Brake System........................188
▫Brake, Power Steering, And Fuel System
Hoses.............................189
▫Brake And Clutch Fluid.................190
▫Master Cylinder......................191▫Hydraulic Clutch.....................192
▫Transmission........................193
▫Rear Axle...........................193
▫Wheel Bearings.......................194
▫Appearance Care.....................194
Fuses—Power Distribution Center..........197
Vehicle Storage........................202
Replacement Bulbs......................204
▫Interior Light Bulbs....................204
▫Exterior Light Bulbs...................205
Exterior Light Bulb Service................205
▫Headlight, Parking, Front Park, Turn Signal, Front
Sidemarker And Front Fog Light Removal....205
158 MAINTAINING YOUR VEHICLE
Page 205 of 264
Exterior Light Bulbs
Headlight-Low/High Beam.... Serviced at dealer only
Aux. Headlight-High Beam.........(HB3A) 9005XS
Front Park/Turn......................3157AK
Fog Light.......................(H10 U) 9145
Front Sidemarker.......................2886X
Center Stop Light.......... 16LED(not serviceable)
Rear Tail/Stop..........................3157
Rear Tail Light.......................... 194
Rear Marker Light........................ 194
Back up Light..........................3157
Rear Turn Light.......................3457AK
License................................ 168
NOTE:You will note that upon turning the (HID) High
Intensity Discharge Headlamp Bulbs on, there is a blue
hue to the lamps. This diminishes and becomes more
white after approximately 10 seconds as the system
charges.
EXTERIOR LIGHT BULB SERVICE
Headlight, Parking, Front Park, Turn Signal, Front
Sidemarker and Front Fog Light Removal
1. Remove the splash shield.
MAINTAINING YOUR VEHICLE 205
7
Page 250 of 264
Inside Rearview Mirror.................... 67
Instrument Cluster........................ 86
Instrument Panel and Controls............... 85
Instrument Panel Lens Cleaning............. 195
Interior and Instrument Lights..........See Lights
Interior Lighting......................... 74
Interior Lights........................... 74
Intermittent Wipers....................... 82
Introduction............................. 4
Jump Starting.......................... 150
Key-In Reminder......................... 12
Keyless Entry System...................... 15
Keys.................................. 11
Knee Bolster............................ 41
Lap/Shoulder Belts....................... 27
LATCH (Lower Anchors and Tether for CHildren) . 36Latches
Hood.............................71,180
Lead Free Gasoline...................... 142
Light Bulbs............................ 205
Lights...............................52,73
Airbag.............................44,91
Anti-Lock Warning...................... 87
Back-Up............................. 74
Brake Warning......................... 91
Bulb Replacement...................... 204
Daytime Running....................... 76
Dimmer Switch, Headlight..............74,78
Engine Temperature Warning.............. 90
Exterior Check......................... 52
Fog .............................75,77,90
Hazard Warning Flasher...............87,148
Headlight Switch....................... 75
Headlights.........................75,207
High Beam........................... 78
250 INDEX
