headlights FIAT 500 2014 2.G Owners Manual

▫EZ Entry Feature ..................... .104
▫ Memory Feature ..................... .104
▫ Heated Seats — If Equipped .............105
▫ Head Restraints ...................... .106
 TO OPEN AND CLOSE THE HOOD .........109
 LIGHTS .............................111
▫ Multifunction Lever ....................111
▫ Headlights ..........................111
▫ High Beams .........................112
▫ Flash-To-Pass ........................112
▫ Parking Lights .......................112
▫ Daytime Running Lights — If Equipped .....112
▫ Turn Signals .........................112 ▫
Lane Change Assist ....................113
▫ Follow Me Home/Headlight Delay .........113
▫ Interior Lights .......................114
▫ Front Fog Lights — If Equipped ...........115
 WINDSHIELD WIPERS AND WASHERS ......116
▫ Front Windshield Wiper Operation .........116
▫ Rear Windshield Wiper .................118
 TILT STEERING COLUMN — IF EQUIPPED . . .119
 ELECTRONIC SPEED CONTROL ...........120
▫ To Activate ......................... .121
▫ To Set A Desired Speed .................121
▫ To Deactivate ....................... .122
▫ To Resume Speed .....................122
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

LIGHTS
Multifunction Lever
The multifunction lever, located on the left side of the
steering wheel, controls the operation of the headlights,
headlight beam selection, passing light and turn signals.
NOTE:The external lights can only be turned on with
the ignition in the ON/RUN position.
Headlights
Rotate the end of the multifunction lever up-
ward to the first detent for headlight operation. NOTE:When the headlights are turned on, the Daytime
Running Lights will be deactivated.Headlight Operation
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111

High Beams
With the low beams activated, push the multi-
function lever towards the instrument panel to
turn on the high beams. Pull the multifunction lever
toward the steering wheel to turn off the high beams.
Flash-To-Pass
You can signal another vehicle with your headlights by
partially pulling the multifunction lever toward the steer-
ing wheel. This will cause the high beam headlights to
turn on until the lever is released.
Parking Lights
To turn on the parking lights, remove the key
or turn the ignition to OFF/LOCK position and
turn on the headlights.
Daytime Running Lights — If Equipped
To activate the Daytime Running Lights (DRL), rotate the
end of the multifunction lever to the Osymbol.
NOTE: The low beams and side/taillights will not be on
with DRL.
If allowed by law in the country in which the vehicle was
purchased the DRL function can be turned on or off using
the display menus. Refer to “Electronic Vehicle Informa-
tion Center (EVIC)” in “Understanding Your Instrument
Panel” for further information.
Turn Signals
Push the multifunction lever upward to signal a right
turn or downward to signal a left turn. The correspond-
ing indicator in the instrument cluster will blink to
indicate the operation of the turn signal.
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:The indicators will automatically turn off when
the turn has been completed and the steering wheel is
returned to a straight position.
Lane Change Assist
Tap the lever up or down once, without moving beyond
the detent, and the turn signal (right or left) will flash
three times then automatically turn off.
Follow Me Home/Headlight Delay
When this feature is selected the driver can choose to
have the headlights remain on for a preset period of time.
Activation
Remove the key or turn the ignition to the OFF/LOCK
position, and pull the multifunction lever toward the
steering wheel, within two minutes. Each time the lever
is pulled, the activation of the lights will be extended by
30 seconds. The activation of the lights can be extended to
a maximum of 210 seconds.
Turn Signal Operation
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113

3. Front Fog Light Indicator — If EquippedThis indicator will illuminate when the front fog
lights are on.
4. Low Fuel Light
When the fuel level reaches approximately 1.0
gallon (3.8L) this light will turn on, and remain on
until fuel is added.
5. High Beam Indicator
This light indicates that the headlights are on high
beam. Pull the turn signal lever toward the steer-
ing wheel to switch the headlights to low beam.
6. Park/Headlight ON Indicator / Follow Me Home
(Headlight Delay) Indicator — If Equipped
This indicator will illuminate when the park
lights or headlights are turned on. If the Follow
Me Home feature is activated this indicator will illuminate and the EVIC will show how long the
function remains active. For further information, refer to
“Follow Me Home” in “Understanding The Features of
Your Vehicle”.
7. Turn Signal Indicator
The arrow will flash in unison with the exterior
turn signal, when using the turn signal lever.
8. Generic Warning Light The Generic Warning Light will illuminate if
any of the following conditions occur: Oil
Change Request, Engine Oil Pressure Sensor
Failure, External Light Failure, Fuel Cut-Off
Intervention, Fuel Cut-Off Not Available, Parking Sensor
Failure.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 147

Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and MOPAR® Total Clean. Care should be taken to avoid
soaking your leather upholstery with any liquid. Please
do not use polishes, oils, cleaning fluids, solvents, deter-
gents, or ammonia-based cleaners to clean your leather
upholstery. Application of a leather conditioner is not
required to maintain the original condition.
WARNING!
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
CAUTION!
Do not use Alcohol and Alcohol-based and/or Keton
based cleaning products to clean leather seats, as
damage to the seat may result.
Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
384 MAINTAINING YOUR VEHICLE

Adding............................. .298
Additives ............................ .296
Capacity ............................ .399
Clean Air ............................ .294
Cutoff ................................50
Filler Cap (Gas Cap) .....................157
Filler Door (Gas Cap) ....................157
Gasoline ............................. .293
Gauge .............................. .157
Light ............................... .147
Materials Added ....................... .296
Octane Rating ......................... .293
Requirements ......................... .293
Tank Capacity ......................... .399
Fueling ............................... .298
Fuses ................................. .388
Gas Cap (Fuel Filler Cap) ...................298
Gasoline, Clean Air ....................... .294Gasoline (Fuel)
.......................... .293
Gasoline, Reformulated .....................294
Gauges Coolant Temperature .....................155
Fuel ................................ .157
Odometer ............................ .156
Tachometer ........................... .157
Gear Ranges ............................ .233
Gear Select Lever Override ..................338
General Information ...................... .292
General Maintenance ...................... .352
Glass Cleaning .......................... .385
Hazard Driving Through Flowing, Rising, or Shallow Stand-
ing Water ............................ .241
Headlights ..............................111
Cleaning ............................ .384
High Beam ........................... .147
