trip computer FIAT 500C 2014 2.G Owners Manual

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ..........143
 INSTRUMENT CLUSTER — POP, LOUNGE,
500C ............................... .144
 INSTRUMENT CLUSTER — SPORT ..........145
 INSTRUMENT CLUSTER DESCRIPTIONS .....146
 ELECTRONIC VEHICLE INFORMATION
CENTER (EVIC) ...................... .158
▫ EVIC Displays ....................... .159
▫ EVIC Control Buttons ..................160
▫ Electronic Vehicle Information Center (EVIC)
Setup Menu ........................ .160▫
Change Engine Oil Indicator System ........162
▫ Trip Computer ...................... .163
▫ Trip Button ......................... .163
▫ Trip Functions ...................... .164
▫ Values Displayed ..................... .165
▫ Personal Settings (Customer-Programmable
Features) ........................... .166
 SALES CODE (RAB) RADIO ..............177
▫ Introduction ........................ .178
▫ Suggestions ......................... .1784

INSTRUMENT PANEL FEATURES
1 — Side Vent7 — Passenger Air Bag13 — Storage Compartment
2 — Multifunction Lever – Light Control 8 — Glove Compartment 14 — Shift Lever
3—
Instrument Cluster And Warning Lights9 — Rear Defrost Button 15 — Sport Button
4—Windshield Wiper, Washer, Trip Computer10 — Hazard Button 16 — Horn/Driver Airbag
5 — Central Air Vents 11 — Climate Controls
6 — Storage Compartment/Radio 12 — Power Windows Control
4
UNDERSTANDING YOUR INSTRUMENT PANEL 143

ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC)
The Electronic Vehicle Information Center (EVIC) fea-
tures a driver-interactive display that is located in the
instrument cluster.The EVIC consists of the following:
•
System Status
• Vehicle Information Warning Message Displays
• Personal Settings (Customer-Programmable Features)
• Outside Temperature Display
• Trip Computer Functions
• Tire Pressure Monitoring Display
Electronic Vehicle Information Center (EVIC) Display
158 UNDERSTANDING YOUR INSTRUMENT PANEL

NOTE:If the indicator message illuminates when you
start the vehicle, the oil change indicator system did not
reset. If necessary, repeat this procedure.
Trip Computer
The Trip Computer is located in the instrument cluster. It
features a driver-interactive display (displays informa-
tion such as; trip information, range, fuel consumption,
average speed and travel time).
Trip Button
The TRIP button, located on the right steering column
stalk, can be used to display and to reset the previously
described values.
• A short button press displays the different values.
• A long button press resets the system and then starts a
new trip.
New Trip
To reset:
• Push and hold the TRIPbutton to reset the system
manually.
• When the “Trip distance” reaches 99999.9 miles or
kilometers or when the “Travel time” reaches 999.59
(999 hours and 59 minutes), the system is reset auto-
matically.
• Disconnecting/Reconnecting the battery resets the
system.
NOTE: If the reset operation occurs in the presence of
the screens concerning Trip A or Trip B, only the infor-
mation associated with Trip A or Trip B functions will be
reset.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 163

3. When the function is activated (On), briefly press theMENU button to display the presently set activation
speed. Pressing the UP
or DOWNbuttons
selects the speed limit. Press MENU
to confirm
selection.
NOTE: The setting can be increased or decreased by
5 mph or km/h each time the UP/DOWN button is
pressed for speed settings above 20 mph (32 km/h). To
increase or decrease the set speed rapidly, press and hold
the UP/DOWN button. Save the setting by briefly press-
ing the button when you approach the required setting.
• Briefly press the MENUbutton to go back to the menu
screen, or press and hold the MENUbutton (approxi-
mately one second) to go back to the main screen
without storing the settings. To cancel the setting, proceed as follows:
1. Briefly press the
MENUbutton. “On” will flash on the
display.
2. Press the DOWNbutton. “Off” will flash on the
display.
3. Briefly press the MENUbutton to go back to the menu
screen, or press and hold the MENUbutton (approxi-
mately one second) to go back to the main screen
without storing the settings.
Trip B Data (Trip B On)
Through this option, it is possible to activate (On) or
deactivate (Off) the Trip B (partial trip) display.
For further information see “Trip Computer.”
For activation / deactivation, proceed as follows:
1. Briefly press the MENUbutton.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 167

Dealer Service........................... .351
Defroster, Windshield .......................80
Diagnostic System, Onboard .................349
Dipsticks Automatic Transmission ..................379
Disposal Antifreeze (Engine Coolant) ................373
Door Locks ..............................20
Door Locks, Automatic ......................23
Downshifting ........................... .229
Driving Through Flowing, Rising, or Shallow Standing
Water ............................... .241
Electrical Power Outlets .....................133
Electric Remote Mirrors ......................91
Electronic Brake Control System ...............249
Brake Assist System .....................250
Electronic Speed Control (Cruise Control) ........120Electronic Stability Control (ESC)
..............253
Electronic Vehicle Information Center (EVIC) ......158
Exit Trip ............................. .164
NewTrip ............................ .163
Start Of Trip Procedure ...................164
Trip Computer ........................ .163
Trip Functions ........................ .164
Emergency, In Case of Hazard Warning Flasher ..................305
Jacking .............................. .319
Jump Starting ......................... .332
Towing ............................. .340
Emission Control System Maintenance ..........349
Engine Air Cleaner .......................... .356
Break-In Recommendations .................77
Checking Oil Level ..................... .353
Compartment ......................... .347
Cooling ............................. .369
10
INDEX 425
